ENGLISH (Original instructions) INSTRUCTION MANUAL Cordless Driver Drill DDF470 DDF480 013955 IMPORTANT: Read Before Using.
ENGLISH (Original instructions) SPECIFICATIONS Model Capacities -1 No load speed (min ) DDF470 DDF480 Steel 13 mm 13 mm Wood 38 mm 38 mm 10 mm x 90 mm Wood screw 10 mm x 90 mm Machine screw M6 M6 High (2) 0 - 1,550 0 - 1,550 Low (1) Overall length 0 - 400 0 - 400 185 mm 185 mm Net weight 1.6 kg 1.5 kg 1.7 kg Battery cartridge BL1430 / BL1440 BL1815 / BL1815N BL1830 / BL1840 Rated voltage D.C. 14.4 V D.C.
ENH101-16 Electrical safety 4. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. 5. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. 6. Do not expose power tools to rain or wet conditions.
terminal to another. Shorting the battery terminals together may cause burns or a fire. 27. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. Service 28. Have your power tool serviced by a qualified repair person using only identical replacement parts.
WARNING: Tips for maintaining maximum battery life DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adherence to safety rules for the subject product. MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. 1. 2. ENC007-8 IMPORTANT SAFETY INSTRUCTIONS 3. FOR BATTERY CARTRIDGE 4. 1.
Battery protection system (Lithium-ion battery with star marking) FUNCTIONAL DESCRIPTION • CAUTION: Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. 1. Star marking 1 Installing or removing battery cartridge 1. Red indicator 2. Button 3. Battery cartridge 1 012128 Lithium-ion batteries with a star marking are equipped with a protection system.
Lighting up the front lamp LED indicator status Remaining battery capacity 1. Lamp About 50% or more About 20% - 50% 1 013957 CAUTION: Do not look in the light or see the source of light directly. Pull the switch trigger to light up the lamp. The lamp keeps on lighting while the switch trigger is being pulled. The lamp goes out 10 -15 seconds after releasing the trigger.
To change the speed, switch off the tool first. Select the "2" side for high speed or "1" for low speed but high torque. Be sure that the speed change lever is set to the correct position before operation. Speed change 1 1. Speed change lever Adjusting the fastening torque 1 1. Adjusting ring 2. Graduation 3. Arrow 2 3 013959 • • • CAUTION: Always set the speed change lever fully to the correct position.
When not using the driver bit, keep it in the bit holders. Bits 45 mm-long can be kept there. ASSEMBLY • OPERATION CAUTION: Always be sure that the tool is switched off and the battery cartridge is removed before carrying out any work on the tool. • Installing or removing driver bit or drill bit 1. Sleeve 1 • CAUTION: Always insert the battery cartridge all the way until it locks in place. If you can see the red part on the upper side of the button, it is not locked completely.
Drilling in metal To prevent the bit from slipping when starting a hole, make an indentation with a center-punch and hammer at the point to be drilled. Place the point of the bit in the indentation and start drilling. Use a cutting lubricant when drilling metals. The exceptions are iron and brass which should be drilled dry. • • • • • OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual.
