Specification Sheet

1 Rev 1.4 12/16
From 3X - 30X, We’ve got you covered
Model Number:
HC10X-GY-G3 (Gray)
HC10X-WH-G3 (White)
http://huddlecamhd.com
/10x-g3/
2
3
4
2
1
5
6
7
8
9
HuddleCamHD 10X G3
Conferencing Camera
The HuddleCamHD 10X is ideal for medium to large sized meeting rooms.
Comes standard with certified SONY lens
KEY FEATURES
 10X Optical Zoom
 USB 3.0 *(requires
quad core processor)
 USB 2.0 *(640x480 only)
 RS232 Serial Control
 1920 x 1080
 61° Field of View
 Up to 60fps
 64 Presets
 IR Remote
1. Lens
4. Standby LED
7. VISCA IN Port
10x Optical Zoom
Orange LED blinks
for Stand-By status
For hard wired remote control from
a 3rd party PC, joystick, etc...
2. IR Receiver
5. USB 3.0 Interface
8. VISCA OUT Port/RS485
To receive IR
remote controller
signal
For connection to PC USB 3.0 port (also
compatible with USB 2.0 port and
driver)
Used for daisy chaining multiple
cameras for RS-232 and for RS-485
control
3. Power LED
6. IR Selective Switch
9. DC in 12V Socket
Blue LED lights when
unit is powered and
is dark in standby
mode.
When using only one remote to control
more than one camera, this switch will
assign a unique ID to each camera
Only use the Power Adapter supplied
with this camera
Image Sensor & Lens
Physical
Video Sensor 1/2.8” CMOS, 2.1 Mega Pixel
Material Aluminum, Plastic
Frame Rate 30fps 1920x1080p, 60fps 1280x720p
Dimensions (in.) 5.7W x 6.3H x 6.0D (7.4H max w/ tilt)
Lens Zoom 10X Optical, 12X Digital, f=4.7-47mm
Dimensions (mm) 145W x 160H x 151D (188H max w/ tilt)
Field of View 8° (tele) to 61° (wide)
Weight 2.4 lbs (1.1 kg)
Min Lux 0.1
Working Environment Indoor
White Balance Auto/Manual/Outdoor/Indoor/One
Push/ATW
Operating Temperature 32°F to 113°F (0°C to 45°C)
Color Gray, White
Pan/Tilt Movement
Rear Board Connectors
Pan Movement ±355°
High Definition Interface USB 3.0
Tilt Rotation Up: 90°, Down: 30°
Controller Signal Interface Mini DIN-8 (VISCA IN, VISCA OUT/RS485)
Presets 64 Presets
Power Supply Interface DC 12V 2A
Electrical Index
Other
Power Supply 12V DC 2A
Mfg. Warranty 2 Years Parts & Labor
Input Voltage 12V DC (10.5-14V DC)
Quality Management System
Input Power 24W (Max)
QMS Certified ISO9001: 2008
WHAT’S IN THE BOX
 10X Zoom USB 3.0 Camera
 12V/2.0A DC Power Adapter
 Installation Bracket & Screw
 USB 3.0 Data Cable (3m)
 Serial Control Cable
 RS-232C to RS-485 Cable
 IR Remote Control
 User Manual
