Wireless-G PCI Adapter with SpeedBooster Chapter 1: Introduction Welcome Thank you for choosing the Wireless-G PCI Adapter. With this Adapter, your wireless networking experience will be faster and easier than ever. Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. This adapter communicates over the 54Mbps 802.11g wireless standard, which is almost five times faster than 802.11b. But since they share the same 2.
Wireless-G PCI Adapter with SpeedBooster What’s in this Guide? This user guide covers the steps for setting up and using the Wireless-G PCI Adapter. • Chapter 1: Introduction This chapter describes the Adapter’s applications and this User Guide. • Chapter 2: Planning Your Wireless Network This chapter discusses a few of the basics about wireless networking. • Chapter 3: Getting to Know the Wireless-G PCI Adapter This chapter describes the physical features of the Adapter.
Wireless-G PCI Adapter with SpeedBooster • Appendix G: Regulatory Information This appendix supplies the Adapter’s regulatory information. • Appendix H: Contact Information This appendix provides contact information for a variety of Linksys resources, including Technical Support.
Wireless-G PCI Adapter with SpeedBooster Chapter 2: Planning your Wireless Network Network Topology A wireless network is a group of computers, each equipped with one wireless adapter. Computers in a wireless network must be configured to share the same radio channel. Several PCs equipped with wireless cards or adapters can communicate with one another to form an ad-hoc network. Linksys wireless adapters also provide users access to a wired network when using an access point or wireless router.
Wireless-G PCI Adapter with SpeedBooster Network Layout Linksys wireless access points and wireless routers have been designed for use with 802.11a, 802.11b, and 802.11g products. With 802.11g products communicating with the 802.11b standard and some products incorporating both “a” and “g”, products using these standards can communicate with each other. Access points and wireless routers are compatible with 802.11a, 802.11b and 802.
Wireless-G PCI Adapter with SpeedBooster Chapter 3: Software Installation and Configuration for Windows 2000, 98, and ME The Wireless-G PCI Adapter Setup Wizard will guide you through the installation procedure. The Setup Wizard will install the Wireless Network Monitor and driver, as well as configure the Adapter. IMPORTANT: You must run the Setup Wizard to install the software before connecting the Adapter.
Wireless-G PCI Adapter with SpeedBooster 2. Read the License Agreement displayed on the following screen and click the Next button to continue the installation. If you click the Cancel button, you will end the installation. Figure 3-2: The License Agreement Screen 3. The Wireless Mode screen will ask for some information about your wireless network. In the SSID field, enter your network’s SSID (Service Set Identifier). The SSID is your network name and must be identical for all devices in the network.
Wireless-G PCI Adapter with SpeedBooster 4. If you chose Infrastructure Mode, go to Step 5 now. If you chose Ad-Hoc Mode, select the correct operating channel for your network from the Channel drop-down menu. Then, select the Network Mode from the dropdown menu. Click the Next button, and go to Step 5. Click the Back button to change any settings. Channel - The channel you choose should match the channel set on the other devices in your wireless network.
Wireless-G PCI Adapter with SpeedBooster 6. The Setup Wizard will ask you to review your settings before it starts to copy files. Click the Next button to save these settings, or click the Back button to change any settings. Figure 3-6: The Check Settings Screen 7. At this point, a screen stating that a digital signature was not found may appear. This software has been tested and found to work properly with Windows 2000. Click the Yes button to continue installation.
Wireless-G PCI Adapter with SpeedBooster 8. After the files have been successfully copied, the Congratulations screen will appear. Click the Exit button. Now that the software installation is complete, proceed to Chapter 4: Connecting the Wireless-G PCI Adapter.
Wireless-G PCI Adapter with SpeedBooster Chapter 4: Connecting the PCI Adapter 1. Before connecting the PCI Adapter to your PC, turn off your desktop PC. 2. Open your PC case and locate an available PCI slot on the motherboard. Check with your computer manufacturer for instructions. 3. Slide the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the slot's contacts. You may have to apply a bit of pressure to slide the adapter all the way in.
Wireless-G PCI Adapter with SpeedBooster 4. Attach the external antenna to the adapter’s antenna port. port: the connection point on a computer or networking device used for plugging in a cable or an adapter. Figure 4-2: Proper Positioning of the Antenna 5. Power on your desktop PC. You may see a Windows Digital Signature screen, but can continue installation. If your PC is running Windows XP, proceed to “Chapter 5: Driver Installation for Windows XP.
Wireless-G PCI Adapter with SpeedBooster Chapter 5: Driver Installation for Windows XP After connecting the Adapter to your PC, as shown in Chapter 4, you’ll need to install the driver. Windows XP will automatically detect the Adapter. Insert the Setup CD-ROM into the CD-ROM drive. Click the radio button next to Install the software automatically (Recommended). Then, click the Next button.
Wireless-G PCI Adapter with SpeedBooster Windows XP Wireless Zero Configuration NOTE: Windows XP has a built-in configuration tool. Use Windows XP Wireless Zero Configuration (in the system tray at the bottom of your screen) to configure the Adapter. 1. After installing the Adapter, the Windows XP Wireless Zero Configuration icon will appear in your computer’s system tray. Double-click the icon.
Wireless-G PCI Adapter with SpeedBooster 3. If WEP is enabled, you will be asked to enter the network (WEP) key. Enter the WEP key of your wireless network in the Network key field, and re-enter it in the Confirm network key field. Then, click the Connect button, and proceed to step 4. Figure 5-6: Network Connection - WEP NOTE: Windows XP Wireless Zero Configuration does not support the use of a passphrase. Enter the exact WEP key used by your access point. 4.
Wireless-G PCI Adapter with SpeedBooster Chapter 6: Using the Wireless Network Monitor Overview Use the Wireless Network Monitor to check the link information, search for available wireless networks, or create profiles that hold different configuration settings. Accessing the Wireless Network Monitor After installing the Adapter’s Setup Wizard, the Wireless Network Monitor icon will appear in your system tray. Double-click the icon. The Link Information tab will appear.
Wireless-G PCI Adapter with SpeedBooster Clicking the More Information button displays much more information about the Adapter’s connection, as shown below: wep: a method of encrypting data transmitted on a wireless network for greater security. Wireless Network Status Status - This shows the status of the wireless network connection. SSID - This is the unique name of the wireless network. Wireless Mode - The mode of the wireless network currently in use is displayed here.
Wireless-G PCI Adapter with SpeedBooster Clicking the Statistics button brings up the following information on your wireless connection: Transmit Rate - This shows the speed, in megabits per second, at which data is transmitted from the Adapter. Receive Rate - This shows the speed, in megabits per second, at which data is received by the Adapter.
Wireless-G PCI Adapter with SpeedBooster The Site Survey Tab The Site Survey tab displays available networks and allows you to connect to them. The information about these networks are displayed as below: SSID - The SSID or unique name of the wireless network. CH - The channel upon which the network broadcasts. Signal - The percentage of signal strength, from 0 to 100%. Site Information Figure 6-4: The Site Survey Tab SSID - The SSID or unique name of the wireless network.
