Cover[US].
Safty[US].fm Page 1 Friday, March 4, 2005 4:31 PM Warnings, Cautions and Others CAUTION— (STANDBY/ON) button! Disconnect the mains plug to shut the power off completely (all lamps and indications go off). The (STANDBY/ON) button in any position does not disconnect the mains line. • When the unit is on standby, the STANDBY/ON lamp lights in red. • When the unit is turned on, the STANDBY/ON lamp lights in green. The power can be remote controlled. CAUTION To reduce the risk of electrical shocks, fire, etc.
UX-GD6_US_TOC.fm Page 1 Tuesday, March 8, 2005 5:37 PM Introduction Precautions Contents Installation Connections ..............................................................3 Display Indicators....................................................6 Daily Operations—Playback ..................................7 Daily Operations—Sound & Other Adjustments .....12 • Install the System in a location with adequate ventilation to prevent internal heat buildup in the System.
UX-GD6[US].book Page 2 Tuesday, March 8, 2005 5:03 PM Playable Disc Types INFO COMPACT DIGITAL VIDEO SUPER VIDEO DIGITAL AUDIO • CD-R/RW: Recorded in the Audio CD, Video CD, SVCD, MP3, and JPEG formats. • DVD-R: Recorded in the DVD Video format. • DVD-RW/RAM: Recorded in the DVD Video Recording (VR) format. In addition to the above discs, this system can play back audio data recorded on CD Text, CD-G (CD Graphics), and CD-Extra.
UX-GD6[US].book Page 3 Tuesday, March 8, 2005 5:03 PM Connections Supplied accessories Do not connect the AC power cord until all other connections have been made. • Connect VIDEO OUT/COMPONENT directly to the video input of your TV. Connecting VIDEO OUT/COMPONENT to a TV via a VCR may interfere with your viewing when playing back a copy-protected disc. Your viewing may be interfered when connecting VIDEO OUT/COMPONENT to an integrated TV/VCR system.
UX-GD6[US].book Page 4 Tuesday, March 8, 2005 5:03 PM ~ AM/FM antenna Ÿ TV/monitor To assemble the AM loop antenna Connect the COMPONENT, S-VIDEO, or VIDEO jacks which you want to use. Red PR Blue PB Y NENT PO COM Green Component video cord (not supplied) To connect AM/FM antenna AM loop antenna (supplied) • To select progressive scanning mode (see page 13), use COMPONENT jacks.
UX-GD6[US].book Page 5 Tuesday, March 8, 2005 5:03 PM ! Digital audio component When connecting auxiliary equipment (AUX) Stereo mini plug PCM EAM Protective cap / STR CAL OPTI DVD TAL OUT DIGI (not supplied) Before plugging in the System • Set “DIGITAL AUDIO OUTPUT” in the “AUDIO” menu correctly according to the connected digital audio equipment (see page 35). If setting is incorrect, loud noise may be generated causing damage to the speakers.
UX-GD6[US].book Page 6 Tuesday, March 8, 2005 5:03 PM Display Indicators The indications on the display teach you a lot of things while you are operating the System. Before operating the System, be familiar with when and how the indicator illuminates on the display. 1 2 3 MONO ST MP3 PL PG 1 ALL RANDOM PROGRAM 3DPHONIC 7 8 9 5 6 SOUNDTURBO AHB PRO A.STANDBY 1 2 3 REC SLEEP REC B.S.P.
UX-GD6[US].book Page 7 Tuesday, March 8, 2005 5:03 PM Daily Operations—Playback 1 10 keys RETURN SET MENU/PL , , , ENTER TOP MENU/PG 2 FM/PLAY MODE 8 7 GROUP/TITLE SKIP 4/¢ 1/¡ 3 SHIFT In this manual, the operation using the remote control is mainly explained; however, you can use the buttons and controls on the main unit if they have the same (or similar) name and marks. 1 Turn on the power. The STANDBY/ON lamp on the main unit lights in green.
UX-GD6[US].book Page 8 Tuesday, March 8, 2005 5:03 PM Listening to the Radio To select the band (FM or AM) INFO Remote control: To set the AM tuner interval spacing Main Unit ONLY Main unit: FM/AM FM Before operating the tuner, it is required to select the appropriate AM space interval used for your area. FM 1 Select the AM band. AM AM AUX FM/AM To tune in to a station FM AM While FM or AM is selected... Remote control: Main unit: 2 sec. 2 Turn off the power. 2 sec.
Basic_US.fm Page 9 Wednesday, March 9, 2005 9:50 AM 2 Activate the preset number entry mode. CANCEL SET Playing Back a Tape INFO To insert a tape You can play back type I tapes. Push 3 Insert Close • Finish the following process while the indication on the display is flashing. Select a preset number for the station you store. DIMMER SLEEP A.STANDBY 1 2 3 VFP SCAN MODE 4 5 3D PHONIC 6 DVD LEVEL 8 7 PAGE 9 RETURN 10 10 Examples: To select preset number 5, press 5.
UX-GD6[US].book Page 10 Tuesday, March 8, 2005 5:03 PM Playing Back a Disc On-screen guide icons INFO Before operating a disc, be familiar how a disc is recorded. • DVD Video comprises of “Titles” which includes “Chapters,” DVD Audio/MP3/JPEG comprise of “Groups” which includes “Tracks,” and CD/SVCD/VCD comprise of only “Tracks.” • For MP3/JPEG playback, see also page 25. To insert a disc You can insert a disc while playing another source.
UX-GD6[US].book Page 11 Tuesday, March 8, 2005 5:03 PM To locate an item directly Remote ONLY You can select a title/chapter/track directly and start playback. • For DVD Video, you can select a title before starting playback, while you can select a chapter after starting playback. DIMMER SLEEP A.STANDBY 3 1 2 VFP SCAN MODE 4 5 3D PHONIC 6 DVD LEVEL 9 8 7 Examples: To select number 5, press 5. To select number 15, press +10, then 5. To select number 30, press +10, +10, then 10.
UX-GD6[US].book Page 12 Tuesday, March 8, 2005 5:03 PM Daily Operations—Sound & Other Adjustments Adjusting the Volume Remote control You can adjust the volume level from level 0 (VOL MIN) to level 40 (VOL MAX). Main unit: Remote control: SCAN MODE SLEEP DIMMER VFP 3D PHONIC A.
UX-GD6[US].book Page 13 Tuesday, March 8, 2005 5:03 PM To adjust the tone You can adjust the bass and treble level from –3 to +3. Remote ONLY Increase Level To adjust the bass BASS/ TREBLE Presetting Automatic DVD Video Sound BASS TRE Canceled VOLUME TV VOLUME To adjust the treble The DVD Video sound is sometimes recorded at a lower level than for other discs and sources.
UX-GD6[US].book Page 14 Tuesday, March 8, 2005 5:03 PM To adjust the picture tone Remote ONLY Changing the Display Brightness 1 Select “USER1” or “USER2.” You can dim the display window. 2 DIMMER DIM2 DIM1 1 • Follow steps 1 and 2 explained on the left column. Select a parameter you want to adjust. TV CH ENTER AUTO DIM DIM OFF (Canceled) TV CH (at the same time) DIM1 Dims the display. DIM2 Erases the display illumination.
UX-GD6[US].book Page 15 Tuesday, March 8, 2005 5:03 PM Setting the Clock Remote ONLY Turning Off the Power Automatically INFO Without setting the built-in clock, you cannot use Timers (see page 32) and Sleep Timer. • To correct a misentry during the process, press CANCEL (while holding SHIFT) or CLOCK/TIMER. You can return to the previous step. Remote ONLY Auto Standby A.STANDBY On Canceled 3 1 Activate the clock setting mode.
UX-GD6[US].book Page 16 Tuesday, March 8, 2005 5:03 PM Unique DVD/VCD Operations INFO For DVD Video: While playing back a chapter containing audio languages, you can select the language to listen to. For DVD Audio: While playing back a track containing audio channels, you can select the audio channel to listen to. For DVD-VR and Karaoke SVCD/VCD: When playing back a track, you can select the audio channel to play. • You can also select the audio track using the on-screen bar (see page 22).
UX-GD6[US].book Page 17 Tuesday, March 8, 2005 5:03 PM Remote ONLY Selecting the Subtitle Language For DVD Video: While playing back a chapter containing subtitles in different languages, you can select the subtitle language to display on the TV. For SVCD: While playing, you can select the subtitles even if no subtitles are recorded on the disc. • You can also select the subtitle language using the onscreen bar (see page 22).
UX-GD6[US].book Page 18 Tuesday, March 8, 2005 5:03 PM 2 Slow-motion playback Enter the key number. DIMMER SLEEP A.STANDBY 1 2 3 VFP SCAN MODE 4 5 3D PHONIC 7 1 ENTER Still picture playback starts. 6 DVD LEVEL 9 8 2 0 3 While playing... Follow the interactive instructions shown on the screen. Select slow motion speed. Forward slow motion starts. – SLOW + 1/32 To cancel the key number entry, press 7.
UX-GD6[US].book Page 19 Tuesday, March 8, 2005 5:03 PM Advanced Disc Operations Programming the Playing Order— Remote control Remote ONLY Program Play INFO You can arrange the playing order of the chapters or tracks (up to 99) before you start playback. • Program play cannot be used for DVD-VR/JPEG discs. 1 10 keys CANCEL Before starting playback, activate Program Play. REV.
UX-GD6[US].book Page 20 Tuesday, March 8, 2005 5:03 PM 3 Start playback. Playing at Random—Random Play Playback starts in the order you have programmed. DVD/CD You can play all chapters or tracks at random. • Random Play cannot be used for DVD-VR and some DVDs. 1 To skip a step: To pause: To stop: GROUP/TITLE SKIP Remote ONLY Before starting playback, activate Random Play. REV. MODE FM/PLAY MODE PROGRAM RANDOM Canceled To release, press DVD/CD 3.
UX-GD6[US].book Page 21 Tuesday, March 8, 2005 5:03 PM Playing Repeatedly Remote ONLY INFO • You can also select the repeat mode using the on-screen bar (see pages 23 and 24). • For JPEG/DVD-VR discs, see page 27. A-B Repeat You can repeat playback of a desired portion by specifying the beginning (point A) and the ending (point B). • A-B Repeat cannot be used for MP3 and for some DVDs. 1 Repeat Play While playing (without PBC for SVCD/VCD), select the start point (A). You can repeat playback.
UX-GD6[US].book Page 22 Tuesday, March 8, 2005 5:03 PM On-Screen Disc Operations On-screen Bar Information Remote control You can check the disc information (except for MP3/JPEG disc) and use some functions through the on-screen bar. 10 keys TOP MENU/PG , , , DVD/CD 3 8 ¡ 1 Disc type 2 Playback information MENU/PL ENTER Indication Dolby D 3/2.
UX-GD6[US].book Page 23 Tuesday, March 8, 2005 5:03 PM Remote ONLY Operations Using the On-screen Bar INFO Ex.: Selecting a subtitle (French) for DVD Video For detailed operations of the following functions, see also “Operations Using the On-screen Bar” on the left. While a disc is selected as the source... To change the time information 1 You can change the time information in the on-screen bar and the display window on the main unit. Display the entire on-screen bar.
UX-GD6[US].book Page 24 Tuesday, March 8, 2005 5:03 PM Time Search 4 Select the repeat mode you want. A-B Repeats a desired portion (see below). TITLE* Repeats the current title. GROUP Repeats the current group. ALL Repeats the disc (except for DVD) or program. CHAPTER** Repeats the current chapter. TRACK** Repeats the current track. OFF Cancels Repeat Play. You can move to a particular point by specifying the elapsed playing time from the beginning.
UX-GD6[US].book Page 25 Tuesday, March 8, 2005 5:03 PM 4 Enter the desired chapter/track number. DIMMER SLEEP A.STANDBY 3 1 2 VFP SCAN MODE 4 5 3D PHONIC 6 DVD LEVEL 8 7 9 0 Operations on the Control Examples: To select chapter/track 5, press 5. To select chapter/track 15, press 1, then 5. To select chapter/track 30, press 3, then 0. • To correct a misentry, press the 10 keys until the desired number shown in the pop-up window. 5 Finish the setting.
UX-GD6[US].book Page 26 Tuesday, March 8, 2005 5:03 PM Control screen for DVD-RW/RAM in DVD-VR format To move the highlight bar between group list and track list (for MP3/JPEG): The control screen is superimposed on the TV screen when you call up Program List (PG) or Play List (PL). Moves the bar to the track list. To select playback type To select the Play List: To select the Program List: MENU/PL ECHO TOP MENU/PG KARAOKE Moves the bar to the group list.
UX-GD6[US].book Page 27 Tuesday, March 8, 2005 5:03 PM To zoom in the still picture (for JPEG) • You cannot zoom in the still picture during slide-show. To select a group (for MP3/JPEG): GROUP/TITLE SKIP 1 While playing back a still picture... • During slide-show, press 8 to display the still picture, then... ZOOM ZOOM 1 (at the same time) To skip a track: ZOOM 2 ZOOM OFF To stop playback: GROUP/TITLE SKIP 2 Move the zoomed-in position.
UX-GD6[US].book Page 28 Tuesday, March 8, 2005 5:03 PM Advanced Tape Operations IMPORTANT It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. Remote control Recording on a Tape INFO You can use type I tapes for recording. • To play a tape, see page 9. 1 Insert a recordable cassette. Push TAPE 2 3 FM/AM /AUX DVD/CD 3 7 REV.
UX-GD6[US].book Page 29 Tuesday, March 8, 2005 5:03 PM 3 Select and start playing the source—“FM,” “AM,” “DVD/CD,” or “AUX.” • When recording a disc, you can also use “Synchronized Disc Recording” (see below). 4 Start recording. To record Program Play or Random Play 1 Select Program Play (and make a program) or Random Play, but do not start playback. 2 Press REC to start recording. • When disc play stops, recording stops automatically.
UX-GD6[US].book Page 30 Tuesday, March 8, 2005 5:03 PM Enjoying Karaoke IMPORTANT Always set MIC VOLUME to MIN when connecting or disconnecting the microphone. Remote control DO NOT keep the microphone connected while they are not in use. / Singing Along (Karaoke) INFO You can enjoy singing along (Karaoke) while playing a disc. KARAOKE ECHO TAPE 2 3 FM/AM /AUX DVD/CD 3 To sing along using the Karaoke discs You can enjoy Karaoke using the Karaoke disc (except Karaoke CD).
UX-GD6[US].book Page 31 Tuesday, March 8, 2005 5:03 PM To adjust the Key (disc playback only) 4 Activate Vocal Cancel. 1 Activate Key Control. TOP MENU/PG KARAOKE TOP MENU/PG KARAOKE KEYCON KEYCON OFF V-CANCEL (Canceled) OFF (Canceled) (at the same time) 2 Adjust the Key (at the same time) 5 Sing into the microphone. 6 Adjust the MIC VOLUME and VOLUME. VOLUME VOLUME To raise the key. To lower the key. (at the same time) • Key Control cannot be activated for DVD Audio/DVDVR.
UX-GD6[US].book Page 32 Tuesday, March 8, 2005 5:03 PM Timer Operations Setting the Timer Remote control AUDIO CANCEL SET , Remote ONLY INFO Using Daily Timer, you can wake up with your favorite song. On the other hand, with Recording Timer, you can make a tape of a radio broadcast automatically. • You can store three Daily Timer settings and one Recording Timer setting; however, you can activate only one of Daily Timers and Recording Timer at the same time.
UX-GD6[US].book Page 33 Tuesday, March 8, 2005 5:03 PM 5 Select the volume level. • You can select the volume level (“1” to “40” and “VOL – –”). If you select “VOL – –,” the volume is set to the last level when the unit has been turned off. Once settings are complete, the Timer setting information appears in sequence. For Recording Timer: 1 Set the hour then the minute for on-time. 2 Set the hour then the minute for off-time. 3 Select the playback source—“TUNER FM,” “TUNER AM,” or “AUX.
UX-GD6[US].book Page 34 Tuesday, March 8, 2005 5:03 PM Setup Menu Operations Initial settings Remote Control INFO Some items in the menus cannot be changed during playback. 10 keys 1 Press SET UP. LANGUAGE , , , SET UP MENU LANGUAGE ENGLISH AUDIO LANGUAGE ENGLISH SUBTITLE ENGLISH ON SCREEN LANGUAGE ENGLISH ENTER 2 3 4 5 Press (or )to select the menu. Press (or ) to move to select the item. Press ENTER. Press (or ) to select the options, then press ENTER.
UX-GD6[US].book Page 35 Tuesday, March 8, 2005 5:03 PM AUDIO menu Item DIGITAL AUDIO OUTPUT DOWN MIX D.RANGE COMPRESSION Contents Set this item correctly when using the DVD OPTICAL DIGITAL OUT terminal on the rear. PCM ONLY: When connecting to audio equipment which can decode only linear PCM signals. DOLBY DIGITAL/PCM: When connecting to a Dolby Digital decoder or an amplifier with a builtin Dolby Digital decoder. STREAM/PCM: When connecting to a DTS decoder or an amplifier with a built-in DTS decoder.
UX-GD6[US].book Page 36 Tuesday, March 8, 2005 5:03 PM Additional Information Learning More about This System Introduction (see pages 1 to 2) Playable Disc Types: • If you play back an NTSC disc with this setting set to “PAL,” you can watch the playback pictures (the disc will be reproduced using “PAL 60” format), but the TV screen may roll over upward and downward rapidly.
UX-GD6[US].book Page 37 Tuesday, March 8, 2005 5:03 PM Daily Operations—Sound & Other Adjustments On-Screen Disc Operations (see pages 22 to 27) (see pages 12 to 15) Adjusting the Sound: • This function also affects the sound through the headphones. Presetting Automatic DVD Video Sound Increase Level: • This also functions for DVD-VR formatted discs.
UX-GD6[US].book Page 38 Tuesday, March 8, 2005 5:03 PM Advanced Tape Operations (see pages 28 to 29) Timer Operations (see pages 32 to 33) Recording on a Tape: Setting the Timer: • The recording level is automatically set correctly. Thus, you can adjust the sound you are actually listening to without affecting the recording level. • There is leader tape which cannot be recorded onto at the start and end of cassette tapes.
UX-GD6[US].book Page 39 Tuesday, March 8, 2005 5:03 PM Maintenance To get the best performance of the System, keep your discs, tapes, and mechanism clean. Handling discs • Remove the disc from its case by holding it at the edge while pressing the center hole lightly. • Do not touch the shiny surface of the disc, or bend the disc. • Put the disc back in its case after use to prevent warping. • Be careful not to scratch the surface of the disc when placing it back in its case.
UX-GD6[US].book Page 40 Tuesday, March 8, 2005 5:03 PM Troubleshooting General: Adjustments or settings are suddenly canceled before you finish. ] There is a time limit. Repeat procedure again. Operations are disabled. ] The built-in microprocessor may malfunction due to external electrical interference. Unplug the AC power cord and then plug it back in. Unable to operate the System from the remote control. ] The path between the remote control and the remote sensor on the System is blocked.
UX-GD6[US].
UX-GD6[US].book Page 42 Tuesday, March 8, 2005 5:03 PM OPTICAL DIGITAL OUTPUT Signals DIGITAL AUDIO OUTPUT Playback disc DVD Video with 48 kHz, 16/20/24 bit Linear PCM with 96 kHz, Linear PCM with Dolby Digital with DTS DVD Audio*2 with 48/96/192 kHz, 16/20/24 bit Linear PCM with 44.1/88.2/176.
UX-GD6[US].
UX-GD6[US].book Page 44 Tuesday, March 8, 2005 5:03 PM Parts Index Remote control Button AUDIO TV 7 ¡/1 ¢/4 8 / ENTER (Clear Voice) (One-Touch Replay) 10 keys 3D PHONIC AHB PRO ANGLE AUDIO A.
M EM O .
Cover[US].fm Page 2 Friday, March 4, 2005 4:30 PM Mains (AC) Line Instruction (not applicable for Europe, U.S.A., Canada, Australia, and U.K.
