AV-32/28EX5BK / LCT1821-001A-U / All Cover AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 2 Wednesday, April 13, 2005 5:51 PM Warning DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adaptor or consult your dealer.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 3 Wednesday, April 13, 2005 5:51 PM How to move the TV When moving the TV, make sure that it is held by two people as shown in the illustration. Be careful not to trap your hands when putting the TV down.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 4 Wednesday, April 13, 2005 5:51 PM Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: • Operate only from the power source specified (AC 220 – 240 V, 50 Hz) on the unit. • Avoid damaging the AC plug and power cord.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 5 Wednesday, April 13, 2005 5:51 PM CONTENTS Setting up your TV ...................................6 Connecting the aerial ................................. 6 To view the pay-per-view of the Digital Terrestrial broadcasting.......................... 7 Connecting the power cord to the AC outlet....................................................... 7 Putting the batteries into the remote control.............................................
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH Body_Eng.fm Page 6 Thursday, April 14, 2005 4:14 PM Setting up your TV Connecting the aerial • The connecting cables are not provided. • For further details, refer to the manuals provided with the devices to be connected. Caution • Turn off all the equipment including the TV before connecting anything. If you connect via a device with an antenna terminal such as a VCR, follow A → B → C in the diagram opposite.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 7 Wednesday, April 13, 2005 5:51 PM Setting up your TV To view the pay-per-view of the Digital Terrestrial broadcasting It is required to subscribe to a pay-per-view company to view the pay-per-views of the Digital Terrestrial broadcasting. Obtain the Conditional Access Module (CAM) and the Viewing card by subscribing to a pay-per-view company, then insert those to the Television using the following procedure.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 8 Wednesday, April 13, 2005 5:51 PM Setting up your TV Initial settings When the TV is first turned on, it goes into the initial settings mode, and you will see the JVC logo. Follow the instructions on the screen display to make the initial settings. 7 buttons 1 Press the Main power button on the TV The Power lamp lights green and the JVC logo is displayed.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 9 Wednesday, April 13, 2005 5:51 PM Setting up your TV 3 Press the H button The Analogue terrestrial broadcasting AUTO PROGRAM starts. The AUTO PROGRAM menu appears and received TV channels are automatically stored in the programme numbers (PR).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 10 Wednesday, April 13, 2005 5:51 PM Setting up your TV Downloading the data to VCR You can transmit to the latest Analogue terrestrial broadcasting Programme numbers (PR) data to a VCR with the T-V LINK function. • This only works when a T-V LINK compatible VCR is connected to the EXT-2 terminal. • This only works when the T-V LINK menu is being displayed.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 11 Wednesday, April 13, 2005 5:51 PM Setting up your TV Direct Rec “What You See Is What You Record” When the VCR is not ready, the following messages are displayed. You can easily record to VCR the images that you are watching on the TV. ERROR MESSAGE Cause and countermeasure For details, read the manual for your VCR. Use your VCR controls. “DEVICE IS RECORDING” is displayed. NO RECORDING The VCR is not able to record.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 12 Wednesday, April 13, 2005 5:51 PM Basic operations (TV) Turn the Main power on Press the Main power button on the TV. The Power lamp lights red and your TV is in the standby mode. • If the power lamp lights green, the TV is already on. To turn the Main power off: Press the Main power button again. The Power lamp goes off. Caution • The main power button on the TV does not fully isolate the TV from the AC supply.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 13 Wednesday, April 13, 2005 5:51 PM Basic operations (TV) Choose a TV channel Press the P p buttons to choose a programme number (PR) or an EXT terminal The EXT terminal cannot be chosen when watching Digital terrestrial broadcasting (DVB-T). Switching between Digital terrestrial broadcasting (DVB-T) and Analogue terrestrial broadcasting. 1 Press the r (Volume) button once The volume level indicator appears.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 15 Wednesday, April 13, 2005 5:51 PM Basic operations (Remote control) Turn the TV on or off from standby mode Press the # (standby) button to turn the TV on or off. When the TV is turned on, the power lamp lights green. • The power can be turned on by pressing the TV/DTV button, p p buttons or Number buttons. To turn the TV on or off, set the VCR/TV/ DVD switch on the remote control to the TV position and press the # button.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 16 Wednesday, April 13, 2005 5:51 PM Basic operations (Remote control) To return to a TV channel: Press the TV/DTV button, the p p buttons or the number buttons. To use the programme number PR 0 (AV): When the TV and VCR are connected only by the aerial cable, choosing the programme number PR 0 (AV) allows you to view images from the VCR. Set the VCR RF channel to the programme number PR 0 (AV) manually.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 17 Wednesday, April 13, 2005 5:51 PM Basic operations (Remote control) PANORAMIC: This stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the screen, without making the picture appear unnatural. “This mode may result in information such as headlines or rolling text at the very top or bottom of the screen not being fully viewable on some programmes.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 18 Wednesday, April 13, 2005 5:51 PM Basic operations (Remote control) • The visible area adjustment is saved even after the TV channel is changed. However, it is cancelled if the following operations are performed.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 19 Wednesday, April 13, 2005 5:51 PM Operation while watching DTV Information function When the h (Information) button is pressed, the programme information appears for approximately 1 minute. ITV News 41 CH61 Now: 13:00-14:00 Steve Scott 13:19 Next: 14:00-14:30 Steve Scott Using the Electronic Programme Guide (EPG) The EPG screen appears when the GUIDE button is pressed while watching Digital terrestrial broadcasting (DVB-T).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 20 Wednesday, April 13, 2005 5:51 PM Operation while watching DTV Using the Set Reminder 1 Press the 6 buttons and choose the date from the Date column When the TV is being watched, it automatically changes to the channel of the scheduled programme when the start time of the scheduled program is reached. • The scheduling function does not work when the TV is turned off.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 21 Wednesday, April 13, 2005 5:51 PM Operation while watching DTV Using the Genre function By using the Genre function you can sort programmes by genre. 1 Press the green button The Genre window appears. 2 Press the 6 buttons and choose the genre 3 Press the a button The selected genre programme appears on the Programme column. Cancelling the Genre function. Display the Genre window and choose “All” for the genre.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 22 Wednesday, April 13, 2005 5:51 PM Digital Teletext function 1 Press the g button The digital teletext information appears. BBC ONE Powers For a full list of sections, press SELECT VCR/TV/ DVD switch Contact info CBeebies Home Music Taking Care NEWS SPORT WEATHER MAIN MENU Number buttons Colour buttons 7 buttons With Digital terrestrial broadcasting (DVBT), in addition to pictures and sound, you can also watch digital teletext.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 23 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Buttons used to operate the menus TV/DTV Displaying the DTV menu 1 Press the H button to display the MENU (main menu) MENU PICTURE SETTING EXT SETTING PICTURE FEATURES FEATURES SOUND SETTING INSTALL 3D CINEMA SOUND DTV OK D5105-EN • DTV in the menu bar can only be chosen when watching Digital terrestrial broadcasting (DVB-T).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 24 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu 1 Choose Timers and press the a button The TIMER menu appears. REC TIMER No.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 25 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu The TV power lamp begins flashing at three minutes before the timer start time. If you are watching TV at the time, a message appears on the screen to inform you the timer is about to start. If the TV is in Standby, the power lamp lights orange while timer recording is in progress.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 26 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Subtitle language Configuration Set the basic setting for watching Digital terrestrial broadcasting (DVB-T). With Digital terrestrial broadcasting (DVBT), a number of subtitles can be broadcast at the same time. Choose the subtitle you want to display when watching these broadcasts. Choose configuration and press the a button CONFIGURATION appears.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 27 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Receiver Upgrade Set the method to upgrade the Digital terrestrial broadcasting (DVB-T) receiver software. 1 Press the 6 buttons and choose Receiver Upgrade, and press the a button The setting window appears. CONFIGURATION Audio Language Subtitle Favourite Mode Receiver Upgrade Enter PIN code Automatic Download Search for New Version English English Off V.3.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 28 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Choosing a channel Edit PR List The Edit PR List can be used to do the following: • delete registered channels • edit channel names • lock channels so that they cannot be watched by children • set Favorites so that you can easily choose from only the channels you often watch. Choose Edit PR List and press the a button EDIT PR LIST appears.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 29 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Editing a channel name 1 Press the 5 buttons and choose Edit Name on the bar at the bottom of the screen 2 Press the 6 buttons and choose the channel to be edited, and then press the a button The edit window appears. 2 2 Press the 6 buttons and choose the channel to be locked, and then press the a button The Enter PIN code input window appears.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 30 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu Setting the favourite channels Channels that you often watch can be set as favourite channels. You can choose from just those channels when the p p buttons are pressed. • After setting the favourite channels, check that “Favourite Mode” in “Configuration” (see page 26) is set to ON.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 31 Wednesday, April 13, 2005 5:51 PM Operation with the DTV menu First Time Installation: Choose when you have moved house etc and want to automatically re-register all the channels. In addition to registering all the channels that can be received, it will reset the timer settings. When Factory Settings is chosen and the a button is pressed, the confirmation window appears.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 32 Wednesday, April 13, 2005 5:51 PM Operation while watching analogue TV Information function You can see the channel number of the programme you are watching, the current time or the PR LIST. From the PR LIST, you can choose a channel or EXT terminal. Press the h (Information) button to display the information you want to see.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 34 Wednesday, April 13, 2005 5:51 PM Analogue teletext function Using the List Mode You can store the numbers of your favourite teletext pages in memory and call them up quickly using the colour buttons. To store the page numbers: 1 Press B button to go into the List mode The page numbers you have stored are displayed at the bottom of the screen. 2 Press a colour button to choose a position.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 35 Wednesday, April 13, 2005 5:51 PM Analogue teletext function Size You can double the height of the teletext display. Press the F (Size) button Index You can return to the index page instantly. Press the G (Index) button Returns to page 100 or a previously specified page. Cancel You can search for a teletext page while watching TV.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 36 Wednesday, April 13, 2005 5:51 PM Setting the TV Call the menu and perform the settings for the picture and sound.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 37 Wednesday, April 13, 2005 5:51 PM PICTURE SETTING Refer to “Setting the TV” (see page 36) for details of displaying the menu. PICTURE SETTING PICTURE MODE CONTRAST BRIGHT SHARP COLOUR HUE COLOUR TEMP. BRIGHT NORMAL RESET OK D0014-EN PICTURE MODE You can choose one of three PICTURE MODEs to adjust the picture settings automatically. BRIGHT: Heightens contrast and sharpness. STANDARD: Standardizes picture adjustment.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 38 Wednesday, April 13, 2005 5:51 PM PICTURE FEATURES Refer to “Setting the TV” (see page 36) for details of displaying the menu. PICTURE FEATURES DIGITAL VNR DigiPure Pro COLOUR SYSTEM MOVIE THEATRE 4:3 AUTO ASPECT PICTIRE TILT AUTO AUTO AUTO OK D1015-EN • COLOUR SYSTEM cannot be chosen when watching Digital terrestrial broadcasting (DVB-T). DIGITAL VNR The DIGITAL VNR function cuts down the amount of noise in the original picture.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 39 Wednesday, April 13, 2005 5:51 PM PICTURE FEATURES MAX: The level of DigiPure effect is set to the maximum. If you set the DigiPure Pro function to AUTO but feel that the original picture quality has not been reproduced fully, change the setting from AUTO to MAX. • The MAX setting is not suitable for lowquality pictures which contain a lot of noise. • The AUTO function may not function properly if you have poor signal quality.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 40 Wednesday, April 13, 2005 5:51 PM PICTURE FEATURES 4:3 AUTO ASPECT You can choose one of three ZOOM modes, REGULAR, PANORAMIC or 14:9 ZOOM, as the ZOOM mode for the normal picture (4:3 aspect ratio). 1 Choose 4:3 AUTO ASPECT then press the a button 4:3 AUTO ASPECT PANORAMIC REGULAR 14:9 ZOOM OK D0017-EN 2 Press the 6 buttons to choose a ZOOM mode.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 41 Wednesday, April 13, 2005 5:51 PM SOUND SETTING Refer to “Setting the TV” (see page 36) for details of displaying the menu. Sound Adjustment You can adjust the sound to your liking. SOUND SETTING STEREO/ BASS TREBLE BALANCE HYPER SOUND OFF ON OK D0019-EN STEREO / I • II When you are viewing a bilingual broadcast programme, you can choose the sound from Bilingual I (Sub I) or Bilingual II (Sub II).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 42 Wednesday, April 13, 2005 5:51 PM 3D CINEMA SOUND Refer to “Setting the TV” (see page 36) for details of displaying the menu. 3D CINEMA SOUND SURROUND BASS BOOST HIGH HIGH MID MID LOW LOW OK D0063-EN Adjust the 3D CINEMA SOUND effect. For details on how to turn 3D CINEMA SOUND on and off, read “3D CINEMA SOUND function” (see page 18). • In order to experience true 3D CINEMA SOUND, the audio needs to be stereo sound.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 43 Wednesday, April 13, 2005 5:51 PM EXT SETTING Refer to “Setting the TV” (see page 36) for details of displaying the menu. EXT SETTING EXT-1 DUBBING EXT-2 EXT-3 TV DTV ID LIST OK S-IN D0020-EN S-IN (S-VIDEO input) When connecting a device (such as S-VHS VCR) which enables an S-VIDEO signal (Y/ C signal) to be output, you can enjoy highquality picture of the S-VIDEO signal (Y/C signal).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 44 Wednesday, April 13, 2005 5:51 PM EXT SETTING 3 Press the 6 buttons to choose a name. Then press the a button The ID LIST disappears and the name is assigned to the EXT terminal. • You cannot assign an EXT terminal name not found in the name list (ID LIST). To erase a name assigned to the EXT terminal: Choose a blank space.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 45 Wednesday, April 13, 2005 5:51 PM FEATURES Refer to “Setting the TV” (see page 36) for details of displaying the menu. FEATURES SLEEP TIMER BLUE BACK CHILD LOCK DECODER(EXT-2) OFF ON OFF ON OK D0023-EN • BLUE BACK, CHILD LOCK, and DECODER (EXT-2) cannot be chosen when watching Digital terrestrial broadcasting (DVB-T). You can set the TV to automatically turn off after a specified period of time.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 46 Wednesday, April 13, 2005 5:51 PM FEATURES 3 Press the a button The Sub-menu of CHILD LOCK appears. CHILD LOCK PR AV 01 02 03 04 05 06 07 08 09 ID CH BBC1 BBC2 ITV CH4 CH5 CH CH CH CH CH CH CH CH CH 21 22 23 24 25 26 27 28 29 2 Press the h (Information) button while the n (CHILD LOCK) is displayed The “ID NO.” (ID NO. input screen) appears. 5 ID NO .
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 47 Wednesday, April 13, 2005 5:51 PM FEATURES DECODER (EXT-2) Only when connecting a Decoder with a T-V LINK compatible VCR connected to the EXT-2 terminal, you can use this function. Caution • If you have not connected a Decoder with a T-V LINK compatible VCR connected to the EXT-2 terminal, setting this function to “ON” by mistake causes the picture/ sound of a TV channel you are currently viewing not to be issued.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 48 Wednesday, April 13, 2005 5:51 PM INSTALL Refer to “Setting the TV” (see page 36) for details of displaying the menu. INSTALL AUTO PROGRAM EDIT / MANUAL OFF ATTENUATOR 2 Press the a button to display the T-V LINK menu T-V LINK DOWNLOAD ON TV RECORDING DEVICE OK OK D0029-EN EXIT • AUTO PROGRAM and EDIT/MANUAL cannot be chosen when watching Digital terrestrial broadcasting (DVB-T).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 49 Wednesday, April 13, 2005 5:51 PM INSTALL EDIT/MANUAL The EDIT/MANUAL functions are divided into two types: editing of the current Programme numbers (PR) (EDIT functions) and manual registration of a TV channel you want to view to the Programme number (PR) (MANUAL function). The details about these functions are as follows: Caution • Using the MOVE, DELETE or INSERT function rewrites the current Programme numbers (PR) list.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 50 Wednesday, April 13, 2005 5:51 PM INSTALL 4 If you do not have a T-V LINK compatible VCR connected: Press the TV/DTV button to exit the T-V LINK menu. The T-V LINK menu disappears and all the settings are completed. If you have a T-V LINK compatible VCR connected to the EXT-2 terminal: Follow the operating procedure “Downloading the data to VCR” on page 10 to transmit the Programme number (PR) data to the VCR.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 51 Wednesday, April 13, 2005 5:51 PM INSTALL 5 Press the 6 buttons to choose the Channel name (ID) To cancel the ID function: Press the b button. 6 Press the a button to register a Channel name (ID) to a TV channel • You can register your unique Channel name (ID) to the TV channel.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 52 Wednesday, April 13, 2005 5:51 PM INSTALL 3 Press the green or red button to search for a TV channel Scanning stops when the TV finds a TV channel. Then the TV channel is displayed. 4 Press the green or red button repeatedly until the TV channel you want appears If the TV channel reception is poor: Press the blue or yellow button to finetune the TV channel.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH Body_Eng.fm Page 53 Thursday, April 14, 2005 4:14 PM Additional preparation Connecting the external devices Connect the devices to the TV, paying attention to the following connection diagram. Before connecting anything: • Read the manuals provided with the devices. Depending on the devices, the connection method may differ from the figure. In addition, the device settings may be changed depending on the connection method to secure proper operation.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 54 Wednesday, April 13, 2005 5:51 PM Additional preparation Equipment which can output the S-VIDEO signal (Y/C signal) Connect the equipment to an EXT terminal (but not the EXT-1 terminal). You can choose between an S-VIDEO signal (Y/C signal) and a regular video signal (composite signal). For details of how to operate the equipment, see “S-IN (S-VIDEO input)” on page 43.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 55 Wednesday, April 13, 2005 5:51 PM Additional preparation Connecting Speakers/Amplifier While referring to the Audio equipment connection diagram, connect the audio equipment you desire to the TV. You can use external front speakers to listen to the TV sound instead of the TV speakers. Before connecting anything: • Read the manuals provided with the amplifier and speakers. • Turn the TV and Amplifier off.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 56 Wednesday, April 13, 2005 5:51 PM CH numbers When you want to use the INSERT function on page 51, find the CH number corresponding to the Channel number of the TV channel from this table.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 57 Wednesday, April 13, 2005 5:51 PM Troubleshooting Digital terrestrial broadcasting (DVB-T) service area Although this TV can receive both Digital terrestrial broadcasting (DVB-T) and Analogue terrestrial broadcasting, depending on the area in which you live, you may not be able to receive Digital terrestrial broadcasting (DVB-T).
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 58 Wednesday, April 13, 2005 5:51 PM Troubleshooting • If the TV suffers interference from signals reflecting from mountains or buildings, double-pictures (ghosting) will occur. Try to change the aerial’s direction or replace it with one with better directionality. • Are your COLOUR SYSTEM settings correct? Follow the description “COLOUR SYSTEM” on page 39 to try to solve the trouble.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH Body_Eng.fm Page 59 Friday, April 15, 2005 5:25 PM Troubleshooting • A picture may be tilted due to the influence of the earth’s magnetism. In this case, use the “PICTURE TILT” on page 40 to complete the tilt. • Touching the screen may cause you feel a slight electric shock due to its static electricity. It is an unavoidable phenomenon due to the construction of the picture tube. It is not a problem with the TV.
AV-32/28EX5BK / LCT1821-001A-U / ENGLISH AV-32&28EX5BK_Eng.book Page 60 Wednesday, April 13, 2005 5:51 PM Specifications Item Model AV-32EX5BK AV-28EX5BK Broadcasting systems CCIR, I Colour systems PAL • The EXT terminals also support the NTSC 3.58/4.43 MHz system.
AV-32/28EX5BK / LCT1821-001A-U / All Cover AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / All Cover AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / All Cover AV-32&28EX5BK_Eng.
AV-32/28EX5BK / LCT1821-001A-U / All Cover AV-32&28EX5BK_Eng.
