Operating Instructions www.hotpoint.co.
15 24 14 25 26 13 8 12 16 7 27 6 28 29 11 30 31 10 23 9 22 21 20 19 17 1 18 5 4 3 SL M07 A3E O UK | SL M07 A3M O UK 2
A B C 36 34 32 D 33 35
E F 37 38 39
en SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED • • Before using the appliance, read these safety instructions. Keep them nearby for future reference. These instructions are also available on www.hotpoint.co.uk These instructions and the appliance itself provide important safety warnings, to be observed at all times. The manufacturer declines any liability for failure to observe these safety instructions, for inappropriate use of the appliance or incorrect setting of controls.
en • or damp substances - risk of electrical shock. Do not use the appliance on persons or animals - risk of injury. INSTALLATION • • Do not repair or replace any part of the appliance unless specifically stated in the user manual. After unpacking the appliance, make sure that it has not been damaged during transport. In the event of problems, contact the dealer or your nearest After-sales Service. Once assembled, packaging waste (plastic, styrofoam parts etc.
en ELECTRICAL CONNECTIONS Fuse replacement If the mains lead of this appliance is fitted with a BS 1363A 13amp fused plug, to change a fuse in this type of plug use an A .S .T .A . approved fuse to BS 1362 type and proceed as follows: B 1. Remove the fuse cover (A) and fuse (B) A 2. Fit replacement 13A fuse into fuse cover 3. Refit both into plug Important: The fuse cover must be refitted when changing a fuse and if the fuse cover is lost, the plug must not be used until a correct replacement is fitted.
en DESCRIPTION OF THE VACUUM CLEANER 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. Multi brush* Bristle-adjustment pedal Deluxe parquet brush* Parquet brush* Upholstery brush* Nozzle for delicate surfaces* Clamp* Precision nozzle* Metal extension lower pipe Pipe lenght regulator Metal extension upper pipe Hose handle Air regulator Remote Power control* Handle grip Plastic flexible hose Release Suction inlet 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38.
en 5. To switch off the appliance press the start/stop button (32) again. 6. Disconnect the plug from the electrical outlet and press the cord-rewind button (34) until rewinding is complete. Make sure the cord does not get entangled during rewinding. 7. Secure the floor head into its housing (33) and store the appliance. Do not start the vacuum cleaner if the plastic flexible hose is entangled, as this could damage the appliance.
en 7. 8. When the indicator mark on the upper multicyclone (22) and the blocked mark on the dustbin are lined up completely, the dustbin is correctly fitted. Replace the dustbin into the main body Cleaning the filters (F) This model comprises a Pure Clean Hepa 14 filter. The Pure Clean Hepa 14 filter ensures maximum protection against allergens and high air quality, because the air given back by the appliance is entirely free from dust/powder residues (filtering power > 99.995 %).
en SAFEGUARDING THE ENVIRONMENT GUARANTEE DISPOSAL OF PACKAGING MATERIALS The packaging material is 100% recyclable and is marked with the recycle symbol (*). The various parts of the packaging must therefore be disposed of responsibility and in full compliance with local authority regulations governing waste disposal. SCRAPPING OF HOUSEHOLD APPLIANCES This appliance is manufactured with recyclable or reusable materials. Dispose of it in accordance with local waste disposal regulations.
en • • plugs, cables, light bulbs, hoses, brushes, covers and filters. Replacement of any removable parts made of glass or plastic. After Sales Service No one is better placed to care for your Hotpoint product during the course of its working life than us – the manufacturer. Essential Contact Information Advice Line We have a dedicated team who can provide free advice and assistance with your product if you experience any technical difficulties.
en TROUBLESHOOTING Problem Possible causes / Solutions The vacuum cleaner cannot be switched on. • • • Check if the Start/Stop button was pressed. The plug was not inserted or is not making contact. If the product is in park position with the Start&Pause function (if available) remove the brush from housing and press the Start/Stop button. The full dust container indicator lights up although it is not full yet. • • • Clean the dust container. Clean the filters and, if needed, replace them.
en 14
en hotpoint.co.
www.hotpoint.co.uk Multi Cyclonic UK 08/2016 - ver. 5.
