Specifications Sheet

267 CARLETON AVE SUITE 202 | CENTRAL ISLIP, NEW YORK 11722
CONTACT US TODAY! 1-844-LED GURU | WWW.LUMIGHT.COM | [e-mail]
KEY BENEFITS APPLICATIONS
CERTIFICATIONS
LED WALLPACK
• DLC 4.1 Premium • cUL-us Listed • Lighting Facts •
PRODUCT SUMMARY
PRODUCT PERFORMANCE
EFFICACY
LED CHIP
2835 Mid-Power
CCT
4000K
DRIVER
YG® driver technology, Dimmable LED
power supplies, Current can be adjusted the
120-277V Dimming type is continuous, The
product can dim to 10%
DRIVER EFFICIENCY
>85%
INDIVIDUAL CARTON DIMENSIONS
INDIVIDUAL CARTON WEIGHT
STANDARD LIFETIME
Design minimum 50,000 + hours
STANDARD WARRANTY
5 Years
WATER PROOFING GRADE
Wet Location
SYSTEM
WATTAGE
LED
WATTAGE
LUMENS LP/W CRI
REPLACES
(MH)
20W 19W 1622 lm 114 lm/w ≥80 50W
LED WALLPACK
NOMAD
20W | 1622 LUMENS | REPLACES 50W
* Please refer to the DLC QPL website for the latest and most complete
information at www.designlights.org/QPL
ORDER NUMBER: L-NO20-4UD-P-Z
8.70 in
222 mm
8.40 in
214 mm
9.20 in
235 mm
9.20 in
235 mm
8.70 in
222 mm
114 lm/w
10 x 10.5 x 10.5 in
7.4 lbs
Philips®
5
5
20FT
10’ MOUNT HEIGHT
20FT
PRODUCT PHOTOMETRY
PRODUCT DIMENSIONS
PRODUCT WEIGHT: 7.4 lbs
UL wet listed die-cast aluminum construction with borosilicate glass lens or
UV stabilized polycarbonate diuser complete with stainless steel hardware.
Mounts to standard 4 inch square electrical junction boxes. Alternate junction
box mounting possible via universal mounting ring. Ingress resistant gasket
included.
• Same footprint as traditional HID fixtures • Premium brand LEDs (Philips®
chips depending on SKU) and YG® driver technology • Dimming option available
• Precision die-cast Aluminum • Wet location rated fixture for outdoor use • Chip
and fade resistant powder coat finish in any color • Precision prismatic reector
• Industrial grade, Standard buon Photocell available
Suitable for for building-mounted doorway, pathway and security
illumination
QUICK SHIP
