USER GUIDE 3.5 Cu. Ft. Chest Freezer NS-CZ35WH9 Before using your new product, please read these instructions to prevent any damage.
Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NS-CZ35WH9 3.5 Cu. Ft. Chest Freezer Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-CZ35WH9 represents the state of the art in chest freezer design and is designed for reliable and trouble-free performance. Important Safety Instructions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your freezer.
3.5 Cu. Ft. Chest Freezer WARNING 1 2 3 4 5 6 7 8 9 10 11 12 Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. WARNING–Keep ventilation openings, in both your freezer and the built-in structure, clear of obstruction. WARNING–Do not touch the interior of your freezer with wet hands. This could result in frostbite.
NS-CZ35WH9 Features Package contents • 3.5 cubic foot chest freezer • User Guide 30.8 in. (78.3 cm) 51.7 in. (131.4 cm) Dimensions 21.9 in. (55.5 cm) 22.0 in. (56 cm) www.insigniaproducts.
3.5 Cu. Ft. Chest Freezer Exterior Door handle Removable storage basket Blue power indicator Temperature control knob Drain plug Setting up your freezer Before using your freezer • Remove the exterior and interior packing including the bottom cushions, foam pads, and tape inside your freezer. • Let your freezer stand upright for approximately 24 hours before connecting it to power. This reduces the possibility of a malfunction in the cooling system from incorrect handling during transportation.
NS-CZ35WH9 Providing the correct power source Check your local power source. Your freezer requires a 115V, 60Hz power supply. WARNINGS: Make sure that: • The power outlet accepts a 3-prong grounding plug. The third prong on the power cord plug grounds your freezer to minimize the possibility of electric shock. Do not modify the power plug. • DO NOT plug anything else into the same power outlet as your freezer. You may overload the circuit which can cause a fire. • DO NOT use an extension cord.
3.5 Cu. Ft. Chest Freezer Defrosting your freezer For your freezer to operate most efficiently and with minimum energy consumption, it should be defrosted when the frost on the freezer walls is .25 inches (6.4 mm) or more thick. Defrosting usually takes a few hours. Leaving the top open speeds up the process. Note: To prevent damage to your freezer, do not use a sharp utensil (like a knife) to remove thick layers of ice or frost. 1 2 3 4 Unplug your freezer.
NS-CZ35WH9 Tips on saving energy • Locate your freezer in the coolest area of the room, away from heat producing appliances or heating ducts and out of direct sunlight. • Let hot foods cool to room temperature before placing them in your freezer. Overloading your freezer forces the compressor to run longer. Foods that freeze too slowly may lose quality or spoil. • Wrap foods correctly and wipe containers dry before placing them in your freezer. This cuts down on frost build-up inside your freezer.
3.5 Cu. Ft. Chest Freezer PROBLEM The outside of the freezer is hot. SOLUTION Heat dissipation from the condenser may make the outside feel hot. This is normal and happens if: • The room temperature is high. • You have too much food in your freezer. • You open and close the door excessively. Water condenses on the outside of the freezer. • Condensation on the exterior surface and door seal is normal when the room humidity is high.
NS-CZ35WH9 ONE-YEAR LIMITED WARRANTY Definitions: The Distributor* of Insignia branded products warrants to you, the original purchaser of this new Insignia-branded product (“Product”), that the Product shall be free of defects in the original manufacturer of the material or workmanship for a period of one (1) year from the date of your purchase of the Product (“Warranty Period”).
For product inquiries, please contact us with the information below: 1-877-467-4289 www.insigniaproducts.com INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2018 Best Buy. All rights reserved.
