Model Modèle Modelo DB 3DL2 Cordless Driver Drill Perceuse-visseuse sans fil Taladro atornillador a batería SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL WARNING IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury! This manual contains important information about product safety. Please read and understand this manual BEFORE operating the power tool. Please keep this manual available for other users and owners before they use the power tool.
English CONTENTS Page IMPORTANT SAFETY INFORMATION ..................... 3 MEANINGS OF SIGNAL WORDS ............................. 3 SAFETY........................................................................ 3 GENERAL POWER TOOL SAFETY WARNINGS ..... 3 SPECIFIC SAFETY RULES AND SYMBOLS ............ 5 IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CHARGER ........................................ 6 IMPORTANT SAFETY INSTRUCTIONS FOR USE OF THE BATTERY AND BATTERY CHARGER .......................................
English IMPORTANT SAFETY INFORMATION Read and understand all of the safety precautions, warnings and operating instructions in the instruction manual before operating or maintaining this power tool. Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic safety rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it occurs, and by observing appropriate safety procedures.
English e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool.
English c) When battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws, or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
English 13. Keep all screws, bolts and covers tightly in place. Keep all screws, bolts, and plates tightly mounted. Check their condition periodically. 14. Do not use power tools if the plastic housing or handle is cracked. Cracks in the tool’s housing or handle can lead to electric shock. Such tools should not be used until repaired. 15. Blades and accessories must be securely mounted to the tool. Prevent potential injuries to yourself or others.
English Table 1 RECOMMENDED MINIMUM AWG SIZE FOR EXTENSION CORDS FOR BATTERY CHARGERS AC Input rating amperes* AWG size of cord Length of cord, feet (meter) Equal to or but less greater than than 25 (7.
English CAUTION ON LITHIUM-ION BATTERY This battery is exclusively for the driver drill. Never use with any other heavy-duty power tools (i.e. Circular saw, Reciprocating saw, Disc grinder and Blower etc.). To extend the lifetime, the lithium-ion battery is equipped with the protection function to stop the output. In the cases of 1 and 2 described below, when using this product, even if you are pulling the switch, the motor may stop. This is not the trouble but the result of protection function. 1.
English SAVE THESE INSTRUCTIONS AND MAKE THEM AVAILABLE TO OTHER USERS AND OWNERS OF THIS TOOL! 9 000Book_DB3DL2_US.
English FUNCTIONAL DESCRIPTION NOTE The information contained in this instruction manual is designed to assist you in the safe operation and maintenance of the power tool. Never operate, or attempt any maintenance on the tool unless you have first read and understood all safety instructions contained in this manual. Some illustrations in this instruction manual may show details or attachments that differ from those on your own power tool. NAME OF PARTS 1.
English 2. Battery charger (UC3SFL) Battery installation hole Cord Pilot lamp Nameplate Plug Fig. 2 SPECIFICATIONS 1. Cordless driver drill (DB3DL2) Motor No-load speed Capacity Drilling Screw Driver Low High Metal (Thickness 1/32″ (1.0 mm)) Wood screw Small screw Bit shank size Model Type Battery Voltage Charging & discharging frequency Weight DC motor 200 / min 600 / min 13/64″ (5 mm) (Mild steel or aluminum) #8 × 1-1/2″ (3.8 mm × 38 mm) 3/16″ (5 mm) 1/4″ (6.35 mm) Hex.
English ASSEMBLY AND OPERATION 1. Insert the plug of battery charger into the receptacle. APPLICATIONS ○ Use as a drill Drilling of soft steel, plastic and aluminum materials ○ Use as a screwdriver Tightening and loosening of machine screws, wood screws and tapping screws REMOVAL AND INSTALLATION METHOD OF BATTERY ○ How to install the battery Align the battery with the groove in tool handle and slip it into place. Always insert it all the way until it locks in place with a little click.
English NOTE The battery charging time becomes longer when a temperature is low or the voltage of the power source is too low. When the pilot lamp does not go off even if more than four hour has passed after start of the charging, stop the charging and contact your HITACHI AUTHORIZED SERVICE CENTER. ○ Regarding the temperature of the rechargeable battery.
English Shift knob OPERATION Low speed How to make the batteries perform longer. ○ Recharge the batteries before they become completely exhausted. When you feel that the power of the tool becomes weaker, stop using the tool and recharge its battery. If you continue to use the tool and exhaust the electric current, the battery may be damaged and its life will become shorter. 1. Installing the bit Always follow the following procedure to install driver bit. (Fig.
English CAUTION ● The clutch dial cannot be set between the numbers “1, 5, 9 ... 21” or the black dot. ● Do not use with the clutch dial set at the line between the number “21” and the drill mark “ ”. Doing so may cause damage (See Fig. 9). Drill mark Triangle mark ● If the motor is locked, immediately turn the power off. If the motor is locked for a while, the motor or battery may be burnt. ● Too long hammering may cause the screw broken due to excessive tightening. 8.
English 9. Using the light The light lights when the light switch is pushed. When the light switch is pushed again, the light is turned off. (Fig. 12) CAUTION When using the tool in the pistol configuration, do not hold onto the bending portion of the tool when returning to the straight configuration. Your finger or other part of the hand may be pinched by the bending portion resulting in possible injury (Fig. 13). Light switch Bending portion Fig. 12 CAUTION Do not look directly into the light.
English MAINTENANCE AND INSPECTION CAUTION Pull out battery before doing any inspection or maintenance. 1. Checking the condition of the bit The bits should be checked regularly. If worn or broken bits can slip or decrease the efficiency of the motor and burn it out. Replace worn bits with new ones. CAUTION If you use a driver bit of which point is worn or broken, it will be dangerous since it slips. So replace it with a new one. 2. Check the screws Loose screws are dangerous.
English ACCESSORIES WARNING Always use only authorized HITACHI replacement parts and accessories. Never use replacement parts or accessories which are not intended for use with this tool. Contact HITACHI if you are not sure whether it is safe to use a particular replacement part or accessory with your tool. The use of any other attachment or accessory can be dangerous and could cause injury or mechanical damage. NOTE Accessories are subject to change without any obligation on the part of the HITACHI.
Français INFORMATIONS IMPORTANTES DE SÉCURITÉ Lire et comprendre toutes les précautions de sécurité, les avertissements et les instructions de fonctionnement dans ce mode d’emploi avant d’utiliser ou d’entretenir cet outil motorisé. La plupart des accidents causés lors de l’utilisation ou de l’entretien de l’outil motorisé proviennent d’un non respect des règles ou précautions de base de sécurité.
Français Le risque de choc électrique est accru en cas de mise à la masse du corps. c) Ne pas exposer les outils électriques à la pluie ou à des conditions humides. Si l’eau pénètre dans l’outil, cela augmente les risques de choc électrique. d) Ne pas utiliser le cordon à tort. Ne jamais utiliser le cordon pour transporter ou débrancher l’outil électrique. Maintenir le cordon loin de la chaleur, de l’huile, des bords pointus ou des pièces mobiles.
Français ou toute autre condition susceptible d’affecter l’opération de l’outil. Si l’outil est endommagé, le faire réparer avant utilisation. De nombreux accidents sont dus à des outils mal entretenus. f) Maintenir les outils coupants aiguisés et propres. Des outils coupants bien entretenus avec des bords aiguisés sont moins susceptibles de se coincer et plus simples à contrôler. g) Utiliser l’outil électrique, les accessoires et les mèches de l’outil, etc.
Français 4. Toujours porter des protecteurs d’oreille lors de l’utilisation de l’outil pendant de longues périodes. Une exposition prolongée à un son de forte intensité peut endommager l’ouïe de l’utilisateur. 5. Ne jamais approcher les mains ni aucune autre partie du corps de la mèche ou du mandrin pendant le travail. Tenir la perceuse uniquement par sa poignée. 6. La perceuse-visseuse fonctionannt sans fil, bien avoir conscience qu’elle est constamment prête à fonctionner. 7.
Français CONSIGNES DE SÉCURITÉ IMPORTANTES POUR LE CHARGEUR DE BATTERIE AVERTISSEMENT Une utilisation incorrecte ou dangereuse des chargeurs de batterie peut entraîner la mort ou des blessures graves. LIRE TOUT CE MODE D’EMPLOI 1. Ce manuel renferme des consignes de sécurité et d’utilisation importantes pour le chargeur de batterie modèle UC3SFL. 2.
Français CONSIGNES DE SÉCURITÉ IMPORTANTES POUR L’UTILISATION DE LA BATTERIE ET DU CHARGEUR DE BATTERIE Pour pouvoir utiliser la scie circulaire à batterie, il faudra recharger la batterie. Avant d’utiliser le chargeur de batterie modèle UC3SFL, bien lire attentivement toutes les consignes et les avertissements signalés sur le chargeur, sur la batterie ou dans ce manuel. PRÉCAUTION Utiliser exclusivement le batterie Hitachi de série EBM315.
Français ○ Assurez-vous que les copeaux et la poussière qui tombent sur l’outil lorsque vous travaillez ne s’accumulent pas sur la batterie. ○ Ne conservez pas une batterie inutilisée dans un endroit qui est exposé aux copeaux et à la poussière. ○ Avant de stocker une batterie, retirez tous les copeaux et la poussière qui ont pu y adhérer et ne la conservez pas avec des pièces métalliques (vis, clous, etc.). 2. Ne percez pas la batterie à l’aide d’un objet pointu tel qu’un clou.
Français DESCRIPTION FONCTIONNELLE REMARQUE Les informations contenues dans ce mode d’emploi sont conçues pour assister l’utilisateur dans une utilisation sans danger et un entretien de l’outil motorisé. Ne jamais utiliser ni entreprendre une révision de l’outil sans avoir d’abord lu et compris toutes les instructions de sécurité contenues dans ce manuel. Certaines illustrations dans ce mode d’emploi peuvent montrer des détails ou des accessoires différents de ceux de l’outil motorisé utilisé.
Français 2. Chargeur de batterie (UC3SFL) Orifice d’installation de la batterie Cordon Lampe témoin Plaque signalétique Fiche Fig. 2 SPECIFICATIONS 1. Perceuse-visseuse sans fil (DB3DL2) Moteur Faible Vitesse à vide Elevée Bois (Epaisseur 1/32″ Perçage (1.0 mm)) Capacité Vis en bois Vissage Petite vis Taille de la tige du couteau Modèle Type Batterie Tension Fréquence de recharge et de décharge Poids DC motor 200 / min 600 / min 13/64″ (5 mm) (Acier tendre ou Aluminium) #8 × 1-1/2″ (3.
Français ASSEMBLAGE ET FONCTIONNEMENT AVERTISSEMENT UTILISATIONS ○ Utilisation comme mèche Perçage d’acier doux, de plastique et d’aluminium ○ Utilisation comme tournevis Serrage et desserrage de vis à métaux, vis en bois et vis auto-taraudeuses MÉTHODE DE RETRAIT ET D’INSTALLATION DE LA BATTERIE ○ Installation de la batterie Aligner la batterie sur la fente de la poignée de l’outil et la glisser à l’intérieur. Toujours insérer la batterie à fond, jusqu’à ce qu’elle se bloque avec un petit déclic.
Français ○ Quand la batterie est rechargée à fond, la lampe témoin ne s’allume. REMARQUE Le temps de recharge de la batterie devient plus long si la température est basse ou que la tension d’alimentation est trop faible. Si la lampe témoin ne s’éteint pas bien qu’il se soit écoulé plus de quatre heures après le début de la recharge, arrêter la recharge et consulter son SERVICE APRES-VENTE HITACHI AGREE.
Français AVANT L’UTILISATION Vérifier l’aire de travail pour s’assurer qu’il n’y a ni débris ni désordre. Evacuer toutes les personnes non nécessaires au travail. S’assurer que l’éclairage et la ventilation sont satisfaisants. UTILISATION Comment prolonger la durée de vie des batteries ○ Recharger les batteries avant qu’elles ne soient complètement épuisées. Quand la puissance de l’outil utilisé faiblit, l’éteindre et recharger la batterie.
Français 6. Vérification de la position du sélecteur de débrayage (Voir Fig. 8). Sélecteur de débrayage Triangle Faible Fort Indice de foret Fig. 8 Le couple de serrage est défini par la position du sélecteur de débrayage. (1) En mode visseuse, alignez l’un des chiffres du sélecteur “1, 5, 9 ... 21” ou le point avec le repère triangulaire sur le corps. (2) En mode perceuse, alignez le indice de foret ” sur le sélecteur de débrayage avec le “ repère triangulaire sur le corps.
Français Fig. 10 PRECAUTION Toujours régler l’interrupteur de verrouillage en position “▼ LOCK (verrouiller)” pour le transport ou le stockage de l’outil pour éviter les démarrages intempestifs. (2) Interrupteur principal L’interrupteur principal fonctionne comme interrupteur du moteur et comme interrupteur du sélecteur de direction de rotation. Lorsque l’interrupteur principal est en position “R”, le couteau tourne dans le sens des aiguilles d’une montre.
Français PLAGE D’UTILISATION ET SUGGESTIONS Travail Perçage Vissage Acier Aluminium Tableau 6 Position du capuchon Suggestions Utilisation à des fins de perçage. Petite vis 1 – 21 Utiliser la mèche et la douille correspondant au diamètre de la vis. Vis en bois 1– Utiliser après avoir percé un trou d’amorce. PRÉCAUTION ● Lors de l’utilisation de la perceusevisseuse à fil, faire attention de ne pas bloquer le moteur. Si le moteur se bloque, arrêter immédiatement l’outil.
Français ENTRETIEN ET INSPECTION PRÉCAUTION Sortir la batterie avant toute opération d’inspection ou d’entretien. 1. Vérifier l’état de la mèche Les mèches doivent être vérifiées régulièrement. Si elles sont usées ou cassées, elles risquent de glisser ou de réduire le rendement du moteur et de le brûler. Remplacer les mèches usées par des neuves. PRÉCAUTION Si l’on utilise une mèche dont la pointe est usée ou cassée, elle sera dangereuse car elle risque de glisser. La remplacer par une neuve. 2.
Français ACCESSOIRES AVERTISSEMENT Toujours utiliser uniquement des pièces de rechange et des accessoires HITACHI. Ne jamais utiliser de pièce de rechange ou d’accessoires qui ne sont pas prévus pour être utilisé avec cet outil. En cas de doute, contacter HITACHI pour savoir si une pièce de rechange ou un accessoire particulier peuvent être utilisés en toute sécurité avec votre outil.
Español INFORMACIÓN IMPORTANTE SOBRE SEGURIDAD Antes de utilizar o de realizar cualquier trabajo de mantenimiento de esta herramienta eléctrica, lea y comprenda todas las precauciones de seguridad, advertencias e instrucciones de funcionamiento de este manual de instrucciones. La mayoría de los accidentes producidos en la operación y el mantenimiento de una herramienta eléctrica se deben a la falta de observación de las normas o precauciones de seguridad.
Español Si no se modifican los enchufes y se utilizan tomas de corriente adecuadas se reducirá el riesgo de descarga eléctrica. b) Evite el contacto corporal con superficies conectadas a tierra como tuberías, radiadores y frigoríficos. Hay mayor riesgo de descarga eléctrica si su cuerpo está en contacto con el suelo. c) No exponga las herramientas eléctricas a la lluvia o a la humedad. La entrada de agua en una herramienta eléctrica aumentará el riesgo de descarga eléctrica.
Español familiarizadas con las mismas o con estas instrucciones. Las herramientas eléctricas son peligrosas si son utilizadas por usuarios sin formación. e) Mantenimiento de las herramientas eléctricas. Compruebe si las piezas móviles están mal alineadas o unidas, si hay alguna pieza rota u otra condición que pudiera afectar al funcionamiento de las herramientas eléctricas. Si la herramienta eléctrica está dañada, llévela a reparar antes de utilizarla.
Español 3. Sostenga la herramienta eléctrica por las superficies de agarre aisladas cuando realice una operación en la que el sujetador pueda entrar en contacto con el cableado oculto o con su propio cable. Si el sujetador entra en contacto con un cable con corriente, las partes metálicas expuestas de la herramienta eléctrica pueden transmitir esa corriente y producir una descarga eléctrica al operador. 4. Emplee siempre protectores auditivos cuando tenga que utilizar la herramienta durante mucho tiempo.
Español 20. Definiciones para los símbolos utilizados en esta herramienta V ............ voltios — --- ......... corriente continua no.......... velocidad sin carga ---/min ... revoluciones o reciprocación por minuto INSTRUCCIONES IMPORTANTES DE SEGURIDAD PARA EL CARGADOR DE BATERÍAS ADVERTENCIA La utilización inadecuada del cargador de baterías puede resultar en lesiones serias o en la muerte. Para evitar estos riesgos, siga las instrucciones de seguridad ofrecidas a continuación.
Español 11. No desarme el cargador de baterías. Cuando necesite reparación, llévelo a un técnico cualificado. El reensamblaje incorrecto podría resultar en el riesgo de incendios o descargas eléctricas. 12. Para reducir el riesgo de descargas eléctricas, desenchufe el cargador del tomacorriente antes de intentar realizar cualquier operación de mantenimiento o de limpiarlo. La extracción de la batería no reducirá este riesgo.
Español ○ Asegúrese de que las virutas o el polvo que caen sobre la herramienta eléctrica durante el trabajo no entran en la batería. ○ No almacene una batería sin utilizar en un lugar expuesto a virutas y polvo. ○ Antes de almacenar una batería, retire las virutas y el polvo que se haya adherido y no la almacene junto a piezas metálicas (tornillos, clavos, etc.). 2.
Español DESCRIPCIÓN FUNCIONAL NOTA La información contenida en este manual de instrucciones ha sido diseñada para ayudarle a utilizar con seguridad y mantener esta herramienta eléctrica. Nunca haga funcionar ni efectúe el mantenimiento de la herramienta antes de leer y comprender todas las instrucciones de seguridad contenidas en este manual. Algunas ilustraciones de este manual de Instrucciones pueden mostrar detalles o accesorios diferentes a los de la propia herramienta eléctrica. NOMENCLATURA 1.
Español 2. Cargador de baterías (UC3SFL) Orificio de instalación de la batería Cable Lámpara piloto Placa de características Enchufe Fig. 2 ESPECIFICACIONES 1. Taladro atornillador a batería (DB3DL2) Motor Baja Velocidad sin carga Alta Metal (Grosor 1/32″ Taladro (1,0 mm)) Capacidad Destornil- Tornillo para madera lador Tornillo pequeño Tamaño del vástago de la broca Modelo Tipo Battería Tensión Frecuencia de carga y descarga Peso Motor de c.d.
Español MONTAJE Y OPERACIÓN ADVERTENCIA APLICACIONES ○ Utilización como taladro Taladrado de materiales de acero dulce, plástico, y aluminio ○ Utilización como atornillador Apriete y aflojado de tornillos para metal, tornillos para madera, y tornillos autorroscantes MÉTODO DE EXTRACCIÓN E INSTALACIÓN DE LA BATERÍA ○ Forma de instalar la batería Alinee la batería con la ranura de la empuñadura de la herramienta y deslícela en su lugar. Insértela siempre completamente hasta que suene un pequeño chasquido.
Español NOTA Si la lámpara piloto no se encende, desconecte el enchufe del tomacorriente y compruebe si la batería está correctamente insertada. ○ Cuando la batería se haya cargado completamente, la lámpara no se encende. NOTA El tiempo de carga de la batería disminuye a bajas temperaturas o cuando el voltaje de la fuente de alimentación es muy bajo.
Español ANTES DE LA UTILIZACIÓN Compruebe el área de trabajo para cerciorarse de que esté libre de escombros y bien ordenada. Despeje el área de personal innecesario. Cerciórese de que la iluminación y la ventilación sean adecuadas. OPERACIÓN Forma de hacer que las baterías duren más 4. Confirmar que la batería está puesta correctamente 5. Cambio de velocidad de rotación Operar la perilla de cambio para cambiar la velocidad de rotación.
Español El par de apriete de esta unidad se puede ajustar en base a la posición de ajuste del dial del embrague. (1) Cuando utilice esta unidad como atornillador, alinee uno de los números “1, 5, 9 ... 21” del dial del embrague, o los puntos, con la marca de triángulo del cuerpo exterior. (2) Cuando utilice esta unidad como taladro, alinee la marca de taladro “ ” del dial del embrague con la marca de triángulo del cuerpo exterior.
Español (2) Interruptor principal El interruptor principal funciona como un interruptor del motor y un interruptor selector de la dirección de giro. Cuando el interruptor principal se pulsa en la “R” indicada, la broca gira en el sentido de las agujas del reloj. Cuando el interruptor principal se pulsa en la “L”, la broca gira en dirección contraria a las agujas del reloj. Cuando se suelta el interruptor principal, la herramienta se detiene. (Fig. 11) R Interruptor principal R L L 10.
Español ALCANCE Y SUGERENCIAS PARA LA UTILIZACIÓN Trabajo Taladrado Apriete de tornillos Acero Aluminium Tornillo pequeño Tornillos para madera Tabla 6 Posición de la tapa Sugerencias Utilización para fines de taladrado. 1 – 21 Utilice la broca y el cubo adecuados al diámetro del tornillo. 1– Utilice después de haber taladrado un orificio piloto. PRECAUCIÓN ● Cuando utilice el taladro atornillador inalámbrico, tenga cuidado de no bloquear el motor.
Español MANTENIMIENTO E INSPECCIÓN PRECAUCIÓN Extraiga la batería antes de realizar cualquier trabajo de inspección o de mantenimiento. 1. Comprobación de las condiciones de la broca Las brocas deberán comprobarse regularmente. Si una broca está desgastada o rota, puede patinar o reducir la eficacia del motor, o hacer que se queme. Reemplace las brocas gastadas por otras nuevas. PRECAUCIÓN Si utiliza una broca de destornillador con su punta desgastada o rota, puede resultar peligroso, porque patinará.
Español ACCESORIOS ADVERTENCIA Siempre utilice únicamente repuestos y accesorios autorizados por HITACHI. No utilice nunca repuestos o accesorios no previstos para usar con esta herramienta. Si tiene dudas en cuanto a la seguridad de usar determinado repuesto o accesorio junto con su herramienta, póngase en contacto con HITACHI. La utilización de otros accesorios puede resultar peligrosa y causar lesiones o daños mecánicos.
000Book_DB3DL2_US.indb 53 2010/11/18 14:01:30 35 36 37 38 39 34 33 32 Item No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 1 1 1 1 1 1 1 1 1 1 1 1 1 3 3 1 6 2 1 3 1 2 1 3 1 1 3 1 1 1 1 GEAR BOX ASS’Y GUIDE SLEEVE SET RETAINING RING WASHER (D) GUIDE SPRING GUIDE SLEEVE CLUTCH DIAL NUT SPRING WASHER (D) STEEL BALL D3.
000Book_DB3DL2_US.
000Book_DB3DL2_US.
Applicable only in USA and Canada. Please contact HITACHI KOKI U.S.A. LTD. at 1-800-59-TOOLS (toll free), or HITACHI AUTHORIZED POWER TOOL SERVICE CENTER regarding COLLECTION. Applicable seulement aux Étas-Unis et au Canada. Pour le RAMASSAGE, contacter HITACHI KOKI U.S.A. LTD. au 1-800-59-TOOLS (appel gratuit), ou UN SERVICE APRES-VENTE D’OUTILS ELECTRIQUE AGREE PAR HITACHI. Aplica solo en USA y Canada. Con respecto a la RECOLECCIÓN de baterías, póngase en contacto con HITACHI KOKI U.S.A. LTD.
