10 Dual Fuel User Guide & Installation Instructions U108600-07 Australia
Contents 1. 2. 3. Before you Start...
1. Before You Start... Ventilation This User Guide covers a number of different models. Although some of the illustrations will look different to your particular model the functions will be the same. We hope the meaning is clear. CAUTION: The use of a gas cooking appliance results nn in the production of heat and moisture in the room in which it is installed. Make sure that the kitchen is well ventilated: keep natural ventilation holes open or install a powered cookerhood that vents outside.
DO NOT use water on grease fires and never pick nn up a flaming pan. Turn the controls off and then Cooking high moisture content foods can create a ‘steam burst’ when an oven door is opened. When opening the oven stand well back and allow any steam to disperse. smother a flaming pan on a surface unit by covering the pan completely with a well fitting lid or baking tray. If available, use a multi-purpose dry chemical or foam type fire extinguisher. Take care that no water seeps into the appliance.
2. Cooker Overview DocNo.020-0013 - Overview - 110DF - Classic, RM & Toledo lidded Fig.2-1 A O O O O O O B C E D F ArtNo.212-0002 - 110 Classic ceramic front view The 110 dual fuel cooker (Fig.2-1) has the following features: A. B. C. D. E. F. Fig.2-2 5 hotplate burners including a warmer and wok burner A control panel A grill Main conventional oven Fan oven Storage drawer Hotplate Burners The drawing by each of the central knobs indicates which burner that knob controls.
The igniter should spark and light the gas. Keep holding the knob pressed in to let the gas through to the burner for about ten seconds. Fig.2-3 If, when you let go of the control knob, the burner goes out, then the FSD has not been bypassed. Turn the control knob to the OFF position and wait for one minute before you try again, this time making sure to hold in the control knob for slightly longer. Adjust the flame height to suit by turning the knob clockwise (Fig.2-3).
The Wok Cradle Fig.2-9 The wok cradle is designed to fit a 35 cm wok. If you use a different wok, make sure that it fits the cradle. Woks vary very widely in size and shape. It is important that the wok sits down on the pan support – however, if the wok is too small, the cradle will not support it properly (Fig.2-9). The cradle should be used on the triple ring wok burner only.
Warmer Fig.2-15 On the right of the hob is the warmer (Fig.2-15). Use the warmer for keeping food warm while the final touches are put to a meal. Turn the control knob counter-clockwise to the ‘On’ position. For best results, preheat a covered serving dish for 10 minutes before adding food to it. Use only heat resistant dishes. The Grill CAUTION: This appliance is for cooking purposes nn only. It must not be used for other purposes, for example room heating. Fig.
The Ovens Fig.2-19 The clock must be set to the time of day before the ovens will work. See the following section on ‘The Clock’ for instructions on setting the time of day. References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed from the front of the appliance. ArtNo.210-0002 Classic oven 1 The left-hand oven is a conventional oven, while the righthand oven is a fan oven.
The Clock Fig.2-21 You can use the timer (Fig.2-21) to turn the ovens on and off. The clock must be set to the time of day before the ovens will work. Setting the Time of Day ArtNo.302-0002 - 6BC annotated A B C D E When the clock is first connected the display flashes ( 0.00 ) and ( ) alternately. F Press and hold both the [] and [] buttons down (Fig.2-22). Now press the [+] button (or the [–] button) until the correct time shows.
AUTO is Showing, You Want to Reset to Manual Cooking Fig.2-31 To return to manual cooking from any automatic setting, the ‘cook period’ must be cancelled. Press and hold the [] button and then press the [–] button until the display reads ( 0.00 ). Fig.2-32 ArtNo.302-0008 Activating the key lock 1 Press the [] button to return to manual cooking. ArtNo.302-0009 - Activating the key lock 2 Key Lock When the key lock is activated, the ovens are locked and will not come on. Fig.2-33 Fig.
Accessories Fig.2-36 Oven Shelves Shelf guard The oven shelves (Fig.2-36) can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by the shelf stop bumps in the oven sides (Fig.2-37). Front Lift up the front of the shelf so the back of the shelf will pass under the shelf stop and then pull the shelf forward (Fig.2-38). Fig.2-37 To refit the shelf, line up the shelf with a groove in the oven side and push the shelf back until the ends hit the shelf stop.
3. Cooking Tips Tips on Cooking with the Timer General Oven Tips If you want to cook more than one dish, choose dishes that require approximately the same cooking time. However, dishes can be ‘slowed down’ slightly by using small containers and covering them with aluminium foil, or ‘speeded up’ slightly by cooking smaller quantities or placing them in larger containers. The wire shelves should always be pushed firmly to the back of the oven.
4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. Food is cooked at lower temperature in a fan oven than in a conventional oven. When using recipes, reduce the fan oven temperature by 10 °C and the cooking time by 5-10 minutes.
5. Cleaning Your Cooker Isolate the electricity supply before carrying out any thorough cleaning. Allow the cooker to cool. Fig.5-1 A NEVER use paint solvents, washing soda, caustic nn cleaners, biological powders, bleach, chlorine based C bleach cleaners, coarse abrasives or salt. B DO NOT mix different cleaning products – they may nn react together with hazardous results. All parts of the cooker can be cleaned with hot soapy water – but take care that no surplus water seeps into the appliance.
Grill Fig.5-5 The grill pan and trivet should be washed in hot soapy water. Alternatively, the grill pan can be washed in a dishwasher. After grilling meats or any foods that soil, leave to soak for a few minutes immediately after use. Stubborn particles may be removed from the trivet using a nylon brush. Before you remove any of the grill parts for cleaning, nn make sure that they are cool, or use oven gloves. DO NOT use any abrasive substances. nn ArtNo.
Removing the Main Oven Linings Cleaning Table Some of the lining panels can be removed for cleaning. You will need to remove the shelves before removing the panels. Cleaners listed (Table 5-1) are available from supermarkets or electrical retailers as stated. Each side of the oven is fixed with four fixing screws. You do not have to remove the screws to remove the oven linings. Simply lift each side panel upwards and they will slide off the screws (Fig.5-6). Then pull them forwards.
6. Troubleshooting Hotplate ignition or hotplate burners faulty Is the power on? Is the clock illuminated? Power failure In the event of a failure in the electrical supply, remember to reset the clock to make sure that the timed oven continues to operate. If not, there maybe something wrong with the power supply. Food is cooking too slowly, too quickly, or burning Cooking times may differ from your previous oven.
An oven light is not working The bulb has probably burnt out. You can buy a replacement bulb (which is not covered under the warranty) from a good electrical shop. Ask for a 15 W – 230 V lamp, FOR OVENS. It must be a special bulb, heat resistant to 300 °C (Fig.6-1). Fig.6-1 ArtNo.324-0005 Oven light bulb Turn off the power at the circuit breaker. Before removing the existing bulb, turn off the power supply and make sure that the oven is cool. Open the oven door and remove the oven shelves. Fig.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. 7. Installation Service and Spares Firstly, please complete the appliance details below and keep them safe for future reference – this information will enable us to accurately identify the particular appliance and help us to help you. Filling this in now will save time and inconvenience if you later have a problem with the appliance. It may also be of benefit to keep your purchase receipt with this leaflet.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Dear Installer Provision of Ventilation Before you start your installation, please complete the details below, so that, if your customer has a problem relating to your installation, they will be able to contact you easily. This appliance is not connected to a combustion products evacuation device. Particular attention shall be given to the relevant requirements regarding ventilation.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Checking the Parts: You will need the following equipment to complete the cooker installation satisfactorily: • • • Flexible gas hose. Gas pressure tester/manometer. Multimeter: For electrical checks. 3 pan supports Griddle plate Wok cradle Grill pan & trivet You will also need the following tools: 1. Electric drill 2.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Positioning the Cooker Fig.7-1 The diagram (Fig.7-1) shows the minimum recommended distance from the cooker to nearby surfaces as given in AS 5601. 1. Overhead – Measurement A A The minimum height of any surface above the cooker is 650 mm above the hotplate. B D C E Cookerhoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Moving the Cooker Fig.7-3 On no account try and move the cooker while it is nn plugged into the electricity supply. The cooker is very heavy, so take great care. nn We recommend that two people manoeuvre the cooker. Make sure that the floor covering is firmly fixed, or removed, to prevent it being disturbed when moving the cooker around.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Fitting the Stability Bracket and Chain Fig.7-6 Stability bracket A stability bracket and chain MUST be fitted when the cooker is connected to a flexible gas supply. nn Unless properly installed, the cooker could be tipped by leaning on the door. Injury might result from spilled hot liquids or from the cooker itself.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Levelling Fig.7-9 You are recommended to use a spirit level on a shelf in one of the ovens to check for level. Place the cooker in its intended position taking care not to twist it within the gap between the kitchen units as damage may occur to the cooker or the units. ArtNo.215-0026 - Handle gaskets fixed The front feet and rear rollers can be adjusted to level the cooker.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Gas Connection 600 Must be in accordance with the relevant standards. Fig.7-12 350 The gas supply needs to terminate with a down-facing threaded fitting ½” connection. The inlet connector is located just below the hotplate level at the rear of the cooker. 100 250 Because the height of the cooker can be adjusted and each connection is different it is difficult to give precise dimensions.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Electrical Connection Fig.7-13 This appliance must be installed by a qualified electrician to comply with the relevant regulations (AS/NZS 60335.2.6) and also the local electricity supply company requirements. Make sure that the mains characteristics (voltage, nominal, power, etc.) match the ratings indicated on the cooker data plate. ArtNo.
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Final Checks Fig.7-17 Hotplate Check Check each burner in turn (refer to the ‘Hotplate Burners’ section at the front of the instructions). Grill Check Turn on the grill control and check that the grill heats up. Oven Check Set the clock as described earlier in the instructions, and then turn on the ovens. Check that the oven fan starts to turn and that the ovens start to heat up. ArtNo.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 8. Conversion to LP Gas Conversion from Natural Gas (1.0 kPa) to LPG X Propane (2.75 kPa) Fig.8-1 A suitably competent person must perform the nn conversion. After conversion the installation must comply with the relevant regulations and also the local electricity supply company requirements.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Set the Governor Fig.8-4 Unscrew the governor’s brass top. In the base of the brass top is a plastic snap-in converter device (Fig.8-4). To convert the governor, snap the device out of the top and refit it the other way round. The snap-in converter device is marked to show the gas for which it is set (Fig.8-5). ArtNo.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 9. Servicing BEFORE SERVICING ANY GAS CARRYING nn COMPONENTS TURN OFF THE GAS SUPPLY Fig.9-1 Check the appliance is gas sound after completion nn of service. When checking for gas leaks DO NOT use washing up liquid – this can corrode. Use a product specifically manufactured for leak detection.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 2.5 To Replace a Hotplate Burner Right-hand tray From the rear remove the screws securing the flue grill to the hotplate tray. If the left-hand hotplate has not been removed, slacken the screws holding the left-hand tray. Remove pan support, burner head, caps and trim rings. Remove the screws holding the wok burner to the hotplate.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 3.2 To Replace the Clock Fig.9-4 DISCONNECT FROM THE ELECTRICITY SUPPLY. Remove the control panel (see 1.1). Pull off the timer control buttons. Undo the timer fixing screws and remove the timer/ mounting bracket assembly from the control panel.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Remove the screws securing the electric cover to the back sheet, and then remove cover and disconnect the terminals from the rear. Fit the new elements and reassemble in the reverse order. Check the operation of the grill. 5 Fig.9-5 Ovens 5.1 To Replace a Thermostat DISCONNECT FROM THE ELECTRICITY SUPPLY.
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Fit the replacement control and re-assemble in the reverse order. Fig.9-6 5.5 To Remove the Right-hand Oven Element DISCONNECT FROM THE ELECTRICITY SUPPLY. Remove the oven inner back (see 5.2). Remove the two screws from the top of the element and the one from the bottom of the element (Fig.9-6).
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 6.2 To Replace an Oven Door Centreline of hinge pin Open the oven door. Support the door and loosen the two screws securing the upper hinge and gasket to the cooker front (Fig.9-9). Fig.9-11 The door is heavy, so take care. nn Support the door and remove the screw nearest the hinge pin (Fig.9-10).
10.
11. Technical Data DocAUS.101-0024 - Technical data - DF 110 - Classic-Toledo This cooker is designed for use on natural gas but can be used converted to LP (Propane X (2.54 kPa)). A conversion kit from Natural Gas to Propane is supplied with the cooker. INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening. COUNTRY OF DESTINATION: Australia.
Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457400 Fax: +44 (0) 1926 450526 E-mail: consumers@falconappliances.co.
