TK-C215VP4_JP.book Page 1 Thursday, November 2, 2006 10:51 AM DOME CAMERA TK-C215VP4U/E TK-C215VP12U/E INSTRUCTIONS For Customer Use: Enter below the Serial No. which is located on the body. Retain this information for future reference. Model No. TK-C215VP4U/E,TK-C215VP12U/E Serial No.
TK-C215VP4_JP.book Page 2 Thursday, November 2, 2006 10:51 AM Introduction These are general IMPORTANT SAFEGUARDS and certain items may not apply to all appliances. IMPORTANT SAFEGUARDS 1. 2. 3. 4. Read all of these instructions. Save these instructions for later use. All warnings on the product and in the operating instructions should be adhered to. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 5.
TK-C215VP4_JP.book Page 3 Thursday, November 2, 2006 10:51 AM Safety Precautions FOR USA AND CANADA INFORMATION FOR USA INFORMATION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TK-C215VP4_JP.book Page 4 Thursday, November 2, 2006 10:51 AM Introduction Safety Precautions (continued) Information for Users on Disposal of Old Equipment [European Union] This symbol indicates that the electrical and electronic equipment should not be disposed as general household waste at its end-of-life.
TK-C215VP4_JP.book Page 5 Thursday, November 2, 2006 Thank you for purchasing this product. (These instructions are for: TK-C215VP4U/TKC215VP4E/TK-C215VP12U/TK-C215VP12E.) Before beginning to operate this unit, please read the instruction manual carefully in order to make sure that the best possible performance is obtained.
TK-C215VP4_JP.book Page 6 Thursday, November 2, 2006 10:51 AM Introduction Table of Contents Introduction Safety Precautions .................................... 3 Characteristics .......................................... 5 Table of Contents ...................................... 6 Precautions for proper use of this product ... 7 Name of Parts ........................................... 9 Setting the Switches and the Lens (TK-C215VP4U/E) ................................
TK-C215VP4_JP.book Page 7 Thursday, November 2, 2006 Precautions for proper use of this product Storage and Location of Use 䢇 Do not install this unit at the following locations. ● Places that are exposed to vapor or oil, such as kitchens. ● Places that exceed the ambient temperature range (-10 I to 50 I). ● Places at which corrosive gases are emitted. ● Places where radiation or X-rays and strong radio waves or magnetism are present. ● Places that are subject to vibration.
TK-C215VP4_JP.book Page 8 Thursday, November 2, 2006 10:51 AM Introduction Precautions for proper use of this product (continued) Maintenance 䢇 Turn off the power before performing maintenance. 䢇 Clean the dome cover using a lens cleaning cloth (or soft cloth). Wiping it with thinner or benzene may melt the surface or cause it to fog. For tough stains, wipe using a cloth that is dipped into a neutral detergent diluted with water, followed by wiping with a dry cloth.
TK-C215VP4_JP.book Page 9 Thursday, November 2, 2006 10:51 AM Name of Parts Camera A B C F D E A Mounting hole ⳯ 2 C Mounting Screw for Fall Prevention Wire Use these when mounting the camera to the ceiling, wall or electrical box. (A Pg. 21)(A Pg. 31) Use this screw when mounting the fall prevention wire to this unit. (Fall prevention wire is not supplied with this product.
TK-C215VP4_JP.book Page 10 Thursday, November 2, 2006 10:51 AM Introduction Name of Parts (continued) Camera (continued) L K J TK-C215VP12U/E only I G H G Base J Alarm signal cable Mount the base to the ceiling, wall or electrical box before mounting the camera. (A Pg. 21)(A Pg. 31) (TK-C215VP12U/E only) H Fastening Screw for Dome Cover K Protection Cover This is a fastening screw for the dome cover. Use a supplied wrench to fasten/unfasten the screw.
TK-C215VP4_JP.book Page 11 Thursday, November 2, 2006 10:51 AM Camera (Interior) M Lens (A next page) Y X N W O P Q V R U S T *TK-C215VP4U/E is used in the above illustration M Rotation Knob ( TK-C215VP4U/E only) U Camera Unit Fastening Clip ⳯ 2 Rotate the lens unit to adjust the inclination of the image. (A Pg. 25) This clip is used for fastening the camera unit to the base. When removing the base, press toward the direction indicated by the arrow to release. (A Pg.
TK-C215VP4_JP.book Page 12 Thursday, November 2, 2006 10:51 AM Introduction Setting the Switches and the Lens (TK-C215VP4U/E) Set the video setting switches on the camera unit before mounting it. To set the switches, use a fine-tipped screwdriver. A F G RESET/ [SPOT] B R B LL PHASE C D E 1 2 3 4 5 6 7 8 O N 2 4 WHT. BAL.
TK-C215VP4_JP.book Page 13 Thursday, November 2, 2006 10:51 AM 3. [SYNC] Synchronization system selection switch. This switch sets the synchronizing system for the camera. INT: This is set for internal synchronization LL (Line Lock): The camera’s vertical synchronization is locked to the AC 24 V 60 Hz or 50 Hz power line frequency.
TK-C215VP4_JP.book Page 14 Thursday, November 2, 2006 10:51 AM Introduction B [ZOOM / FOCUS,MEMORY] zoom, focus Setting the Switches and the Lens (TK-C215VP12U/E) RESET/[SPOT] B LL PHASE R L H LEVEL [MEMORY] WHT.BAL. TELE ZOOM/FOCUS NEAR ALARM POSITION 2 FAR WIDE 4 POSITION SELECT 1 2 3 4 5 6 7 8 A B C D IRIS Set the video setting switches on the camera unit before mounting it. To set the switches, use a fine-tipped screwdriver.
TK-C215VP4_JP.book Page 15 Thursday, November 2, 2006 G Function selection switches 1. [AGC] Auto-gain control switch. Setting this switch to AONB automatically increases the sensitivity even when the brightness of the subject is insufficient. (Default setting: ON) 2. [SELECT] WHT.BAL./PHASE setting switch. WHT.BAL.: The F [R/B,+/-] buttons are used as [R/B] adjustment buttons. PHASE: The F [R/B,+/-] buttons are used as [+/-] adjustment buttons. (Default setting: WHT.BAL.) 3.
TK-C215VP4_JP.book Page 16 Thursday, November 2, 2006 10:51 AM Installation and Connection System Example ● Turn off the power of devices to be used before connecting the cables. ● Read through the “Instruction Manual” of the devices to be used carefully before connecting.
TK-C215VP4_JP.book Page 17 Thursday, November 2, 2006 About Connection Cables The maximum connection distance varies with the type of cable used. Please refer carefully to the table for each cable during connection. * Be sure to turn off the power of devices before connecting cables. To video Signal Cable 10:51 AM DC 12 V or AC 24 V power supply cable Connect the DC 12 V or the AC 24 V power supply to the DC 12 V/AC 24 V terminals on the terminal board.
TK-C215VP4_JP.book Page 18 Thursday, November 2, 2006 Installation and Connection About Connection Cables (continued) Electrical Specifications of Alarm Input Terminals (TK-C215VP12U/E only) ● To prevent penetration of noise in the internal circuitry, apply a non-voltage contact signal to the ALARM input terminal. Never apply a voltage. ● Apply an alarm signal for at least 200 ms. If it is shorter, it is not guaranteed that the signal will be recognized as an alarm signal.
TK-C215VP4_JP.book Page 19 Thursday, November 2, 2006 The right sequence to connect and set the camera Follow the procedures below to connect/set this unit. Turn off the power of devices to be used before connecting the cables. 䢇 Before touching the camera unit, make sure to touch the metal surface of the [MONITOR] terminal to discharge any static electricity from your body. Static electricity may cause the camera to malfunction.
TK-C215VP4_JP.book Page 20 Thursday, November 2, 2006 10:51 AM Installation and Connection Setting the switches Remove the dome cover, followed by setting the video image switches. 3. Setting the switches Set the switches for video images. (APg. 12 eSetting the Switches and the Lens (TK-C215VP4U/E)f) (APg. 14 eSetting the Switches and the Lens (TK-C215VP12U/E)f) 1. Removing the dome cover Remove the dome cover by unfastening the 3 fastening screws using the wrench supplied.
TK-C215VP4_JP.book Page 21 Thursday, November 2, 2006 10:51 AM 2. Mounting the fall prevention wire to the Mounting the base Remove the camera unit from the base and mount the base to the ceiling or wall. When mounting to a wall, follow the procedures by replacing areas indicated as [ceiling] by [wall] accordingly. base (fall prevention wire is not supplied) Remove the fastening screw for the fall prevention wire and mount the fall prevention wire.
TK-C215VP4_JP.book Page 22 Thursday, November 2, 2006 10:51 AM Installation and Connection Cable Connection 1. Connecting the coaxial cable (A Pg. 17) Lower the protection cover and connect the connectors. Upon connecting, cover the connectors using the protection cover. 2 2. Connecting the AC 24 V/DC 12 V power supply wires Solder or Caulk Note: Insulating Tape ● To mount a heater (sold separately) to this unit, make sure to connect it to an AC 24 V supply during use.
TK-C215VP4_JP.book Page 23 Thursday, November 2, 2006 Mounting the camera unit Fill the piping hole and mounting hole with a sealing material, mount the camera unit to the base, and insert the silica gel. 1. Fill the hole with sealing material Fill the piping hole as well as the 2 mounting holes mounted with screws using a sealing material. 10:51 AM 2. Mounting the camera unit to the base Press the 2 clips until a “click” sound is heard.
TK-C215VP4_JP.book Page 24 Thursday, November 2, 2006 Installation and Connection Mounting the camera unit (continued) 4. Inserting the silica gel supplied Take out the silica gel from the aluminum package, insert it into the silica gel insertion space of the camera unit and fasten using the lug plate.
TK-C215VP4_JP.book Page 25 Thursday, November 2, 2006 10:51 AM Adjusting the video image Panning: ±175 ⬚ Upon mounting the camera, adjust the images while checking the actual image. Mounting the test monitor Connect the [MONITOR] terminal of this unit to the test monitor to adjust the camera’s shooting direction, angle of view and focus. Rotation: ±175 ⬚ Memo: ● Before setting, ensure to turn on the power of the system.
TK-C215VP4_JP.book Page 26 Thursday, November 2, 2006 10:51 AM Installation and Connection Adjusting the video image (continued) 䡵 TK-C215VP4U/E L Adjusting the angle of view, focus and brightness Upon determining the imaging direction, adjust the angle of view, focus and brightness accordingly. Note: ● When adjusting the focus, make sure to cover the dome cover over the lens. The dome cover of this unit is thick.
TK-C215VP4_JP.book Page 27 Thursday, November 2, 2006 10:51 AM Adjusting the brightness Usually, adjustment of the brightness is not required. When this is necessary, adjust the iris level accordingly. To darken : Anti-clockwise direction (L side) To brighten : Clockwise direction (H side) Memo: ● Do not perform iris level adjustment within 30 seconds after pressing the focus adjustment button. (It cannot be adjusted correctly as the electronic shutter mode is activated.
TK-C215VP4_JP.book Page 28 Thursday, November 2, 2006 10:51 AM Installation and Connection Adjusting the video image (continued) 䡵 TK-C215VP12U/E ● 2 types of angle of view may be selected for TK-C215VP12U/E. In general, set in a way such that the home position shoots a wide range and the alarm position a narrow range. ● Use the alarm input mode selection switch to set the actions when there is an alarm input. (A Pg. 15) 3. Press the [MEMORY] button for 2 seconds or longer.
TK-C215VP4_JP.book Page 29 Thursday, November 2, 2006 10:51 AM 䢇 Registering alarm position RESET/[SPOT] B LL PHASE R L H LEVEL [MEMORY] WHT.BAL. NEAR ALARM POSITION TELE ZOOM/FOCUS FAR WIDE 2 POSITION SELECT 4 1.,5. 1 2 3 4 5 6 7 8 3. 2.,4. IRIS For registering the angle of view during monitoring when there is an alarm input. 1. Check that the [ALARM POSITION] indicator light is turned on. Registration of alarm position is enabled.
TK-C215VP4_JP.book Page 30 Thursday, November 2, 2006 10:51 AM Installation and Connection Mounting the inner dome Mounting the dome cover After setting is complete, mount the inner dome to the camera. 1. Cleaning the dome cover 1. Mounting the inner dome Before mounting, remove any dust or dirt from the dome cover. Mount the inner dome to the 3 clips. Memo: ● Dirt that is not removed from the cover before mounting may appear on the camera’s image.
TK-C215VP4_JP.book Page 31 Thursday, November 2, 2006 Note: ● Make sure that the dome cover is firmly fastened. Otherwise, the humidity level may rise, which may result in fogging and even falling of the cover. ● Ensure that the fall prevention wire of the dome cover is not caught in the space between the dome cover and base. Failing to do so may cause the dust-proof and waterproof features to malfunction. 10:51 AM Mounting the camera using the electrical box Mounting the base to the electrical box. 1.
TK-C215VP4_JP.book Page 32 Thursday, November 2, 2006 10:51 AM Installation and Connection Mounting the camera using the pipe Sealing Tape 4 12 mm(15/32 inch) and below 7 Use the piping hole to mount the camera. Fall Prevention Wire Mounting the camera using the piping hole at the bottom surface of the base 5 1. Setting the switches (A Pg. 20) 2. Removing the camera unit from the base. 3 8 mm (A Pg. 21 , step 1) 2 mm 3. Mount the fall prevention wire to the base (A Pg. 21) 4.
TK-C215VP4_JP.book Page 33 Thursday, November 2, 2006 Mounting the camera using the piping hole at the side surface of the base If the camera cannot be mounted directly to the ceiling, mount it to the pipe using the piping hole at the side surface of the base. 1. Setting the switches (A Pg. 20) 2. Dismantle the camera unit from the base and mount the fall prevention wire (A Pg. 21)(A Pg. 9) 3.
TK-C215VP4_JP.book Page 34 Thursday, November 2, 2006 10:51 AM Installation and Connection White-spot correction 1. Remove the dome cover. 2. Cover the lens surface using a black sheet of paper, etc. so that light does not enter the lens. As a general characteristic unique to CCDs, white-spots may appear on the screen with age. In order to reduce this phenomenon, this unit is equipped with a white-spot correction feature. Switch on the camera power supply and wait for at least 30 minutes. 3.
TK-C215VP4_JP.
TK-C215VP4_JP.book Page 36 Thursday, November 2, 2006 10:51 AM Others Specifications 䡵 Camera Signal system: U type : Based on NTSC standard E type : Based on PAL standard Scanning frequencies U type : 15.734 kHz (Horizontal), 59.94 Hz (Vertical) E type : 15.
TK-C215VP4_JP.book Page 37 Thursday, November 2, 2006 䡵 Lens Focal length TK-C215VP4U/E : 2.8 mm to 10 mm (variable) TK-C215VP12U/E : 3.8 mm to 45.6 mm (variable) Zoom ratio TK-C215VP4U/E : Approx. 3.6 TK-C215VP12U/E : Approx. 12 Maximum aperture TK-C215VP4U/E : F1.3 (f = 2.8 mm) to F3.
TK-C215VP4_JP.book Page 38 Thursday, November 2, 2006 Others Specifications (continued) 䡵 Dimensional Outline Drawing [Unit: mm (inch)] 121(4-3/4) 113(4-1/2) 4 1/ 6- ( 60 9 (3/8) 42(1-5/8) 5(1/4) 1 Ǿ .7 53 /8) SR 2-1 ( 125(4-7/8) G3/4-14 UNC screw for piping (bottom surface, side surface) Ǿ160(6-1/4) * Specifications and appearance of this unit and related products are subject to change for product improvement without prior notice.
