FS-C5010DN Operation Guide BASIC OPERATION GUIDE Please read this Operation Guide before using this machine. Keep it close to the machine for easy reference.
Contents Contents Legal and Safety Information 1 Machine Parts Components at the Front of the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Components at the Left of the Printer and Internal Components . . . . . . . . . . . . . . . . . . . . . . . . 1-2 Components at the Rear of the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Operation Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents ii OPERATION GUIDE
Legal and Safety Information CAUTION: NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION. Notice on Software SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION MODE. The printer is factory-set to emulate the PCL. The emulation mode can be changed. Notice The information in this guide is subject to change without notification. Additional pages may be inserted in future editions.
This product uses PeerlessPrintXL to provide the HP LaserJet compatible PCL 6 language emulation. PeerlessPrintXL is a trademark of Peerless Systems Corporation, 2381 Rosecrans Ave. El Segundo, CA 90245, U.S.A. This product was developed using the Tornado™ Real Time Operating System and Tools from Wind River Systems. This product contains UFST™ and MicroType® from Monotype Imaging Inc. USB This product has been certified by the USB Implementers Forum, Inc.
License Agreements IBM Program License Agreement THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”). THIS DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS LICENSE, THEN WITHIN 14 DAYS AFTER YOUR ACQUISITION OF THE DEVICE YOU MAY RETURN THE DEVICE FOR A FULL REFUND.
Some jurisdictions do not allow the exclusion of implied warranties, so the above exclusion may not apply to you. 3. Limitation of Remedies IBM's entire liability under this license is the following; For any claim (including fundamental breach), in any form, related in any way to this license, IBM's liability will be for actual damages only and will be limited to the greater of: 1 the equivalent of U.S.
Typeface Trademark Acknowledgement All resident fonts in this printer are licensed from Monotype Imaging Inc. Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG. ITC Avant Garde Gothic, ITC Bookman, ITC ZapfChancery and ITC Zapf Dingbats are registered trademarks of International Typeface Corporation.
8 THE PARTIES AGREE THAT ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY, ARE EXCLUDED. 9 Your exclusive remedy and the sole liability of Monotype Imaging in connection with the Software and Typefaces is repair or replacement of defective parts, upon their return to Monotype Imaging.
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver.
Safety Information Laser Safety This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to Radiation Control for Health and Safety Act of 1968. This means that the printer does not produce hazardous laser radiation. Since radiation emitted inside the printer is completely confined within protective housings and external covers, the laser beam cannot escape from the printer during any phase of user operation.
Caution Labels The printer bears any of the following labels. Label inside the printer (Laser radiation warning) For Europe, Asia, and other countries For U.S.A. and Canada CDRH Regulations The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. These regulations apply to laser products manufactured after August 1, 1976. Compliance is mandatory for products marketed in the United States.
Declaration of Conformity for U.S.A. Model name: Page Printer FS-C5010DN Trade name: Kyocera Mita Responsible party: Kyocera Mita America, Inc. Address: 225 Sand Road PO Box 40008 Fairfield, New Jersey 070040008, U.S.A. Telephone: (973) 808-8444 Fax: (973) 882-6000 Manufacturer: Kyocera Mita Corporation Manufacturer’s address: 2-28, 1-Chome, Tamatsukuri, Chuo-ku, Osaka, 540-8585, Japan This device complies with Part 15 of the FCC Rules.
EN 60 950-1:2001+A11 EN 60 825-1:1994+A1+A2 EN 300330-1 EN 300330-2 The manufacturer and its merchandising companies retain the following technical documentation in anticipation of the inspection that may be conducted by the authorities concerned: User’s instruction that conforms to the applicable specifications. Technical drawings. Descriptions of procedures that guarantee conformity. Other technical information.
Canadian Department of Communications Compliance Statement This Class B digital apparatus complies with Canadian ICES-003. Avis de conformité aux normes du ministere des Communications du Canada Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. EN ISO 7779 Maschinenlärminformationsverordnung 3. GSGV, 18.01.1991: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger gemäß EN ISO 7779.
Please read this Operation Guide before using the machine. Keep it close to the machine for easy reference. The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine. The symbols and their meanings are indicated below.
The following symbols indicate that the related section includes information on actions which must be performed. Specifics of the required action are indicated inside the symbol. .... [Alert of required action] .... [Remove the power plug from the outlet] .... [Always connect the machine to an outlet with a ground connection] Please contact your service representative to order a replacement if the safety warnings in this Operation Guide are illegible or if the guide itself is missing.
adequate space, especially around the vents, to allow air to be properly ventilated out of the printer. Top: 400mm (15-3/4 inches) Left: 300mm (11-13/16 inches) Right: 250mm (9-14/16 inches) Rear: 300mm (11-13/16 inches) Front: 600mm (23-5/8 inches) Other Precautions Adverse environmental conditions may affect the safe operation and performance of the machine.
Power Supply/Grounding the Machine WARNING: Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet. If metallic objects come in contact with the prongs on the plug, it may cause a fire or electric shock.
Precautions for Use Cautions when Using the Machine WARNING: Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the machine. This situation presents a danger of fire or electrical shock should they fall inside. Do not remove any of the covers from the machine as there is a danger of electrical shock from high voltage parts inside the machine. Do not damage, break or attempt to repair the power cord.
CAUTION Do not pull the power cord when removing it from the outlet. If the power cord is pulled, the wires may become broken and there is a danger of fire or electrical shock. (Always grasp the power plug when removing the power cord from the outlet.) Always remove the power plug from the outlet when moving the machine. If the power cord is damaged, there is a danger of fire or electrical shock. If the machine will not be used for a short period of time (overnight, etc.), turn the power switch off (O).
CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Cautions when Handling Consumables CAUTION Do not attempt to incinerate the Toner Container. Dangerous sparks may cause burns. Keep the Toner Container out of the reach of children. If toner happens to spill from the Toner Container, avoid inhalation and ingestion, as well as contact with your eyes and skin.
About the Operation Guide This Operation Guide has the following chapters: Chapter 1 - Machine Parts This chapter explains the names of parts. Chapter 2 - Loading Paper This chapter explains how to load paper into your printer. Chapter 3 - Printing This chapter explains how to print from your PC. Chapter 4 - Maintenance This chapter explains how to replace the toner container and how to care for your printer.
Conventions This manual uses the following conventions. Convention Description Example Italic Typeface Used to emphasize a key word, phrase or reference to additional information. Close the front cover. Refer to Toner Container Replacement on page 3-3. Bold Typeface Used to denote operation panel keys. Press [GO]. To start printing, click OK. Notes Used to provide additional or useful information about a function or feature.
xxiv OPERATION GUIDE
1 Machine Parts This section provides explanations and illustrations for you to determine the parts and their functions. Try to become familiar with the names and functions of these parts for correct use and optimal performance. This chapter contains explanations on the following topics: • • • OPERATION GUIDE Components at the Front of the Printer ........................ 1-2 Components at the Left of the Printer and Internal Components .................................................................
Machine Parts Components at the Front of the Printer 3 2 4 1 7 6 5 1 Front Cover 2 Paper Stopper 3 Top Tray 4 Operation Panel 5 Paper Cassette 6 MP (Multi-Purpose) Tray 7 Toner Container Components at the Left of the Printer and Internal Components 1 2 1-2 1 Waste Toner Box 2 Left Cover OPERATION GUIDE
Machine Parts Components at the Rear of the Printer 1 2 5 7 6 4 1 Rear Cover (Face up Tray) 2 Rear Subcover 3 USB Interface Connector 4 Network Interface Connector 5 Network Indicators 6 Power Cord Connector 7 Power Switch 3 IMPORTANT: If you turn the power off, you have to wait for an interval of five or more seconds before turning it back on.
Machine Parts Operation Panel 1 6 2 3 5 1-4 4 1 Toner Indicators 2 Ready Indicator 3 Data Indicator 4 GO Key 5 Cancel Key 6 Attention Indicator OPERATION GUIDE
Machine Parts Indicators There are four types of indicators located on the top right of the printer. The indicators are used to identify the status of the printer at any time. To identify the printer status, check the indicators on the printer and then refer to the table below. Indicator Ready (Green) Data (Green) Attention Status Meaning Lit Indicates online status (printing is possible).
Machine Parts Keys Refer to the following table for the name and description of the basic functions of each key. Key Status Cancel GO 1-6 Operation Function Press momentarily Stops the buzzer. Press for 1 second or more Cancels data from the PC. Press momentarily Switches On-line / Off-line. Press for 3 to 10 seconds Prints the status page after the toner indicators flashed. Press for 10 seconds or more Prints the service status page after the toner indicators flashed.
2 Loading Paper This chapter contains explanations on the following topics: • • • • OPERATION GUIDE General Guidelines....................................................... 2-2 Selecting the Right Paper............................................. 2-4 Paper Type ................................................................. 2-12 Loading Paper ............................................................
Loading Paper General Guidelines The machine is designed to print on standard copier paper, but it can also accept a variety of other types of paper within the limits specified below. NOTE: The manufacturer assumes no liability for problems that occur when paper not satisfying these requirements is used. Selection of the right paper is important. Using the wrong paper can result in paper jams, curling, poor print quality, and paper waste, and in extreme cases can damage the machine.
Loading Paper Item Specification Direction of grain Long grain Pulp content 80% or more Minimum and Maximum Paper Sizes The minimum and maximum paper sizes are as follows. For nonstandard paper, the MP tray must be used.
Loading Paper Selecting the Right Paper This section describes the guidelines for selecting paper. Condition Avoid using paper that is bent at the edges, curled, dirty, torn, embossed, or contaminated with lint, clay, or paper shreds. Use of paper in these conditions can lead to illegible printing and paper jams, and can shorten the life of the machine. In particular, avoid using paper with a surface coating or other surface treatment. Paper should have as smooth and even a surface as possible.
Loading Paper namely uneven paper thickness may cause multiple-sheet feeding or print quality problems such as blurring because of poor toner fusing. The recommended basis weight is between 60 and 105g/m² (16 to 28 lib/ ream) for the cassette and between 60 and 220g/m² (16 to 59 lib/ream) for the MP tray. Paper Weight Equivalence Table The paper weight is listed in pounds (lb) and metric grams per square meter (g/m²). The shaded part indicates the standard weight. U. S.
Loading Paper The moisture content of the paper varies with the relative humidity in the room. When the relative humidity is high and the paper absorbs moisture, the paper edges expand, becoming wavy in appearance. When the relative humidity is low and the paper loses moisture, the edges shrink and tighten, and print contrast may suffer. Wavy or tight edges can cause jams and alignment anomalies. The moisture content of the paper should be 4 to 6%.
Loading Paper Packaging: Paper should be packed in a sturdy carton to protect it from damage during transport. Quality paper obtained from a reputable supplier is usually correctly packaged.
Loading Paper Transparencies must be placed on the MP tray with the long edge towards the printer. MP Tray Labels Labels must be fed to the MP Tray. One label can be loaded at a time. The basic rule for printing on adhesive labels is that the adhesive must never come into contact with any part of the machine. Adhesive paper sticking to the drum or rollers will damage the machine. Label paper has a structure comprising of three layers, as shown in the diagram. The top Top sheet (white sheet is printed on.
Loading Paper Some label paper is manufactured with an extra margin of top sheet around the edge. Do not remove the extra top sheet from the carrier sheet until after printing is finished. Acceptable Unacceptable Top sheet Carrier sheet The table below lists the specifications for adhesive label paper. Item Specification Weight of top sheet 44 to 74g/m² (12 to 20 lb/ream) Composite weight 104 to 151g/m² (28 to 40 lb/ream) Thickness of top sheet 0.086 to 0.107mm (3.9 to 4.
Loading Paper Envelopes Up to 5 envelopes can be loaded at a time. Envelopes should be fed in the face-up position, right edge first. Since the composition of an envelope is more complex than that of ordinary paper, it is not always possible to ensure consistent printing quality over the entire envelope surface. Normally, envelopes have a diagonal grain direction. Refer to Paper Grain on page 2-6. This direction can easily cause wrinkles and creases when envelopes pass through the printer.
Loading Paper Preprinted Paper Preprinted paper should satisfy the same conditions as white bond paper. Refer to Paper Specifications on page 2-2.The preprinted ink must be able to withstand the heat of fusing during the printing process, and must not be affected by silicone oil. Do not use paper with any kind of surface treatment, such as the type of paper commonly used for calendars. Recycled paper Select recycled paper that meets the same specifications as the white bond paper except for whiteness.
Loading Paper Paper Type The printer is capable of printing under the optimum setting for the type of paper being used. A different paper type setting can be made for each paper source including the MP tray. Not only can preset paper types be selected, but it is also possible for you to define and select customized paper types. Paper type can be changed using the printer driver and Configuration Tool. The following types of paper can be used.
Loading Paper Loading Paper The following explains the procedure for loading paper in the cassette and the MP tray. Loading Paper into the Cassette The paper cassette can accommodate A5 to A4/Letter and Legal size paper, and can hold approximately 250 sheets. 1 Pull the paper cassette all the way out of the printer. Standard paper sizes are marked on the inside of the paper cassette.
Loading Paper 2 Adjust the paper length guide to the paper size required. 3 Adjust the position of the width guides located on the left and right sides of the cassette. Press the release button on the left guide and slide the guides to the paper size required. Release Button If using Folio or Oficio II paper, remove the green stopper (1) from the paper length guide and fix it on the paper length guide (2). Pull the paper length guide (3) to the desired paper size.
Loading Paper If using Legal paper, pull the paper length guide all the way out, without stopper. 4 OPERATION GUIDE Fan the paper, then tap it on a level surface to avoid media jams or skewed printing.
Loading Paper 5 Place the paper in the paper cassette. Ensure the side to be printed is facing down and the paper is not folded, curled, or damaged. NOTE: Do not load more paper than will fit under the load limits on the paper guides. 6 Insert the paper cassette into the slot in the printer. Push it straight in as far as it will go. There is a paper gauge on the left side of the front of the paper cassette to indicate the remaining paper supply.
Loading Paper Loading Paper into the MP (Multi-Purpose) Tray The MP tray can accommodate various paper sizes and can hold approximately 50 sheets of paper. 1 Fan the media (paper/ transparencies), then tap it on a level surface to avoid paper jams or skewed printing. 2 Pull the MP tray towards you until it stops. 3 Pull out the subtray and unfold the flap.
Loading Paper 4 5 Adjust the position of the paper guides on the MP tray. Standard paper sizes are marked on the MP tray. For standard paper sizes, slide the paper guides to the corresponding mark. A5 B5 A4 LTR Align the paper with the paper guides and insert as far as it will go. Tab Tab NOTE: Do not load more paper than exceeds the tab of the MP tray.
