Data Sheet

Product Information

Page 1 of 2

SKINDICHT® MINI Valid: 07.02.2012

Product Description

High degree of protection;For the smallest conductor sizes;Low height;Gentle cable clamping;High packing density

Application range

• For use wherever there is limited assembly space.

• Sensors

• Measuring technology

Benefits

• High degree of protection

• For the smallest conductor sizes

• Low height

• Gentle cable clamping

• High packing density

PAGE 1
Product Information Page 1 of 2 SKINDICHT® MINI Valid: 07.02.2012 Product Description High degree of protection;For the smallest conductor sizes;Low height;Gentle cable clamping;High packing density Application range • For use wherever there is limited assembly space.
PAGE 2
Product Information Page 2 of 2 SKINDICHT® MINI Valid: 07.02.2012 Technical Data Material Temperature range Body: nickel-plated brass Seal: CR/NBR -20°C to +100°C Protection rating IP 68 Article List Part Article Clamping SW number designation / size range ØF (mm) (mm) Overall Thread length/ C length/ D (mm) (mm) Pieces / PU SKINDICHT® MINI 52001860 MINI 6 x 1 2-3 9 19,5 5.0 50 52001880 MINI 8 x 1 3,5 - 5,5 11 20,5 5.
