COLOUR TELEVISION EQUALIZER • CINEMA SURROUND • COMPONENT INPUT Contents AV-21DX14 AV-20NX14 Knowing your TV’s features ....................................................... 3 Remote control buttons and basic functions .............................. 4 TV buttons and functions ........................................................... 6 Setting up your TV ..................................................................... 7 Basic setting for picture ..................................................
Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES REGARDING THE USE OF THIS TV. 7 If you are not going to use this TV for a long period of time, be sure to disconnect the AC plug from the AC socket.
Knowing your TV’s features Main features FAVORITE CH (Channel) You can register up to four favorite channels for quick recall with one press. AI VOLUME TV adjusts the volume automatically to the same level for all TV channels to avoid sudden change of the volume when selecting different TV channel. VNR You can reduce the picture noise when viewing noisy TV programmes or video sources. WHITE BALANCE You can choose one of three tones of white to match the video source such as movie, sports, etc.
Remote control buttons and basic functions 1 2 3 4 5 6 7 8 No. Press POWER MENU/OK 5/∞/2/3 CHANNEL -/+ VOLUME -/+ TV/VIDEO MUTING 9 Ä DISPLAY 0~9, -/-RETURN + To Turn on or off the TV from standby mode. Display menu and confirm selected function. Select and adjust menu function. Select the desired channel number. Adjust the volume level. Select TV or video terminal input. Turn off the volume. Press this button again to resume the volume.
Remote control buttons and basic functions (continued) How to operate menus and menus locations To Operation Display the MENU Press the MENU/OK button MENU Note 2. To exit the MENU, press the DISPLAY button or choose EXIT menu. 8 3 3 Display the top menu to Press 5/∞ buttons to choose a Press ∞ button menu title. Then press MENU/OK display the next page for more functions. button . Display the 2nd menu Press 5/∞ buttons to choose a menu title. Then press MENU/OK button .
TV buttons and functions Front of the TV AV-20NX14 9 8 V L / MONO IN (VIDEO-3) R 7 6 5 MENU OK CHANNEL VOLUME 7 6 5 MENU OK CHANNEL VOLUME 4 3 2 TIMER 1 POWER AV-21DX14 9 8 V L / MONO IN (VIDEO-3) R Rear of the TV AV-20NX14/AV-21DX14 VIDEO-1 INPUT COMPONENT (VIDEO-2) INPUT 4 32 TIMER POWER 1 No. Button/terminal Description Page L (main power) Press to turn on or turn off the TV’s main power. – POWER lamp Indicate the TV is being turned on or off.
Setting up your TV CAUTION • Turn off the equipment including the TV before connecting. 1 Connecting the aerial cable. 2 Connecting the compatible main plug to the AC outlet. 3 Inserting batteries into the remote control. Insert two batteries by following the + and polarities and inserting the - end first. CAUTION: Follow the cautions printed on the batteries. Notes: • Use AA/R6/UM-3 dry cell batteries. • It the remote control does not work properly, fit new batteries.
Setting up your TV (continued) 5 Making the initial settings Set up your TV by pressing any button except POWER button, then operate the TV menu by following the steps as below: LANGUAGE AUTO PROGRAM ENGLISH êìëëäàâ EDIT AUTO PROGRAM PR 7 8 9 10 11 12 13 SETUP TOUR RESTART? CH 12 22% MELAYU INDONESIA OK ■ RESTART NO BACK ■ OK CH/CC CH 09 CH 11 CH 13 ■ . BACK ■ OK OK 3 MOVE ■INSERT ■DELETE ■MANUAL . • Press 5/∞ button to select your desired language, then press MENU/OK button.
Basic setting for picture PICTURE MODE COLOUR SYSTEM You can select the appropriate colour system when the picture is not clear or no colour appears. Press the COLOUR SYSTEM button to select a setting. AUTO PAL SECAM NTSC3.58 NTSC4.43 You can choose the desired picture setting with one-touch. Press the PICTURE MODE button to select a setting. SOFT BRIGHT STANDARD USER To operate this function with a menu: ❇ MENU PICTURE menu PICTURE FEATURES menu COLOUR SYSTEM Softens contrast and sharpness.
Basic setting for picture (continued) Adjusting the picture – USER You can adjust the desired picture setting when selecting USER in PICTURE MODE. 1 Select the USER in PICTURE MODE under PICTURE menu. ❇ MENU USER PICTURE menu PICTURE MODE the setting. CONTRAST BRIGHT SHARP COLOUR TINT* You can change the white balance of the picture to better match the type of video being viewed. Select the WHITE BALANCE in the PICTURE menu, then choose the desired setting.
Advanced setting for picture COMPRESS (16:9) BLUE BACK You can convert a normal picture (4:3 aspect ratio) into a wide picture (16:9 aspect ratio). Select the COMPRESS (16:9) in the PICTURE FEATURES menu under PICTURE menu, then choose ON or OFF. ❇ MENU PICTURE menu PICTURE FEATURES menu You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an antenna.
Basic setting for sound SOUND MODE SOUND SYSTEM You can select an appropriate sound system when abnormal sound occurs even when the picture appears normally. Press the SOUND SYSTEM button to select a setting. B/G I D/K M ❇ MENU . . This function is not available in video mode. For the sound system in each country or region, see the table below: Area Asia, Middle East Europe Oceania Africa Country or Region Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc.
Advanced setting for sound CINEMA SURROUND EQUALIZER You can enjoy an enhanced sound for wider audience. Press the CINEMA SURROUND button to select a setting. Cancel the function. Listen to sound with less wider audience effect. Listen to sound with more wider audience effect. Listen to mono sound with stereo effect. To operate this function with a menu: SOUND MODE ❇ MENU USER SOUND menu EQUALIZER The following display appears.
Favorite channel and video setting 4 Select the desired item that you wish to adjust. To register the favorite channel You can register and recall 4 favorite channels by using the colour buttons (red, green, yellow, blue). 1 In TV mode, select a TV channel (PR01-99) you desired to register. 2 Press and hold a colour button for 3 seconds or more. “FAVORITE CHANNEL ■ PROGRAMMED!” appears on the screen and current channel is registered. 3 To register other favorite channels, repeat Step 1 to 2.
Customized setting VNR CHILD LOCK You can reduce the noise. Select the VNR in the PICTURE FEATURES menu under PICTURE menu, then choose a setting of VNR function. ❇ MENU PICTURE menu PICTURE FEATURES menu You can disable the front control buttons of the TV. Select the CHILD LOCK in the FEATURES menu, then choose ON or OFF. ❇ MENU FEATURES menu CHILD LOCK VNR OFF TIMER OFF AUTO MIN MAX VNR is turned off. Effect of VNR is automatically controlled. Effect of VNR becomes minimum level.
Customized setting (continued) AUTO SHUTOFF EXT. INPUT (TV/VIDEO) You can set the TV to turn off automatically when no signal is received for about 15 minutes or longer after the end of a broadcast. Select AUTO SHUTOFF in INSTALL menu, then choose ON or OFF. ❇ MENU INSTALL menu AUTO SHUTOFF The AUTO SHUTOFF function does not turn off the TV’s main power. The AUTO SHUTOFF function is not available in video mode. You can select TV or video terminal input with one touch.
TV channel presetting To register the TV channels automatically 2 Choose EDIT/MANUAL, then press the MENU/OK button. EDIT menu appears. You can register the TV channels into the TV’s channel list automatically. 1 Display the INSTALL menu. ❇ MENU EDIT PR 7 8 9 10 11 12 13 INSTALL menu 2 Choose AUTO PROGRAM, then press the MENU/OK button. 3 AUTO PROGRAM function starts, and the channels received are registered in the channel list (PR list) automatically. “SETUP TOUR RESTART?” appears.
TV channel presetting (continued) To edit the channel list (PR LIST) (MOVE and DELETE in the EDIT menu) You can edit the TV channel list as you like. Note: After this operation, other channel’s PR numbers will be changed. 1 Display the INSTALL menu. ❇ MENU INSTALL menu 2 Choose EDIT/MANUAL, then press the MENU/OK button. ❇ MENU INSTALL menu EDIT menu appears. EDIT PR 7 8 9 10 11 12 13 CH/CC CH 09 CH 11 CH 13 ■ BACK ■ OK .
TV channel presetting (continued) CH/CC number When you want to use the INSERT function on page 18, find the CH/CC number corresponding to the channel number of the TV channel from this table. Channel No. US CCIR OIRT AUSTRALIA Country United States, Philippines, etc.. Middle East, Southeast Asia, etc.. Eastern Europe, Russia, Vietnam, etc.. Australia, etc..
Additional preparation Before connecting • Read the manuals provided with the devices for the proper connection. • Turn off all the devices including the TV. • Note that connecting cables are not supplied. Connecting to rear component/video input terminal and output terminal Rear of TV VIDEO-1 INPUT COMPONENT (VIDEO-2) INPUT OUTPUT VCR (for playing) DVD player (composite signals) .
Troubleshooting If a problem occurs when you are using the TV, check the below troubleshooting guide before calling for repair. • No picture, no sound • Deactivate the BLUE BACK function if it is turned on. • Choose the appropriate sound system. Refer to “SOUND SYSTEM” on page 12. • Snowy picture • Check the aerial cable and its connection with the TV. • Stripes appear on the picture • Interference occurs caused by other devices such as an amplifier, personal computer, or a hair drier.
Specifications TV RF systems B, G, I, D, K, M Colour systems PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Receiving channels VHF low channel (VL), VHF high channel (VH), UHF channel (U) Receives cable channels in mid band, super band and hyper band. External input / output VIDEO-1: VIDEO-2/COMPONENT: VIDEO-3: OUTPUT: Headphone jack: VIDEO input, AUDIO L/R input VIDEO input, AUDIO L/R input, COMPONENT VIDEO (Y/CB/CR) input VIDEO input, AUDIO L/R input VIDEO output, AUDIO L/R output Stereo mini jack (3.
