-1-

Introduction

LuxeMate R910 is a Bluetooth product designed to create a total

solution for a Bluetooth environment. It supports the boot mode

function that allows you to activate the keyboard and mouse function

before the Bluetooth driver has been installed.

Hardware Installation

1. Connect the Bluetooth receiver to a USB port of your PC or

Notebook.

2. Insert two AA batteries into the keyboard and make sure the

polarity is correct.

3. Push the button to open the upper cover and insert two AA

batteries in the mouse.

Summary of content (9 pages)

PAGE 1
English Introduction LuxeMate R910 is a Bluetooth product designed to create a total solution for a Bluetooth environment. It supports the boot mode function that allows you to activate the keyboard and mouse function before the Bluetooth driver has been installed. Hardware Installation 1. Connect the Bluetooth receiver to a USB port of your PC or Notebook. 2. Insert two AA batteries into the keyboard and make sure the polarity is correct. 3.
PAGE 2
English How to start when the Bluetooth driver has not been installed 1. 2. 3. 4. Press the connect button underneath the keyboard and observe the flashing LED light. Press the ID switch button on the receiver for four seconds and observe the flashing light. To confirm the connection status, the LED light on the keyboard will now turn off. Repeat the above steps for mouse connection. Software Installation (when you use Genius Bluetooth dongle receiver) For Windows: 1.
PAGE 3
English 5. When you finish, you will find a “My Bluetooth Place” icon on the desktop or in the program folder.
PAGE 4
English 6. Follow the instructions on the screen and press “Next” to finish the software installation. 7.
PAGE 5
English 8. Type in the numbers shown on the screen through the keyboard to complete the keyboard connection. 9. Repeat Step 7 for mouse connection. 10. If the installation was successful, this window should appear.
PAGE 6
English Note: 1. If you want to check your Bluetooth mouse and keyboard status (signal or power), double click on the Genius Bluetooth mouse icon. 2. When the LED light on the Bluetooth device (keyboard or mouse) flashes twice within one second when pairing (it should be flashing once within one second normally), it indicates that battery power is insufficient, so replace with charged batteries.
PAGE 7
English Charger and charging usage 1. The charger device can be used to recharge both AA and AAA batteries; two batteries must be charged simultaneously. 2. Make sure that only rechargeable batteries (NiMH~Nickle-Metal-Hydride) batteries are used and placed in the correct position. 3.
PAGE 8
English Keyboard hotkeys definition 1. Scrolling button: the function of mouse middle button 2. My computer: Open My Computer folder from Windows 3. Email: Open Mail function 4. WWW: Open browser in IE 5. Back: see last page when viewing the internet 6. Forward: Go to next page when b\viewing the internet 7. Sleep: Turn system into sleep mode 8. Calculator: Open calculator from Windows 9. Media: Open Media player program 10. Volume +: Turn the volume up 11.
PAGE 9
This device complies with Part 15 of the FCC rules, operation is subject to the following two conditions. （1）This device may not cause harmful interference and, （2）This device must accept any interference received, including interference that may cause undesired operation . NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.
