AWS RRH User Manual AWS RRH User Manual Written by Reviewed by Approved by Jinhee Lee Kshin Michale Yoon 1
AWS RRH User Manual Index Contents 1. 2. 3. 4.
AWS RRH User Manual 1. Test Environment 1.1. Preperation List KMW AWS RRH (Remote Radio Head 2110 ~ 2155MHz) PSU (Power Supply Unit) D2U (Alacaltel Lucent) Optic transceiver 2EA Optic Cable Ehternet Cable Laptop computer 1.2.
AWS RRH User Manual 1.3. RRH Setup Procedure Checke PSU Power 48V off Connect PSU power to RRH Power connector Connect D2U and RRH with Optic transceiver and Optic cable Turn on PSU to power up RRH Make sure computer to join RRH and D2U network. If the computer joined the same network which BBU joined, it is able to access RRH network from the GUI.
AWS RRH User Manual 2. Network Configuration Setup computer network configuration IP: assigned by ALU (ex; 10.10.10.55) Subnet mask: 255.0.0.0 Default gateway: assigned by ALU (ex; 10.10.10.1) DNS: assigned by ALU Test network configuration Windows Start > Run > CMD [Enter] C:\> ping RRH IP(10.14.0.
AWS RRH User Manual 3. Output Spectrum If you set up Signal Analyzer, you can monitor carrier power just like below image. 4.
Alcatel-Lucent RRH2x60-B4 Installation Guide Issue Date Change 0.01 March 3, 2014 First draft 0.02 March 10, 2014 Updated for comments Legal notice Alcatel, Lucent, Alcatel-Lucent , and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. Th f ti presented t d iis subject bj t tto change h ith t notice. ti Al t lL t assumes no responsibility ibilit ffor iinaccuracies i The iinformation without Alcatel-Lucent contained herein.
Mandatory documents Document number Title 3MN-01520-0001-RJZZA Alcatel-Lucent RRH2x60-B4 – Site Preparation Guidelines Related Documents Document number Title 3MN-01520-0003-DEZZA Alcatel-Lucent RRH2x60-B4 – Technical Description Terminology In this document, Alcatel-Lucent Remote Radio Head 2x60-B4 is referred to by its abbreviated name, “AlcatelLucent RRH2x60-B4,” its shortened name, “RRH2x60-B4,” and may be generically referred to as the Remote Radio Head (RRH).
1. Safety - General precautions for installation procedures The following general precautions must be observed for installation procedures. WARNING Personal injury hazard Failure to observe these safety precautions may result in personal injury or damage to equipment. g to equipment, q p g instructions: To avoid p personal injuryy or damage observe the following • Read and understand all instructions. • Follow all warnings and instructions marked on this product.
1. Safety – Specific hazards DANGER DANGER L h d Laser hazard El t i shock h kh d Electric hazard This equipment operates with invisible laser radiation. Laser radiation can cause considerable injuries to the eyes. p ffiber or into an Never look into the end off an exposed open optical connector when the optical source is switched on. Always observe the laser warning instructions.
1. Safety – Specific hazards (continued) DANGER NOTICE N i b t h d Noxious-substance hazard T l hazard h d Tools Use of unspecified cleaning agents can result in personal injury. Use only specified cleaning agents. Never use fflammable solvents. Always ensure there is adequate ventilation in the work area and wear the appropriate personal protective equipment. Tools left in the working area can cause short circuits during operation which can lead to the destruction of units.
3.
2. Product overview – physical interfaces Solar Shield Bottom view CPRI-1 Status LED (primary) CPRI-2 (secondary) GND GND -48V DC IN AISG (output) alarms ports Rx3 TxRx1 TxRx2 Rx4 Notes: Solar shield now shown in these views GND = Protective Earth (PE) ground ground, located on lower right side and lower right side of RRH (when facing front of RRH) Alcatel-Lucent RRH 2x60-B4 Rear view Alcatel-Lucent – Internal Proprietary – Use pursuant to Company instruction 3MN-01520-0002-RJZZA Issue 0.
3.
3. Tools, materials, and prerequisites – Required materials, parts list Required installation parts list Item Part No. Description Qty.
3. Tools, materials, and prerequisites – Prerequisites Verify site preparation and physical installation are completed: (see Alcatel-Lucent RRH2x60-B4 – Site Preparation Guidelines, 3MN-01520-0001-RJZZA): Before installation of the Alcatel-Lucent RRH2x60-B4 site can begin, site preparation must be completed.
4-1. Pre-installation steps - Preparing the RRH CPRI-2 Step 1 Remove the optical port cover. Step 2 Install the optical transceiver in the right slot. Step 3 Place the cover of the optical port back to protect the port. CPRI1 NOTE: if only one optical port is used, used insert the transceiver in CPRI1 Note: Clean and inspect the LC connectors on the CPRI fiber optic cable before connecting to SFP. 4-2.
Required materials 5-1. Install RRH on a pole Note: The RRH is shipped with the Wall Mounting Bracket and the solar shields installed ((in Type yp A configuration.) g ) Step 1 Remove the mounting bracket from the RRH by loosening the four M8 side screws (see arrows). Do not completely remove the screws from the holes. Description Qty.
5-2. Procedure to change from Type A configuration to Type B Note: The RRH is shipped with the Mounting Bracket installed in Type A configuration (on the same side as the antenna connectors). To convert to Type B configuration (Mounting Bracket on opposite side of antenna connectors). Step 1 Remove the mounting bracket from the RRH by loosening the four M8 side screws. Do not completely remove the screws from the holes. holes Step 4 Flip over the RRH so the antenna connector side is up.
Required materials 5-3. Install RRH on a wall Note: The RRH is shipped with the wall Mounting Bracket installed (in Type A configuration). For wall mounting, the Mounting Bracket must be t d to t T fig ti SSee 4 2 Procedure P d tto change h g ffrom converted Type B configuration. 4-2 Type A configuration to Type B. Part No. Description Qty. 3JR52709AA Alcatel-Lucent RRH2x60-B4 1 N/A Wall anchors (customer provided) 4 Step 5 Torque each M8 side screw (4 total) to 15.3 Nm (135 in-lb).
Required materials 4-4. Connect protective Earth (PE) ground Part No. Description Qty. 301022679 Ground lug kit (kit WES bag) 1 Step p1 Route the 35 mm2 (#2 AWG) ground cable pigtail from the ground system (installed during site preparation) to the PE ground pad located on the lower right side or the lower left side of the RRH.
Required materials 4-5. Connect optical fiber cables Part No. NOTICE Description Qty.* SFP transceiver, SMDF or MMDF , LC connector 1 Protect fiber cable Depends on length Mishandling fiber optic cable can result in damaged and nonfunctioning cables. Optical fiber, SMDF, LC-LC 1 connectors 1AB027220001 R2CT weatherized plug The optical cable is very sensitive, take the maximum precaution when installing it. The optical fiber should be protected in solid pipe.
5-4. Connect optical fiber cables (continued) Step p4 Using the assembly instructions provided with the R2CT weatherized plug, assemble the R2CT plug onto the SMDF optical fiber and connect to CPRI-1 port. Step 4A Using your left hand, connect the R2CT plug body to the CPRI-1 port receptacle as follows: Align arrow on plug body with alignment mark on receptacle. Insert plug body bayonet pins into slots on receptacle. Rotate the plug body counterclockwise to lock it into place.
5-5. Connect optical fiber cables – Step 4 (continued) Step p 4B Remove the protective covers from the LC connector. Clean and inspect the LC connectors on the CPRI fiber optic cable. Step 4C Using your left hand, connect the fiber optic cable to the CPRI1 port SFP transceiver as follows: Gently insert the LC connector into the SFP transceiver until it “clicks” into place. Gently pull on the LC connector to verify that it is locked into place.
5-6. Route and connect user alarm cables (optional) Step 1 Install and route the alarm cables from the alarm ports to the alarm distribution frame. Required materials Part No. Description Qty. Depends on length User alarm cable, 4 pair, circular DIN male on one end 1 or 2 Connector pin configuration Step 5 Plug the alarm cable connectors into the alarm ports and hand tighten the outer connector shell to secure the h cables.
5-7. Route and connect AISG cable (optional) Step p1 Install and route the AISG cable from the AISG port on the bottom of the RRH to the respective AISG controller or external antenna line device (ALD) port. Required materials Part No. Description Qty.* Depends on length AISG connection cable, 8pin circular DIN 1 Connector pin configuration AISG cable terminal configuration AISG (output) Note: AISG OUT ports have female pins. Step 2 S Remove the protective cover from the AISG port on the RRH.
5-8. Route and connect RF cables (optional) Step p1 Install and route the RF cables to the RF ports on the top of the RRH. Important! Ensure that RF cable shield grounding has been completed for all antenna cables. Required materials Part No. Description Qty. Depends on length RF cable, coax, DIN maleDIN male/loose 1 to 4 Step 2 Providing adequate slack, cut each cable so it reaches its corresponding RF antenna connector or, if applicable, its corresponding RF surge protector.
5-9. Connect DC power cable DANGER Required materials Part No. Description Qty. 1AB435070001 DC power plug, circular, 2-pin 1 N/A cable customer provided 1 Power cable, Electric shock hazard Contact with energized network element power supply lines can result in serious personal injury. Ensure that the DC power is OFF and secured against turn-on before completing this procedure.
5-10. Final checks of installation Step p1 Inspect site for loose tools, materials, and parts. Remove all such loose tools, materials, and parts. Step 2 Verify that all the exterior mounting hardware and cable connections are secure. Step 3 Check the overall appearance of the Alcatel-Lucent RRH2x60-B4. Note: Verify that nothing is unbalanced, unsecured, or out of alignment and no unintended mechanical alteration of the Alcatel-Lucent RRH2x60-B4, mounting brackets, or support structure has occurred.
