Supplement This equipment is in conformity with the provisions and protection requirements of the corresponding European Directives.
SAFETY PRECAUTIONS Warning Notice FOR YOUR SAFETY (Australia) 1. Insert this plug only into effectively earthed three-pin power outlet. 2. If any doubt exists regarding the earthing, consult a qualified electrician. 3. Extension cord, if used, must be three-core correctly wired.
Thank you for purchasing our DV Video Cassette Recorder BR-DV3000. As this is a DV-format video cassette recorder, video cassettes with the or logos can be used with it. DVCAM cassettes can be recorded in DV format. This VTR features dual support for NTSC and PAL. Certain functions however, are supported by only one signal system. They are indicated with (NTSC only) or (PAL only).
TABLE OF CONTENTS INTRODUCTION Precautions .................................................... 6 Daily maintenance and regular inspection ..... 7 Precautions on the use of cleaning tape ........ 8 Cassette tape ................................................. 8 Condensation ................................................. 9 NAMES AND FUNCTIONS OF VARIOUS PARTS Front panel ................................................... 10 Rear panel ....................................................
INTRODUCTION Precautions Place of storage and use Please avoid storing or using this VTR in the following places: ● Extremely hot or cold places beyond the allowable temperature for operation (5˚C – 40˚C). ● Humid or dry places beyond the allowable humidity range for operation (30% –80% RH). ● Dusty or sandy places. ● Places exposed to oil, smoke or steam, such as the kitchen vicinity. ● Intensely vibrating or unstable places. ● Places prone to condensation.
Daily maintenance and regular inspection This unit uses consumables or components that will wear off. If a worn-out or deteriorated component continues to be used, it may cause the unit to break down. To prevent this, please perform daily maintenance using the head-cleaning tape. With the head-cleaning tape alone, however, the entire tape-winding mechanism cannot be completely cleaned. Please perform regular maintenance of the components as shown below.
INTRODUCTION Precautions on the use of cleaning tape Please use cleaning tape produced by JVC. Please follow the instructions below when using the cleaning tape. 1. The tape will run for 10 seconds in the PLAY mode. (Thereafter, it stops automatically and enters the STOP mode.) • After loading the cleaning tape, press the PLAY button. 2. For a single cleaning session, use it up to 4 times. 3. Please refer to the following table as a guide for cleaning. Memo: 1.
For recording and storing videotapes in the best condition Observe the following instructions for the best recording and storage of videotapes. ● Take care of the conditions of handling videotapes. It is recommended that you record and store videotapes in the environment below.
NAMES AND FUNCTIONS OF VARIOUS PARTS – Front panel – 2 OPERATE EJECT 1 MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV SET CH-2/4 Y/C FF BR-DV3000 4 3 1 [OPERATE] Operate button/LED ● Press this button to turn on the power and operate the unit. (Operate ON) Press this button again to turn off the power. (Operate OFF) ● The OPERATE LED lights up as follows.
OPERATE EJECT 7 MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN 6 5 [REMOTE WIRELESS DV Y/C SET CH-2/4 BR-DV3000 5 SEL.] Remote select switch Use this switch to select the remote controller type. 9 PIN : Select this to use the RS-422Acompatible editing remote controller (RM-G820) that connects to the 4 9 PIN REMOTE terminal located at the rear panel. Please use this unit as a player.
NAMES AND FUNCTIONS OF VARIOUS PARTS – Front panel – 8 (continued) 9 OPERATE EJECT MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. 0 PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV SET CH-2/4 Y/C # ● Hold down this button and press the 9 PLAY button to start recording. During recording, the LED lights up red. ● Hold down this button and press the 0 PAUSE button to pause the recording.
% $ ^ OPERATE EJECT MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV Y/C SET CH-2/4 FF BR-DV3000 $ Indicator : When a cassette is loaded, the LED lights up green. (Likewise when the unit is in the OPERATE OFF state.) When a cassette is being loaded or ejected, the LED blinks. DVCAM : When the unit plays back a tape recorded in the DVCAM format, the LED lights up green.
NAMES AND FUNCTIONS OF VARIOUS PARTS – Rear panel – DV IN/OUT AUDIO CH 2/4 LINE VIDEO Y/C IN CH 1/3 REMOTE DC12V OUT NTSC/PAL 9PIN 4 1 DC power input terminal (2P) This is used for DC12V input. It connects the DC power cord of the provided AC adapter. Memo ● When power is supplied to this terminal, the OPERATE indicator located at the front panel lights up. (The LED lights up red when the OPERATE indicator is OFF.
! 6 5 DV IN/OUT AUDIO CH 1/3 CH 2/4 LINE VIDEO Y/C IN 9 REMOTE DC12V NTSC/PAL OUT 0 9PIN 8 SERIAL NTSC PAL 7 E-15
NAMES AND FUNCTIONS OF VARIOUS PARTS – Wireless remote controller – 4 [STILL MODE] button 245 1 DISPLAY 3 BARS STILL MODE MENU SEARCH+ BLANK 9 AUDIO MUTING OUT SEL. SET SET button 0 ! $ SEARCH– A.DUB PAUSE F.REV PLAY OUT LEV. REC F.ADV REW FF STOP ^ INDEX– 6 7 8 @ # & % INDEX+ REMOTE CONTROL UNIT RM-G3000 Use this button to select images in the STILL mode. When the unit is in the STILL mode, press this button to toggle images in the following sequence.
[SEARCH–] / button • During playback, STILL mode or variable speed playback in the forward direction, press this button to slow down the playback speed. • During reverse playback or variable speed playback in the reverse direction, press this button to speed up the playback speed. (☞ page 46) • When the menu is displayed, use this button to select the menu items or setting values. [P] / button • During reverse payback/ variable-speed playback, press this button to execute forward playback.
ON-SCREEN DISPLAY – Regarding on-screen display – Besides E-E images and playback images, the monitor connected to the VIDEO LINE OUT terminal and Y/ C OUT terminal provides the following on-screen information. Wireless remote controller – – –D I SPLAY [ 1 / 2 ] – – – D I PLAY ON COUN T E R POS I . L OW E R - R T I ME COD E ON V T R MO D E ON T A P E R EMA I N OF F T I ME D A T E DA T E + TM AUD I O I N FO .
ON-SCREEN DISPLAY – Status display – Status display: It displays the current settings and operating status. 1 3 2 K CH – 1 / 2 2 No. 1 10 / 10 / 02 12 : 00 : 00 Item Sampling frequency/audio output CH Memo If the time code display position is set to the upper left, this item will be displayed on the lower right. 2 Date/time Memo If the display position of the time code is set to the lower left, this item will be displayed on the lower right.
ON-SCREEN DISPLAY – Status display – 3 2 K CH – 1 / 2 10 / 10 / 02 12 : 00 : 00 S P 000m i n S T ANDB Y -OF F T CR 0 2 : 0 0 : 0 0 : 0 0 (continued) 5 4 3 No. 3 Item Time code Content • It displays the time codes (hour, minute, second and frame). During playback, the time codes recorded on the tape are displayed.
ON-SCREEN DISPLAY – Event display – Event display : When a specific function is in activation or when the operation status is changed with the remote controller, etc, the events will be displayed at the positions shown below.
ON-SCREEN DISPLAY – Alarm display – Alarm display : Alarm messages are displayed as shown below, when an operation error has occurred or when the unit is in a poor condition for operation. E.g., dirty head. Display LOW VOLTAGE HEAD CLEANING REQUIRED! OVERHEATING! E-22 Contents The ideoy hear is dirt The voltage of the DC input power is lo Coninured oper36.
Display Contents COPY INHIBIT The user attempts to record signals protected with the copy guard. REC INHIBIT The user attempts to record on a write protected cassette tape. (The rear slide is pushed to “SAVE”.) A. DUB INHIBIT (REC TAB) The user attempts to perform audio dubbing on a write protected cassette tape. (The rear slide is pushed to “SAVE”.) A.
PREPARATION – Provided wireless remote controller – Loading the batteries Before using the wireless remote controller, please load 2 batteries (AA) in. 1 Lift up the cover of the battery compartment. 2 Load in 2 batteries (AA). + + Memo - Precautions on the use of battery Guide on battery replacement. When the operable distance of the remote controller is decreased, the batteries have become exhausted. Please replace them.
Using the wireless remote controller Maximum distance to the sensor of the unit : 6m Angle : within 30˚ E-25
PREPARATION – Power – Connect the provided AC adapter to the main unit.
Switching on the power OPERATE indicator OPERATE A.DUB Mini DVCAM NTSC REC PLAY REW STO PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV Y/C CH-2/4 BR-DV3000 OPERATE button DISPLAY BARS STILL MODE MENU SEARCH+ BLANK AUDIO MUTING When the unit is in the OPERATE OFF mode (the OPERATE indicator lights up red), press the OPERATE button on the unit or the remote controller. • The power is turned on and the OPERATE indicator lights up green.
PREPARATION – Selecting the NTSC/PAL signal system – This unit supports both the NTSC and PAL signal system. Before inputting analogue signals (composite or YC separate video signals), please select the signal system.
PREPARATION – OPERATION LOCK mode – This unit comes with an operation lock function to prevent unintended, erroneous operation. In the OPERATE LOCK mode, the buttons on the main unit and the slide switch are invalid. However, OPERATE ON and MENU operations are still possible. SYSTEM (2/2) menu – – – S Y S T EM [ 2 / 2 ] – – – D C I N MO D E OP E OF F OP E R A T I ON L OC K ON P AGE B ACK To set the unit to the OPERATION LOCK mode: Set the OPERATION LOCK item of the SYSTEM (2/2) menu to “ON”.
PREPARATION – Loading/ejecting cassettes – Please use standard DV cassettes or mini DV cassettes. Loading the cassette 1. Check the cassette. • Set the rear slide. Push it to “REC” for recording or “SAVE” to prevent its contents from being erased accidentally. • Check that the tape is not slackened. Use an object, such as a clip, to turn the reel in the direction of the arrow. If the tape is taut, the reel will not rotate. 2. Check that the cassette indicator on the unit is unlit.
PREPARATION – Setting/displaying date and time – This function sets up the date and time data of the built-in clock. With the built-in chargeable battery, the configured date and time data is maintained even after the main power is turned off. The data will be displayed on the monitor according to the menu setting. During tape recording, the time and date data is registered.
PREPARATION – Setting/displaying date and time – (continued) 3. – 13, 4. 3. – 13, 4. PLAY button button 5. MENU button BARS MENU EJECT 3. – 4, 4. DISPLAY STILL MODE SEARCH+ 5. EJECT button SET button BLANK MENIU AUDIO MUTING DVCAM NTSC 3. – 2, 4. button OUT SEL. SET SEARCH– OUT LEV. REC PLAY 3. – 2 REW STOP 3. – 4, 4. PAUSE button SET CH-2/4 button PAUSE PAL REC INH. CH-1/3 FF 3. – 2 BR-DV3000 FF button 3. – 13, 4. 3. – 2 , 4. button 3. – 13, 4. REW button 3.
Selecting date/time display The date and time data is displayed on the monitor screen connected to the VIDEO LINE OUT terminal and Y/C OUT terminal. Setup can be performed via the DISPLAY (1/2) menu to turn on/off the date & time display and via the DISPLAY (2/2) menu to determine the display style. (For details on setup method: ☞ Page 54) Top MENU display Setting – – – ME NU – – – S Y S T EM . . R E MO T E . . AUD I O / V I DEO . . T I ME COD E . . D I SPLAY SET . . C L OC K A D J U S T . .
RECORDING – Connection and setting – This chapter explains the connection, setting and operation methods required to use this unit as a recorder. This unit cannot be used as an editing system recorder. Connection When connected to a video device equipped with a DV terminal Images can be recorded with almost no deterioration of image quality.
Setting E-35
RECORDING – Setting time codes – Time code recording This unit has a built-in time code reader/ generator. It records time codes during recording. It does not record the user’s bit. Time codes are recorded according to the recording condition as follows: Time codes are recorded in the REC RUN mode. (REC RUN: time codes run only during recording.) Condition Time code recording Time code is preset with this unit. Time code is not preset. Preset time codes.
1. Top MENU – – – ME NU – – – Remote controller S Y S T EM . . R E MO T E . . AUD I O / V I DEO . . T I ME COD E . . D I SPLAY SET . . C L OC K A D J U S T . . F A C T OR Y S E T T I NG C A NC E L D R UM H O U R M E T E R 0 0 0 0 0 0 EX I T Press the MENU button. 2. Minute TC CL EAR Hour Remote controller Frame Second – – – T I ME COD E – – – 00 : 00 : 00 : 00 CANCE L ND F / D F ( N T SC ) T C DUP L I CA T E TC AD J UST ( DV ) P AGE B ACK 3.
RECORDING – Recording method – Main unit Remote controller 2. 3. PAUSE button 2. 4. REC PLAY button button 2. REC button OPERATE 2. 4. A.DUB PLAY button F.REV PAUSE PLAY EJECT REC F.ADV MENIU A.DUB Mini REW FF 5. STOP button DVCAM NTSC STOP REC PLAY REW STOP PAUSE 3. PAL REC INH. PROFESSIONAL CH-1/3 INDEX– MIC INDEX+ REMOTE CONTROL UNIT RM-G3000 REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV SET CH-2/4 Y/C FF PAUSE button BR-DV3000 5.
RECORDING – Audio dubbing – For tapes recorded in the 32kHz audio mode, audio dubbing can be performed on the CH3 and CH4 channel after the recording. (After-recording) Notes • For tapes recorded in the 48kHz audio mode, audio dubbing cannot be performed. • Audio dubbing cannot be performed for DV input signals. 3. 2. 3. A.DUB button 1. 4. PLAY button A.DUB F.REV PAUSE PLAY REC OPERATE EJECT MENIU FF A.DUB Mini DVCAM NTSC MIC REMOTE SEL. INPUT SEL.
RECORDING – Backup recording function – By linking this unit to other DV devices, this unit can perform continuous, long-hour recording. This unit can be set as a backup unit connected to a DV camcorder (GY-DV300/DV500/DV550/ DV5000, etc.). When the recording tape of the source unit ends, this unit can start recording. This enables long-hour recording.
RECORDING – Recording using the serial remote terminal – Recording can be turned ON/OFF with the serial remote controller or the footswitch connected to the SERIAL REMOTE terminal on the rear panel. SERIAL REMOTE terminal OPERATE EJECT DV IN/OUT MENIU A.DUB DVCAM NTSC REC PLAY REW STOP AUDIO PAUSE CH 1/3 PAL REC INH. CH 2/4 LINE VIDEO Y/C IN Mini PROFESSIONAL CH-1/3 REMOTE SEL. INPUT SEL.
PLAYBACK – Connection/setting – This section explains the required connection, setting and operation method for using this unit as a player.
Setting REMOTE SEL. switch on the front panel OPERATE To use the wireless remote controller, set the switch to “WIRELESS”. Memo A.DUB Mini DVCAM NTSC PAL REC PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL LINE 9PIN WIRELESS DV Y/C To control the unit with the 9 PIN REMOTE or the SERIAL REMOTE terminal, set the REMOTE menu item to “ON”. CH-2/4 BR-DV3000 REMOTE SEL. switch SYSTEM (1/2) menu – – – S Y S T EM [ 1 / 2 ] – – – ST L / F .
PLAYBACK – Basic playback method – DVCAM indicator PLAY button OPERATE EJECT MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL.
PLAYBACK – Special playback function – Frame advance (reverse) playback Use the remote controller. Setting The STL/F. ADV MODE item of the SYSTEM menu DISPLAY STILL MODE BARS MENU Select the amount of frame advance playback and still image. FIELD : Image is advanced field by field. (1st /2nd alternate) 1st FIELD : Image is advanced frame by frame and the 1st field image is displayed. 2nd FIELD : Image is advanced frame by frame, and 2nd field image is displayed.
PLAYBACK – Special playback – (continued) Variable speed playback Use the remote controller. SEARCH +/( ) button ( ) button ( ) button BARS MENU BLANK SEARCH+ AUDIO MUTING OUT SEL. SET SEARCH– A.DUB PAUSE F.REV PLAY OUT LEV. Set the unit to the PLAYBACK or the STILL mode. Press the FF button to execute fast-forward playback. Press the REW button to execute reverse playback.
PLAYBACK – Locate function – Index search This function locates and advances/rewinds to the position where the index signal is recorded. Use the remote controller. A.DUB REC PAUSE F.REV F.ADV PLAY REW FF STOP INDEX– INDEX+ REMOTE CONTROL UNIT RM-G3000 INDEX – button INDEX + button Monitor screen To locate an index in the forward direction vis-a-vis the current tape position: • Press the INDEX + button.
PLAYBACK – Repeat playback – This unit is capable of 3 types of repeat playback. The repeat playback function is set via the REPEAT MODE item of the SYSTEM (1/2) menu. SYSTEM (1/2) menu – – – S Y S T EM [ 1 / 2 ] – – – ST L / F . ADV 2 ND B A C K U P R E C T I ME OF F L ONG P A U S E T I ME 5M I N L O N G P A U S E MO D E F .
PLAYBACK – Selecting playback audio output – The output mode for audio playback can be selected with the remote controller. To turn the audio muting function ON/ OFF or to mute the EE audio, press the AUDIO MUTING button. DISPLAY BARS STILL MODE MENU SEARCH+ To resume the audio output, press the button again. BLANK AUDIO MUTING OUT SEL. SET SEARCH– A.DUB F.REV PAUSE OUT LEV. REC AUDIO MUTING button OUT SEL. button OUT LEV. button Each time the OUT SEL.
EDIT – Using the unit in an editing system – Cut-edit system This unit can be used as a feeder (player) for an editing system that uses a RS-422A-compatible editing remote controller (RM-G820). Applicable model Editing remote controller : RM-G820 Recorder : VHS/S-VHS ....... BR-S800 (equipped with SA-K26 or SA-R50), BR-S822 * DV signals cannot be input. D9 (digital S) ..... BR-D80, BR-D85, BR-D750 * To input DV signals, please install SA-DV60 to D9VTR.
REMOTE (1/2) menu – – – R E MO T E [ 1 / 2 ] – – – R E MO T E ON L OC A L F UNC T I ON AL L KEYS P R E RO L L 5S F F / R EW R EM F F / R EW M O D E REM S TOP SE L EE PB START DELAY OF SYNCHRON I Z A T I ON ON NEXT PAGE PAGE BACK • REM STOP SEL: Use this menu item to set the operation mode upon reception of a standby-on signal. EE : EE mode (STOP mode) PB : PLAYBACK mode (STILL mode) Memo • PB START DELAY: Use this menu item to set the edit timing.
EDIT – Using the unit in an editing system – (continued) Using the unit in a non-linear system This is a system that captures the content of the source tape on a non-linear editing system and records the non-linear edited contents onto the main unit.
MENU SCREEN – Structure of the menu – Hierarchical menus are displayed on the monitor. SYSTEM (2/2) menu SYSTEM (1/2) menu – – – S Y S T EM [ 1 / 2 ] – – – ST L / F . ADV 2 ND B A C K U P R E C T I ME OF F L ONG P A U S E T I ME 5M I N L O N G P A U S E MO D E F .
MENU SCREEN – Setting the menu – The various functions of this unit can be set from the menu. The configured settings are saved in the unit's memory and are maintained even after the power is turned off. 2. – 1 2. – 1 PLAY button button EJECT BARS 1. MENU MENU button 1. EJECT 2. – 2 DISPLAY STILL MODE SEARCH+ A.DUB AUDIO MUTING DVCAM NTSC REC PLAY SET SEARCH– OUT LEV. NPUT SEL. 2. – 2 LINE REW STOP DV button Y/C PAUSE PAL REC INH. CH-1/3 OUT SEL.
3. – 1 , 3 3. – 1 , 3 PLAY button button EJECT 3. – 2 , 4 DISPLAY 4. BARS MENU button MENU STILL MODE SEARCH+ DVCAM NTSC SET SEARCH– OUT LEV. button MENIU AUDIO MUTING OUT SEL. button 4. EJECT SET button BLANK REC PLAY REW STOP CH-1/3 3. – 2 SET CH-2/4 button PAUSE PAL REC INH. FF 3. – 2 , 4 PAUSE button 3.– 2 BR-DV3000 FF button 3. – 1 , 3 REW button button Setting item Cursor Setting value 3. STOP button Set the items on the menu.
MENU SCREEN – Contents of the menus – In the menu descriptions below, settings with marks are factory settings. Top MENU Items Setting Contents SYSTEM Displays the menus related to the operation system of this unit. REMOTE Displays the menus related to the remote controller. AUDIO/VIDEO Displays the menus related to the audio and video. TIME CODE Displays the menu for setting time codes.
SYSTEM menu The SYSTEM menu consists of the following 2 screens. (1/2 and 2/2 menu) SYSTEM (1/2) menu Items Setting Contents STL/F.ADV MODE FIELD 1st 2nd FRAME Use this item to select the still image type during the STILL mode or frame advance playback: FIELD : Displays field image. During frame advance playback, 1st and 2nd field images are displayed alternately. 1st : displays the 1st field image. 2nd : displays the 2nd field image. FRAME : displays the frame image.
MENU SCREEN – Contents of the menus – (continued) SYSTEM menu (continued) Items Setting Contents INDEX WRITE OFF ON Use this setting to enable/disable index signal recording: OFF : No recording of index signal. ON : Use this setting to record index signals. An index signal is automatically registered at the position where recording starts. REPEAT MODE OFF INDEX VIDEO OUT TAPE END Use this setting to enable/disable repeat playback: OFF : No repeat playback.
REMOTE menu The REMOTE menu consists of 2 menus. (1/2 and 2/2 menu) REMOTE (1/2) menu Items Setting Contents REMOTE OFF ON Use this menu item to enable/disable the REMOTE SEL. switch on the front panel: OFF : Disables the 9 PIN/SERIAL setting of the REMOTE SEL. switch. ON : Enables the 9 PIN/SERIAL setting of the REMOTE SEL. switch. Use this setting when remote controlling the unit via the 9 PIN and SERIAL terminal.
MENU SCREEN – Contents of the menus – (continued) REMOTE menu (continued) Items Setting Contents REM STOP SEL EE PB Use this menu item to set the action to be performed when a STANDBY ON command is received via the 9 PIN REMOTE terminal or DV terminal: EE: Sets the unit to the EE mode. (The unit will go into the STOP mode.) PB: Sets the unit to the PLAY mode. (The unit will go into the STILL mode.) PB START DELAY 0F | 15F Use this menu item to adjust the edit timing.
AUDIO/VIDEO menu Items Setting Contents AUDIO MODE 48K 32K Select the audio sampling frequency for recording: 48K : Records at 48kHz. It records in the 2-channel stereo mode. No audio dubbing. 32K : Records at 32kHz. It records in the 4-channel mode. To perform audio dubbing on CH3 and CH4 later, use this setting. Memo This setting is not required for DV signal input. A.
MENU SCREEN – Contents of the menus – (continued) TIME CODE menu Items Setting TC Contents Presets the time code: For details, please refer to Page 36 "Presetting Time Codes". CLEAR CANCEL EXECUTE Use this menu item to choose whether to clear the time code values: CANCEL : Do not clear. EXECUTE : clear. NDF/DF (NTSC ONLY) NDF DF Select the framing mode for the time code generator: NDF : Sets the unit to the non-drop mode.
DISPLAY menu The DISPLAY menu consists of 2 menus (1/2 and 2/2 menu) DISPLAY (1/2) menu Items DISPLAY Setting OFF ON AUTO Contents Use this menu item to choose whether to have the characters of the status screen displayed on the monitor connected to VIDEO LINE OUT or Y/C OUT terminal: OFF : No on-screen display. Video display only. ON : Always provide on-screen display. AUTO : Provide on-screen display for about 4 seconds on switching modes.
MENU SCREEN – Contents of the menus – (continued) DISPLAY menu (continued) Items AUDIO INFO. Setting OFF ON Contents Use this setting to turn on/off the display of audio channel or sampling frequency on the monitor: OFF : No display ON : Display NEXT PAGE Display the DISPLAY (2/2) menu. PAGE BACK Return to the top MENU. DISPLAY (2/2) menu Items Setting Contents DATE STYLE YY/MM/DD MM/DD/YY DD/MM/YY Select the date format: YY/MM/DD : Display year/month/day.
OTHERS – Placing the unit in an upright position – With the use of the provided stand, the main unit can be placed in an upright position as shown in the following diagram. The left side should be at the bottom. Stand Notes • To place the VTR in an upright position, please use the provided stand. If the stand is not used, the unit may topple and result in injuries or breakdown. • Please place the unit on a leveled place.
OTHERS – Warning display – When an anomaly occurs, this unit automatically identifies the cause and displays an errorcoded warning message on the monitor. If the unit is in a state needing rectification, or if an operation error has occurred, an alarm display will be shown on the monitor.
Warning display (Displayed regardless of the DISPLAY mode) When a warning display appears, this unit stops operation and cease to accept any operation commands. When TAPE DEFFECTIVE (5605 - 5609) is displayed, the unit similarly stops operation but accepts one command, viz EJECT. Display Status Action CONDENSATION ON DRUM Condensation. Please leave the power on and wait for the display to disappear. WARNING 3200 LOADING FAILURE Unable to load tape.
OTHERS – Troubleshooting – Symptom Action The power does not come on. Is the AC adapter correctly connected? The cassette cannot be loaded. Is the cassette indicator lit? If so, a cassette is already loaded. Please unload the cassette first. Push the center of the cassette and make sure that the cassette enters levelly. Unable to record. Is the slide of the cassette set to "REC"? Please set it to "REC" if it is at the "SAVE" position. The operation buttons of the main unit do not work.
OTHERS – Checking the hour meter – This unit displays the drum usage time on the DRUM HOUR METER item of the top MENU. Please use it as a guide for regular maintenance. (☞ Page 7) OPERATE EJECT DISPLAY STILL MODE BARS MENU BLANK SEARCH+ MENIU AUDIO MUTING A.DUB Mini DVCAM NTSC MENU button MIC REMOTE SEL. INPUT SEL. SERIAL LINE SET CH-2/4 WIRELESS DV Y/C FF BR-DV3000 REC PAUSE PLAY STOP PAUSE OUT LEV. 9PIN F.REV REW CH-1/3 SET A.DUB PLAY PAL REC INH.
OTHERS – Specification – General Recording system : DV system (SP mode only) Signal system : NTSC/PAL Cassette : Standard/ mini DV cassette Tape width : 6.35mm Tape speed : 18.812mm/s (NTSC) 18.831mm/s (PAL) Recording/ playback time : 276 minutes (LA-DV276) 60 minutes (M-DV60) Fast forward/ rewind time : About 3 minutes (LA-DV276) About 1 minute (M-DV60) Power : DC12V}(supplied via the provided AC adapter) Power consumption: 14W, 1.
OTHERS – Specification – (continued) 260 Diagram of external dimension (Unit: mm) 174 68 OPERATE EJECT MENIU A.DUB Mini DVCAM NTSC REC PLAY REW STOP PAUSE PAL REC INH. PROFESSIONAL CH-1/3 MIC REMOTE SEL. INPUT SEL. SERIAL 9PIN WIRELESS LINE DV Y/C SET CH-2/4 FF BR-DV3000 Design and specifications subject to change without notice.
