NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 1 Friday, May 12, 2017 8:50 AM USER GUIDE Rugged Speaker System NS-HMPS3018 Before using your new product, please read these instructions to prevent any damage.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 2 Friday, May 12, 2017 8:50 AM Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 3 Friday, May 12, 2017 8:50 AM Rugged Speaker System 8 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 4 Friday, May 12, 2017 8:50 AM NS-HMPS3018 Placement • This speaker system is made out of plastic and is therefore sensitive to extreme temperatures and humidity. Do not put it in locations subject to direct sunlight or in humid places, such as near an air conditioner, humidifier, bathroom, or kitchen. • Do not put water or other liquids close to the speaker system. If liquid is spilled on top of the speaker system, it may be damaged.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 5 Friday, May 12, 2017 8:50 AM Rugged Speaker System Package contents Side Check the battery life • The speaker is designed with a smart battery check feature for your convenience. • Press battery level button to show the current battery charge when it’s turned on. vases should not be placed on it.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 6 Friday, May 12, 2017 8:50 AM NS-HMPS3018 Side view AC power cord socket Setting up your speaker system Choosing and evaluating your sound source • Look at your sound source device, such as a TV, DVD/Blu-ray player, smartphone, or USB thumbdrive to identify the type of connection it requires. Choose the connection option below that fits your audio source. You can connect several devices and switch the sound source as required.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 7 Friday, May 12, 2017 8:50 AM Rugged Speaker System Charging the batteries Your speaker system comes with built-in rechargable batteries so you can use it in places without an AC connection. The batteries are charged automatically when you plug your speaker system into an AC power outlet. To determine the current charge level of your batteries, press the Power On/Off/Battery check button (when your speaker system is powered on) on the top of your speaker system.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 8 Friday, May 12, 2017 8:50 AM NS-HMPS3018 6 If a PIN code is requested, enter “0000.” Notes • • • Some devices, such as an iPhone, connect immediately after pairing. Other devices, such as notebook computers, may ask you if you wish to connect. Your speaker system saves pairing information for up to eight devices. However, it can only be connected and play content from one device at a time.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 9 Friday, May 12, 2017 8:50 AM Rugged Speaker System 2 Press the SOURCE button on the speaker system repeatedly to select “LINE”. 3 Connect one end of a 3.5 mm audio cable to your speaker system’s LINE IN jack. 4 Connect the other end of the 3.5 mm audio cable to the headphone or AUX Output on your audio source device. USB connection 1 Turn on your speaker system. 2 Press the SOURCE button on the speaker system repeatedly to select “USB”.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 10 Friday, May 12, 2017 8:50 AM NS-HMPS3018 Using your speaker system This system lets you access five different sound sources (TUNER (FM), AUX (LINE IN), USB, Microphone, and Bluetooth (BT)). Listening to your speaker system 1 Turn on your speaker system. 2 Press the SOURCE button on the speaker system repeatedly to select the audio source you want, or to select TUNER mode (TUNER will appear on the display).
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 11 Friday, May 12, 2017 8:50 AM Rugged Speaker System Troubleshooting Check this list for a possible troubleshooting solution before calling for service. PROBLEM POSSIBLE SOLUTIONS The power does not come on. • Make sure that the AC power cord is securely plugged into a working power outlet and the speaker system. There is no sound or very low-level sound is heard from the speaker system.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 12 Friday, May 12, 2017 8:50 AM NS-HMPS3018 PROBLEM POSSIBLE SOLUTIONS My speaker system won’t connect to my Bluetooth device. • Shorten the distance between your speaker system and your Bluetooth device. • Turn your devices off, then on. Re-pair your speaker system and your Bluetooth device. • Make sure that your speaker system is not paired to another Bluetooth device. • Make sure that your speaker system and Bluetooth device are both in pairing mode.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 13 Friday, May 12, 2017 8:50 AM Rugged Speaker System Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 14 Friday, May 12, 2017 8:50 AM NS-HMPS3018 ONE-YEAR LIMITED WARRANTY Definitions: The Distributor* of Insignia branded products warrants to you, the original purchaser of this new Insignia-branded product (“Product”), that the Product shall be free of defects in the original manufacturer of the material or workmanship for a period of one (1) year from the date of your purchase of the Product (“Warranty Period”).
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 15 Friday, May 12, 2017 8:50 AM Rugged Speaker System • • • • • • • • • • Modification of any part of the Product, including the antenna Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
NS-HMPS3018_17-0304_MAN_V2_ENG.fm Page 16 Friday, May 12, 2017 8:50 AM www.insigniaproducts.com 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2017 Best Buy. All rights reserved. Made in China.
