How to Guide

Lutron www.lutron.com

Ariadni

preset dimmers

•

toggle turns on/off

•

slide up to brighten,

down to dim

dimmers

incandescent

single pole 600 W AY-600P-

single pole 1000 W AY-10P-

3-way 600 W AY-603P-

3-way 1000 W AY-103P-

magnetic low voltage

single pole 600 VA AYLV-600P-

(450 W)

3-way 600 VA AYLV-603P-

(450 W)

PAGE 1
Ariadni® | preset dimmers dimmers • • incandescent single pole single pole 3-way 3-way toggle turns on/off slide up to brighten, down to dim 600 W 1000 W 600 W 1000 W magnetic low voltage single pole 600 VA (450 W) 3-way 600 VA (450 W) 20 | Lutron AY-600PAY-10PAY-603PAY-103P- AYLV-600PAYLV-603P- www.lutron.
PAGE 2
Maestro® | dimmers, switches & fan controls available models source type incandescent lighting magnetic low voltage lighting electronic low voltage lighting ﬂuorescent lighting quiet 7-speed fan controls quiet 7-speed fan/light controls control locations single pole multi-location available colors colors (gloss ﬁnish) WH IV AL LA white ivory almond light almond colors (satin ﬁnish) HT hot MR merlot TC terracotta GB greenbriar BG bluestone DS desert stone ST stone LS limestone GR gray BR brown BL black
