Before You Begin Before You Begin This section provides you with safety information, technical support information, and sources for additional product information. Safety Information Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do not follow the safety warnings and cautions.
Before You Begin Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com and click Service & Support > Warranty. Web Support Visit the Intermec web site at www.intermec.com to download our current manuals (in PDF). To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Visit the Intermec technical knowledge base (Knowledge Central) at intermec.custhelp.
Before You Begin Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local representative, from the Intermec web site, click Contact. Service Location Support For the most current listing of service locations, click Support > Returns and Repairs > Repair Locations. For technical support in South Korea, use the after service locations listed below: AWOO Systems 102-1304 SK Ventium 522 Dangjung-dong Gunpo-si, Gyeonggi-do Korea, South 435-776 Contact: Mr.
Before You Begin 2 Click Support > Manuals. 3 In the Select a Product field, choose the product whose documentation you want to download. To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Patent Information This product is protected by one or more of the following United States patents: 5,581,293; 5,613,790; 5,927,876; 6,088,049; 6,345,920 There may be U.S. and Foreign Patents Pending.
Before You Begin xiv 6822 Series 80-Column Printer User’s Manual
1 Using the Printer Use this chapter to familiarize yourself with the 6822 printer.
Chapter 1 — Using the Printer Learning About the Printer Models The 6822 printer is used in the route accounting industry to produce high-quality customer invoices, receipts, load reports, transfers, and other documents. A unique “sleep” feature saves energy when the printer is not printing, eliminating the need for an ON/OFF switch. Data input is normally provided by hand-held or mobile computers.
Chapter 1 — Using the Printer Guidelines for Operating the Printer • Make sure that you mobile computer remains connected to the printer when printing or operating. • Keep the printer cover closed except during maintenance or when loading paper. • Make sure the paper is properly installed in the paper tray or dashboard mount. • Disconnect the printer power cable when jump-starting the vehicle. • Make sure your printer is loaded with paper before communicating with your mobile computer.
Chapter 1 — Using the Printer Understanding the Status Indicators (continued) Description Indicator Description Power The power LED turns green when you press any button and goes off after ten seconds.
Chapter 1 — Using the Printer • force a synchronization between the printer and a connected PC when sending control codes • restart the printer for any reason Note: The reset button does not reset a connected Bluetooth module as it is powered from a different power source. Both the fixed mount printer and the portable printer have a reset button on the left-hand side of the raised printer mechanism. See the following illustration for the location of the reset button.
Chapter 1 — Using the Printer Understanding the Power Supply Options The following power supply options are available for the 6822s. Using the Internal Battery The internal battery (P/N 317-075-001) allows the portable printer and some fixed mount printers to operate independently of other power sources. The 6822 discharges the internal battery even when the printer is not is use. Over time, the internal battery can discharge to the point where the battery is not recoverable.
Chapter 1 — Using the Printer Connecting to a DC Power Source Each printer has a dc power jack that connects the printer to a power source, such as the vehicle battery or an external power supply. Each printer communicates with a mobile computer through the mobile computer socket (in terminal holder, remote terminal holder, or vehicle dock). Fixed Mount Printer The dc power connector is on the bottom rear of the printer behind the printer terminal holder.
Chapter 1 — Using the Printer DC Power connector Mobile computer socket Fixed Mount Printer Mobile computer socket DC Power connector Portable Printer 6822 Printer Models 8 6822 Series 80-Column Printer User’s Manual
2 Installing the Printer This chapter provides instructions how to set up the 6822 printer for the first time.
Chapter 2 — Installing the Printer Installing the Internal Battery The optional internal battery is primarily for portable printers. The battery can go in some fixed mount printers using a cable and a factoryinstalled adapter. The printer battery recharges automatically when the printer is connected to an external power source. For most installations, the external power source is passed through the printer to the mobile computer. The printer battery does not provide charge to the computer.
Chapter 2 — Installing the Printer Installing the Ribbon Cartridge Make sure there is a ribbon cartridge in the printer before you print and that the ribbon is fully seated (the cartridge makes a distinct “snap” or “click” when properly seated) with the visible portion of the ribbon straight and even. To install the ribbon cartridge 1 Turn the ribbon advance knob (in the direction of the raised arrows) to remove any slack in the ribbon.
Chapter 2 — Installing the Printer Adjusting the Printhead Gap The head gap adjuster is near the printer mechanism on the side opposite the green thumb wheel. The printhead adjuster has five notches between the printhead and the platen for different paper thicknesses. Verify the thickness of the paper loaded into the printer. To adjust the printhead gap • If you are using single-sheet forms, set the head gap adjuster to the third notch away from the paper.
Chapter 2 — Installing the Printer Loading the Paper Tray Note: Do not exceed the recommended amounts of paper quantity or thickness. When loading multiple-sheet paper, be sure to have the original faced up, with the leading edge towards the rear of the printer. To load the paper tray in fixed mount and portable printers 1 Unlatch and raise the printer mechanism. 2 Lower a stack of paper, with the original faced up, into the paper tray under the printer mechanism.
Chapter 2 — Installing the Printer 2 Take the top edge of the sheet of paper and position it, original side facing down, over the pinfeed holder pins. 3 Align the first few holes of the paper, on each side of the paper, onto the pinfeed holder pins. 4 Close the pinfeed holders. 5 Raise the paper bail. 3 1 4 2 5 Positioning the paper Adjusting the Pinfeed Holders Note: There are two pinfeed holders, one next to the green thumb wheel and one opposite the same wheel.
Chapter 2 — Installing the Printer 2 Adjust the pinfeed holder position so that the pins align with the paper. 3 Close the pinfeed holder. 4 Ensure that the paper is smooth (no folds, bulges, bows, etc.) between the pinfeed holders. If so, push the locking tab down on the pinfeed holder that you adjusted.
Chapter 2 — Installing the Printer Note: If your paper has a preprinted logo on every page, make sure the printhead is below the preprinted logo. If not, you can adjust the position of the paper, either by pressing the Line Feed button, or by using the green thumb wheel. 3 Once the paper is properly positioned, press the Set Page button to clear the Paper Out light and indicate where the top of the page is. 4 Close the printer lid.
Chapter 2 — Installing the Printer 4 Slide the computer to fully seat it in the docking connector.
Chapter 2 — Installing the Printer 18 6822 Series 80-Column Printer User’s Manual
3 Maintaining the Printer Use this chapter maintain your 6822 printer.
Chapter 3 — Maintaining the Printer Cleaning the Printer Case Periodic cleaning helps maintain the appearance and reliability of the printer. When cleaning the printer, inspect both the outside and the inside for signs of damage or wear. Glass cleaners containing ammonia will cause permanent damage to the printer cover. Do not use abrasives or solvents (acetone, ketone, toluene, or xylene) to clean any part of the printer or permanent damage to the printer will occur.
Chapter 3 — Maintaining the Printer Cleaning the Inside the Case Let the printer cool before you clean the inside of the printer or you may burn your fingers. Open the printer cover and inspect the ribbon cartridge and all visible moving parts on the printer mechanism for signs of wear or damage.
Chapter 3 — Maintaining the Printer 3 Lift the ribbon cartridge to remove the ribbon from the printhead. Make sure the ribbon does not catch or get sticky. 4 Lift the ribbon cartridge out of the printer. Cleaning the Mask Spring Check the mask spring behind the printhead.If the mask spring appears to be in good condition, install a new ribbon cartridge. If the mask spring is dirty, clean it as described below.
Chapter 3 — Maintaining the Printer 5 Close the paper bail, reinsert the printhead, latch the two printhead locking tabs, and install the ribbon.
