2 3 1 Music List Displays a music list of the current position. Press and hold the [ ] next to the desired music to delete a file, add to the play list, or add to the current play list. 2 Sort by List You can select the music list sorting method as ‘ALL/MQS/DSD/Ripping’. You can select the music list sorting method as ‘Bit/Sample Rate’. 3 Add-ons List Displays the add-ones window of the music lists. The functions are displays differently by music retrieval scheme. 4 : Copies the file.
Music playback screen 1 2 3 4 5 6 78 5 Lyrics 6 Sound Set Displays the sound set(EQ, etc.) screen. Displays the lyrics. 7 Gap-less 8 Current Playlist Displays the current playlist. 9 Progression Displays the state of the progress. State Bar 9 Turns on/off the gab-less. If you move the position of the bar, it moves to where you want. 10 11 12 13 14 15 16 10 Play Time 11 Play Mode Sets the play mode. 12 Previous Displays the total duration of the song.
Listening to music Select Music Listening to Music 1. Select a music retrieval method from the menu located on the left to display the music list for that classification. 2. Press the music to play on the music list that appears on the screen to play music. - Turn the [Volume Wheel] to adjust the volume. - Press [ ] to pause, and [ ] to restart during playback. - Press [ / ] to play the previous/next music during playback.
Ripping the CD Ripping the CD Automatically Ripping the CD Manually 1. Insert the CD into the CD insertion slot of the product 2. Import the metadata information of the CD that is inserted in the Grace Notes. 3. When you have finished importing the information, CD ripping starts. 4. When ripping is complete and if you press [OK] in the results window, the CD automatically comes out from the insertion slot. You can select auto/manual ripping from [Settings- CD Ripping- Automatic CD Ripping]. 1.
CD Ripping Results - : Tells CD Ripping is successfully completed. : Indicates a failure of CD ripping, because of a physical scratch generated in the CD, etc. : Tells an error occurred, but CD ripping is completed through error correction. To recall the Grace Note DB data, DPF11 has to be connected to the network before ripping. Refer to page 56 for the network connection method. Set the location of the ripped file from [Settings-CD Ripping].
Managing the current playlist Adding the song in the current playlist to the playlist Changing the music order of the current playlist 1. Press [ ] next to the song, and select [ ]. 2. You can add the selected songs to your playlist. - Add a playlist: Create a new playlist and add the songs you selected. - Add to the playlist: Select the playlist to add the songs that you selected to the list. 1. Press [ ] next to the song. 2.
Managing the playlist Creating the Playlist 1. If you select [Playlist] from the left menu, the playlist is displayed. 2. Select [Playlist], and press [Add Playlist] at the top. 3. If you set the name of the playlist, and click [OK], a new playlist will be added. Add a playlist to the current playlist 1. Press [ ] next to the desired playlist from the playlist, and select [ ]. 2. Select the location you want to add. - Add after the current playlist: Adds the selected playlist at the end of the playlist.
Adding music to playlists 1. A playlist is displayed, if you press [Add Song] on the top of the playlist. 2. Check a select box in front of the music you want to add, and press [Add], then the selected music will be added to the playlist. Deleting a playlist 1. Press [ ] next to the desired playlist from the playlist, select [ ] and press [OK], then the selected playlist will be deleted. Changing the name of the playlist 1.
Adding a song in the playlist to the current playlist 1. Select the desired playlist from the playlist, and select [ ] next to the song you want to add. 2. Press [ ], and select the location you want to add. - Add after the current playlist: Adds the selected playlist at the end of the playlist. - Add after the currently playing song: Adds the selected playlist after the current playing song.
Searching files Searching files Managing Files Managing files Moving Folders 1. Select [ ] next to the folder you want to copy. 2. Select [ ], and press [Paste]. Then the selected folder will be copied. 3. You can make a new folder by pressing [New Folder]. 1. Select [ ] next to the folder you want to move. 2. Select [ ], and press [Paste]. Then the selected folder will be moved. 3. You can make a new folder by pressing [New Folder]. 1.
Deleting folders 1. Select [ ] next to the folder you want to delete. 2. If you press [ ] on the music list add-ons window, the selected folder will be deleted. Adding to the playlist 1. Select [ ] next to the folder you want to add to the playlist. 2. Select [ ] on the music list add-ons window, then select the list you want to add. 3. If you press [OK], the selected file will be added to the playlist.
Adding to the current playlist 1. Select [ ] next to the file you want to add to the current playlist. 2. If you select [ ] on the music add-ons window, the selected file will be added to the current playlist. Changing a name 1. Select [ ] next to the folder you want to change the name. 2. If you select [ ] on the music add-ons window, a name-changing window will be displayed. 3. If you press [OK], the folder name will be changed. The name can be changed only if you select one folder.
MQS streaming You can play or download the music from a PC on the same network via DPF11 in real time. Installing MQS Streaming Server Choosing MQS Streaming Server 1. Download MQS Streaming Server from [Support > Download of http://www.astellnkern.com/] depending on the version of the PC. 2. After running the setup file, install it according to the installation guide screen. 3. You can check the using method for MQS Streaming Server via the Help in the Server Program. 1.
Wireless Control PP 1. You can operate this product wirelessly through the application. 2. Recommended Control APP: Android(BubbleUPnP) / iOS(Sitecom Media Controller, Network Audio Remote) 3. You can download relevant applications from Google Play Market and Apple App Store. For the use method of applications, please refer to the help for the application. In order to connect to Network Server and Network Player, DPF11 and the product you want to connect must be connected in the same network.
Purchasing music in the store Purchasing music 1. Connect DPF11 to the network. 2. If you press [Store] in the menu, and select ‘Groovers’ from the list appears, the APP will be activated. 3. You can check the using method through the user guide and help in the STORE. For the network connection method, refer to page 56. The currently supported STORE is ‘Groovers’. ‘Groovers’ of the store menu is displayed if you currently select [Setting> Date and Time > GMT+09:00, Korea Standard Time].
Using USB DAC function USB DAC function is a function to recognize DPF11 via a sound card and listen to sound through the earphone port of DPF11. USB DAC Specifications - Supported USB DAC OS + Windows XP (32bit) / Windows 7 (32bit / 64bit) / Windows 8 (32bit / 64bit) / Mac OS 10.7 (Lion) or later - USB DAC Support Specifications + Supported formats: WAV, FLAC, WMA, MP3, OGG, APE (Normal, High, Fast), AAC, ALAC, AIFF, DFF, DSF + Sample Rate: 44.
Installing USB DAC 1. Set [Settings-Connecting USB] as [DAC input]. 2. Connect the product and a PC by using a USB cable for data transfer. 3. Run the ‘Setup.ext’ file on the Driver. 4. Press [Next] if the following screen appears. - When the following screen appears, please check if [SettingsConnecting USB] is set as [DAC Input]. 5. Press [Browser] to set the folder to install the driver, and then press [Install]. 6. If the following screen is displayed, press [Finish] to complete the installation.
7. According to the operating system, you can change the default device to output the sound with the following methods: - XP: Change the default sound playback device to [DPF11 USB DAC] from ‘Control Panel> Sounds and Audio Device’. - 7/8: Select [DPF11 USB DAC] from ‘Control Panel>Sound>Playback’ tab, and select [Set as Default Device] on the bottom. - MAC OS X: Select the Output tab from the sound menu under the System Preferences, and select [DPF11 USB DAC].
Using bluetooth Bluetooth on/off Pairing Bluetooth 1. Please refer to the instruction manual of the Bluetooth remote control handset for a pairing. 1. Select the Bluetooth remote control you want to pair from the list you can use. Supported Bluetooth Specifications - Supported profiles: A2DP (Only Bluetooth remote control can be connected.) Do not turn off the power during the Bluetooth connectivity. If Bluetooth is malfunctioning, turn off the power of the Bluetooth device, and turn it on again.
Settings You can manually set your own production environment. Set menu structure may vary depending on the firmware version. Settings 1. Select [DPF11-Settings] on the home screen. 2. Set by selecting the desired item. You can also select the setting menu by selecting [ ] on the top, or [Notification bar] screen at the bottom of the screen. Ethernet Connect of disable the wired network. - Auto IP: IP is set automatically. - Manual IP: Set by directly entering information such as IP address, DNS.
Sound Equalizer: Set the equalizer to suit your tastes. - PRO EQ: Recommend Preset EQ by experts - USER EQ: Change the height of the equalizer on your tastes Sound In/out: Connect or disconnect Sound in/out If Sound In/Out is connected to Digital In(Coax, OPT, AES /EBU, BNC), you cannot output the sound as ‘Digital Out’. - If you select ‘Digital In’ on the ‘Sound In/Out’ select screen, you cannot select ‘Digital out’.
Screen Screen Brightness: Set the brightness of the screen. Screen Off: Set the screen off time in 6 steps. Language Set the language. - Korean, English, Japanese, Chinese(Simplified/ Traditional), German are supported. Server/Player MQS Server/Player Setting : Set Network server & player specific features. - 500N Server : If you turn off the network server, DPF11 is not found in other product. - Network Server Name : Set the name of the server.
Update System Update: Updates the system when there is a new update. System Information System Information: You can check the model number of the product, Firmware version, Memory usage information, the license of the product, and you can munt the microSD card/USB Storage or delete the data. Initialization Database Initialization: Initialize the database within the product. The database initialization time may be longer depending on the number of products within the file.
Connecting to the network Connecting to a wireless network Connecting to a wired network 1. If you press and hold [ ] in the notification bar, or turns on [Settings – Wireless Network], the AP lists of available connection appear. 2. If you choose the AP to connect, the wireless network will be connected. - You may need to type the key index and network key according to the AP setting. 3. If you press and hold [Modify Network] with the connected AP, you can modify the AP history. 1.
Setting the equalizer Setting the equalizer 1. Activate the equalizer menu at [Settings – Sound – Equalizer]. 2. Press [PRO EQ] on the bottom. 3. Select [Create] on the bottom. 4. Set the name of the equalizer, and select [OK]. 5. Set by changing the height of the equalizer to suit your tastes.
Reset Equalizer Renaming the equalizer 1. Press [ ] to reset the equalizer. 1. Press [Rename] on the bottom of the equalizer, and type a new name. 2. If you press [OK] after typing a new name of the equalizer, the name of the equalizer will be changed. Deleting Equalizer 1. Select the equalizer you want to delete. 2. Press [Delete] on the bottom of the equalizer, and press [OK] to delete the selected equalizer.
Trouble shooting Check! 1. The device won’t turn on. Please check if the power supply is correctly connected. 2. The operation of the product is unstable. If you press and hold the power button on the side longer than 10 seconds, the product will be turned off. Please turn on the product again and check. 3. The screen turns off repeatedly. After a certain period time, the screen turns off to reduce power consumption when playing the file. Set the time on [Settings – Power- Screen off]. 4.
