Filename [HM-HDS4EX_01Cov1.fm] HM-HDS4EX_01Cov1.
Filename [HM-HDS4EX_02Safety.fm] HM-HDS4EX.book Page 2 Wednesday, April 2, 2003 3:55 PM 2 EN Masterpage:Left-FullCol SAFETY FIRST Safety Precautions The rating plate and the safety caution are on the rear of the unit. WARNING: DANGEROUS VOLTAGE INSIDE WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. CAUTION 8 When you are not using the recorder for a long period of time, it is recommended that you disconnect the power cord from the mains outlet.
Filename [HM-HDS4EX_02Safety.fm] HM-HDS4EX.book Page 3 Wednesday, April 2, 2003 3:55 PM Masterpage:Right-Full-NoTitle0 EN 3 For Italy: “It is declared that this product, brand JVC, conforms to the Ministry Decree n. 548 of 28 Aug.’95 published in the Official Gazette of the Italian Republic n. 301 of 28 Dec.’95” The STANDBY/ON 1 button does not completely shut off mains power from the unit, but switches operating current on and off. “`” shows electrical power standby and “!” shows ON.
Filename [HM-HDS4EX_02Safety.fm] HM-HDS4EX_02Safety.fm Page 4 Monday, April 7, 2003 2:44 PM 4 EN Masterpage:Left-FullCol SAFETY FIRST (cont.) PRECAUTION FOR Hard Disk Drive 1. Before installing the recorder This recorder has a built-in hard disk drive, which is a device to read minute magnetic changes. The inside of the device is precision-built, which, when installing the recorder, requires you to note the following: ● DO NOT use the recorder in a location prone to vibration or dust.
Filename [HM-HDS4EXTOC.fm] Masterpage:Right HM-HDS4EXTOC.fm Page 5 Monday, April 7, 2003 3:47 PM EN CONTENTS SAFETY FIRST 2 Safety Precautions ............................................... 2 INDEX INSTALLING YOUR NEW RECORDER 6 12 Basic Connection .............................................. 12 S-VIDEO Connection ........................................ 13 INITIAL SETTINGS 14 Auto Set Up ....................................................... 14 Preset Download ...............................
Filename [HM-HDS4EX_03Names.fm] Masterpage:Left HM-HDS4EX.book Page 6 Wednesday, April 2, 2003 3:55 PM 6 EN INDEX FRONT VIEW LIVE NAVIGATION MODE S-VHS S-VHS / VHS REC HDD REC HDD PR-/+ PUSH / TURN S-VHS / HDD SAT DV IN / OUT A Eject x Button 墌 pg. 34 B Cassette Loading Slot C S-VHS mode Indicator 墌 pg. 34 D S-VHS/VHS Recording Mode Indicator (S-VHS/ VHS REC) 墌 pg. 34 E MODE Button 墌 pg. 9, 22 HDD Capacity Check Button 墌 pg. 9 F LIVE Button* 墌 pg.
Filename [HM-HDS4EX_03Names.fm] HM-HDS4EX.book Page 7 Wednesday, April 2, 2003 3:55 PM Masterpage:Right-index2 EN 7 REAR VIEW S VIDEO OUT SORTIE SAT CONTROL CONTROLEUR SAT A Mains Power Cord 墌 pg. 12 B Cooling Fan ●This prevents the temperature from rising inside the recorder. Do not remove it. ●Install the recorder so as not to block the area around the fan. ●The fan may be activated even if the recorder is turned off. F L-2 IN/DECODER Connector 墌 pg.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Left HM-HDS4EX_03Names.fm Page 8 Monday, April 7, 2003 2:46 PM 8 EN INDEX (cont.) ON-SCREEN DISPLAY (for HDD deck) When “O.S.D.” is set to “ON” (墌 pg. 84), various operational information appear on the TV screen. You can show or clear the following operational information by pressing . Each time you press , the information appears and disappears alternately.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_03Names.fm Page 9 Monday, April 7, 2003 2:46 PM EN 9 ON-SCREEN DISPLAY (for HDD deck) When “O.S.D.” is set to “ON” (墌 pg. 84), various operational information appear on the TV screen. When pressing MODE ( ) (Appears for eight seconds.) A HDD capacity graph (Six conditions (full, 60 hours or less open, 40 hours or less open, 20 hours or less open, 10 hours or less open, empty) is displayed in SEP mode.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Left HM-HDS4EX.book Page 10 Wednesday, April 2, 2003 3:55 PM 10 EN INDEX (cont.) ON-SCREEN DISPLAY (for VHS deck) When “O.S.D.” is set to “ON” (墌 pg. 84), various operational indicators appear on the TV screen. H Type of Broadcast 墌 pg. 44 I VHS Indicator J Current Day/Month/Year K Clock Display L Channel Position Number and Station Name/ Auxiliary Input Indicator (L-1, L-2 (or SAT*), F-1, D-1, or DUB) * When “L-2 SELECT” is set to “SAT” (墌 pg.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 11 Wednesday, April 2, 2003 3:55 PM EN REMOTE CONTROL · Q Resume 11 Button* 墌 pg. 95 * Press this button to return to the previous screen on the Navigation screen. When a confirmation message appears by pressing this button during timer programming or title editing, etc., follow the instruction to return to the previous screen. R LIVE Button* Auto Tracking Button 墌 pg.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Left HM-HDS4EX.book Page 12 Wednesday, April 2, 2003 3:55 PM 12 EN INSTALLING YOUR NEW RECORDER Basic Connection THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO OPERATION CAN BE PERFORMED. A Check the contents. Aerial connector Back of TV It’s essential that your video recorder be properly connected. TV aerial cable Make sure the package contains all of the accessories listed in “SPECIFICATIONS” on page 102. B Situate the recorder.
Filename [HM-HDS4EX_03Names.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 13 Wednesday, April 2, 2003 3:55 PM EN 13 8 To connect to a TV with S-VIDEO/AUDIO IN S-VIDEO Connection connectors . . . A Connect the recorder to TV. A Connect the aerial, recorder and TV as per “Basic Connection” (墌 pg. 12). B Connect the recorder’s S VIDEO OUT connector to the TV’s S-VIDEO IN connector. C Connect the recorder’s AUDIO OUT connectors to the TV’s AUDIO IN connectors. B Connect the recorder to mains.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 14 Wednesday, April 2, 2003 3:55 PM 14 EN INITIAL SETTINGS Auto Set Up Auto Channel Set/Auto Clock Set/ Auto Guide Program Number Set After the 1 button on the recorder or remote control is pressed for the first time to power on the recorder, by simply selecting your country*, the Auto Set Up function sets the tuner channels, clock** and Guide Program numbers automatically.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 15 Wednesday, April 2, 2003 3:55 PM EN C Select the language. Press OK. The Language Set display appears on the TV screen. Press rt to move the highlight bar (pointer) to the language of your choice. (Example) DEUTSCH is selected. DANSK SUOMI NORSK SVENSKA NEDERLANDS CASTELLANO ITALIANO FRANCAIS DEUTSCH ENGLISH D Perform Auto Set Up. Press OK.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 16 Wednesday, April 2, 2003 3:55 PM 16 EN INITIAL SETTINGS (cont.) Preset Download Auto Channel Set by Downloading from TV/Auto Clock Set/Auto Guide Program Number Set ATTENTION You can use this function only with a TV offering T-V Link, etc.* Be sure to use a fully-wired 21-pin SCART cable. * Compatible with TVs offering T-V Link, EasyLink, Megalogic, SMARTLINK, Q-Link or DATA LOGIC via fully-wired 21-pin SCART cable.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-Full-NoTitle0 HM-HDS4EX.book Page 17 Wednesday, April 2, 2003 3:55 PM EN 17 Results of Auto Set Up/Preset Download appear on the front display panel If both Auto Channel Set and Auto Clock Set have been performed successfully, the correct current time is displayed. Turn on the TV and select its AV mode, then make sure that all necessary stations have been stored in the recorder’s memory by using the VCR PR button(s). ● If station names (ID – 墌 pg.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 18 Wednesday, April 2, 2003 3:55 PM 18 EN INITIAL SETTINGS (cont.) Language ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. This recorder offers you the choice to view on-screen messages in 10 different languages. Though Auto Set Up selects the language automatically (墌 pg. 17), you can change the language setting manually as required. A Access the Main Menu screen. Press MENU.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right HM-HDS4EX.book Page 19 Wednesday, April 2, 2003 3:55 PM EN SAT CONTROL SET Satellite Receiver Control Setting Satellite receiver 19 The following procedure is required if you receive satellite channels through a satellite receiver. Approximately 20 seconds before the SHOWVIEW timer programming (墌 pg. 46) or Express timer programming (墌 pg.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 20 Wednesday, April 2, 2003 3:55 PM 20 EN SAT CONTROL SET (cont.) Setting satellite receiver’s brand and channel After installation, set the satellite receiver’s brand and channel correctly; otherwise, the Satellite Controller cannot work correctly. ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. C Access the Initial Set screen. A Press w e to move the arrow to “INITIAL SET UP”, then press t.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-2lineTitle0 HM-HDS4EX.book Page 21 Wednesday, April 2, 2003 3:55 PM SAT CONTROL SET (cont.) T-V LINK G Check the result of the test. If the satellite receiver’s channel number has been changed to the same one as you set in step F ... Press rt to move the highlight bar (pointer) to “CHANGED TO ...”, then press OK or e to finish the Sat Control Set mode. If the satellite receiver’s channel number has not been changed correctly ...
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 22 Wednesday, April 2, 2003 3:55 PM 22 EN RECORDING/PLAYBACK ON HDD DECK Basic Recording A Turn on the recorder. ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen. Press 1. ● The button corresponding to the previously selected deck lights on the recorder.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 23 Wednesday, April 2, 2003 3:55 PM EN Basic Playback ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen. 23 C Start playback. Press 4.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 24 Wednesday, April 2, 2003 3:55 PM 24 EN RECORDING/PLAYBACK ON HDD DECK (cont.) Playback with HDD Navigation The HDD Navigation enables you to search and select the desired programmes recorded on the HDD deck very easily. There is a 80 Gbyte hard disk drive on this recorder. You can record up to 100 programmes for the HDD deck.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 25 Wednesday, April 2, 2003 3:55 PM EN Scan for Beginning of Programme (or Play List) You can scan the beginning of the programme (or play list) easily with the HDD Navigation. For details of the play list, refer to “Play List Features” (墌 pg. 60). ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 26 Wednesday, April 2, 2003 3:55 PM 26 EN RECORDING/PLAYBACK ON HDD DECK (cont.) Playing Two or More Programmes (or Play Lists) Continuously in Desired Order You can select up to eight programmes (or play lists) for continuous programme play.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 27 Wednesday, April 2, 2003 3:55 PM EN Family Option Preset You can easily search for a desired programme (or play list) using this option. (“Sort Recorded Programmes (or Play Lists) by Category and Playback” (墌 pg. 26)) Before using this feature, it is recommended to disengage the unnecessary options using the following procedure to eliminate the labor of selection among many options.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 28 Wednesday, April 2, 2003 3:55 PM 28 EN RECORDING/PLAYBACK ON HDD DECK (cont.) Live Memory Features Equipped with a hard disk drive, this recorder allows information to be written to and read from the hard disk at high speeds. Taking advantage of this feature, you can temporarily record programmes received with the tuner or from an externally connected equipment, and can watch them only a few seconds behind actual air time.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 29 Wednesday, April 2, 2003 3:55 PM EN A Turn on the recorder. 29 Live Memory Recording Press 1. B Select the HDD deck. Press HDD. C Choose a programme. Press VCR PR +/– or the number keys to select the channel you wish to record. ● The temporary recording begins. D Locate the point to start playback from.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 30 Wednesday, April 2, 2003 3:55 PM 30 EN RECORDING/PLAYBACK ON HDD DECK (cont.) Playback Features Slow Motion 1 Pause during playback. Push the JOG dial. ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen. OR Press 9. 2 Activate slow motion playback.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 31 Wednesday, April 2, 2003 3:55 PM EN 31 Jump search Quick Rewind a little You can locate a scene ahead or behind the current one by jumping scenes according to selected time intervals (墌 pg. 81) during playback (or Live Memory Playback). This feature is also available during recording (or Live Memory Recording) or when watching a TV received programme. During playback (or Live Memory Playback), press .
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 32 Wednesday, April 2, 2003 3:55 PM 32 EN RECORDING/PLAYBACK ON HDD DECK (cont.) Repeat Playback Your recorder can automatically play back the desired programme(s) repeatedly. 1 Select the desired programme. Perform steps A to D of “Scan for Beginning of Programme (or Play List)” (墌 pg. 25) before continuing. 2 Start Repeat Playback. ? Press w e to move the arrow to “REPEAT”, then press OK.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_04Basic.fm Page 33 Monday, April 7, 2003 3:07 PM EN Recording Features ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen. 33 Instant Timer Recording (ITR) This easy method lets you record for from 30 minutes to 6 hours (selectable in 30-min.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 34 Wednesday, April 2, 2003 3:55 PM 34 EN RECORDING/PLAYBACK ON VHS DECK Basic Recording ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen. A Load a cassette. Insert a cassette with the record safety tab intact.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 35 Wednesday, April 2, 2003 3:55 PM EN 35 A Load a cassette. Basic Playback ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. ● If the recorder is turned on with HDD deck selected, there may be about 30 seconds’ delay in starting to show pictures on the screen.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 36 Wednesday, April 2, 2003 3:55 PM 36 EN RECORDING/PLAYBACK ON VHS DECK (cont.) Playback with VCR Navigation The VCR Navigation enables you to search and select the desired programmes recorded on the VHS deck very easily. When you record a programme with the VHS deck for more than 8 minutes in SP mode for more than 15 minutes in LP mode) with “NAVIGATION” set to “ON” (墌 pg.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 37 Wednesday, April 2, 2003 3:55 PM EN 37 A Turn on the recorder. Sort Recorded Programmes by Record Date/Cassette Number and Playback B Select the VHS deck. You can easily search for a desired programme in the Index screen by sorting according to the record date or cassette number registered during recording. Press 1. Press S-VHS. C Load the cassette. Insert a cassette with the record safety tab intact.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 38 Wednesday, April 2, 2003 3:55 PM 38 EN RECORDING/PLAYBACK ON VHS DECK (cont.) Sort Recorded Programmes by Title and Playback You can easily search for a desired programme in the Index screen by sorting according to the title registered at recording (or after recording). Perform steps A and B of “Scan for Beginning of Programme”(墌 pg. 37) before continuing.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 39 Wednesday, April 2, 2003 3:55 PM EN Playback Features 39 Slow Motion 1 Pause during playback. Push the JOG dial. OR Press 9. 2 Activate slow motion playback. Press and hold 5 or 3 for over 2 seconds. ● The playback speed changes for each direction by pressing 5 or 3 repeatedly. ● To resume normal playback, press 4.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 40 Wednesday, April 2, 2003 3:55 PM 40 EN RECORDING/PLAYBACK ON VHS DECK (cont.) Index Search Your recorder automatically marks index codes at the beginning of each recording. This function gives you quick access to any one of 9 index codes in either direction. NOTE: Before starting, make sure the recorder is in the Stop mode. Activate Index Search. Press w or e (2 or 6).
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 41 Wednesday, April 2, 2003 3:55 PM EN 41 Soundtrack Selection Your recorder is capable of recording three soundtracks (HI-FI L, HI-FI R and NORM) and will play back the one you select.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 42 Wednesday, April 2, 2003 3:55 PM 42 EN RECORDING/PLAYBACK ON VHS DECK (cont.) Recording Features Record One Programme While Watching Another Once recording is in progress, all you need to do is to set the channel controls on the TV for the station you wish to view. ● The programme selected with the TV’s channel controls appears on the TV screen, while the one selected with the recorder’s VCR PR buttons is recorded on the tape.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 43 Wednesday, April 2, 2003 3:55 PM EN 43 Elapsed Recording Time Indication 1 Set the counter display. Press – –:– – so that a counter reading appears on the TV screen and the front display panel. ● The front display panel shows the counter reading with “:” lit. 2 Reset the counter. Press 0000 before starting recording or playback. ? ● The counter is reset to “0:00:00” and shows the exact elapsed time as the tape runs.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Left HM-HDS4EX.book Page 44 Wednesday, April 2, 2003 3:55 PM 44 EN RECORDING/PLAYBACK ON VHS DECK (cont.) Receiving Stereo and Bilingual Programmes Your recorder is equipped with a Sound-Multiplex decoder (A2) and a Digital stereo sound decoder (NICAM) making reception of stereo and bilingual broadcasts possible. When the channel is changed, the type of broadcast being received will be displayed on the TV screen for a few seconds.
Filename [HM-HDS4EX_04Basic.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 45 Wednesday, April 2, 2003 3:55 PM EN B.E.S.T. Picture System The B.E.S.T. (Biconditional Equalised Signal Tracking) system checks the condition of the tape in use during playback and recording, and compensates to provide the highest-possible playback and recording pictures. You can set “B.E.S.T.” to “ON” or “OFF” to your preference (墌 pg. 83). Playback The recorder assesses the quality of the tape once you initiate playback.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX_05Timer.fm Page 46 Monday, April 7, 2003 2:48 PM 46 EN TIMER RECORDING SHOWVIEW Timer Programming ® You can programme this recorder to timer-record as many as 16 programmes. With the SHOWVIEW system, timer programming is greatly simplified because each TV programme has a corresponding code number which your recorder is able to recognize.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 47 Wednesday, April 2, 2003 3:55 PM EN H Set the VPS/PDC mode. A Press r t to move the arrow to “VPS/PDC”. B Press VPS/PDC to select “ON” or “OFF”. OR A Press r t to move the arrow to “VPS/PDC”, then press OK. B Press r t to select the desired setting, then press OK. ● If “VPS/PDC ON” is displayed on the TV screen, VPS/PDC is set to ON. ● If “VPS/PDC OFF” is displayed on the TV screen, VPS/PDC is set to OFF.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 48 Wednesday, April 2, 2003 3:55 PM 48 EN TIMER RECORDING (cont.) Express Timer Programming You can programme this recorder to timer-record as many as 16 programmes. If you do not know the SHOWVIEW number for the programme you wish to record, use the following procedure to set your recorder to timer-record the programme. Before performing Express Timer Programming: ● Make sure that the recorder’s built-in clock is set properly.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 49 Wednesday, April 2, 2003 3:55 PM EN I Set the VPS/PDC mode. A Press r t to move the arrow to “VPS/PDC”. B Press VPS/PDC to select “ON” or “OFF”. OR A Press r t to move the arrow to “VPS/PDC”, then press OK. B Press r t to select the desired setting, then press OK. ● If “VPS/PDC ON” is displayed on the TV screen, VPS/PDC is set to ON. ● If “VPS/PDC OFF” is displayed on the TV screen, VPS/PDC is set to OFF.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 50 Wednesday, April 2, 2003 3:55 PM 50 EN TIMER RECORDING (cont.) To cancel or change a programme... D Cancel or change a programme. To cancel the programme, press w r e t to move the arrow to “CANCEL“, then press OK. To change programme settings, perform steps D to K of “Express Timer Programming”. (墌 pg. 48) ? E Return to the normal screen. Press w r e t to move the arrow to “EXIT”, then press OK. F Return to the timer mode.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 51 Wednesday, April 2, 2003 3:55 PM EN Automatic Satellite Programme Recording NOTE: This function is available for the HDD deck only. This function allows you to automatically record a satellite programme which is timer-programmed on your external satellite receiver. Connect a satellite receiver to the recorder’s L-2 IN/DECODER connector and programme the timer on the satellite receiver.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 52 Wednesday, April 2, 2003 3:55 PM 52 EN REMOTE CONTROL FUNCTIONS Remote A/B/C/D Code Switching On the remote control The remote control is capable of controlling four JVC video recorders independently. Each of recorders can respond to one of four codes (A, B, C or D). The remote control is preset to send A code signals because your video recorder is initially set to respond to A code signals.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 53 Wednesday, April 2, 2003 3:55 PM EN TV Multi-Brand Remote Control Your remote control can operate the basic functions of your TV set. In addition to JVC TVs, other manufacturer’s TVs can also be controlled. Before performing the following steps: Turn off the TV using its remote control. 53 A Set the TV brand code. Slide TV/CABLE/SAT to the left and keep S-VHS pressed during this step.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 54 Wednesday, April 2, 2003 3:55 PM 54 EN REMOTE CONTROL FUNCTIONS (cont.) Satellite Receiver Multi-Brand Remote Control Your remote control can operate the basic functions of your satellite receiver set. In addition to JVC satellite receivers, other manufacturer’s satellite receivers can also be controlled. Before performing the following steps: Turn off the satellite receiver using its remote control.
Filename [HM-HDS4EX_05Timer.fm] HM-HDS4EX.book Page 55 Wednesday, April 2, 2003 3:55 PM EDITING About Hybrid Navigation Masterpage:Right EN 55 About editing of programmes Navigation system has six functions for editing of programmes. In the sections “Playback with HDD Navigation” (墌 pg. 24) and “Playback with VCR Navigation” (墌 pg. 36), it is briefly described how to search for the beginning of each recorded programme using the Navigation functions.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 56 Wednesday, April 2, 2003 3:55 PM 56 EN Modify Information NOTE: The Navigation systems cannot work during recording on the HDD deck or in SAT# mode (墌 pg. 51). EDITING (cont.) C Access the Navigation screen. Press EDIT. ● The Navigation screen corresponding to the selected deck appears. ● For the VHS deck: When “NAVIGATION” is set to “OFF” (墌 pg. 81), the Navigation screen does not appear. D Select the programme.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 57 Wednesday, April 2, 2003 3:55 PM EN Modify Category Perform steps A to D of “Modify Index” (墌 pg. 56) before continuing. 57 C Register new title. Press w r e t to move the arrow to “SAVE“, then press OK. A Access the modify screen. D Return to the normal screen. B Select new category. Modify Cassette Title (available only for VHS Navigation) Press w e to move the arrow to “CATEGORY”, then press OK.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 58 Wednesday, April 2, 2003 3:55 PM 58 EN Delete Programme Information For HDD Navigation: When you delete the registered information of a programme, the recorder delete the programme itself on the hard disk drive. The deleted programme is never resumed. For VCR Navigation: When you delete the registered information of a programme, the recorder delete only the information on the hard disk drive.
Filename [HM-HDS4EX_05Timer.fm] HM-HDS4EX.book Page 59 Wednesday, April 2, 2003 3:55 PM Masterpage:Right-NoTitle0 EN 59 B Locate the divide point. A Confirm the arrow is on “DIVIDE”. Playback starts in the left large window. B Press the appropriate buttons (4, 9, 5, or 3) to search for the divide point. You can also search for the divide point by turning and pressing the JOG dial. C Press OK at the divide point.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 60 Wednesday, April 2, 2003 3:55 PM 60 EN EDITING (cont.) Play List Features A play list is a collection of the scenes selected from original recorded programmes. A play list can be freely edited and played back without ever changing any original recorded data. A play list includes information such as the beginning and ending time of the scenes, indexes for checking the contents of the recorded data, category information, and more.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 61 Wednesday, April 2, 2003 3:55 PM EN 61 G Confirm the play list. D Change the beginning or ending time. ● Playback of current play list starts in the left large window. ● To cancel the change, press w r e t to move the arrow to “RETRY”, then press OK. H Register the selected scenes. E Register the modified play list. Press w r e t to move the arrow to “PREVIEW”, then press OK. Perform step E of “Create Play List”.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 62 Wednesday, April 2, 2003 3:55 PM 62 EN Delete scenes Perform steps A to C of “Create Play List” (墌 pg. 60), then steps A and B of “Edit Scenes” (墌 pg. 61) before continuing. A Delete the scene. A Press w r e t to move the arrow to “DELETE”, then press OK. B Press r t to move the arrow to the desired scene to be deleted in the scene list, then press OK.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 63 Wednesday, April 2, 2003 3:55 PM EN 63 Easy Dubbing from HDD deck to VHS deck Dubbing Because this recorder includes both HDD deck and VHS deck, you can easily use it for dubbing up to eight programmes (or play lists) without connecting any other equipment. A Access the HDD Navigation screen. Slide TV/CABLE/SAT to the right, then press HDD, then press EDIT. B Access the Easy Dubbing screen.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 64 Wednesday, April 2, 2003 3:55 PM 64 EN EDITING (cont.) D Select the VHS deck. Press S-VHS. E Load a cassette. Insert a cassette with the record safety tab intact. · · ? F Set the recording speed. Press MODE. G Locate the start point. A Search for the point where you want to start dubbing by pressing 4, 5 or 3 then press 8. B Press 7 and 9 simultaneously to enter the RecordPause mode. H Select the HDD deck. Press HDD.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 65 Wednesday, April 2, 2003 3:55 PM EN Normal Dubbing (from HDD to VHS) 65 You can dub selected scenes from the HDD deck to a cassette, starting and stopping wherever you wish. A Load a cassette. Insert a cassette with the record safety tab intact. B Prepare the HDD deck for dubbing. A Slide TV/CABLE/SAT to the right, then press HDD and select the programme to be dubbed. You can select the programme by HDD Navigation.
Filename [HM-HDS4EX_05Timer.fm] Masterpage:Left HM-HDS4EX.book Page 66 Wednesday, April 2, 2003 3:55 PM 66 EN EDITING (cont.) Normal Dubbing (from VHS to HDD) You can dub selected scenes from a cassette to the HDD deck, starting and stopping wherever you wish. A Load a cassette. Insert a cassette with the record safety tab intact. B Prepare the VHS deck for dubbing. A Slide TV/CABLE/SAT to the right, then press S-VHS and select the programme to be dubbed.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 67 Wednesday, April 2, 2003 3:55 PM EN Edit From A Camcorder A Recorder VIDEO input AUDIO input Audio cable (not provided) Video cable (not provided) Camcorder VIDEO OUT AUDIO OUT 67 You can use a camcorder as the source player and your recorder as the recording deck. A Make connections. A If the camcorder has no S-VIDEO output connector ... ...
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 68 Wednesday, April 2, 2003 3:55 PM 68 EN EDITING (cont.) Output/Input Set B Access the Input/Output Set screen. A Press w e to move the arrow to “FUNCTION SET UP”, then press t. B Press w e to move the arrow to “INPUT/ OUTPUT”. the output or input mode for the L-1 C Select IN/OUT connector. ? A Press rt to move the arrow to “L-1 OUTPUT” or “L-1 INPUT”, then press OK. B Press rt to select the appropriate setting, then press OK.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 69 Wednesday, April 2, 2003 3:55 PM EN L-2 SELECT and L-2 INPUT Setting Set “L-2 SELECT” and “L-2 INPUT” to the appropriate mode depending on the type of appliance connected to the recorder’s L-2 IN/DECODER connector. Perform steps A and B of “L-1 OUTPUT and L-1 INPUT Setting” on page 68. the input mode for the L-2 IN/ A Select DECODER connector. A Press rt to move the arrow to “L-2 SELECT”, then press OK.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 70 Wednesday, April 2, 2003 3:55 PM 70 EN EDITING (cont.) Edit To Or From Another Video Recorder ? You can use your recorder as the source player or as the recording deck. A Make connections. Connect the player’s 21-pin SCART connector to the recorder’s 21-pin SCART connector as illustrated on page 71. A When using your recorder as the source player ... ... connect its L-1 IN/OUT connector to the recording deck.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 72 Wednesday, April 2, 2003 3:55 PM 72 EN EDITING (cont.) DV Dubbing You can dub programmes from a camcorder or DV equipment connected to the recorder with a DV cable. The recorder’s remote control allows you the limited control of the connected camcorder or DV equipment functions during dubbing. NOTE: When you use a PC connecting to the DV IN/OUT connector, we do not assure the normal operation of this recorder.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_06Edit.fm Page 73 Thursday, April 17, 2003 12:18 PM EN A Make connections. Connect the camcorder to the DV IN/OUT connector on the recorder’s front panel. B Select the HDD deck. F End dubbing. Press w e to move the arrow to OK. 73 , then press When you dab form DV equipment other than a camcorder Slide TV/CABLE/SAT to the right, then press HDD. C Prepare the HDD deck for dubbing. A Perform step A to C.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 74 Wednesday, April 2, 2003 3:55 PM 74 EN EDITING (cont.) Audio Dubbing Audio Dubbing replaces the sound of a recorded programme in the recording speed of “DV” on the HDD deck with the sound played back from external audio equipment. ATTENTION: Audio dubbing is only possible for the programme having the recording speed of “DV” (12BIT) on the HDD deck. ? Your recorder CD player, etc. CD player, etc.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_06Edit.fm Page 75 Thursday, April 17, 2003 12:43 PM EN A Make connections. Connect an audio component to the AUDIO L + R input connectors on the recorder’s front panel. ● When connecting a monaural audio component, use only the recorder’s AUDIO L input connector. B Select the HDD deck. Slide TV/CABLE/SAT to the right, then press HDD. the audio track to monitor the C Select recorded programme’s original sound.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 76 Wednesday, April 2, 2003 3:55 PM 76 EN SYSTEM CONNECTIONS Connecting To A Satellite Receiver Simple Connections NOTES: This is an example of simple connection if your TV has one 21-pin AV input (SCART) connector. Connect the satellite receiver to the L-2 IN/DECODER connector, then connect the L-1 IN/OUT connector to the TV’s connector.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 77 Wednesday, April 2, 2003 3:55 PM EN Perfect Connections NOTES: ● Set “L-2 SELECT” to “A/V” (墌 pg. 69). ● You can use Automatic Satellite Programme Recording function (墌 pg. 51) with this connection. ● To record a programme via the satellite receiver, select L-2 mode by pressing AUX (number key “0”) and/or VCR PR so that “L-2” appears on the front display panel.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Left HM-HDS4EX.book Page 78 Wednesday, April 2, 2003 3:55 PM 78 EN SYSTEM CONNECTIONS (cont.) Connecting/Using A Decoder The L-2 IN/DECODER connector can be used as an input connector for an external decoder (descrambler). Simply connect a decoder and you can enjoy the variety of programming that is available through scrambled channels. A Select the input mode. Set “L-2 SELECT” to “DECODER”. (墌 pg. 69) TV receiver B Connect the decoder.
Filename [HM-HDS4EX_06Edit.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 79 Wednesday, April 2, 2003 3:55 PM EN 79 Connecting/Using A Stereo System These instructions enable you to connect your video recorder to your Hi-Fi stereo system (if you have one) and listen to the soundtrack through the stereo.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 80 Wednesday, April 2, 2003 3:55 PM 80 EN SUBSIDIARY SETTINGS Mode Set ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. You can change various mode settings on the TV screen by following the procedure described below. The table below shows the structure of the menu system. HDD/VCR SET UP HDD SET UP 1 (墌 pg. 81) HDD SET UP 2 (墌 pg. 81) VCR SET UP 1 (墌 pg. 81) VCR SET UP 2 (墌 pg.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-Full-NoTitle0 HM-HDS4EX.book Page 81 Wednesday, April 2, 2003 3:55 PM EN HDD SET UP 1 8 LIVE MEMORY OFF 30MIN 1HR 3HR 8 AUDIO REC NICAM MONO 81 * The default setting is bold in the table below. When this function is set to “30MIN”, “1HR” or “3HR”, hard disk drive illumination lights blue and you can apply the selected time length to the “Live Memory Features” (墌 pg. 28). When this function is set to “NICAM”, the NICAM audio programmes will be recorded.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left-FullCol HM-HDS4EX.book Page 82 Wednesday, April 2, 2003 3:55 PM 82 EN SUBSIDIARY SETTINGS (cont.) VCR SET UP 1 (cont.) 8 S-VHS ET ON OFF * The default setting is bold in the table below. You can record in SP mode on VHS cassettes with S-VHS picture quality. Tapes recorded using this function can be played back on a recorder equipped with the S-VHS ET function. When this function is set to “ON”, the S-VHS indicator lights up on the front display panel.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-Full-NoTitle0 HM-HDS4EX.book Page 83 Wednesday, April 2, 2003 3:55 PM EN 8 AUTO SP]LP TIMER ON OFF 83 When this function is set to “ON”, the recorder automatically switches to LP mode to allow complete recording if there is not enough tape to record the entire programme while timer-recording in SP mode. For Example . . .
Filename [HM-HDS4EX_07Sub.fm] HM-HDS4EX.book Page 84 Wednesday, April 2, 2003 3:55 PM 84 EN 8 COLOUR SYSTEM PAL/NTSC MESECAM Masterpage:Left-FullCol SUBSIDIARY SETTINGS (cont.) You can play back PAL, NTSC and MESECAM tapes, or record PAL and SECAM* signals on this recorder. Select the appropriate colour system. PAL/NTSC: To record PAL signals, or play back a PAL or NTSC tape. MESECAM: To record SECAM signals, or play back a MESECAM tape.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 85 Wednesday, April 2, 2003 3:55 PM EN 85 SHOWVIEW System Setup ® IMPORTANT Normally, Auto Set Up (墌 pg. 14), Preset Download (墌 pg. 16) or Auto Channel Set (墌 pg. 88) sets the Guide Program numbers automatically. You need to set the Guide Program numbers manually only in the following cases.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 86 Wednesday, April 2, 2003 3:55 PM 86 EN SUBSIDIARY SETTINGS (cont.) Clock Set ● Turn on the TV and select the AV mode. ● Slide TV/CABLE/SAT switch to the right. IMPORTANT If you performed Auto Set Up (墌 pg. 14) or Preset Download (墌 pg. 16), without ever having set the clock previously, the recorder’s built-in clock is also set automatically.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 87 Wednesday, April 2, 2003 3:55 PM EN E Set the date and time. Press rt to set the time, then press OK or e. The “DATE” display begins blinking. Repeat the same procedure to set the date and year. ● When you set the time, press and hold rt to change the time by 30 minutes. ● When you set the date, press and hold rt to change the date by 15 days. F Set Just Clock. The default setting is “OFF”.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 88 Wednesday, April 2, 2003 3:55 PM 88 EN SUBSIDIARY SETTINGS (cont.) Tuner Set Turn on the TV and select the AV mode. IMPORTANT Perform the following steps only if — — Auto Channel Set has not been set correctly by Auto Set Up or by Preset Download (墌 pg. 14, 16). — you have moved to a different area or if a new station starts broadcasting in your area.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 89 Wednesday, April 2, 2003 3:55 PM EN G Perform Auto Channel Set. Press OK twice. ● When you have connected the video recorder to a TV offering T-V Link via a fullywired 21-pin SCART cable (墌 pg. 12), the recorder automatically performs the Preset Download and the T-V LINK screen will appear (墌 pg. 16). ● The Auto Set screen appears, Beginning End and remains on screen while the recorder searches for receivable stations.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 90 Wednesday, April 2, 2003 3:55 PM 90 EN SUBSIDIARY SETTINGS (cont.) Manual Channel Set Store channels that were not stored during Auto Set Up (墌 pg. 14), Preset Download (墌 pg. 16) or Auto Channel Set (墌 pg. 88). A Access the Main Menu screen. Press MENU. ? B Access the Tuner Set screen. A Press w e to move the arrow to “INITIAL SET UP”, then press t. B Press w e to move the arrow to “TUNER SET”, then press OK.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_07Sub.fm Page 91 Monday, April 7, 2003 2:55 PM EN 91 F Input the channel. Change Station Channel Position ● Input “0” before any single number entries. ● To input the registered station name (ID – 墌 pg. 94), press e until “– – – –” (ID setting) begins blinking, then press rt. ● For fine tuning adjustment, press e until “+/–” begins blinking, then press rt. While tuning, “+” or “–” appears.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 92 Wednesday, April 2, 2003 3:55 PM 92 EN SUBSIDIARY SETTINGS (cont.) Set Stations (A) Set Stations (B) Set station names that are registered in your recorder. Set station names other than the ones registered in your recorder. Perform steps A and C of “Manual Channel Set” on page 90 to access the Confirmation screen before continuing. A Select the item. Press w r e t until the item you want begins blinking.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX.book Page 93 Wednesday, April 2, 2003 3:55 PM EN Fine-Tuning Channels Already Stored Perform steps A and C of “Manual Channel Set” on page 90 to access the Confirmation screen before continuing. A Select the channel to fine-tune. Press w r e t until the channel you want to tune begins blinking. B Access the Manual Channel Set screen. Press OK twice. The Manual Channel Set screen appears. C Perform tuning.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 94 Wednesday, April 2, 2003 3:55 PM 94 EN SUBSIDIARY SETTINGS (cont.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right HM-HDS4EX.book Page 95 Wednesday, April 2, 2003 3:55 PM EN HELP 95 A Access the Help screen. Help Function Press ?. Use this function if you encounter problems while operating this recorder. ● An INDEX screen that contains the most common needed topics (headings) relating to the current status appears. Topics with the icon refer to HDD deck operations and with the icon refer to those for the VHS deck. B Browse the INDEX and read the help page.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 96 Wednesday, April 2, 2003 3:55 PM 96 EN TROUBLESHOOTING Before requesting service for a problem, use this chart and see if you can repair the trouble yourself. Small problems are often easily corrected, and this can save you the trouble of sending your video recorder off for repair. POWER SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 1. No power is supplied to the recorder. ● The mains power cord is disconnected.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right-NoTitle0 HM-HDS4EX_07Sub.fm Page 97 Monday, April 7, 2003 2:58 PM EN SYMPTOM 3. Tape-to-tape editing is not possible. 4. Camcorder recording is not possible. 5. “䡬” and “$” on the front display panel won’t stop blinking. POSSIBLE CAUSE 97 CORRECTIVE ACTION ● The source (another video recorder, camcorder) has not been properly connected. Confirm that the source is properly connected. ● All necessary power switches have not been turned on.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX_07Sub.fm Page 98 Monday, April 7, 2003 2:58 PM 98 EN TROUBLESHOOTING (cont.) TIMER RECORDING (cont.) SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION 5. “#” blinks for 10 seconds and the Timer mode is disengaged. ● # has been pressed when there are no programs in memory. Check the programmed data and reprogram as necessary, then press # again. 6. The SHOWVIEW system does not timer-record properly.
Filename [HM-HDS4EX_07Sub.fm] HM-HDS4EX.book Page 99 Wednesday, April 2, 2003 3:55 PM Masterpage:Right-Full-NoTitle0 EN 99 ON-SCREEN MESSAGES MESSAGE DESCRIPTION CAN NOT MODIFY LIVE MEMORY TIME, MORE CAPACITY NEEDED DELETE UNWANTED PROGRAMME THEN RETRY There is not enough memory on the hard disk drive for Live Memory Playback. To increase the free space, dub some programmes to cassettes or delete the unwanted programmmes. (墌 pg.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 100 Wednesday, April 2, 2003 3:55 PM 100 EN TROUBLESHOOTING (cont.) ON-SCREEN MESSAGES (cont.) MESSAGE DESCRIPTION PROGRAMME NOT COMPLETED PROGRAMME OVERLAPPED PLEASE CONFIRM AND MODIFY The timer programme you set is overlapping with another timer programme. (墌 pg. 50) TIMER PROGRAMMING STOPPED Appears when you stop setting timer programme.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Right HM-HDS4EX.book Page 101 Wednesday, April 2, 2003 3:55 PM EN QUESTIONS AND ANSWERS 101 PLAYBACK TIMER RECORDING Q. What happens if the end of the tape is reached during playback or search? A. The tape is automatically rewound to the beginning. Q. “䡬“ and “#” remain lit on the front display panel. Is there a problem? A. No. This is a normal condition for a timer recording in progress. Q.
Filename [HM-HDS4EX_07Sub.fm] Masterpage:Left HM-HDS4EX.book Page 102 Wednesday, April 2, 2003 3:55 PM 102 EN SPECIFICATIONS GENERAL TUNER/TIMER Power requirement : AC 220 V – 240 Vd, 50 Hz/60 Hz Power consumption Power on : 42 W Power off : 12 W Temperature Operating : 5°C to 40°C Storage : –20°C to 60°C Operating position : Horizontal only Dimensions (WxHxD) : 435 mm x 98 mm x 357 mm Weight : 5.
Filename [HM-HDS4EX_08IX.fm] Masterpage:Right HM-HDS4EX_08IX.fm Page 103 Monday, April 7, 2003 3:47 PM EN LIST OF TERMS 103 A O Audio Dubbing ...................................................... 74 Auto Channel Set .................................................... 88 Auto Set Up .......................................................... 14 AUTO SP]LP TIMER .............................................. 83 AUTO TIMER ........................................................
