User's Manual

1H
Bluetooth Stereo Headset
HS889 User Guide
Notice before using
Thank you for purchasing our Bluetooth Stereo Headset
HS889. First of all, please check to find everything in your
package and carefully study the user guide to know the
function details. HS889 is developed by the innovative
Bluetooth wireless technology, enabled to connect the
Bluetooth mobile phone/ audio devices with Stereo Gateway
(HS-T809/T819/T829/T839)/or any Bluetooth device which
is with Bluetooth V1.1/V1.2 and supports Bluetooth A2DP
(Audio Advance Distribution Prole).
Package List
Please check the product you purchased. Refer to the below
package list to make sure there is no shortage or defect inside.
The complete package includes the following items:
◆
HS889 Bluetooth Stereo Headset ................................ 1
◆
User Guide ................................................................. 1
◆Warranty Card
.............................................................. 1
◆
Two in one Charger (travel charger head +USB Cable,
input:AC100-240V,50/60Hz, output: DC5.1V,120mA) .. 1
If you nd any shortage, please contact the retailer shop which
you purchase this product from.
1
Button_3
(Indicator)
Button_4
Button_5
Button_6
Button_1
Button_2
DC JACK
MIC
Earphone port
2
The headset comes with a built-in rechargeable battery. Prior
to using the headset, it is recommendable to charge the battery
fully for the rst time.
It takes 1 hour to recharge fully.
In charging : green indicator
Fully recharged: green indicator will shut off
Low-battery indication
When low battery, indicator shows slow red ash instead of
slow blue ash
1.
2.
3.
Product Instruction
3
Battery recharging
4
Power On/Off
Power on : press and hold the function button (button 4) for
3 seconds, the power will turn on after the indicator ashes
blue 3 times fast with 1 voice of “Du----“.
Power off : press and hold the function button (button 4) for
5 seconds until you see a 3 second blue light or a voice of
“Du—Bi—“, no light on indicator when power off.
1.
2.
5S
5
Pairing
When headset is power off, press and hold the function
button (button 4) for 5 seconds until you see indicator
shows two color ash (blue and red ), or a voice of “ Du—
Du—“, to get pairing mode. (If headset is not paired within
60 seconds, it will power off automatically)
Password: 8888 (remark: the headset must be paired with
another Bluetooth device has A2DP prole before you use
it for the rst time.)
1.
2.
1m
6
Answer call
When incoming call, headset will ring and indicator shows fast
blue flash, press function button (button 4) to answer the call.
While answering the call, indicator keeps blue flash.
1.
2.
7
Redial last number
Under standby mode, press and hold function button (button
4) for 3 seconds to redial, indicator keeps blue flash when
talking.
3S
8
Voice dialing
Under standby mode, press function button (button 4) to
process voice dialing, indicator keeps blue ash when talking.
( To check user guide of your mobile phone to get its voice
dialing procedure.)
9
Refuse call
When coming call, press and hold function button (button 4)
for 3 seconds to refuse the call.
3S
10
Transfer call
When talking, press and hold function button (button 4) for 3
seconds to transfer the call from mobile phone to headset or
from headset to mobile phone.
(Refer to your mobile phone user guide for process of
transferring call from mobile phone to headset)
3S
11
End calls
When talking is over, press function button (button 4) to end
call. After ending call, indicator keeps slow blue flash in standby
mode.
12
Putting HS889 in standby mode
Headset is in standby mode when in below three situations:
1.Already paired and power on.
2.When Complete pairing
3.After ending call
When headset is in standby mode, you can answer call without
re-power on.
13
Locally adjust volume on HS889
When talking, you can adjust volume by button 1( - volume)
or button 2 (+ volume).
Remotely adjust volume by mobile phone
When talking, you can adjust headset volume remotely by
mobile phone’s volume key.
+
-
14
Control music of MP3
Button 5 : previous song
Button 6 : next song
Button 3 : pause / play
Button 3 : press and hold for 3 seconds to stop playing
Button 2 : increase volume
Button 1: decrease volume
Button 4 : answer incoming call
15
Specication
Product Model No. : HS889
Frequency Band : 2.4GHz ~ 2.4835GHz, ISM Band
Talking / Standby Time : Up to 12 hours / Up to 200 hours
Supporting Prole : Headset & Handsfree Prole
Advance Audio Distribution Prole (A2DP)
Audio / Video Romote Control Prole (AVRCP)
Bluetooth Specication: Bluetooth V1.2 compliant, class II
Power Rating : 1mW
Connection : Peer to peer
Data Encryption : 128 bits encrypted
Power Consumption : 30Ma ( while talking); <1Ma (while
standby)
Power Capacity : Rechargeable Li-Polymer battery 120mAh
Power Supply : 5V DC, 100-240V AC adapter
Operation Temperature: -10 ~ 55
℃
Storage Temperature: -20 ~ 60
℃
Operation Moisture: 10% ~ 90% (non-concrete status)
Weight : 17.7g
Size : 55mm(L)*25mm(W)*26mm(H)
Working Range: 10 meters
Streaming time : 5-6 hours
16
Wearing
17
Working range
6m
10m
Optimal performance
Limited performance
Button_3
(Indicator)
Button_4
Button_5
Button_6
Button_1
Button_2
Company Website
Please visit our company website to know more product details.
www.huey-chiao.com
www.hcb8.com
15.21
You are cautioned that changes or modications not expressly
approved by the part responsible for compliance could void the
user’s authority to operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the lim-
its for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular instal-
lation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Federal Communications Commission
(FCC) Statement
Operation is subject to the following two conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference
that may cause undesired operation of the device.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. End users must follow the
specic operating instructions for satisfying RF exposure com-
pliance. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
