Installation Guide

ManualsBrandsHome Decorators Collection ManualsCurtain Rods & Hardware50 in. L - 144 in. L Telescoping Curtain Rod Kit in Oil Rubbed Bronze with New Double Rod Conversion Kit

Note:

Finial shown is for illustration purposes only.

It may not represent the style of finial purchased.

For larger width windows, two persons may be

Tools needed:

BRACKET INSTALLATION

STEP 1.

Place brackets against wall at desired locations

and mark screw holes. Use tape measure and level to make

sure marked screw holes are horizontal to each other.

Pre-drill two pilot holes for each bracket (1/4” drill bit) and

insert anchors into wall and insert screws into wall anchors.

STEP 2A.

(FOR MOUNTING TO DRYWALL OR PANELING)

STEP 2B.

If mounting directly into wood or studs, pre-drill two pilot

holes for each bracket (1/4” drill bit) and install bracket on

the wall with screws provided.

(FOR MOUNTING TO WOOD OR STUDS)

Tape Measure, Pencil, Drill & Bit Set, Philips head

Screwdriver, Level

required for easier leveling.

Tape Measure

Philipshead

Screwdriver

Drill & Bit SetPencil Level

STEP 6.

Place the other sheer rod on the left bracket. Connect the sheer

rods to make it a 3 piece telescopic sheer rod.

STEP 7.

Attach finial onto the telescopic sheer rod.

ROD INSTALLATION

STEP 3.

Unscrew finial from the smaller diameter telescopic sheer rod.

STEP 5.

Place the telescopic sheer rod on the center and right bracket.

STEP 4.

Feed half of the sheer panels (not included) onto the sheer

telescopic rod and the other half of the sheer panels (not included)

onto the other sheer rod.

WOOD

STUDS

DRY WALL

FINAL ADJUSTMENT

STEP 8.

Secure each rod by tightening screws provided.

STEP 9.

Repeat step 3 to 8 for the larger diameter telescopic curtain rod (sold separately).

Sheer rod

DRAPERY ROD SET INSTALLATION GUIDE
