Dimensions Guide

Features
•
Center drain.
•
Cascading water over rim.
•
Adjustable bath leveling system.
•
Two raised molded seats.
•
Dual lumbar supports two-person bathing by offering comfort
at both ends.
•
103-3/4" (2635 mm) x 41" (1041 mm) x 26" (660 mm)
Material
•
Acrylic bath, with gel coat FRP overflow channel.
Hydrotherapy
•
Effervescent bubbles with 13 ports.
•
Built-in 4000 W heater.
Installation
•
Drop-in
Recommended Accessories
K-1601 Bath/Whirlpool Footstop
Codes/Standards
ASME A112.19.7/CSA B45.10
CSA B45.5/IAPMO Z124
K-7223 Pop-up Bath Drain
ASTM E162
K-922 Wall- Or -Ceiling-Mount Bath Filler
ASTM E662
K-923 Wall- Or -Ceiling-Mount Bath Filler
UL 1795
K-18486-4 Roman Bath Filler
CSA C22.2 No. 218.2
Greenguard UL 2818 - Gold
CARB P2
KOHLER
®
One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
8-31-2017 01:28
sok
®
104" Effervescence Bath
K-1166-RE
