ENGLISH CASSETTEN-RECEIVER RADIOCASSETTE RADIO/CASSETTESPELER KS-FX730R/FX630R/F530R KS-FX730R ATT FRANÇAIS DEUTSCH CASSETTE RECEIVER BAND PROG DISC FUNC ATT 35W x 4 Detachable DISP MO/RND/ DOLBY B NR CDCHANGERCONTROL KS-FX730R ¢ TP/RDS NEDERLANDS 0 DISC PRESET PTY SSM SEL RM-RK22 SOUND 4 7 8 9 10 11 BAND 12 CD-CH TUNER PROG TAPE 5 KS-FX630R ATT 0 35W x 4 MO/RND CDCHANGERCONTROL DISP KS-FX630R ¢ TP/RDS PTY SSM SEL SOUND 4 7 8 9 10 11 BAND 12 CD-CH TUNER
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS BASIC OPERATIONS .................................................... 3 RADIO OPERATIONS ................................................... 4 Listening to the radio ..................................................................... 4 Storing stations in memory ...........................................
1 ENGLISH BASIC OPERATIONS Note: When you use this unit for the first time, set the built-in clock correctly, see page 21. 3 1 /I ATT 2 Turn on the power. Note on One-Touch Operation: When you select a source in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. 2 KS-FX730R/FX630R BAND CD-CH TUNER PROG Select the source. TAPE To operate the tuner, see pages 4 – 15. To operate the tape deck, see pages 16 – 17.
RADIO OPERATIONS Listening to the radio KS-FX730R/FX630R KS-F530R 2 1 KS-FX730R/FX630R Select the band (FM1, FM2, FM3 or AM). BAND You can select any one of FM1, FM2, and FM3 to listen to an FM station. TUNER FM1 1 1 FM2 FM3 AM Audio level indicator (Only for KS-FX730R) KS-F530R AM FM FM1 FM2 FM3 AM 2 Start searching a station. To search stations of higher frequencies. When a station is received, searching stops. SSM To search stations of lower frequencies.
ENGLISH Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong-station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2, and FM3). 2 1 1 KS-FX730R/FX630R BAND FM1 TUNER FM2 FM3 AM Select the FM band number (FM1, FM2 or FM3) you want to store FM stations into.
Manual preset You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually. EXAMPLE: Storing an FM station of 88.3 MHz into preset number 1 of the FM1 band 2 3 1 KS-FX730R/FX630R KS-F530R BAND Select the FM1 band. FM TUNER 2 Tune into a station of 88.3 MHz. SSM 3 1 1 See page 4 to tune into a station. 2 Press and hold the button for more than 1 second. Preset number “P1” starts flashing for a while.
ENGLISH Tuning into a preset station You can easily tune into a preset station. Remember that you must store stations first. If you have not stored them yet, see pages 5 and 6. KS-F530R KS-FX730R/FX630R EL 7 8 9 10 11 12 6 2 1 1 1 Select the band (FM1, FM2, FM3 or AM) you want. KS-FX730R/FX630R BAND TUNER FM1 FM2 FM3 AM KS-F530R AM FM FM1 FM2 FM3 AM 2 1 2 3 4 5 6 Select the number (1 – 6) for the preset station you want.
Using RDS functions in the FM band RDS (Radio Data System) RDS button TP/RDS To select Network-Tracking mode, press the RDS button for more than one second. • Mode 1 (AF (Alternative Frequencies): on/REG: off): Network-Tracking is activated. Switches between stations belonging to the network being received. Note: • In Mode 1, the broadcast may switch between different programmes even within the same network at certain times.
ENGLISH PTY standby mode Storing your favourite programme type (PTY) into memory (NEWS is factory-preset.) 0 ¢ 4 5 1 3 2 1 Press the SEL button for more than 2 seconds to enter the preferred setting mode (see page 23). SEL 2 Press the ¢ or 4 the “PTY STBY” mode. button to select SSM Each time the ¢ or 4 button is pressed, the display changes as follows.
Setting and operating PTY standby mode PTY • When the PTY button is briefly pressed in the FM mode, the “PTY” indicator is lit during reception of a PTY station and the PTY standby mode is engaged. The PTY name stored on page 9 (for example: “CLASSICS” ) flashes for 5 seconds. Note: When the station being received is not a PTY station, the "PTY" indicator flashes. Press the ¢ or 4 button to engage the PTY standby mode. “SEARCH” appears in the display, and PTY station search starts.
ENGLISH PTY search mode Presetting PTYs in number buttons 1-6 The factory-presets are listed below. 1 2 3 4 5 6 POP M ROCK M EASY M CLASSICS AFFAIRS VARIED 0 2 ¢ 4 5 1 3 1 Press the SEL button for more than 2 seconds to enter the preferred setting mode (see page 23). SEL 2 Select the “PTY SRCH” mode with the ¢ or 4 button.
PTY search operation 0 ¢ 4 5 2 1 Press and hold the PTY button for more than 1 second in the FM mode. PTY programme search mode is engaged. PTY 2 1 1 2 3 4 5 6 Recall a PTY stored on page 11 using a number button (1-6). Ex. When “CLASSICS” is stored in button 1. • PTY station search starts after 5 seconds. Successful programme search results in the desired PTY station being received so its programme can be heard. • When a PTY station cannot be tuned in, the previous station is received.
CULTURE: PTY display No. DISPLAY No.
Other RDS functions EON (Enhanced Other Networks) • When tuning in a broadcasting station transmitting EON data, the EON indicator is lit and the following operations start. EON automatically stores the frequencies of stations from other networks transmitting information codes (TP/TA/AF/PTY/PS (Programme Service), etc.) so they can be mutually used.
Setting the main display mode. 1. Press the SEL button for more than 2 seconds to set the preferred setting mode. 2. Select “DISPMODE” with the ¢ or 4 button. 3. Select the desired mode with the + or button. (Station name (PS NAME) Ô Frequency being received (FREQ) Ô Clock time (CLOCK) Ô) (see page 23.) Note: When the “CLOCK” mode is set, clock time remains on the main display even during tape (or CD (KS-FX730R/FX630R only)) playback.
TAPE OPERATIONS Listening to a tape 1 1 2 Insert a cassette. The unit turns on and tape play starts automatically. When one side of the tape reaches its end during play, the other side of the tape automatically starts playing. (Auto Reverse) Note on One-Touch Operation: When a cassette is already in the cassette compartment, pressing TAPE/PROG turns on the unit and starts tape play automatically. 2 PROG TAPE Select the tape direction.
• Press ¢ for more than 1 second to fast-forward the tape. When the tape reaches its end, the tape is reversed and playback starts from the beginning of the other side. • Press 4 for more than 1 second to rewind the tape. When the tape reaches its end, playback of the same side starts. ENGLISH To fast-forward and rewind a tape Tape direction To stop fast-forward and rewind at any position on the tape, press TAPE/PROG. Tape play starts from that position on the tape.
SOUND ADJUSTMENTS Selecting preset sound modes You can select a preset sound adjustment suitable to the music genre. SOUND Each time you press SOUND, the sound mode changes as follows. SOUND Indication For: Preset values Bass Treble Loudness SCM OFF (Flat sound) 00 00 On BEAT Rock or disco music +2 00 On SOFT Quiet background music +1 –3 Off POP Light music +4 +1 Off Notes: • You can adjust the preset sound mode to your pteference, and store it in memory.
ENGLISH Adjusting the sound You can adjust the sound characteristics to your preference. 1 2 1 SEL Indication Select the item you want to adjust. To do: Range BAS (Bass) Adjust the bass –6 (min.) — +6 (max.) TRE (Treble) Adjust the treble –6 (min.) — +6 (max.
Storing your own sound adjustments You can adjust the sound modes (BEAT, SOFT, POP: see page 18) to your preference and store your own adjustments in memory. 2 3 1 1, 4 SOUND Call up the sound mode you want to adjust. See page 18 for details. Within 5 seconds 2 SEL Select "BAS", "TRE" or "LOUD". Within 5 seconds 3 Adjust the bass or treble level or turn the loudness function ON/OFF. See page 19 for details.
Setting the clock Selecting 24-hour or 12-hour clock display (Set to 24-hour at the factory) 1. Press the SEL button for more than 2 seconds to set the preferred setting mode (see page 23). or 4 button. 2. Select the “24H/12H” mode with the ¢ 3. Select 24H or 12H with the level control buttons (+,–). ENGLISH OTHER MAIN FUNCTIONS How to select the clock mode as the main display mode 1. Press the SEL button for more than 2 seconds to set the preferred setting mode (see page 23). or 4 button. 2.
0 ¢ 4 5 3 3 4 2 1 Set the minute. SSM 1. Select “CLOCK M.” 2. Adjust the minute. 4 Start the clock. DISP To check the current clock time (changing the display mode) Press DISP repeatedly. Each time you press the button, the display mode changes as follows. During tuner operation: Frequency Clock (See page 15 when RDS is on.
ENGLISH Storing your own mode settings Preferred setting mode control This mode has been set at the factory, but it can be set to suit your needs. 1 0 Press the SEL button for more than 2 seconds to set the preferred setting mode. ¢ SEL 4 1 3 2 2 SSM 1 3 Select each mode. Set the desired mode. 3 2 SSM SEL Factory-preset See page settings Set. Select.
Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. How to detach the control panel Before detaching the control panel, be sure to turn off the power. 1 2 3 How to attach the control panel 1 Unlock the control panel. Lift and pull the control panel out of the unit. Put the detached control panel into the provided case.
REMOTE OPERATIONS Remote sensor Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit. Make sure there is no obstacle in between. • Do not expose the remote sensor to strong light (direct sunlight or artificial lighting). ENGLISH This section is ONLY FOR KS-FX730R. 5 Installing the batteries R03 (UM-4)/AAA (24F) Insert the · ends first.
CD CHANGER OPERATIONS This section is ONLY FOR KS-FX730R/FX630R, when used with a JVC CD automatic changer (separately purchased). We recommend that you use one of the CH-X series with your KS-FX730R/FX630R. If you have another CD automatic changer, consult your JVC IN-CAR ENTERTAINMENT dealer for connections. • For example, if your CD automatic changer is one of the KD-MK series, you need a cord (KSU15K) for connecting it to this unit.
Press and hold ¢ , while playing a CD, to fast-forward the track. Press and hold 4 , while playing a CD, to reverse the track. SSM ENGLISH To fast-forward or reverse the track To go to the next track or the previous track SSM Press ¢ briefly, while playing a CD, to go ahead to the beginning of the next track. Each time you press the button consecutively, the beginning of the next track is located and played back. Press 4 briefly, while playing a CD, to go back to the beginning of the current track.
Selecting CD playback modes MO/RND/ (For KS-FX730R) MO/RND (For KS-FX630R) To play back tracks at random (Random Play) KS-FX730R Each time you press MO/RND/ (Mono/Random/Dolby: for KSFX730R) or MO/RND (Mono/Random: for KS-FX630R) while playing a CD, CD random play mode changes as follows: MO/RND/ RND1 RND2 (Random1) (Random2) Cancelled KS-FX630R MO/RND 28 Mode RND Indicator Plays at random RND1 Lights All tracks of the current disc, then the tracks of the next disc, and so on.
To extend the lifetime of the unit This unit requires very little attention, but you will be able to extend the life of the unit if you follow the instructions below. ENGLISH MAINTENANCE To clean the heads • Clean the heads after every 10 hours of use using a wet-type head cleaning tape (available at an audio store). When the head becomes dirty, you may realize the following symptoms: – Sound quality is reduced. – Sound level decreases. – Sound drops out. • Do not play dirty or dusty tapes.
TROUBLESHOOTING What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Remedies • A cassette tape cannot be inserted. You have tried to insert a cassette in the wrong way. • Cassette tapes become hot. This is not a malfunction. • Tape sound is at very low level and sound quality is degraded. The tape head is dirty. Clean it with a head cleaning tape. • Sound is sometimes interrupted. Connections are not good.
AUDIO AMPLIFIER SECTION CASSETTE DECK SECTION Maximum Power Output: Front: 35 watts per channel Rear: 35 watts per channel Continuous Power Output (RMS): Front: 15 watts per channel into 4 , 40 to 20,000 Hz at no more than 0.8% total harmonic distortion. Rear: 15 watts per channel into 4 , 40 to 20,000 Hz at no more than 0.8% total harmonic distortion.
