PAGE 1
MODEL: JS1601
ITEM
PART NO.
DESCRIPTION
QTY
NOTE
001 266091-3 TAPPING SCREW 4X50 4 PC.
002 922147-9 HEX. SOCKET HEAD BOLT M4X25 1 PC.
003 961011-9 STOP RING E-4 1 PC.
004 346131-4 SLIP PLATE R 1 PC.
005 343480-0 SLIP PLATE L 1 PC.
006 343481-8 SPACER 1 PC.
007 792533-6 SIDE BLADE SET 1 SET
008
009 251951-2 HEX. SOCKET HEAD BOLT M5X10 2 PC.
010 261065-9 TEFLON WASHER 7 1 PC.
011 253338-4 THIN WASHER 7 1 PC.
012 792534-4 CENTER BLADE 1 PC.
013 253338-4 THIN WASHER 7 1 PC.
014 261065-9 TEFLON WASHER 7 1 PC.
015 267010-2 FLAT WASHER 5 1 PC.
016 267010-2 FLAT WASHER 5 1 PC.
017 256155-1 PIN 5 1 PC.
018 256155-1 PIN 5 1 PC.
019 331329-6 LINK 1 PC.
020 423118-4 DUST COVER 1 PC.
021 140506-7 CRANK HOUSING COMPLETE 1 PC.
022 325727-4 BLOCK 1 PC.
023 252083-8 HEX. LOCK NUT M4-7 1 PC.
024 266085-8 H.S.SET SCREW(FLAT POINT)M6X10 1 PC.
025 256733-7 PIN 7 1 PC.
026 961012-7 STOP RING E-6 1 PC.
027 211027-7 BALL BEARING 627ZZ 1 PC.
028 253133-2 FLAT WASHER 7 1 PC.
029 331273-7 ROD 1 PC.
030 210067-2 BALL BEARING 6000ZZ 1 PC.
031 325948-8 CRANK SHAFT 1 PC.
032 325949-6 SEALING SCREW 1 PC.
033 227731-8 HELICAL GEAR 40 1 PC.
034 210033-9 BALL BEARING 696ZZ 1 PC.
035 442161-4 GASKET 1 PC.
036 140507-5 GEAR HOUSING COMPLETE 1 PC.
037 210005-4 BALL BEARING 608DDW 1 PC.
038 240076-7 FAN 56 1 PC.
039 517673-7 ARMATURE ASS'Y 220V 1 PC.
040 681636-0 INSULATION WASHER 1 PC.
041 210062-2 BALL BEARING 607ZZ 1 PC.
042 421868-5 LABYRINTH RUBBER RING 19 1 PC.
043 450796-7 BAFFLE PLATE 1 PC.
044 452073-3 SPACER 1 PC.
045 623548-1 FIELD 1 PC.
046 266004-4 TAPPING SCREW 4X70 2 PC.
047 265954-0 TAPPING SCREW BIND PT3X8 2 PC.
048 643839-4 BRUSH HOLDER 6X9 2 PC.
049 195026-6 CARBON BRUSH CB-459 1 PC.
050 450795-9 MOTOR HOUSING 1 PC.
051 418016-5 SWITCH KNOB 1 PC.
052 450797-5 SWITCH LEVER 1 PC.
053 868086-8 JS1601 NAME PLATE 1 PC.
054 233121-5 COMPRESSION SPRING 4 1 PC.
055 650621-4 SWITCH PS10 1 PC.
056 687682-1 STRAIN RELIEF 1 PC.
057 265995-6 TAPPING SCREW 4X18 1 PC.
058
059 682566-8 CORD GUARD 10 1 PC.
060 691015-4 POWER SUPPLY CORD 0.75-2-2.5 1 PC.
SPARE PARTS LIST
