I N S TA L L AT I O N MA N UA L Britt™ Single Handle Commercial Kitchen Faucet KPF-1690 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV.
Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help. For more information about Kraus products, please visit: www.kraususa.
(168mm) 3/8” (10mm) 3 3/4” (96mm) 7/8” (22mm) Prior to Installation: 19.7º • Make sure you have all necessary parts by checking the diagram and parts 10 1/8” 8 5/16” list. If(257mm) any part is missing or damaged, please contact Kraus Customer (21mm) Service at 800-775-0703 for a replacement ∅ 1 15/16” (∅ 50mm) 1 3/8” Turn off the hot and cold water supply at the angle stops and turn on the (35mm) old faucet to release any built up pressure. Remove existing faucet.
Diagram and Parts List B A H E F D G1 C1 C2 C3 G2 A. Spray Head E. Escutcheon B. Faucet Body F. Base Plate C. Mounting Hardware G. Escutcheon Mounting Hardware C1. Plastic & Metal Washer G1. Bolt C2. Mounting Nut G2. Plastic Nut C3. Mounting Screw D. Flange & Washer 3 H. 2.
Faucet Dimensions 10 11/16in [271.6mm] 20 11/16in [525.5mm] 90° 6 7/16in [163.8mm] 8 7/16in [215.0mm] 2 1/8in [54.2mm] MAX:2 5/8in [67.
Step 1: Remove mounting hardware 1 2 3 Shut off the water supply. Remove the old faucet. Clean the mounting surface. Remove mounting hardware (C) from faucet body (B)B D C Step 2: Install the faucet assembly (without deckplate) 2 3 Before installation, ensure that the flange (D) is placed on the bottom of the new faucet assembly (B). Insert the faucet body through the hole in the sink.
3 Step 3: Install the escutcheon E G1 F G2 4 Before installation, remove the flange (D). Screw the bolts (G1) into the escutcheon (E) and B ensure that the base plate (F) is pressed onto the escutcheon (E) before the escutcheon (E) is installed over the three holes in theE sink. From underneath sink, hand tighten the mounting nuts (G2). Do not overtighten.
Step 5: Secure the faucet assembly 5 6 Install the plastic washer and metal washer (C1) onto the threaded mounting shank. Thread the nut (C2) onto the mounting shank. Lock the nut1(C2) into position by tightening the screws (C3). 2 Do not overtighten C1 C2 C3 Step 6: Connect the waterlines 6 7 Thread the nut (1) on the supply line onto the outlet of the water supply valve (2) and tighten with wrench.
Step 7: Flush and check for leaks Pull hose assembly out of spout and remove spray head by unscrewing from hose in a counterclockwise direction. Hold the end of the hose down into the sink and turn the faucet on to the warm position. Flush water lines for one minute to flush away any debris. Check for leaks. Re-tighten any connections if needed. Do not overtighten. Reinstall spray head by hand tightening it back onto the spray hose.
Care & Maintenance *To keep the product clean & shining, follow the steps below: 1.Close 25˚ 2. 3. 4. Rinse with clean water & dry with a soft cloth 90˚ Do not clean with soaps, acid, polish, abrasives, or harsh cleaners Push Do not use cloth with a coarse surface Unscrew the aerator and clean when necessary Left Open Hot Water *This installation manual is subject to change without further notice. Download the Kraus Care & Maintenance Guide at: http://www.kraususa.
Replacement Parts 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 06 07 05 12. 13. 14. 15. 16. 17. 18. 19. 20. 11 08 09 10 12 14 04 15 03 02 13 17 01 16 20 21 18 19 21. 22. 23. 24. 25. 26. Spray Head Check Valve Washer S.
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM 11 CAUSE ACTION Leakage under the handle The bonnet nut (15) has come loose and the ring on the cartridge is dirty or damaged Tighten the bonnet nut.
Codes/Standards Applicable: GREEN NSF/ANSI 372 NSF/ANSI 61-9 Water Efficiency Meets A112.18.1 1.8gpm 6.8L/min maximum FAUCET WARRANTY Kraus products are manufactured and tested to the highest quality standards by Kraus USA Inc. (“Kraus”). Kraus extends this warranty to the original purchaser for personal household use of the “Faucet” in its original location. The warranty is non-transferable.
Except as otherwise provided above, Kraus makes no warranties, expressed or implied, including warranties of merchantability and fitness for a particular purpose, or compliance with any code. Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto Rico shipping charges may apply). International shipping fees are not included.
If you are a homeowner please contact a Kraus Customer Service Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com If you are an Authorized Partner please contact a Partner Support Representative at: Kraus USA, Inc.
