Installation Guide Atmospherix AS and Atmospherix A20
Congratulations on choosing Krix Your Krix speakers are designed to reproduce the highest quality sound. To get the best performance from your speakers please read these installation instructions thoroughly as there are many factors that influence the performance of your speakers. If you have any difficulties please contact one of our friendly authorised Krix dealers. setup in brief The following setup procedure will help you achieve the best performance from your inceiling speaker: 1.
introduction introduction The Atmospherix AS and Atmospherix A20 are high quality in-ceiling loudspeakers featuring fully sealed back-boxes to control and maximise bass response, whilst keeping out dust and other ceiling inhabitants. Atmospherix A20 Atmospherix AS The Atmospherix A20 employs an acoustically optimised front baffle angled at 20 degrees allowing its sound output to be projected towards your primary listening area.
installation installation before you begin ! • Please read the disclaimer on page 2 of this manual. Refers to page 3 of this manual and discuss with your local Krix distributor, or installation consultant, to determine the best location for your loudspeakers. Be sure to check for any obstructions, such as electrical wiring, plumbing, stud work or air conditioning ducts before commencing the installation.
installation figure 5 figure 6 Atmospherix A20 only: Aim arrow towards primary listening area figure 7 figure 8 figure 9 figure 10 5
specifications warranty 5 years warranty applies to the cabinet and speaker. (Refer to the details on the warranty card supplied) queries If you have any queries regarding the Atmospherix or any other Krix product, please contact your nearest Krix dealer or Krix directly. Contact details are on the back cover of this booklet. Atmospherix AS Frequency Range Power Handling Sensitivity Configuration Bass Driver(s) 45Hz - 40kHz in room response 20-120 watts RMS recommended amplifier power 90dB for 2.
specifications Atmospherix A20 Frequency Range Power Handling Sensitivity Configuration Bass Driver(s) 45Hz - 40kHz in room response 20-120 watts RMS recommended amplifier power 90dB for 2.83 volts at 1 metre 5 inch 2-way with 20 degree angle Cast aluminium basket with a nominal 130mm (5”) doped curvilinear paper cone. 25mm (1”) voice coil wound on high powered aluminium former with copper shorting ring.
Krix Loudspeakers Pty Ltd 14 Chapman Road Hackham SA 5163 Australia T 61 8 8384 3433 F 61 8 8384 3419 listen@krix.com krix.
