Specification Sheet

Features
•
0.5 gal/min (1.9 l/min) flow rate.
•
Factory set 30 second max. continual run cycle .
•
Vandal-resistant aerator.
•
24" (610 mm) flexible supply hoses for easy installation.
•
5-5/16" (135 mm) spout reach.
•
Less temperature mixer.
•
Less drain.
Material
•
Brass construction.
Technology
•
Includes two AAA batteries.
CSA B651
OBC
•
Electronic Insight
™
Sensor Technology for accurate and
consistent activation.
Codes/Standards
Installation
ASME A112.18.1/CSA B125.1
•
Single-hole mounting.
NSF 372
•
Above-counter battery and valve for easy installation and
maintenance.
All applicable US Federal and State material
regulations
DOE - Energy Policy Act 1992
Optional Accessories
1101643 Large Concealed Spray 0.5 gpm (1.9 l/min)
1139288 Large Concealed Spray Aerated 1.0 gpm (3.8 l/min)
1139289 Large Concealed Laminar 1.0 gpm (3.8 l/min)
1139290 Large Concealed Aerated 1.5 gpm (5.7 l/min)
1100596 Large Concealed Laminar 1.5 gpm (5.7 l/min)
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER
®
One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
Polished ChromeCP
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
3-7-2017 05:31
Geometric Insight
™
DM Faucet
K-13467
