English English English Lenovo Mobile Phone English User Manual Model: Lenovo A316i Read this manual carefully before operating the handset English English English English English English English English English English English English
Technical Parameters Product WCDMA digital mobile phone Model Lenovo A316i System Android 4.2 Size Approximately 118 mm × 63.5 mm × 12.2 mm Weight Approximately 130.2 g (including battery) Standby Time Max190 hours* Battery Capacity 1300 mAh NOTES:*May vary depending on local signal strength.
Initial Setup Procedure Removing and mounting battery cover To remove the cover, perform the following procedure as shown in the figure. 1. 2. 3. 4. Find the recess in the lower-left corner. Hold the top of your mobile phone. Lift up from the recess. Open the cover. To mount the battery cover, gently fit and press it onto phone body until it completely clicks into place.
Charging the phone 4
Inserting the SIM card Inserting the memory card 5
Port Assignment and Button Layout KEY Description Can enter the commonly used, the 1 MENU KEY 2 HOME KEY Can return to the idle interface. 3 BACK KEY Can return to the superior menu. 4 VOLUME KEY 5 POWER ON/OFF characteristic and more menus. According to the volume switch increase or decrease volume. Short click this button to lock screen function, long press the key to power on/off the phone.
Applications Overview Icon Name Note Browses websites. The web browser in this unit Browser can access the Internet via the WIFI network for business and personal use. Email Receives/Sends and views mails by linking directly to your mailbox. Browses and edits images. In an image Gallery full-screen page it supports slideshow functions and such operations as, Share, Set as, and Details. Contacts Allows you to add or delete contacts and edit or delete particulars of a contact.
Gravity sensor Auto rotate screen according to the rotation of the device. To unlock the screen direction: Menu > Settings > All Settings > Display > Auto-rotate screen. After launching one application, you can rotate the screen to your preferred direction.
Precautions and Tips for A316i Safety and Maintenance When using mobile phone, please abide by the following. Read the user manual thoroughly before using your mobile phone. Do not turn on your mobile phone if use is prohibited or may cause interference or danger. Your mobile phone should be switched off while on airplanes.
phone near credit cards or magnetic fields. In hospitals or other special areas, use your mobile phone in accordance with the site’s regulations. Mechanically vibrating or shaking the mobile phone may cause damage. Do not knock your phone screen with a sharp item. Using a cell-phone case or plastic case may damage the surface of your phone. Do not use solvents (such as benzene, diluents, alcohol, etc.) to wipe the mobile phone's cover.
amount of system activity and the level of charge in the battery. Extended contact with your body, even through clothing, could cause discomfort or even a skin burn. Avoid keeping your hands, your lap, or any other part of your body in contact with a hot section of the Mobile phone for any extended time. Protect your data and software Do not delete unknown files or change the name of files or directories that were not created by you; otherwise, your Mobile phone software might fail to work.
enters your eye. Should this occur, immediately use clean water to rinse the eye (do not rub the eye), and seek medical treatment. Prevent the battery from being squeezed, compressed, vibrated or shaken. Always try to prevent the battery from short circuit, as this may cause damage to the battery or components connected to it.
Dispose of the battery in accordance with regulations (such as recycling regulations). To prevent explosion or pollution, never dispose of batteries as domestic waste. This battery can only be charged by its dedicated charger. Do not charge out range of 32 °F to 113 °F (0 °C to 45 °C). Charging must not exceed 12 hours. To prevent hazards, place the battery in a safe location out of reach of children. When using the battery charger, please abide by the following.
When using headphones (which you may need to purchase separately), please abide by the following. When using headphones, to avoid hearing damage, remember to adjust the volume to an appropriate level. To avoid breakage, do not pull or drag headphone cables. Using headphones in a high temperature and high humidity environment for a long time can easily damage the headphones or reduce their service life.
wide band true RMS output voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band characteristic voltage of 75 mV. Using headphones that do not comply with EN 50332-2 can be dangerous due to excessive sound pressure levels.
Important Notices – Medical Device Any radio equipment (including this mobile phone) may interfere with the function of medical devices if insufficient measures are taken. Consult the medical personnel or the manufacturer of the medical device if you have any question or you are not sure whether the medical device can shield all RF output. Follow the relevant provisions and prohibitions of using electronic equipment or radio transmission.
Polyvinyl Chloride (PVC) cable and cord notice WARNING: Handling the cord on this product or cords associated with accessories sold with this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.
Specific Absorption Rate information This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. Your mobile device is a radio transmitter and receiver. The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate, or SAR.
value. To meet RF exposure guidelines during body-worn operation, the device must be positioned at least 1.5cm away from your body.
Recycling and environmental information General recycling statement Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. For information on recycling Lenovo products, go to: http://www.lenovo.com/recycling. Important WEEE information Country-specific information is available at http://www.lenovo.com/recycling.
Restriction of Hazardous Substances Directive (RoHS) China RoHS The information in the following table is applicable for products manufactured on or after March 1, 2007 for sale in the People’s Republic of China.
Restriction of Hazardous Substances Directive (RoHS) 22
Turkish RoHS The Lenovo product meets the requirements of the Republic of Turkey Directive on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (EEE). Ukraine RoHS India RoHS RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
This device complies with the R&TTE Directive (1999/5/EC), the EMC Directive (2004/108/EC), and the Low Voltage Directive (2006/95/EC) issued by the Commission of the European Community. For the device which tests accordance to EN60950-1:2006+A11:2009+A1:2010+A12:2011, it is mandatory to perform audio tests for EN50332. Federal Communication Commission Interference Statement This device complies with part 15 of the FCC Rules.
radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
