AUDIO/VIDEO CONTROL RECEIVER RX-8022PSL A/V CONTROL RECEIVER CATV/DBS VCR1 TV AUDIO DVD DVD MULTI CD FM/AM TV/DBS VIDEO CDR PHONO VCR1 VCR 2 TAPE/MD SURROUND DSP USB SURR/DSP ANALOG/DIGITAL OFF ANALOG DIRECT BASS BOOST SOUND TEST 1 INPUT RX-8022P 2 3 FM/AM TUNING MENU 4 ∗CENTER ∗SUBWFR 5 6 ∗SURR•L ∗SURR•R MUTING ∗DIGITALEQ ∗SBACK•L ∗SBACK•R CATV/DBS CONTROL TV/VIDEO TEXT DISPLAY 8 10 0 RETURN FM MODE + + FM/AM PRESET MASTER VOLUME MEMORY 9 STANDBY/ON +10
Warnings, Cautions and Others switch! Caution –– Disconnect the mains plug to shut the power off completely. switch in any position does not disconnect the mains The line. The power can be remote controlled. CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. CAUTION • Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc.
Caution: Proper Ventilation To avoid risk of electric shock and fire and to protect from damage. Locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 10 cm from the sides. Top: No obstructions in 10 cm from the top. Back: No obstructions in 15 cm from the back Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated.
Table of Contents Introduction ................................................ 2 Features ...................................................................................... 2 Precautions ................................................................................. 2 Parts Identification ...................................... 3 Getting Started ........................................... 5 Setting Sound ........................................... 30 Attenuating the Input Signal ....................
Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference. Precautions Features Dolby Digital EX* Power sources Dolby Digital EX is newly introduced surround encoding format as an extension of multi-channel Dolby Digital, designed to add an extra surround channel to Dolby Digital 5.1-channel.
Parts Identification Become familiar with the buttons and controls on the receiver before use. Refer to the pages in parentheses for details.
Remote Control Remote Control A/V CONTROL RECEIVER 1 2 3 4 5 CATV/DBS VCR1 TV AUDIO DVD DVD MULTI CD FM/AM TV/DBS VIDEO CDR PHONO VCR1 VCR2 TAPE/MD USB SURROUND DSP ANALOG DIRECT BASS BOOST OFF 1 6 SOUND TEST 7 4 INPUT ∗FRONT•L ∗FRONT•R 2 ∗ 3 8 7/P y u MENU CENTER 5 ∗ SUBWFR 6 ENTER DIMMER ∗SURR•L ∗SURR•R 8 i 9 ∗DIGITALEQ ∗SBACK•L ∗SBACK•R MUTING 9 CATV/DBS CONTROL p TV/VIDEO 10 0 +10 RETURN FM MODE 100+ + + + ∗ CH/ LEVEL TV VOL q w e r SURR/
Getting Started This section explains how to connect audio/video components and speakers to the receiver, and how to connect the power supply. Before Installation Connecting the FM and AM Antennas FM Antenna Connections General Precautions • Be sure your hands are dry. • Turn the power off to all components. • Read the manuals supplied with the components you are going to connect.
AM Antenna Connections ANTENNA Turn the loop until you have the best reception. FM 75 COAXIAL AM Loop Antenna (supplied) AM LOOP AM EXT 1 Connecting the Speakers Snap the tabs on the loop into the slots of the base to assemble the AM loop. 2 You can connect the following speakers: • Two pairs of front speakers to produce normal stereo sound. • One pair of surround speakers to enjoy the surround effect. • One surround back speaker or one pair of surround back speakers to enjoy 6.
Basic connecting procedure 2 1 1 Cut, twist and remove the insulation at the end of each speaker signal cable (not supplied). 4 3 2 Turn the knob counterclockwise. 3 Insert the speaker signal cable. 4 Turn the knob clockwise. For each speaker (except for a subwoofer), connect the (+) and (–) terminals on the rear panel to the (+) and (–) terminals marked on the speakers.
Enhancing your audio system Connecting Audio/Video Components You can use this receiver as the pre-amplifier (control amplifier) when you connect power amplifiers to the PRE OUT jacks on the rear panel using cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, and the red plug to the audio right jack. Left front speaker Right front speaker You can connect the following audio/video components to this receiver. Refer also to the manuals supplied with your components.
CD player CD recorder SUB WOOFER CENTER RIGHT LEFT AUDIO CD recorder DVD SURR (REAR) To audio output To audio input PHONO CD player CD SUB WOOFER CENTER DVD OUT (REC) TAPE MD RIGHT LEFT AUDIO SURR (REAR) PHONO IN (PLAY) To audio output CD OUT (REC) CDR OUT (REC) IN (PLAY) TAPE MD IN (PLAY) OUT (REC) CDR IN (PLAY) Cassette deck or MD recorder Cassette deck To audio output To audio input SUB WOOFER CENTER RIGHT LEFT DVD AUDIO SURR (REAR) If your audio components have a C
Video component connections IMPORTANT: Use the cables with RCA pin plugs (not supplied). Connect the white plug to the audio left jack, the red plug to the audio right jack, and the yellow plug to the video jack. • If your video components have S-video (Y/C-separation) and/or component video (Y, PB/CB, PR/CR) terminals, connect them using an S-video cable (not supplied) and/or component video cable (not supplied).
TV and/or DBS tuner When connecting the TV to the AUDIO jacks (TV SOUND/DBS), DO NOT connect the TV’s video output to these video input jacks. VIDEO AUDIO RIGHT VIDEO LEFT COMPONENT VIDEO S-VIDEO DVD DVD FRONT TV SOUND DBS DBS OUT (REC) MONITOR OUT VCR1 Y PB/CB PR/CR IN (PLAY) A OUT (REC) TV VCR2 IN (PLAY) Connect the TV to the appropriate MONITOR OUT jacks to view a play-backing picture from other connected video components.
DVD player • When you connect a DVD player with stereo output jacks: VIDEO AUDIO RIGHT VIDEO LEFT COMPONENT VIDEO S-VIDEO DVD DVD FRONT TV SOUND DBS DBS OUT (REC) MONITOR OUT VCR1 PB/CB Y PR/CR IN (PLAY) OUT (REC) A DVD player VCR2 IN (PLAY) DVD B C Å ı Ç Î MONITOR OUT D To front left/right audio output To S-video output To component video output To composite video output • When you connect a DVD player with its analog discrete output (5.
Notes: Digital Connections This receiver is equipped with four DIGITAL IN terminals—one digital coaxial terminal and three digital optical terminals—and one DIGITAL OUT terminal. IMPORTANT: • When connecting a DVD player, digital TV broadcast tuner or DBS tuner using the digital terminals, you also need to connect it to the video jacks on the rear. Without connecting it to the video jacks, you can view no playback picture.
USB Connection This receiver is equipped with a USB terminal on the front panel. You can connect your PC to this terminal and enjoy sound reproduced through your PC. When you connect your PC for the first time, follow the procedure below. • Remember you cannot send any signal or data to your PC from this receiver. 5. Check if the drivers are correctly installed. 1. Open the Control Panel on your PC: Select [Start] = [Settings] = [Control Panel]. 2.
Connecting the Power Cord Before plugging the receiver into an AC outlet, make sure that all connections have been made. Putting Batteries in the Remote Control Before using the remote control, put two supplied batteries first. When using the remote control, aim the remote control directly at the remote sensor on the receiver. Plug the power cord into an AC outlet. Keep the power cord away from the connecting cables and the antenna. The power cord may cause noise or screen interference.
Basic Operations The following operations are commonly used when you play any sound sources. Before using the remote control How to confirm the remote control operation mode The display window on the remote control shows the following information when you press certain buttons on the remote control, so that you can confirm which operation you do. Pressing one of the source selecting buttons, the source name selected appears on the display.
From the remote control: Changing the source name When you have connected an MD recorder to the TAPE/MD jacks or a DBS tuner to the TV SOUND/DBS jacks on the rear panel, change the source name which will be shown on the display. DVD DVD MULTI CD FM/AM TV/DBS VIDEO CDR PHONO VCR 1 VCR 2 TAPE/MD USB On the front panel ONLY: When changing the source name from “TAPE” to “MD”: TAPE / MD 1. Press TAPE/MD (SOURCE NAME). • Make sure “TAPE” appears on the display.
Adjusting the Volume Listening Only with Headphones On the front panel: To increase the volume, turn MASTER VOLUME clockwise. To decrease the volume, turn it counterclockwise. MASTER VOLUME From the remote control: To increase the volume, press VOLUME +. To decrease the volume, press VOLUME –. + VOLUME − CAUTION: Always set the volume to the minimum before starting any sources.
Selecting the Analog or Digital Input Mode When you have connected digital source components using the digital terminals (see page 13), you need to change the input mode for these components to the appropriate digital input mode correctly—DGTL AUTO, DGTL DTS, or DGTL D.D. Before you start, remember... The digital input (DIGITAL IN) terminal setting should be correctly done for the sources you want to select the digital input mode for (see “6 Setting the Digital Input (DIGITAL IN) Terminals” on page 25).
When the shut-off time comes: The receiver turns off automatically. Muting the Sound From the remote control ONLY: Press MUTING to mute the sound through all speakers and headphones connected. MUTING “MUTING” appears on the display and the volume turns off (the volume level indicator goes off). L ANALOG To check or change the time remaining until the shut-off time: Press SLEEP once. The remaining time until the shut-off time appears in minutes. • To change the shut-off time, press SLEEP repeatedly.
Basic Settings Some of the following settings are required after connecting and positioning your speakers while others will make operations easier. • When performing the basic settings, it is recommended to use the remote control so that you can show the on-screen display on the TV. • When using the buttons on the front panel, you can perform the same settings. (The following on-screen display cannot be shown if you use the buttons on the front panel.
1 Setting the Speakers To obtain the best possible surround sound from the Surround and DSP modes, you have to register the setting about the speaker arrangement after all connections are completed. 7 Surround back speakers quantity—S BACK (SBACK) OUT [On-screen display] [Front panel] 7 Subwoofer setting—SUBWOOFER [On-screen display] [Front panel] Select the surround back speakers quantity. 2SPK : Select this to use 2 surround back speakers. 1SPK : Select this to use 1 surround back speaker.
2 Selecting Channel Numbers to Reproduce Multi-channel Digital Software—EX/ES [On-screen display] [Front panel] 3 Setting the Speaker Distance The distance from your listening point to the speakers is another important element to obtain the best possible sound of the Surround and DSP modes. You need to set the distance from your listening point to the speakers.
4 Setting the Bass Sounds 5 Setting the Dynamic Range—MID NIGHT You can adjust subwoofer and bass sounds precisely according to your preference. [On-screen display] [Front panel] 7 Crossover frequency—CROSSOVER [On-screen display] [Front panel] You can enjoy a powerful sound at night using the Midnight Mode. Select one of the following: When you use a subwoofer, you can select the cutoff frequency for the small speakers used. 1 : Select this when you want to reduce the dynamic range.
6 Setting the Digital Input (DIGITAL IN) Terminals [On-screen display] When “DIGITAL 1 (DGTL COAX 1)” is set to “CD” 2: DVD 3: TV (or DBS*) 4: CDR 2: DVD 3: TV (or DBS*) 4: MD** 2: DVD 3: MD** 4: CDR 2: MD** 3: TV (or DBS*) 4: CDR (back to the beginning) [Front panel] “ “ “ “ * If you have changed the source name from “TV” to “DBS,” “DBS” appears (see page 17). ** If you want to connect an MD recorder to the digital input terminal, change the source name to “MD” from “TAPE” (see page 17).
8 Memorizing the Volume Level for Each Source —ONE TOUCH OPR (ONE TOUCH) [On-screen display] 9 Showing the Text Information on the Display —FL DISPLAY (DISP) [Front panel] [On-screen display] [Front panel] This unit memorizes some settings separately for each source (see page 20). In addition, you can store the volume level for each source with the other memorized settings.
Receiving Radio Broadcasts You can browse through all the stations or use the preset function to go immediately to a particular station. Tuning into Stations Manually Using Preset Tuning On the front panel: 1. Press FM/AM to select the band (FM or AM). FM/AM Once a station is assigned to a channel number, the station can be quickly tuned in. You can preset up to 30 FM and 15 AM stations. To store the preset stations The FM/AM lamp on the front panel button lights up.
To tune in a preset station Selecting the FM Reception Mode On the front panel: 1. Press FM/AM to select the band (FM or AM). When an FM stereo broadcast is hard to receive or noisy, you can change the FM reception mode while receiving an FM broadcast. • You can store the FM reception mode for each preset station (see page 27). FM/AM The FM/AM lamp on the front panel button lights up. The last received station of the selected band is tuned in.
Operating the Tuner Using the On-Screen Display 7 Storing the preset stations 1. Press MENU. The MENU screen appears on the TV. You can also operate the tuner using the on-screen display. • The on-screen display will disappear if no operation is done for about 1 minute. 2. Press 5 or ∞ to move then press 2 or 3. 7 Operating the tuner 3. Tune into a station you want to store on the TUNER CONTROL menu, referring to “Operating the tuner”. 1. Press MENU. The MENU screen appears on the TV.
Setting Sound You can select the following sound settings to your preference according to your listening conditions or sources. • Items shown in this section are the initial values when shipped from the factory. • The on-screen display will disappear if no operation is done for about 1 minute. Attenuating the Input Signal Turning Analog Direct On and Off When the input level of the analog source is too high, the sounds will be distorted.
Notes: Reinforcing the Bass You can boost the bass level. • Once you have made adjustment, it is memorized for each source. • This function does not affect the sounds outputting from the surround speakers. • When Analog Direct is in use (see page 30), the Bass Boost function is canceled temporarily. On the front panel: Press BASS BOOST to turn on Bass Boost function. BASS BOOST Activating the Subwoofer Sound The BASS BOOST lamp on the front panel button lights up.
Using Surround Modes and DSP Modes This unit activates a variety of Surround modes and DSP (Digital Signal Processor) modes. To use Surround and DSP modes properly, speakers required for creating each Surround and DSP modes should be activated. ■ Surround Modes Reproducing Theater Ambience Introducing the Surround Modes In a movie theater, many speakers are located on the walls to reproduce impressive multi-surround sounds, reaching you from all directions.
Dolby Surround (Dolby Pro Logic)* DTS Digital Surround** Used to reproduce sound tracks of the software encoded with Dolby Surround ( DOLBY SURROUND ). Used to reproduce multi-channel sound tracks of the software ). encoded with DTS Digital Surround ( Dolby Surround encoding format records the left front channel, right front channel, center channel, and surround channel signals (total 4 channels) into 2 channels.
■ DSP Modes DAP (Digital Acoustic Processor) modes All Channel Stereo mode (ALL STEREO) The sound heard in a concert hall, club, etc. consists of direct sound and indirect sound—early reflections and reflections from behind. Direct sounds reach the listener directly without any reflection. On the other hand, indirect sounds are delayed by the distances of the ceiling and walls (see the diagram below). These indirect sounds are the most important elements of the acoustic surround effects.
Available Surround and DSP Modes According to the Speaker Layouts Available Surround and DSP modes will vary depending on how many speakers are used with this receiver. Make sure that you have set the speaker setting correctly (see page 22). • To turn on and select Surround and DSP modes, see page 36.
Activating the Surround Modes Available Surround modes will vary depending on how many speakers are used with this receiver. Make sure that you have set the speaker setting correctly (see page 22). 1. Set the analog or digital input mode for the source you like to use and start playing. When playing back multi-channel digital software, select the digital input mode (see page 19). 2. Press SURROUND to activate Surround mode.
Using the DVD MULTI Playback Mode This receiver provides the DVD MULTI playback mode for reproducing the analog discrete output mode of the DVD player. Before playing back a DVD, refer also to the manual supplied with the DVD player. When using DVD MULTI playback mode, connect the DVD player with its analog discrete output jacks (Å – ‰).
Adjusting Sound You can adjust sound parameters to your preference after completing basic setting. • When performing the sound adjustments, it is recommended to use the TV screen so that you can show the on-screen display on the TV. • When using the buttons on the front panel or remote control without using the on-screen display, you can perform the same adjustments. (The on-screen display cannot be shown.) • The on-screen display will disappear if no operation is done for about 1 minute.
2. Press CONTROL UP 5 or DOWN ∞ repeatedly to adjust the frequency level. Adjusting the Equalization Patterns —DIGITAL EQ You can adjust the equalization patterns to your preference. • Once you have made adjustment, it is memorized for each source. Using the on-screen display (through the remote control]: 1. Show DIGITAL EQ (Equalization) menu (see page 38). CONTROL DOWN UP The DIGITAL EQ indicator lights up on the display. • The frequency level changes from –8 dB to +8 dB in 2 dB steps. 3.
Adjusting the Speaker Output Levels —LEVEL ADJUST You can adjust the speaker output levels. The test tone can be also output from each speaker except subwoofer to check the output level balance when using the Surround mode. • Once you have made adjustment, it is memorized for each source. • When using the buttons on the front panel to adjust output level for the Surround mode, no test tone is available.
From the remote control: Before you start, remember... There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 2 again. Adjustment is also possible without outputting the test tone. In this case, you can skip steps 2 and 6 below. 1. Press SOUND. 5. Press SOUND again then repeat steps 3 and 4 to adjust the other speakers output levels. 6. Press TEST again to stop the test tone.
Adjusting the Sound Parameters for the Surround and DSP Modes—EFFECT ADJUST Using the on-screen display (through the remote control]: 1. Show EFFECT ADJUST menu (see page 38). You can adjust the Surround and DSP sound parameters to your preference. • Once you have made adjustment, it is memorized for each source.
COMPU LINK Remote Control System The COMPU LINK remote control system allows you to operate JVC’s audio components through the remote sensor on the receiver. To use this remote control system, you need to connect JVC’s audio components through the COMPU LINK-4 (SYNCHRO) jacks (see below) in addition to the connections using cables with RCA pin plugs (see pages 8 and 9). • Make sure that the AC power cords of these components are unplugged before connection.
TEXT COMPU LINK Remote Control System The TEXT COMPU LINK remote control system has been developed to deal with the disc information recorded in the CD Text* and MDs. Using these information in the discs, you can operate a CD player or MD recorder equipped with the TEXT COMPU LINK remote control system through the receiver. Connections: Functions: To use this remote control system, you need to connect a CD player and/or MD recorder you want to operate, following the procedures below.
Operations: To use this remote control system, you need to connect the TV to the MONITOR OUT jack on the rear panel (see page 11), and set the TV’s input mode to the proper position to which the receiver is connected. Make sure you have connected a CD player or MD recorder equipped with the TEXT COMPU LINK remote control system. If not, you cannot use the following functions.
Searching for a Disc (Only for the CD player) Search for a disc by its performer: 1. Press TEXT DISPLAY while “CD” is selected as the source. The Disc Information screen appears on the TV. 2. Press 5 or ∞ to move to “SEARCH,” then press SET. The DISC SEARCH screen appears. 3. Press 5 or ∞ to move to “PERFORMER,” then press SET. The PERFORMER SEARCH screen appears. 4. Press 5 / ∞ / 2 / 3 to move in front of the first character of the performer you want to search for, then press SET.
Search for a disc by its genre: 1. Press TEXT DISPLAY while “CD” is selected as the source. The Disc Information screen appears on the TV. 2. Press 5 or ∞ to move to “SEARCH,” then press SET. The DISC SEARCH screen appears. 3. Press 5 or ∞ to move to “GENRE,” then press SET. The GENRE SEARCH screen appears. 4. Press 5 or ∞ to move to the genre you want to search for, then press SET. To show the unseen genres, press 5 or ∞ until they appear.
4. Repeat step 3 until you finish putting a performer name (up to 32 characters). To insert a space, press 5 / ∞ to , / 2 / 3 to move then press SET. To correct an incorrect character: 1) Press 5 / ∞ / 2 / 3 to move to + or =, then press SET until the incorrect character is selected. to , then press SET 2) Press 5 / ∞ / 2 / 3 to move to erase the character. in front of the correct 3) Press 5 / ∞ / 2 / 3 to move character, then press SET to enter the correct character. 5.
AV COMPU LINK Remote Control System The AV COMPU LINK remote control system allows you to operate JVC’s video components (TV, VCR, and DVD player) through the receiver. This receiver is equipped with the AV COMPU LINK-III, which adds a function to operate JVC’s video components through the video components terminals. To use this remote control system, you need to connect the video components you want to operate, following the diagrams below and the procedure on the next page.
1. If you have already plugged your VCR 1 (VCR connected to the VCR 1 jacks), DVD player, TV and this receiver into the AC outlets, unplug their AC power cords first. 2. Connect your VCR 1, DVD player, TV and this receiver, using the cables with the monaural miniplugs (not supplied). • See “CONNECTIONS 1” on the previous page. 3. Connect the audio input/output jacks on VCR 1, DVD player, TV and this receiver using the cables with RCA pin plugs. • See pages 10 to 12. 4.
Operating JVC’s Audio/Video Components You can operate JVC’s audio and video components with this receiver’s remote control, since control signals for JVC’s components are preset in the remote control.
CD player 1 – 10, +10 :Select a track number directly. For track number 5, press 5. For track number 15, press +10, then 5. For track number 20, press +10, then 10. For track number 30, press +10, +10, then 10. :Enter recording pause by pressing this button. To start recording again, press this button, then 3 PLAY. After pressing CD, you can perform the following operations on a CD player: 3 PLAY 4 ¢ 7 STOP 8 PAUSE 1 – 10, +10 :Start playing. :Return to the beginning of the current (or previous) track.
VCR 1 (VCR connected to the VCR 1 jacks) You can always perform the following operations: Operating Video Components VCR1 IMPORTANT: To operate JVC’s video components using this remote control: • You need to connect JVC’s video components through the AV COMPU LINK jacks (see page 49) in addition to the connections using cables with RCA pin plugs (see pages 10 to 12). • Some JVC’s VCRs can accept two types of the control signals— remote code “A” and “B.
Operating Other Manufacturers’ Video Equipment This remote control supplied with the receiver can transmit control signals for other manufacturers’ TVs, CATV converters, DBS tuners, VCRs and DVD players. By changing the transmittable signals from preset ones to the other manufacturers’, you can operate the other manufacturers’ components using this remote control. When operating the other manufacturers’ components, refer also to the manuals supplied with them.
To change the transmittable signals for operating a CATV converter or DBS tuner 1. Press and hold CATV/DBS . 2. Press CATV/DBS CONTROL. “CALL” appears on the remote control display window. 3 Enter a manufacturer’s code using buttons 1–9, and 0. See the following lists to find the code. 4. Release CATV/DBS . The following buttons can be used for operating the CATV converter and DBS tuner: :Turn on and off the CATV converter or DBS tuner. :Change the channels. :Select the channels.
Manufacturer Codes JVC AIWA BELL & HOWELL BLAUPUNKT CGM EMERSON FISHER FUNAI GE GOLDSTAR GOODMANS GRUNDIG HITACHI LOEWE MAGNAVOX MITSUBISHI NEC NOKIA NORDMENDE ORION PANASONIC PHILIPS PHONOLA RCA/PROSCAN SABA SAMSUNG SANYO SHARP SIEMENS SONY TELEFUNKEN TOSHIBA ZENITH 00*, 26, 27, 28, 29, 58 01, 02 03 04, 05 06, 07 08, 10, 11, 12, 64, 65 03, 14, 15, 16, 17 01 18, 19, 20 07 13, 21 06, 22 18, 23, 24, 25, 66 07, 21 04, 19, 24 30, 31, 32, 33, 34, 35 26, 27 03, 36 38 09 19, 24, 39, 40 04, 19, 21, 24, 41, 42 21
Troubleshooting Use this chart to help you solve daily operational problems. If there is any problem you cannot solve, contact your JVC’s service center. PROBLEM POSSIBLE CAUSE SOLUTION The display does not light up. The power cord is not plugged in. Plug the power cord into an AC outlet. (See page 15.) No sound from speakers. Speaker signal cables are not connected. Check speaker wiring and reconnect if necessary. (See pages 6 to 8.
PROBLEM “OVERLOAD” starts flashing on the display. POSSIBLE CAUSE SOLUTION Speakers are overloaded because of high volume. 1.Press STANDBY/ON on the front panel to turn off the receiver. 2.Stop the playback source. 3.Turn on the receiver again and adjust the volume. Speakers are overloaded because of short circuit of speaker terminals. Press STANDBY/ON on the front panel to turn off the receiver, then check the speaker wiring.
Specifications Amplifier Output Power: At Stereo operation: Front channels: 100 W* per channel, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic distortion. (IEC268-3/DIN) At Surround operation: Audio Audio Input Sensitivity/Impedance (1 kHz): Audio Input (DIGITAL IN)* : Front channels: 100 W* per channel, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic distortion. Center channel: 100 W*, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.
FM tuner (IHF) Tuning Range: 87.50 MHz to 108.00 MHz Usable Sensitivity: Monaural: 12.8 dBf (1.2 µV/75 Ω) 50 dB Quieting Sensitivity: Monaural: Stereo: 21.3 dBf (3.2 µV/75 Ω) 41.3 dBf (31.5 µV/75 Ω) Signal-to-Noise Ratio (IHF-A weighted): Monaural: Stereo: 78 dB at 85 dBf 73 dB at 85 dBf Total Harmonic Distortion: Monaural: Stereo: 0.4% at 1 kHz 0.6% at 1 kHz Stereo Separation at REC OUT: Alternate Channel Selectivity: Frequency Response: 35 dB at 1 kHz 45 dB: (±400 kHz) 30 Hz to 15 kHz: (+0.
Mains (AC) Line Instruction (not applicable for Europe, U.S.A., Canada, Australia and U.K.) 110V 220V 127V 230 - 240V VOLTAGE SELECTOR 110V 220V 127V 230 - 240V CAUTION for mains (AC) line BEFORE PLUGGING IN, do check that your mains (AC) line voltage corresponds with the position of the voltage selector switch provided on the outside of this equipment and, if different, reset the voltage selector switch, to prevent from a damage or risk of fire/ electric shock.
