MAN0797-03-EN Specifications / Installation

__________________________________________________________________________________________________________________________________________________

9/16/2009 Page 1 of 7 ECN # 968

1 INTRODUCTION

QX OCS provides:



Powerful Standard Features in one unit including

 Controller

 Network

 I/O

 Operator Interface

 Highly Visual Display Screen



Optional Back Pack adds comprehensive I/O and communication capabilities.

Table 1 – Features of QX Base Models and Back Pack Options

Standard Features on QX Bases Features on Back Pack

(BP)

Optlons

QX Base

Model

Network

Screen Type Standard QX

Features

HE-BP41 HE-BP43

HE-QX451

8.4” TFT SVGA

with 32,768

colors

HE-QX551

10.4” TFT

SVGA

with 32,768

colors

HE-QX651

On-Board

Ethernet

100BaseT

12.1” TFT

SVGA

with 32,768

colors

CompactFlash

3 Serial Ports

Ethernet

FOX

CsCAN

Up to 2

Plastic

SmartStack

Modules (for

additional I/O)

FOX

CsCAN

Up to 4 Plastic

SmartStack

Modules (for

additional I/O)

High Speed I/O

Other Products Commonly Used with Color QX (Back Pack Options Required)

Plastic SmartStack Modules

Provide a wide variety of I/O options for the

QX. Require little space and are easy to

install.

Fiber Optic Extension System

(FOX104 / 404)

Extends a high-speed QX backplane enabling

SmartStack I/O Modules to be mounted

several meters from the QX. The FOX, also,

significantly increases the number of

SmartStack I/O modules supported by one

QX.

SmartStix Modules

Is a family of remote I/O products for the QX.

2 Specifications / Product Descriptions

Table 2 - QX Base Specifications

Base Models QX451

(8-inch) (SVGA)

QX551

10-inch) (SVGA)

QX651

(12-inch) (SVGA)

Display Type

(LCD with

backlight)

800 x 600

TFT

800 x 600

TFT

800 x 600

TFT

Display Size

8.4” 10.4” 12.1”

Display Screen

Dimensions

6.7”W x 5”H

(170 x 128 mm)

8.3“W x 6.2“H

(211 x 159 mm)

9.7“W x 7.3“H

(246 x 185 mm)

Display Memory

8 MBytes

User Keys

7 configurable keys + System Key

Screens

Supported

1,023 screens

(300 objects per screen)

Number of

Colors

32,768

Base

Models

QX451

(8-inch)

QX551

10-inch)

QX651

(12-inch)

Primary

Power

Voltage:

24 VDC (+/-10%)

Steady State

Current:

0.625 A @ 24 VDC

Inrush Current:

(25 A @ 24 VDC)

for 0.7 ms

Voltage:

24 VDC (+/-10%)

Steady State

Current:

1.25 A @ 24 VDC

Inrush Current:

(30 A @ 24 VDC)

for 1 ms

Voltage:

24 VDC (+/-10%)

Steady State Current:

1.25 A @ 24 VDC

Inrush Current:

(30 A @ 24 VDC)

for 1 ms

QX Dimensions (without Back Pack option or SmartStack I/O attached).

See Panel Cut-outs and Dimensions for complete details (Section 3.2)

Base

Models

QX451

(8-inch)

QX551

10-inch)

QX651

(12-inch)

Height

7.0” (178 mm) 9.09” (230.9 mm) 10.25” (260.4 mm)

Width

9.17” (233 mm) 11.95” (303.5 mm) 12.87” (326.9 mm)

Mounting

Depth

2.35” (59.70 mm) 2.52” (64 mm) 2.52” (64 mm)

Keypad

Material

Faceplate made of Lexan HP92 by GE Plastics.

The material is resistant to most corrosive substances found in

industrial environments. The material also holds up well in most

industrial conditions.

Serial Ports

3 RS-232 / RS-485 Ports. Software Selectable.

Network

Options

On-board Ethernet 100BaseT

Control

Memory

256K Ladder Memory plus 32KB Register Space

Control

Scan Rate

0.2mS / K Ladder Logic (typical)

Portable

Memory

Compact FLASH (CF) slot

Temperature

& Humidity

32 - 122°F (0 - 50°C), 5 to 95% Non-condensing

Please refer to Compliance Table located at

http://www.heapg.com/Pages/TechSupport/ProductCert.html

If using a Back Pack Option (BP41 or BP43), refer the following specifications.

Table 3 – Back Pack Specifications

BP41 BP43

I/O

Interfaces

Plastic SmartStack I/O – 2

modules maximum

Fiber Optic Expansion (FOX)

I/O – 5 bases maximum

CsCAN Network Port – 252

SmartStix I/O maximum

Plastic SmartStack I/O – 4

modules maximum

Fiber Optic Expansion

(FOX) I/O – 5 bases

maximum

CsCAN Network Port –

252 SmartStix I/O

maximum

Built-in High

Speed

Counter /

PWM

Yes - >1MHz max TTL or

24vdc level

Built-in PWM

Outputs

Yes

TTL or 24vdc level

LEDs

3 LEDs (CAN, FIBER OK and

OK)

3 LEDs (CAN, FIBER OK

and OK)

Temperature

& Humidity

32 - 122°F (0 - 50°C), 5 to 95% Non-condensing

Please refer to Compliance Table located at

http://www.heapg.com/Pages/TechSupport/ProductCert.html

QX Series Models:

HE-QX451/HE-QX451-16/HEQX451C000/HEQX451C103/HEQX451C105 - 8

”

display models

HE-QX551/HE-QX551-16/HEQX551C000/HEQX551C103/HEQX551C105 - 10

”

display models

HE-QX651/HE-QX651-16/HEQX651C000/HEQX651C103/HEQX651C105 - 12

”

display models

HE-BP41/HE-BP43 – Back Pack Modules

Summary of content (7 pages)

PAGE 1
MAN0797-03-EN Specifications / Installation QX Series Models: HE-QX451/HE-QX451-16/HEQX451C000/HEQX451C103/HEQX451C105 HE-QX551/HE-QX551-16/HEQX551C000/HEQX551C103/HEQX551C105 HE-QX651/HE-QX651-16/HEQX651C000/HEQX651C103/HEQX651C105 HE-BP41/HE-BP43 – Back Pack Modules 1 ” 8 display models ” 10 display models ” 12 display models INTRODUCTION Base Models Primary Power QX OCS provides: Powerful Standard Features in one unit including Controller Network I/O Operator Interface Highly Visual
PAGE 2
MAN0797-03-EN 3 Specifications / Installation INSTALLATION Note: Prior to mounting, observe requirements for the panel layout design and adequate clearances in the QX Hardware Manual (MAN0798). A handy checklist is provided in the Installation chapter. 3.1 Installation Procedures a. QX Base Installation 1. Per specifications of the QX model you are using, carefully prepare the panel cutout. Make sure the corners of the cutout are square and free from burrs.
PAGE 3
MAN0797-03-EN 3.2.2 Specifications / Installation SmartStack I/O QX551 (10-inch) Back Pack QX QX 9.09 (230.9 mm) Back Pack 8.505 (216.0 mm) 2.52 (64 mm) 11.360 (288.5 mm) 11.95 (303.5 mm) 001OCS013 .83 (21.1mm) 3.55 (90.1mm) 001QX002-R1 QX Panel Cut-Out QX Rear View QX Side View Figure 3 – Panel Cut-out and Dimensions 10-inch 3.2.2 QX651 (12-inch) SmartStack I/O Back Pack QX QX 10.25" (260.4mm) Back Pack 9.66 [245.4mm] 2.52” (64 mm) 12.29 [312.0mm] .83" (21.1mm) 001OCS015 3.
PAGE 4
MAN0797-03-EN 3.3.1 Specifications / Installation Primary Power Port / Grounding Signal Pin V+ V- Table 4 – Primary Power Port Pins Description Input power supply voltage Input power supply ground Frame Ground Note: Power Supply Voltage Range is from 24VDC ±10%. 3.3.2 RS-232 Port / RS-485 Port There are a variety of ways to connect to the RS-232 and RS-485 ports; You can use two modular jacks (MJ1 and MJ2) or the 25-pin Dsub connector (CN1).
PAGE 5
MAN0797-03-EN Specifications / Installation Port 3 Signal Shielded Cable Pin No. To RS-232 Port FG 1 Receive Data SD 2 SG RD 3 SG RS 4 Send Data CS 5 SG 7 Figure 8 - Port 3 (CN1) RS-232 Port Port 3 Shielded Cable Signal To RS-485 Port Pin No. FG 1 +RD 24 Send Data (-) -RD 25 Send Data (+) +SD 12 Receive Data (-) -SD 13 Receive Data (+) SG 7 SG Figure 9 – Port 3 (CN1) RS-485 Port 3.
PAGE 6
MAN0797-03-EN Specifications / Installation EXT +24V OUT2 IN3 OUT1 IN2 IN1 EXT 0V OUT2 IN3 IN2 IN1 OUT1 I/O PORT TTL 001BP003 Close-up of the Back Pack I/O Connector Figure 10 – QX Back Pack Connectors and Ports (Side Views) Table 1 – I/O Port Pins (HSC) (Orange Connector) Pin Signal 1 TTL In1 HSC 1 / 5 V Input 1 (See Note*) 2 TTL In2 HSC 2 / 5 V Input 2 (See Note*) 3 TTL In3 HSC 3 / 5 V Input 3 (See Note*) 4 TTL Out1 HSC 1 / 5 V Output 1 (See Note*) 5 TTL Out2 HSC 2 /
PAGE 7
MAN0797-03-EN Specifications / Installation WARNING – EXPLOSION HAZARD – Substitution of components may impair suitability for Class I, Division 2 AVERTISSEMENT - RISQUE D'EXPLOSION - LA SUBSTITUTION DE COMPOSANTS PEUT RENDRE CE MATERIAL INACCEPTABLE POUR LES EMPLACEMENTS DE CLASSE 1, DIVISION 2. WARNING - The USB parts are for operational maintenance only. Do not leave permanently connected unless area is known to be non-hazardous.
