LCD Flat Television Users Guide For Models: LT-37X688 LT-42X688 LT-42X788 LT-47X788 LT-37XM48 LT-42XM48 Illustration of LT-37X688 and RM-C1450 Important Note: In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.
Important Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock. Do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
IMPORTANT RECYCLING INFORMATION This product has a fluorescent lamp that contains mercury. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities or for USA, the Electronic Industries Alliance: http://www.eiae.org IMPORTANT SAFETY INSTRUCTIONS 1) 2) 3) 4) 5) 6) 7) Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.
13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Warnings We have an important note for customers who subscribe to basic cable services (do not have a separate cable box) and plan to use their JVC TV remote control to select channels. Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is receiving through the RF input), every channel number available from your cable company will appear in your television’s Channel Summary and they will all be marked as available for scanning.
Warnings Caring for the Cabinet Normally, light dusting with a soft, non-scratching duster will keep your TV clean. If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt. • • • • DO NOT allow liquid to enter the TV through the ventilation slots. DO NOT use strong or abrasive cleaners on the TV.
Warnings Disconnecting the stand If you disconnect the stand, attach the bottom cover and the screw (supplied) into the hole. This illustration is for models LT-37X688, LT-42X688, LT-37XM48 and LT-42XM48. You can disconnect the stand for models LT-42X788 and LT-47X788 using the same method. 1) Place the TV face down on a soft cloth on a table. 2) Remove the four screws from the back of the TV. 3) Pull out the stand from the TV. 4) Cover the hole with a bottom cover and tighten the screw.
Table of Contents Important Safety Precautions . . 2 Warnings . . . . . . . . . . . . . . . 5 Quick Setup . . . . . . . . . . . . . . 9 Unpacking your TV . . . . . . . . . . . . 9 TV Models . . . . . . . . . . . . . . . . 10 TV Remote Control . . . . . . . . . . . 11 Getting Started . . . . . . . . . . . . . 12 The Remote Control . . . . . . . . . . 12 Connecting Your Devices . . . . . . . 13 Interactive Plug-in Menu . . . . . . . . 22 Onscreen Menus . . . . . . . . . 25 Using the Guide . . . . . . . . . .
Quick Setup Unpacking your TV Thank you for your purchase of a JVC LCD Flat Television. Before you begin setting up your new television, please check to make sure you have all of the following items.
Quick Setup TV Models Before you connect your television to another device, please refer to the proper diagrams for your specific TV and remote. These will help assist you in understanding how to connect your television to another device, as well as use the remote to set up your television.
Quick Setup Remote Control POWER TV MODE STB VCR DVD AUDIO INPUT V1 V2 V3 V4 V5 1 2 3 4 5 6 7 8 9 RETURN + 0 TUNE – CH + TV – VOL + BACK MENU MUTING OK F AV OR E ASP ITE CT DVR STATUS VIDEO SOUND SUB CH TV/VCR GUIDE C.C. SUB T. DISPLAY SLEEP ML/MTS RM-C1450 TV RM-C1450 Notes: • For information on remote control buttons, see pages 58 - 66. • SUB CHANNEL and GUIDE buttons are for digital channels.
Quick Setup Getting Started These quick setup pages will provide you, in three easy steps, with the basic information you need to begin using your new television right away. If you have questions, or for more detailed information on any of these steps, please consult other sections of this manual. Step 1 – The Remote Control Before you can operate your remote control, you first need to install the batteries (included). Raise the latch on the remote's back cover to remove.
Quick Setup Step 2 - Connecting your devices To make these connections, you will use plugs like the ones illustrated below. Component Cables Composite Cables Audio Cables Coaxial Cables Used to connect an external antenna or cable TV system to your TV. S-Video Cable Used to connect audio/video devices like VCRs, DVD players, stereo amplifiers, game consoles, etc. Used to make video connections with S-Video VCRs, Camcorders and DVD players. Notes: • The following connection diagrams are examples.
Quick Setup VCR • DVD Connection Notes: • Green, blue and red are the most common colors for DVD cables. Some models may vary colors. Please consult the user’s manual for your DVD player for more information. • Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables. • You may also connect the DVD player to Input 1.
Quick Setup Diagram #2 Cable or Antenna Output IN OUT OUT Two-Way Splitter (Not supplied) VCR R L IN V IN OUT OUT Coaxial Cable OR INPUT 3 INPUT 5 / INPUT 1 AUDIO INPUT 4 S-VIDEO Y PB VIDEO L L R R 75 Ω (VHF/UHF) PHOTO VIEWER INPUT 1 INPUT 2 DIGITAL AUDIO OPTICAL OUT AUDIO R SERVICE L AUDIO PR VIDEO AUDIO R COMPONENT Y L AUDIO PR VIDEO COMPONENT PB AUDIO OUT TV Rear Panel Green Y Blue PB Red PR AUDIO OUT OUT R L DVD Player 15 LCT2275-001B-A English.
Quick Setup Connecting to a Camcorder You can connect a camcorder to your television by using the input jacks located on the back of the TV. TV Rear Panel CAMCORDER INPUT 3 INPUT 5 / INPUT 1 AUDIO INPUT 4 S-VIDEO Y Y L PB L L R R AUDIO R AUDIO PR VIDEO L AUDIO R VIDEO COMPONENT VIDEO AUDIO PR COMPONENT PB AUDIO OUT 1) Connect a yellow composite cable from the camcorder VIDEO OUT to the VIDEO IN on the back of the TV.
Quick Setup Connecting to an External Amplifier TV Rear Panel Speaker Speaker Amplifier INPUT 3 INPUT 5 / INPUT 1 AUDIO INPUT 4 S-VIDEO Y L PB L L L R R AUDIO R AUDIO PR AUDIO OUT VIDEO AUDIO AUDIO R VIDEO COMPONENT Y COMPONENT PB PR VIDEO 1) Connect a white cable from the LEFT AUDIO OUTPUT on the back of the TV to the LEFT AUDIO INPUT on the amplifier. 2) Connect a red cable from the RIGHT AUDIO OUTPUT on the back of the TV to the RIGHT AUDIO INPUT on the amplifier.
Quick Setup Connecting to a Digital TV Receiver By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in their digital form. TV Rear Panel INPUT 3 INPUT 5 / INPUT 1 AUDIO INPUT 4 S-VIDEO Y Y L PB L After the connections have been made, tighten the screw to secure the cables.
Quick Setup Connecting to an HDMI Compatible Device By connecting an HDMI compatible device, high definition pictures can be displayed on your TV in their digital form. Some HDMI devices can include DVD players, D-VHS or any HDMI compatible device. HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all digital audio/video interface.
Quick Setup Connecting to an amplifier using your optical output You can connect an amplifier that has an optical digital input terminal by using an optical digital cable from the optical output. The signal that is output can be PCM or DOLBY DIGITAL. SERVICE 75 Ω (VHF/UHF) Amplifier PHOTO VIEWER INPUT 1 INPUT 2 DIGITAL AUDIO OPTICAL OUT TV Rear Panel 1) Connect the optical cable from underneath the television to the back of the amplifier. Notes: • This terminal can only output digital audio.
Quick Setup Connecting to an AV Receiver using your television's V3 Smart Input By connecting your AV Receiver to your television's V3 Smart Input, you can watch picture sources from many different devices, without having to change or use the other input connections on your TV. This allows you to free up the other input connections so you can connect more devices to your television.
Quick Setup Step 3 – The Interactive Plug-in Menu When you turn your television on for the first time the interactive plug-in menu will appear. The plug-in menu helps you to get your TV ready to use by letting you set your preferences for: • The language in which you want the onscreen menus to appear. • Setting the TV’s clock to the correct time so your timer functions will work properly. You can choose “Auto” or “Manual” for setting the clock. • The auto tuner setup of which channels you wish to receive.
Quick Setup Auto Clock Set You may set your clock using the time data sent via broadcasting. √® Set Clock † Mode √® Auto (Analog) Channel † –– Time 10 Time Zone : 30 AM √® Atlantic D.S.T.
Quick Setup Auto Tuner Setup In auto tuner setup, the TV automatically scans through all available channels, memorizing the active ones and skipping over blank ones or channels with weak signals. This means when you scan (using the CHANNEL +/– buttons) you will receive only clear, active channels.
Onscreen Menus Using the Guide Certain symbols are used throughout this guide to help you learn about the features of your new television.
Onscreen Menus The Onscreen Menu System Your television comes with JVC’s onscreen menu system. The onscreen menus let you make adjustments to your television’s operation simply and quickly. All menus are navigated from the Main Menu at first. Detailed explanations on using each menu follow later in this guide. For information about the Interactive Plug-in Menu, see pages 22 - 24. 1. To open the onscreen menu system, press the MENU button on the remote control. The main menu will appear.
Onscreen Menus Press the MENU button Menu – + The left main menu will appear Ini tial Setup Tuner Setup External Input Picture Adj ust Sound Adj ust Clock/Ti mers Interacti ve Plug-i n Photo Viewer Auto Demo To select a menu from the main menu To enter The following menu you selected will appear π† √® Menu Press the BACK button to return to the previous menu screen Initial Setup Initial Setup 1/2 Noise Muting Auto Shut Off On Language 2/2 Off English Software Version Off Power Indicator
Onscreen Menus Press the MENU button Menu – + Ini tial Setup Tuner Setup External Input Picture Adj ust Sound Adj ust Clock/Ti mers Interacti ve Plug-i n Photo Viewer Auto Demo The left main menu will appear π† √® Menu To select a menu from the main menu To enter The following menu you selected will appear Press the BACK button to return to the previous menu screen Sound Bass Treble Balance Turn On Volume Adjust [ [ [ 00 ] 00 ] 00 ] Volume Limit Current 50 Reset Select Operate Back Back M
Initial Setup Noise Muting This feature inserts a blank black screen over channels which are not broadcasting or are too weak to be received clearly. Press the MENU button π† √® π† √® To "Initial Setup" To enter To "Noise Muting" To turn "On" or "Off" Press the MENU button when finished Initial Setup 1/2 Noise Muting On Language English Front Panel Lock Off V-Chip Set Lock Code Closed Caption Select Note: • Noise muting will not work when you operate channel summary.
Initial Setup V-Chip Your TV is equipped with V-Chip technology which enables you to block channels or content that you feel to be inappropriate for children, based on US and Canada rating guidelines. V-Chip has no effect on video signals from a DVD discs, VCR tapes or Camcorder connection. Note: Some programs, and movies are broadcast without a ratings signal. Even if you set up V-Chip ratings limits, these programs will not be blocked. See page 35 for information on how to block unrated programs.
Initial Setup US V-Chip Ratings U.S. PARENTAL RATING SYSTEMS Programs with the following ratings are appropriate for children. ❒ TV Y is Appropriate for All Children Programs are created for very young viewers and should be suitable for all ages, including children ages 2 - 6. ❒ TV Y7 is for Older Children Most parents would find such programs suitable for children 7 and above. These programs may contain some mild fantasy violence or comedic violence, which children should be able to discern from reality.
Initial Setup Setting US V-Chip Ratings Press the MENU button π† √® π† √® To "Initial Setup" To enter To "V-Chip" To operate (Password input screen will appear) Enter the password by using the 10 keypad The V-Chip main screen will appear √® π† √® Initial Setup > V-Chip On V-Chip Set US TV Ratings Set Movie Ratings Set Canadian Ratings English Set Canadian Ratings French Advanced V-Chip Rating Advanced Canadian Rating View Unrated OK Select BACK Operate Back MENU Exit To turn V-Chip "On" or
Initial Setup Movies Ratings ❒ NR – Not Rated This is a film which has no rating. In many cases these films were imported from countries which do not use the MPAA ratings system. Other NR films may be from amateur producers who didn’t intend to have their film widely released. NR (Not Rated) Programming may contain all types of programming including children’s programming, foreign programs, or adult material.
Initial Setup Canadian V-Chip Ratings ❒ E – Exempt Exempt programming includes: news, sports, documentaries and other information programming, talk shows, music videos, and variety programming. ❒ C – Programming Intended for Children Violence Guidelines: There will be no realistic scenes of violence. Depictions of aggressive behavior will be infrequent and limited to portrayals that are clearly imaginary, comedic or unrealistic in nature.
Initial Setup Unrated Programs Unrated programming refers to any programming which does not contain a rating signal. Programming on television stations which do not broadcast rating signals will be placed in the “Unrated Programming” category.
Initial Setup Set Lock Code Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes preset with a lock code of “0000”. You may change the code to any four-digit number you wish. To change the lock code, follow the steps below.
Initial Setup Closed Caption Many broadcasts now include an onscreen display of dialog called closed captions. Some broadcasts may also include displays of additional information in text form. Your television can access and display this information using the closed caption feature. To activate the closed caption feature, follow the steps below.
Initial Setup Manual Setting √® π† √® To select "Manual" for Appearance Mode To "Font Size", "Font Style", "Text/Edge Opacity", "Background Opacity", "Text Color", "Edge Color" or "Backgrond Color" To select the setting you like Font Size: Auto, Standard, Large or Small Font Style: Auto, SerifMono, Serif, SanSerifMono, SanSerif, Casual, Cursive or Small Capital Text/Edge Opacity, Background Opacity: Auto, Transparent, Translucent, Solid or Flashing Text Color, Edge Color, Background Color: Auto, White,
Initial Setup Auto Shut Off This function automatically shuts off your TV when there is no signal from the channel and no operation if the TV is on for 10 minutes.
Initial Setup Optical Out You can select the optical digital sound output, either PCM or DOLBY DIGITAL when your TV is connected to an amplifier that has DOLBY DIGITAL decoder. If you select DOLBY DIGITAL, you can enjoy listening in 5.1ch sound when watching digital broadcasts. This only effects digital channels.
Tuner Setup Auto Tuner Setup The auto tuner setup function is described on page 24 as the interactive plug-in menu. If you need to run the auto tuner setup again, follow the steps below.
Tuner Setup Channel Summary Channel summary allows you to customize the line-up of channels received by your TV. You can add or delete channels from the line-up or prevent any unauthorized viewers from watching any or all channels. Press the MENU button To "Tuner Setup" To enter π† To "Channel Summary" √® To enter A channel having the Scan mark “√” can be selected by using CH+/- (channel +/-) button. You can delete channels from the scan by removing the “√”.
Tuner Setup Channel Summary (Continued) If you want to reset the characters you set: Press the MENU button π† √® √® To To To To To π† To select "Reset" π† √® "Tuner Setup" enter "Channel Summary" enter "Station" Press the OK button to enter Press the OK button to finish Your characters are now reset Press the MENU button when finished Notes: • You can use characters for: Alphabet, numbers, marks and spaces. • It is possible to set the maximum of 500 channel labels.
Tuner Setup Find Channel Add a digital channel that does not exist in the channel map. Press the MENU button π† √® π† √® To To To To – + "Tuner Setup" enter "Find Channel" enter Tuner Setup Auto Tuner Setup Channel Summary Find Channel Find Channel Digital Antenna Level Channel Num. Tuner Diagnostic (Service Use Only) Add Add a channel using 0 to 9 0 Select Press the OK button to finish 9 OK ...
External Input HDMI Size The HDMI Size option can only be selected in the External Input menu when an HDMI 480p picture signal is being input to the HDMI terminal. This option adjusts the position when an HDMI or DVI 480p picture signal is being displayed on the screen. There are two types of HDMI 480p picture signals: 640x480 and 720x480. If the displayed picture is slightly shifted, the position can be adjusted by selecting Auto, Size1 or Size2.
External Input Video Input Label This function is used to label video input connections for the onscreen displays.
Picture Adjust Picture Settings These settings allow you to change and adjust the way the picture appears on your television. Tint Tint allows you to adjust the levels of red and green in your TV picture. Color The color function lets you make all the colors in the TV picture appear either more vivid or subtle. Picture Picture allows you to adjust the levels of black and white on the TV screen, giving you a darker or brighter picture overall.
Picture Adjust Color Management This TV supports the Color Management function to ensure dull colors are compensated to produce natural hues.
Picture Adjust Digital VNR This function can be selected to change the effect of Digital VNR. Press the MENU button π† √® π† √® π† To To To To To "Picture Adjust" enter "Digital VNR" enter select the effect you like. Digital VNR Auto Min Max Off Auto: adjusts the effect of VNR automatically. Min: adjusts the effect of VNR to minimum. Max: adjusts the effect of VNR to maximum. Off: turns the effect of VNR off.
Picture Adjust Position Adjustment Position adjustment allows you to adjust the position of the picture. Press the MENU button π† √® π† √® π † To "Picture Adjust" To enter To "Position Adjustment" To enter To adjust the position Press the MENU button to finish Operate OK Reset Back Back Menu Exit Notes: • To reset the adjustment to the center, press the OK button. • When the arrow disappears, while you are adjusting the position, the position is at it’s maximum limit.
Sound Adjust Sound Settings These settings allow you to change and adjust the sound on your television. Bass – You can increase or decrease the level of low-frequency sound in the TV’s audio with the bass adjustment. Treble – Use treble to adjust the level of high-frequency sound in your TV’s audio. Balance – Adjust the level of sound between the TV’s left and right speakers with the balance setting.
Sound Adjust Volume Limit Volume Limit allows you to set the maximum volume level. Press the MENU button π† √® π† √® To To To To 00 S o u nd "Sound Adjust" enter "Volume Limit" set the maximum volume level 01 02 B a ss Tre b l e B a l a nc e Tu r n O n Vo l u me 48 49 50 Press the MENU button to finish Ad ju st [ [ [ 0 0 ] 0 0 ] 0 0 ] Vo l u me Lim it C u r re nt 5 0 R e se t Select Operate Back Back Menu Exit Reset Reset resets all sound adjustments at once to the default settings.
Clock/Timers Set Clock The set clock function is described on page 23 as the Interactive Plug-in Menu. You can choose to set the clock automatically, or manually. If you need to set the clock again, follow the steps below. Press the MENU button π† √® π† √® To "Clock/Timers" To enter To "Set Clock" To enter When you set the clock automatically, choose "Auto (Digital)" or "Auto (Analog)" by pressing the √ or ® arrows.
Clock/Timers On/Off Timer The on/off timer lets you program your television to turn itself on or off. You can use it as an alarm to wake up, to help you remember important programs, or as a decoy when you’re not home.
Photo Viewer Photo Viewer allows you to enjoy your digital pictures stored on your USB Mass Storage Class devices. You are able to view them on this TV as high quality images. How to start the Photo Viewer 1) 2) 3) 4) Turn the power off on the device containing your photos. Switch to "PHOTO" mode if your device has a mode switch (VIDEO/PHOTO). Turn on your device containing your photos and switch to play mode to view the photos.
Photo Viewer Multi Screen Multi Screen allows you to display JPEG images that are in your digital still camera or external USB Mass Storage Class memory as "thumbnails" .
Photo Viewer Slide Show Slide Show allows you to display the images in order. π† √® To "Slide Show" To enter The Slide Show starts Press the BACK button to stop the Slide Show Notes: • To pause the Slide Show, press the OK button. To unpause, press the OK button again. • When you set the Interval Time (seconds), the image will change automatically to the next image. By default, it is 5 seconds. • Slide Show may take extra time more than setting the Interval Time, depending on the file size.
Button Functions Power Turns the TV on or off. Press the POWER button Number Buttons - 10Key Pad Use the number buttons on the remote control to move directly to a specific channel. For example, to move to channel 12: 1 (ONE) 2 (TWO) Tune Lets you decide the input channel and select it. After you press the number buttons on the remote, press the TUNE button. For example, to move to channel 12: 1 (ONE) 2 (TWO) Press the TUNE button Sub Channel The main channel sometimes has minor channels (Sub Channels).
Button Functions Input Selects the signal input source for the television: VIDEO-1, 2, 3, 4 or 5 for video devices like VCRs, DVD players, or camcorders. Press the V1, V2, V3, V4 or V5 button Notes: • When you return to TV mode, press the RETURN+/TV button or direct 10 key pad or CHANNEL +/- button. • You can also access by pressing the INPUT button on the side of the TV instead of the remote. Channel +/– Use these buttons to move up or down all the available channels your TV is able to receive.
Button Functions Sound By pressing the SOUND button, you can change the A.H.S. (Advanced Hyper Surround) and Smart Sound on or off. A.H.S. - Adds a more spacious surround sound. Music gives basic effect and movie for more effect. Smart Sound - Decreases high sound levels, giving a regulated sound level. Press the SOUND button π† √® To select "A.H.S." or "Smart Sound" To choose the setting Press the MENU when finished S o u nd A. H. S .
Button Functions Sleep Timer The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work for a total time of up to 180 minutes. When you press the SLEEP button once, the rest of the time will be displayed.
Button Functions Aspect This feature will help you adjust the picture you are watching to give you the best possible picture quality. Aspect Ratios Panorama - With this ratio a normal 4:3 aspect picture is stretched to fit the dimensions of the 16:9 aspect screen. Cinema - This ratio “zooms in” on the center part of a 4:3 aspect picture, blowing it up to fill the 16:9 screen. Full - This is the ratio to use when watching 16:9 High-Definition broadcasts.
Button Functions Aspect Ratios (Continued) Press the ASPECT button • By pressing the ASPECT button, you can change the size. When you change the aspect ratios, it is different from their broadcast or recorded program.
Button Functions ML/MTS ML/MTS technology allows several audio signals to be broadcast in analog at once, giving you a choice in what you wish to hear with a TV program. In addition to mono or stereo sound, an MTS broadcast may also include a second audio program (SAP). When you are receiving a digital broadcast, it is possible to choose a language that you wish to receive.
Button Functions Favorite The Favorite button allows you to select your favorite channels easily. First, you must register the channels that you like. See how to register below. π† Press the FAVORITE button The favorite channel list will appear. To select the channel you want to watch Press the OK button It will change to the channel you have selected.
Button Functions Mode Your remote control can be used to operate some basic functions of your external devices. To use your device, select the proper mode. Device MODE TV TV STB STB/DVR (Cable Satellite) VCR VCR/DVR DVD DVD Player (DVD Recorder) AUDIO Amplifier/Home Theater in Box Press the MODE button By every press of the Mode button, you can select the mode. TV STB VCR DVD AUDIO • The mode LED indicator on the remote control lights for 3 seconds each time the remote control is operated.
Remote Programming Remote programming You can program your remote control to operate your external devices, using the instructions and codes on pages 68 - 72. The following external devices can be operated using your remote control.
Remote Programming Programming Codes STB mode Cable Set Top Box ABC Americast Bell South Digeo Director General Instrument GoldStar Hamlin Jerrold Memorex Motorola Pace Panasonic Paragon Philips Pioneer Pulsar Quasar Regal Runco Samsung Scientific Atlanta Sony Starcom Supercable Torx Toshiba Zenith 0003, 0008 0899 0899 1187 0476 0476, 0810, 0276, 0003 0144 0009, 0273 0476, 0810, 0276, 0003 0000 1376, 0476, 0810, 0276, 1187 1877, 0237, 0008 0000, 0008, 0107 0000 1305, 0317, 0025 1877, 0877, 0144, 0533 0000
Remote Programming VCR mode VCR ABS Admiral Adventura Aiko Aiwa Akai Alienware America Action American High Asha Audiovox Beaumark Bell & Howell Broksonic Calix Canon Capehart Carver CCE Citizen Colt Craig Curtis Mathes Cybernex CyberPower Daewoo Daytron Dell Denon DirecTV Durabrand Dynatech Electrohome Electrophonic Emerex Emerson VCR 1972 0048, 0209 0000 0278 0037, 0000, 0307, 0479 0041, 0061, 0106 1972 0278 0035 0240 0037, 0278 0240 0104 0184, 0121, 0209, 0002, 0479, 1479 0037 0035 0020 0081 0072, 0278
Remote Programming VCR mode VCR Philips Pilot Pioneer Polk Audio Portland Presidian Profitronic Proscan Protec Pulsar Quarter Quartz Quasar RadioShack Radix Randex RCA Realistic ReplayTV Ricavision Runco Samsung Sanky Sansui Sanyo Scott Sears Sharp Shintom Shogun Singer Sonic Blue Sony Stack 9 STS Sylvania PVR VCR 0035, 0081, 0000, 0563, 0593, 0618, 0739, 1081, 1181, 1266 0037 0081, 0042, 0067 0081 0020 1593 0240 0060, 0202, 0760, 0761, 1060 0072 0039 0046 0046 0035, 0162, 1035, 1162 0000, 1037 0037
Remote Programming DVD mode DVD Accurian Advent Aiwa Akai Alco Allegro Apex Digital Arrgo Aspire Digital Audiovox Blaupunkt Blue Parade Broksonic Cinea Cine Vision Citizen Coby Craig Curtis Mathes CyberHome Daewoo Denon Disney Durabrand DVD2000 Emerson Enterprise ESA Fisher Funai Gateway GE Go Video GoldStar Greenhill Harman/Kardon Hitachi Hiteker Humax iLo Initial Insignia Integra JBL Jensen JVC Kawasaki Kenwood KLH Koss Lasonic Lenoxx LG LiteOn DVD Recorder DVD 1416 1016 0641 0695, 0770, 0899 0790 08
Remote Programming Audio mode Amplifier Amstrad Bose Curtis Mathes Durabrand GE Harman/Kardon JVC Left Coast Lenoxx Linn Marantz NEC Optimus Philips Pioneer Polk Audio RCA Shure Sony Soundesign Victor Wards Yamaha Receiver 0078 0674 0300 1561 0078 0892 0331 0892 1561 0269, 0282, 0829 0892, 0269 0264 0300, 0823 0892, 0269 0013, 0300, 0823 0892, 0269 0300, 0823 0264 0689, 0815, 1126 0078 0331 0078, 0013 0354, 0133 Koss Lasonic Lenoxx LG Liquid Video Magnavox Marantz Mitsubishi NexxTech Norcent Nova Onkyo Op
OSD Information Weak Signal This OSD appears when the digital channel that you have selected is too weak to receive or no signal is being detected for that channel. It also appears when Noise Muting is On and no signal is being received from an external source. No Program or Weak Signal Audio / Data Only Channel This OSD appears when the selected channel is not broadcasting any picture or sound, or is only broadcasting data information. Audio / Data Only Channel 73 LCT2275-001B-A English.
Troubleshooting Refer to the table below to check the condition. If you think that there is a problem, contact the JVC Service Center where you purchased the television. PROBLEMS There is no power There is no picture or sound CHECK • See if the power cord became unplugged. • Check for a blown fuse or circuit breaker or a power outage. • The antenna could be disconnected. • The input mode could be set improperly. See page 59. • The tuner (Auto Tuner Setup) could be set improperly. See page 41.
Troubleshooting PROBLEMS CHECK Static electricity • It is normal to feel static electricity if you brush or touch the screen. You hear occasional crackling sounds • It is normal for the TV to make crackling sounds when first turned on or off. Unless the sound or picture become abnormal, this is fine. It does not operate correctly • Press the CHANNEL- and VOLUME- buttons on the side panel of the TV simultaneously for a few seconds. The Digital Tuner will be reset.
Specifications Model LT-37X688 LT-37XM48 LT-42X688 LT-42XM48 Type LCD Flat Television Reception Format NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable Reception Range VHF 2 to 13, UHF 14 to 69 at ATSC, CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands (191 channel frequency synthesizer system) at Analog • Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers) is n
Specifications Model LT-42X788 LT-47X788 Type LCD Flat Television Reception Format NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable Reception Range VHF 2 to 13, UHF 14 to 69 at ATSC, CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands (191 channel frequency synthesizer system) at Analog • Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers) is not recommended for y
