User's Manual

User Manual

1. General Specification List

GENERAL HEADSET FEATURES

Standards Bluetooth Specification VR4.1

Stereo Portable (A2DP) Support

Bluetooth Headset Profile(HSP) Support

Bluetooth Hands Free Profile(HFP) Support

Bluetooth AVRCP Profile AVRCP Support

Theoretical range in open field >10m no obstructer

Re-program the firmware Yes (Using the Tst Jig through SPI interface)

Battery type power 3.7V,185mAh Lithium polymer Battery (type)

Stand By (Paired mode)/talk 300hrs/ 9hrs

ANC Power on//BT talk 6hrs

VOL‐

MFB

VOL‐

ANCPoweron/Poweroff

MIC

USB

PAGE 1
User Manual VOL‐ ANC Power on/Power off MFB VOL‐ USB MIC 1. General Specification List GENERAL HEADSET FEATURES Standards Stereo Portable Bluetooth Specification (A2DP) Support Bluetooth Headset Profile(HSP) Support Bluetooth Hands Free Profile(HFP) Support Bluetooth AVRCP Support Profile VR4.1 AVRCP Theoretical range in open field >10m no obstructer Re-program the firmware Battery type power Yes (Using the Tst Jig through SPI interface) 3.
PAGE 2
Antenna Ceramic antenna Input Battery Micro USB In (charging) Type Power Complete charge time 2.Operation Lithium Polymer 3.7 V，185mAh <2hrs Indication Button Action Operation Press once Increase Volume Press and hold Next Song Press once Decrease Volume Press and hold In Song Press once Play/Pause MFB Press and hold for 1.
PAGE 3
Not charging (not plugged into power source)/low battery Power Off n/a 3. Power Source/Electrical Requirements 3.1 3.7V 185mAh (two 150mAh Lithium Ion rechargeable batteries) FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
