Color Plasma Display Monitor Model CMP4121HDU-511 USER'S MANUAL MANUEL UTILISATEUR The stand is an option. Le socle est en option. READ THE INSTRUCTIONS INSIDE CAREFULLY. KEEP THIS USER MANUAL FOR FUTURE REFERENCE. For future reference, record the serial number of your monitor. SERIAL NO. The serial number is located on the rear of the monitor. This monitor is ENERGY STAR® compliant when used with a computer equipped with VESA DPMS.
NOTE: The information in this manual is subject to change without notice. The manufacturer assumes no responsibility for any errors that may appear in this manual. TRADEMARK ACKNOWLEDGEMENT VGA and XGA are registered trademarks of International Business Machines Corporation. APPLE and Macintosh are registered trademarks of Apple Computer, Inc. VESA is a trademark of a nonprofit organization, Video Electronics Standard Association.
SAFETY GUIDELINES ENGLISH This monitor is designed to be safe to use. However, due to high voltage of about 400 V, fire or serious injury may occur unless you use this monitor in the proper way. Please follow the instructions shown below in order to avoid injury.
SAFETY GUIDELINES(continued) ENGLISH • Do not apply shock to the monitor. • Do not use monitor if glass is broken or damaged. If there is no picture appearance, broken glass , smoking or something smells after applying shock to the monitor, turn off the monitor and disconnect the power plug from the mains immediately. Then, call the service center. If you continue to operate the monitor with such abnormal conditions, it may cause fire or you may receive an electric shock.
• Do not touch the power plug with wet hands. ENGLISH You may receive an electric shock. • Do not obstruct a ventilation hole. If you obstruct a ventilation hole during the operation of the monitor or just after switching off the power, it may cause a fire or electric shock due to heating up the monitor. • Do not put the monitor screen side up. • Do not put the monitor on a shelf or in a cabinet without adequate ventilation of 4 inches top, sides, bottom and rear.
ENGLISH SAFETY GUIDELINES(continued) CAUTION You may have serious injury or your property may be damaged unless you follow the instruction below. • Do not coil or wind the power cord. This may cause excessive heat resulting in a fire. • Caution for 200 - 240V operation only This equipment relies on the protective devices in the building installation for short - circuit and over - current protection.
ENGLISH PRECAUTIONS • Installation environment Do not obstruct a ventilation hole. Do not put the monitor on carpet or blanket, or near a curtain which has a possibility of obstructing a ventilation hole of the monitor. Do not put the monitor in the following places. • Hot places such as near heater, place exposed to the direct rays of the sun. • A place where the temperature is widely changing. • Places with soot, dust or high humidity. • Poor air ventilation place. • Place near fire.
SAFETY GUIDELINES(continued) ENGLISH • Prevention of an obstacle to Radio receivers This monitor has been designed pursuant to the FCC class B Rules (see page VII). This is to prevent a problem to Radio receivers. - Keep the monitor away from Radio. - Adjust Radio antennas in order for the monitor not to receive interference. - The antenna cable of Radio should be kept away from the monitor. - Use a coaxial cable for antenna.
For model CMP4121HDU WARNING : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
INSTRUCTIONS DE SÈCURITÈ FRANÇAIS Ce moniteur est conçu de façon à pouvoir être utilisé en toute sécurité. Cependant, à cause de la haute tension de 400 V utilisée, un incendie ou des blessures sérieuses peuvent se produire si vous n’utilisez pas ce moniteur correctement. Suivez les instructions suivantes afin d’éviter toutes blessures.
AVERTISSEMENT Un incendie ou une secousse électrique peuvent provoquer des blessures graves, voire la mort, si les instructions suivantes ne sont pas respectées. • Si le moniteur émet de la fumée ou une odeur inhabituelle: FRANÇAIS Mettez immédiatement le moniteur hors tension et débranchez la fiche du cordon d’alimentation au niveau de la prise secteur. Lorsque la fumée s’est arrêtée, faites réparer le moniteur.
INSTRUCTIONS DE SÈCURITÈ (suite) AVERTISSEMENT Un incendie ou une secousse électrique peuvent provoquer des blessures graves, voire la mort, si les instructions suivantes ne sont pas respectées. • LE CABLE D'ALIMENTATION FOURNI DOIT ETRE UTILISE FRANÇAIS Le non-respect de ces normes, peut entraîner des électrocutions ou risque d’incendie.
ATTENTION Une secousse électrique et d’autres anomalies peuvent provoquer des blessures graves ou des dommages physiques. • Débranchez la fiche du cordon d’alimentation au niveau de la prise secteur quand vous transportez le moniteur. FRANÇAIS Transporter le moniteur sans débrancher la fiche du cordon d’alimentation, peut endommager le cordon d’alimentation et provoquer, ultérieurement, un incendie ou une secousse électrique. Nous vous conseillons de transporter le moniteur à deux personnes.
INSTRUCTIONS DE SÈCURITÈ (suite) ATTENTION Vous pourriez vous blesser ou endommager votre matériel si vous ne suivez pas les instructions ci-dessous. • Ne bobinez pas ni n’enroulez le cordon d’alimentation. Ce pourrait causer un échauffement excessif et provoquer un incendie. FRANÇAIS • ATTENTION uniquement destiné à l’utilisation en 200 - 240 V Cet équipement utilise les systèmes de protection électriques du bâtiment où il est installé pour l’isolation contre les courts-circuits ou les surtensions.
PRÉCAUTIONS • Environnement d’installation N’installez pas le moniteur dans un des endroits suivants. • Endroits chauds, près d’un radiateur, endroits exposés à la lumière directe du soleil. • Endroits qui sont soumis à des variations rapides et amples de température. • Endroits où existent des suies, des poussières, une atmosphère hautement humide. • Endroits confinés. • Endroits humides tels qu’une salle de bain ou une salle de douche. • Endroits où vos jambes peuvent s’emmêler.
INSTRUCTIONS DE SÈCURITÈ (suite) FRANÇAIS • Prévention d’obstacle vis-à-vis des récepteurs de radio Ce moniteur a été conçu conformément au règlement FCC pour les appareils de classe B (voir page VII). Afin d’éviter les problèmes avec les récepteurs radio. - Veillez à ce que le moniteur soit loin de la radio. - Orientez l'antenne de la radio de manière que le moniteur ne soit pas brouillé. - Le câble de l'antenne de radio ne doit pas cheminer à proximité du moniteur.
CONTENTS ENGLISH SAFETY GUIDELINES ................................................................ I CONTENTS ................................................................................ 1 FEATURES ................................................................................ 2 STANDARD ACCESSORIES ...................................................... 2 INSTALLATION INSTRUCTIONS .............................................. 3 Installation............................................................
FEATURES ENGLISH The following features are provided by the color Plasma Display Monitor. Large-screen, high-definition plasma display panel The 42-inch color plasma display panel, with a resolution of 1024 (H) x 1024(V) pixels, creates a high-definition, large-screen (aspect ratio : 16:9) and low-profile flat display.
INSTALLATION INSTRUCTIONS ENGLISH Installation ■ No stand is provided with this product. When installing the monitor, use the optional Desk-top Stand (CMPAD05), Wall Mount Unit (horizontal-mount CMPAK04 or CMPAK05, vertical/horizontal-mount CMPAK14), or Ceiling Mount Unit (CMPAT04). The Desk-top Stand has been used for the illustrations in this manual. WARNING • Use one of the special mount units to install this product.
INSTALLATION INSTRUCTIONS (continued) ENGLISH Component Names Front Cabinet (front frame) Panel Remote-control receiver 8 The stand is an Optional Control panel ■ Adjustment buttons are located on the bottom. ■ The inner side of the cover is provided with indications to distinguish the adjustment buttons. Indicating lamp 9 ■ The main power switch is located at the back, on the lower surface.
Handgrips Handgrips • As this product is heavy, whenever it is moved, two people are required to transport it safely. • Whenever the unit is moved it should be lifted forwards using the two handgrips at the back, and the unit should then be held at the base on both sides for stability.
INSTALLATION INSTRUCTIONS (continued) ENGLISH Installation and Cabling Connecting to a PC ■ Read SAFETY GUIDELINES ( before proceeding to these steps: to I VII ) carefully to ensure maximum safety 1) Make sure that the display signals produced by your PC meet the specifications of this product. • For the specifications of this product, see Product Specifications ( 27 to 29 ). 2) Choose an appropriate site and install the product on a level table where the stand is secure.
ENGLISH Connecting to Video Equipment (such as a Laser Disc player, a DVD player, a DSS,or a Video Camera) ■ Read SAFETY GUIDELINES ( I to VII ) carefully to ensure maximum safety before proceeding to these steps: 1) Choose an appropriate site and install the product on a level table where the stand is secure. • Install the monitor to have ready access to a power socket available. 2) Make sure that the video equipment’s power switch is off.
INSTALLATION INSTRUCTIONS (continued) ENGLISH Handling the Remote Controller Loading Batteries 1) Open the battery cover. • Slide the battery cover towards the arrow mark while pressing it. 2) Load batteries. • Load two Size AA batteries included observing the correct polarities. 3) Close the battery cover. • Slide back the battery cover towards the arrow mark.
OPERATING INSTRUCTIONS ENGLISH Turning Power On and Off ■ To turn the monitor power ON, press the main power switch ( ) on the monitor main unit to ON, and then press the SUB POWER button or the or button on the remote control. ■ To turn the monitor power OFF, press the SUB POWER button or the or button on the remote control, and then press the main power switch ( ) on the monitor main unit to OFF.
OPERATING INSTRUCTIONS (continued) ENGLISH Input Selection ■ The input is switched by pressing the RGB1, RGB2, VIDEO1 or VIDEO2 button on the remote control. Pressing the INPUT SELECT button on the monitor main unit switches the input in the order of Remote RGB1 → RGB2 → VIDEO1 → controller When using INPUT SELECT VIDEO 1 VIDEO 2 RGB 1 RGB 2 VIDEO2 → RGB1. RGB1 (D-sub input) • When the same signal is input to RGB1 and RGB2, the phase may in some cases shift slightly but this is not a malfunction.
ENGLISH Contrast Adjustment ■ While the on-screen display system 12 , is not on display, press the remote controller SELECT button or to adjust the contrast. • When you press these buttons, the status of contrast adjustment and the input horizontal (H) and vertical (V) frequencies of the input signal will be displayed in a guidance image. (For RGB input only) • While the guidance is on display, press the key to narrow the difference between darkness and brightness.
OPERATING INSTRUCTIONS (continued) ENGLISH On-Screen Display System ■ Press the MENU button to open an MAIN MENU allowing you to complete various adjustments and settings using the SELECT buttons (The , , , and keys of the remote controller or the SELECT or VOLUME button of the main unit.). Pink • Press the SELECT button of the main unit ( or key of the remote controller) to select an item by moving the pink text.
RGB MAIN MENU PICTURE SOUND DISPLAY FUNCTION PICTURE MENU CONTRAST : 127 BRIGHTNESS : 0 PICTURE MODE : SUPER OPTIONS RETURN Selected characters CONTRAST BRIGHTNESS COLOR TINT SHARPNESS PICTURE MODE ENGLISH PICTURE MENU VIDEO PICTURE MENU CONTRAST : 127 BRIGHTNESS : 0 COLOR : 0 TINT : 0 SHARPNESS : 0 PICTURE MODE : SUPER OPTIONS RETURN Setup hint Broadens the gap Narrows the gap between between brightness and brightness and darkness. darkness.
OPERATING INSTRUCTIONS (continued) RGB RGB ENGLISH OPTIONS MENU PICTURE MENU CONTRAST : 127 BRIGHTNESS : 0 PICTURE MODE : SUPER OPTIONS RETURN MAIN MENU PICTURE SOUND DISPLAY FUNCTION OPTIONS MENU COLOR SELECT : USER GAMMA : 2.2 VIDEO LEVEL : 0.7V R-GAIN : 255 G-GAIN : 255 B-GAIN : 255 RETURN USER VIDEO VIDEO OPTIONS MENU COLOR SELECT : USER GAMMA : 2.
DISPLAY MENU (RGB) MAIN MENU PICTURE SOUND DISPLAY FUNCTION ENGLISH RGB DISPLAY MENU DISPLAY AREA : NORMAL AUTO ADJUST MANUAL ADJUST INTERPOLATION : LINEAR WIDE MODE : OFF DISPLAY INIT. RETURN NORMAL Selected characters DISPLAY AREA Setup hint FULL NORMAL Set to FULL to display images across the screen for gaining an overview of the overall images. ZOOM ADJUST OK? Adjusts the CLOCK, PHASE, etc. automatically. AUTO ADJUST * INTERPOLATION WIDE MODE ** Set to YES. Set to NO. Set to DOUBLE.
OPERATING INSTRUCTIONS (continued) ENGLISH MANUAL ADJUST MENU (RGB) RGB MAIN MENU PICTURE SOUND DISPLAY FUNCTION RGB MANUAL ADJUST MENU H. POSITION : 0 V. POSITION : 0 CLOCK : 0 PHASE : 0 RETURN DISPLAY MENU DISPLAY AREA : NORMAL AUTO ADJUST MANUAL ADJUST INTERPOLATION : LINEAR DISPLAY INIT. RETURN Selected characters Setup hint Moves the horizontal position to left. Moves the horizontal position to right. Moves down the vertical position. Moves up the vertical position.
ENGLISH • Composite / S signal (video1 input) and componet (SD1 480i) signal applicable for all size modes. • For component (HD1: 480p) signals, the display mode is selectable among 4:3, MOVIE1, and FULL. • For component (HD3: 1035i, 1080i, 720p) signals, the display mode is not selectable. • If an S1 or S2 image is input from the S image of video1 , the S1 image would be set to FULL, and the S2 image would be set to MOVIE1.
OPERATING INSTRUCTIONS (continued) ENGLISH FUNCTION MENU VIDEO RGB FUNCTION MENU LANGUAGE : ENG. AUTO FREQ : ON MODE : PC SCREEN SAVER RETURN MAIN MENU PICTURE SOUND DISPLAY FUNCTION ENGLISH FUNCTION MENU LANGUAGE : ENG. AUTO FREQ : ON LINE INTP. : OFF 3D COMB : ON COMPONENT VIDEO SYSTEM : AREA1 SCREEN SAVER RETURN ENGLISH Selected characters LANGUAGE AUTO FREQ. (RGB input only) Setup hint ENG.(ENGLISH) D.(DEUTSCH) ESP.
VIDEO MAIN MENU PICTURE SOUND DISPLAY FUNCTION ENGLISH COMPONENT MENU(VIDEO) VIDEO COMPONENT MENU COMPONENT SD1: Cb/Cr COMPONENT SD2: Cb/Cr COMPONENT HD1: Cb/Cr COMPONENT HD2: Pb/Pr COMPONENT HD3: Pb/Pr RETURN FUNCTION MENU LANGUAGE : ENG. AUTO FREQ : ON LINE INTP. : OFF 3D COMB : ON COMPONENT VIDEO SYSTEM : AREA1 SCREEN SAVER RETURN Cb/Cr Selected characters Pb/Pr Setup hint COMPONENT SD1 (480i) COMPONENT SD2 (European SDTV) The default is Y/Cb/Cr.
OTHER FEATURES ENGLISH Automatic Store ■ Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below. Item Display Sound volume Sound balance Treble Bass Mute volume Input status automatic display Line correction Three-dimensional Y/C separation HD signal Language selection VOLUME BALANCE TREBLE BASS MUTE LEVEL AUTO FREQ.
ENGLISH Reset (Settings Initialization) ■ The on-screen display system shown to the right will be displayed when the SELECT button is used to select DISPLAY and moreover DISPLAY INIT is selected from the On-screen Display System 12 . If the key (select YES) of the SELECT button is pressed at this time, the user adjustment values in the table below for the signal currently being received will be deleted and the factory settings will be restored.
OTHERFEATURES (continued) ENGLISH Power Save Mode ■ When the RGB input is selected • When this unit is connected to a VESA DPMS computer, the Power Save (Off) mode can be set to be activated automatically when the computer is not being used to reduce power consumption by this unit.
TROUBLESHOOTING ENGLISH Symptoms That Seemingly Appear to be Failures ■ Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer. WARNING • Customer servicing can be hazardous. Symptom Point to check • No picture with the powerindicating lamp off. • Check the way the power cable is connected. • Press the power switch. • The message “POWER SAVE” is displayed. No sync signal is detected. • Check the way the signal cable is connected.
TROUBLESHOOTING (continued) ENGLISH Symptom • The temperature of the display panel surface is high. • There are locations on the screen that are different from the periphery (*). *Points that do not light, points with brightness different from that of the periphery, points with color different from that of the periphery, etc. Point to check • The plasma display panel is lighting the phosphors by the discharge of internal radiation.
ENGLISH Actions to Correct Abnormal Displays ■ Depending on the kind of system equipment used, images may not be displayed normally. In this case, make the adjustments suggested below. Symptom 1 Text displayed across the screen appears vertically streaked, with some characters blurred (figure 1). The display image appears flowing (figure 2) (RGB input). Vertical streaks Figure 1 Before adjustment Some characters are blurred.
TROUBLESHOOTING (continued) ENGLISH Symptom 2 Text displayed across the screen appears blurred in its entirety (figure 2). A fine pattern flickers when displayed on the screen (figure 3). Figure 2 Before adjustment ABCDEFGHIJ abcdefgABCDEFGabcd ABCDEFGHIJ Example Figure 3 Before adjustment ABC ABC abcdefgABCDEFGabcd After adjustment After adjustment ABC Adjustment procedure 1) Press MENU button to open the MAIN MENU. 2) Press SELECT button several times to choose DISPLAY.
PRODUCT SPECIFICATIONS Type Panel ENGLISH ■ Product specifications and designs are subject to change without notice. PD1 (CMP4121HDU) Display Approx. 42 inches (922 mm (H), vertical 522 mm (V), diagonal 1059 mm) dimensions Resolution Input terminals Input signals Video signals Sync signals 1024 (H) x 1024 (V) pixels RGB input VIDEO input RGB one-line two input terminals (D-sub 15-pin) (BNC) RGB audio two-line two input terminals (left, right) (3.
PRODUCT SPECIFICATIONS (continued) ENGLISH Signal Input 5 ■ RGB terminal (D-sub 15-pin connector) 15 Pin Input signal 1 2 3 4 5 6 7 8 9 10 11 12 13 14 R. video G. video or sync on green B. video No connection No connection R.GND G.GND B.GND No connection GND No connection [SDA] H. sync or H/V composite sync V.sync. [V.CLK] 15 [SCL] ■ RGB terminal (BNC connector) V.sync. H. sync or H/V composite sync B.
ENGLISH Recommended Signal List ■ The following are recommended for use with this moniter RGB signal input (RGB1 or RGB2 signal input) Signal mode No. Horizontal Dot clock frequency (kHz) frequency (MHz) Resolution Vertical frequency (Hz) 640 X 400 70.08 31.47 25.18 640 X 480 59.94 31.47 25.18 864 X 480 59.94 31.47 34.24 4 640 X 480 72.81 37.86 31.50 5 640 X 480 75.00 37.50 31.50 6 640 X 480 85.01 43.27 36.00 7 800 X 600 60.32 37.88 40.00 8 800 X 600 72.19 48.08 50.
PRODUCT SPECIFICATIONS (continued) ENGLISH Recommended Signal List (continued) Composite / S input (VIDEO 1 input) Signal mode No. Horizontal Dot clock frequency (kHz) frequency (MHz) Signal Name Resolution Vertical frequency (Hz) 1 NTSC NTSC-4.43 M-PAL 525 59.94 15.73 - 2 PAL N-PAL SECAM 625 50.00 15.63 - Remarks Component input (VIDEO 1 input) Signal mode No. Horizontal Dot clock frequency (kHz) frequency (MHz) Signal Name Resolution Vertical frequency (Hz) 1 480/60i 480 59.
CONTENTS FRANÇAIS INSTRUCTIONS DE SÈCURITÈ.......................................................... VIII CONTENTS ............................................................................................ 1 PARTICULARITÈS .................................................................................. 2 ACCESSOIRES STANDARD .................................................................. 2 INSTRUCTIONS D’INSTALLATION ...................................................... 3 Instruction .............
PARTICULARITÈS Les particularités de l’écran couleur à plasma sont les suivantes. Grand écran à plasma, à haute définition FRANÇAIS Cet écran à plasma de 42 pouces offre une définition de 1024 (H) x 1024 (V) pixels permettant de créer des images de très grande qualité (rapport de la largeur à la hauteur égale à 16:9) sur un support plat.
INSTRUCTIONS D’INSTALLATION Instruction ■ Aucun pied n’est fourni avec ce produit. Pour l’installation du moniteur, utiliser le pied de AVERTISSEMENT • Utilisez un des supports spéciaux de montage pour installer cet appareil. Un support trop faible peut entraîner le renversement ou la chute de l’appareil et conduire à un incendie, une électrocution ou des blessures.
INSTRUCTIONS D’INSTALLATION (suite) Nom des parties FRANÇAIS Avant Coffret (cadre avant) Ecran Capteur de télécommande Le socle est un accessoire supplémentaire en option. 8 Panneau de commande ■ Le bouton de réglage se trouve sur le fond. ■ Le côté intérieur du couvercle contient des indications permettant de distinguer les boutons de réglage. Témoin ▼ Touche SELECT 12 Touches MENU 12 Touche INPUT SELECT 10 4 ■ L'interrupteur d'alimentation secteur se trouve au dos, sur la surface inférieure.
Précaution au déplacement de l'unité principale Poignées Poignées • Comme ce produit est pesant, deux personnes sont requises pour le déplacer sans danger. • Lors d'un déplacement de l'unité, soulevez-la vers l'avant à l'aide des deux poignées prévues à l'arrière et tenez-la alors des deux côtés à la base pour la maintenir stable.
INSTRUCTIONS D’INSTALLATION (suite) Installation et câblage Raccordement à un PC ■ Avant d’effectuer les INSTRUCTIONS DE SÈCURITÈ, lisez attentivement les Remarques d’emploi ( VIII à XIV) pour garantir un fonctionnement sûr: FRANÇAIS 1) Assurez-vous que les signaux d’affichage produits par le PC sont compatibles avec les caractéristiques de cet appareil. • Pour de plus amples détails concernant les caractéristiques de cet appareil, reportez-vous au paragraphe Caractéristiques techniques 27 à 29 .
Raccordement à un appareil vidéo (tel qu’un lecteur de disque vidéo, un lecteur de DVD ou une caméra vidéo) ■ Avant d’effectuer les INSTRUCTIONS DE SÈCURITÈ, lisez attentivement les Remarques d’emploi ( VIII à XIV ) pour garantir un fonctionnement sûr: Panneau arrière du moniteur Haut-parleur (G) FRANÇAIS 1) Choisissez un endroit convenable et installez l’appareil sur une table horizontale où le support peut être posé sans risque. • Installer le moniteur près d’une prise secteur.
INSTRUCTIONS D’INSTALLATION (suite) Utilisation du boîtier de télécommande Mise en place des piles FRANÇAIS 1) Ouvrez le couvercle du logement des piles. • Appuyez sur le couvercle et faites-le glisser dans la direction de la flèche. 2) Mettez en place les piles. • Mettez en place les deux piles AA fournies en respectant les polarités indiquées. 3) Fermez le couvercle du logement des piles. • Faites glisser le couvercle dans la direction de la flèche.
INSTRUCTIONS DE FONCTIONNEMMENT Mise sous tension et hors tension FRANÇAIS ■ Pour allumer le moniteur, mettre le commutateur principal ( ) situé sur l’unité principale du moniteur sur ON, puis appuyer sur le touche SUB POWER, ou sur le touche ou de la télécommande. ■ Pour éteindre le moniteur, appuyer sur le touche SUB POWER, ou sur le touche ou de la télécommande, puis mettre le commutateur principal ( ) situé sur l’unité principale du moniteur, sur OFF.
INSTRUCTIONS DE FONCTIONNEMMENT (suite) Sélection de l’entrée FRANÇAIS ■ L’entrée est sélectionnée en appuyant sur le touche RGB1, RGB2, VIDEO 1 ou VIDEO 2 de la télécommande. La pression sur le touche INPUT SELECT situé sur l’unité principale du moniteur change Boîtier de télécommande l’entrée dans cet ordre : RGB1 → RGB2 → VIDEO 1 VIDEO 2 RGB 1 RGB 2 Si vous utilisez INPUT SELECT RVB1 (Entrée D-sub) VIDEO 1 → VIDEO 2 → RGB1.
Réglage du contraste • Quand vous appuyez sur ces touches, le réglage du VIDÉO contraste et les fréquences horizontal (H) et Boîtier de verticale (V) du signal d’entrée sont affichées à télécommande CONTRASTE : 100 titre d’aide.(Pour une entrée RVB seulement) • Tandis que l’aide est affichée, appuyez sur la touche pour réduire la différence entre la partie Réglage du contraste la plus sombre et la partie la plus lumineuse.
INSTRUCTIONS DE FONCTIONNEMMENT (suite) Système d’affichage sur l’écran FRANÇAIS ■ Appuyez sur la touche MENU pour ouvrir le MENU PRINCIPAL permettant d’effectuer divers réglages et ajustements au moyen des touches SELECT (Les touches , , et du boîtier de télécommande ou la touche SELECT ou VOLUME de l’appareil.). • Appuyez sur la touche SELECT de l’appareil Boîtier de (la touche , ou la touche , du boîtier de télécommande MENU télécommande) pour choisir un paramètre en déplaçant le texte de couleur rose.
MENU IMAGE RVB IMAGE SON AFFICHAGE FUNCTION MENU IMAGE CONTRASTE : 127 LUMINOSITE : 0 IMAGE MODE : SUPER OPTIONS RETOUR VIDÉO MENU IMAGE CONTRASTE : 127 LUMINOSITE : 0 COULEURS : 0 TEINTE : 0 NETTETÉ : 0 IMAGE MODE : SUPER OPTIONS RETOUR Caractères choisis FRANÇAIS MENU PRINCIPAL Conseil de réglage CONTRASTE Diminue l’écart entre la luminosité et l’obscurité Augmente l’écart entre la luminosité et l’obscurité Réglez pour que la visibilité soit maximale compte tenu de la luminosité ambiante.
INSTRUCTIONS DE FONCTIONNEMMENT (suite) RVB RVB MENU OPIONS MENU IMAGE CONTRASTE : 127 LUMINOSITE : 0 IMAGE MODE : SUPER OPTIONS RETOUR MENU PRINCIPAL IMAGE SON AFFICHAGE FUNCTION MENU OPTIONS REG. TEINTE : UTILISAT GAMMA : 2.2 VIDÉO LEVEL : 0.7V GAIN-R : 255 GAIN-V : 255 GAIN-B : 255 RETOUR UTILISAT FRANÇAIS VIDÉO VIDÉO MENU OPTIONS REG. TEINTE : UTILISAT GAMMA : 2.
MENU ECRAN (RVB) RVB Caractères choisis ZONE ECRAN Conseil de réglage TOTAL NORMAL ZOOM AJUSTMENT OK? AUTO AJUSTE * INTERPOLATION MODE LARGE ** FRANÇAIS MENU ECRAN ZONE ECRAN : NORMAL AUTO AJUSTE. MANUEL AJUSTE. INTERPOLATION : LINEAR MODE LARGE : OFF INIT. ECRAN RETOUR NORMAL MENU PRINCIPAL IMAGE SON AFFICHAGE FUNCTION Choisissez TOTAL pour afficher des images sur tout l'écran afin d'avoir une vue d'ensemble des images. Ajuste les paramètres HORLOGE, PHASE, etc. automatiquement. Réglé sur OUI.
INSTRUCTIONS DE FONCTIONNEMMENT (suite) MANUAL ADJUSTMENT MENU (RVB) RVB FRANÇAIS MENU PRINCIPAL IMAGE SON AFFICHAGE FUNCTION RVB MANUAL ADJUSTMENT MENU POSITION H. : 0 POSITION V. : 0 HORLOGE : 0 PHASE : 0 RETOUR MENU ECRAN ZONE ECRAN : NORMAL AUTO AJUSTE. MANUEL AJUSTE. INTERPOLAT : LINEAR INIT. ECRAN RETOUR Caractères choisis Conseil de réglage Déplace la position Déplace la position horizontale vers la gauche. horizontale vers la droite. POSITION H. Déplace la position verticale vers le bas.
FRANÇAIS .• Signal en composantes /S (entrée vidéo 1) et signal en composantes (SD1 480i) applicable pour tous les modes. • Pour les signaux de composantes (HD1: 480p), le mode d’affichage peut être choisi entre 4:3, FILM1 et PLEIN. • Pour les signaux de composantes (HD3: 1035i, 1080i, 720p), le mode d’affichage ne peut pas être sélectionné. • Si une image S1 ou S2 est entrée de l'image S de vidéo1, l'image S1 sera réglée sur TOTAL et l'image S2 sera régléesur FILM1.
INSTRUCTIONS DE FONCTIONNEMMENT (suite) MENU FONCTION RVB MENU PRINCIPAL MENU FONCTION LANGUE : FRA. AUTO FREQ : ON MODE : PC SCREEN SAVER RETOUR FRANÇAIS IMAGE SON AFFICHAGE FUNCTION FRANÇAIS Caractères choisis LANGUE AUTO FREQ. (uniquement entrée RVB) Conseil de réglage ENG.(ENGLISH) 3D COMB SYSTEME VIDEO 18 D.(DEUTSCH) ESP.(ESPAÑOL) Réglé sur OFF. La fréquence du nouveau signal n’est pas affichée quand elle est reçue.
MENU COMPOSANT (VIDÉO) MENU PRINCIPAL VIDÉO MENU FONCTION LANGUE : FRA. AUTO FREQ : ON INTERPOLAT : OFF 3D COMB : ON COMPOSANT SYSTEME VIDÉO : AREA1 SCREEN SAVER RETOUR IMAGE SON AFFICHAGE FUNCTION Cb/Cr Pb/Pr Conseil de réglage FRANÇAIS Caractères choisis VIDÉO MENU COMPOSANT COMPOSANT SD1: Cb/Cr COMPOSANT SD2: Cb/Cr COMPOSANT HD1: Cb/Cr COMPOSANT HD2: Pb/Pr COMPOSANT HD3: Pb/Pr RETOUR COMPOSANT SD1 (480i) COMPOSANT SD2 (European SDTV) COMPOSANT HD1 (480p) La valeur par défaut et Y/Cb/Cr.
AUTRES PARTICURARITÈS Sauvegarde automatique ■ Une seconde environ après le réglage, les réglages s’enregistrent comme indiqué dans le tableau ci-dessous. FRANÇAIS Rubrique Niveau sonore Equilibre sonore Aigus Graves Atténuation du son Affichage automatique de l’état d’entrée Correction de ligne Séparation Y/C tridimensionnelle Signal ID Sélection de langue Affichage VOLUME BALANCE AIGUE BASSES NIVEAU ATTENUATION AUTO FREQ. Condition d'inscription Il est possible d’enregistrer un jeu.
Réinitialisation (Réglages initiaux) • Pour annuler l’effacement et revenir au MENU ECRAN, appuyez sur la touche sélectionner NON). FRANÇAIS ■ Le représenté à droite s’affiche lorsque vous sélectionnez AFFICHAGE avec le touche SELECT et que vous sélectionnez par ailleurs INIT. ECRAN sur le du système d’affichage à l’écran INITIALISER ? 12 .
AUTRES PARTICURARITÈS (suite) Mode d’économie d’énergie ■ Si vous sélectionnez la prise d’entrée RGB FRANÇAIS • Lorsque l’appareil est raccordé à un ordinateur VESA DPMS, il est possible de régler le mode d’économie d’énergie (Off) pour qu’il se déclenche automatiquement lorsque vous ne vous servez pas de l’ordinateur, afin de réduire la consommation d’énergie de l’appareil.
GUIDE DE DÈPANNAGE Symptômes qui semblent dénoter une anomalie ■ Procédez aux vérifications suggérées ci-dessous en fonction des symptômes observés. Si aucune amélioration n’est obtenue, consultez le revendeur. • La réparation par le client peut être dangereuse. Symptômes Points à vérifier Voyez page • L’écran apparaît vierge et le témoin d’alimentation est éteint. • Vérifiez la manière dont le cordon d’alimentation est connecté. • Appuyez sur l’interrupteur d’alimentation.
GUIDE DE DÈPANNAGE (suite) Points à vérifier Voyez page • Le panneau d'affichage à plasma allume le phosphore au moyen d'une décharge de rayons internes. Dans certains cas, cela peut provoquer une augmentation de la température à la surface de l'écran. Ceci est normal. - Symptômes FRANÇAIS • La température de la surface de l'écran est élevée. • Il y a des endroits de l'écran qui sont différents de la périphérie (*).
Actions pour corriger les images anormales ■ Selon le type d’équipements de système utilisés, les images peuvent ne pas être affichées normalement. En ce cas, effectuez les réglages ci-dessous. Le texte affiché sur l’ensemble de l’écran apparaît rayé verticalement, avec certains caractères flous (image 1). Le texte affiché apparaît se déplacer (image 2).(entrée RGB) Vertical streaks Image 1 Before adjustment Some characters are blurred.
GUIDE DE DÈPANNAGE (suite) Symptôme 2 Le texte affiché sur l’ensemble de l’écran apparaît flou dans sa totalité (image 2). Un motif fin clignote quand il est affiché sur l’écran (image 3). Image 2 Before adjustment ABCDEFGHIJ abcdefgABCDEFGabcd ABCDEFGHIJ Exemple Image 3 Before adjustment ABC ABC abcdefgABCDEFGabcd After adjustment After adjustment FRANÇAIS ABC 1) Appuyez sur la touche MENU pour ouvrir le menu MENU PRINCIPAL. 2) Appuyez plusieurs fois sur la touche SELECT pour choisir AFFICHAGE.
CARACTÈRISTIQUES DU PRODUIT ■ Les caractéristiques peuvent être modifiées sans avis préalable. Type Dimensions Environ 42 pouces (922 mm (H), vertical 522 mm (V), diagonale 1059 mm) d'affichage Définition Prises d’entrée Signaux d'entrée Signaux Vidéo 1024 (H) x 1024 (V) pixels Entrée RGB Entrée VIDEO Deux prise d'entrée ligne RGB (D-sub 15 broches) (BNC) Deux prises d'entrée deux lignes RGB audio (gauche,droite) (3.
CARACTÈRISTIQUES DU PRODUIT (suite) Entrée signaux 5 FRANÇAIS ■ Prise RGB (connecteur D-sub 15 broches) Broche Signal d'entrée 1 2 3 4 5 6 7 8 9 10 11 12 13 14 R. vidéo G. vidéo ou synchronisation sur le vert B. vidéo Pas reliée Pas reliée R.GND G.GND B.GND Pas reliée GND Pas reliée [SDA] Synchronisation H ou synchronisation composite H/V Synchronisation V. [V.
Liste des signaux conseillés ■ Les signaux suivants sont conseillés pour ce projecteur : Signal d’entrée RGB (Signal d’entrée RGB1 ou RGB2) Nom du signal Fréquence horizontale (Hz) Fréquence de l'horloge de point(Hz) Définition Fréquence Verticale (Hz) 640 X 400 70,08 31,47 25,18 640 X 480 59,94 31,47 25,18 864 X 480 59,94 31,47 34,24 4 640 X 480 72,81 37,86 31,50 5 640 X 480 75,00 37,50 31,50 6 640 X 480 85,01 43,27 36,00 7 800 X 600 60,32 37,88 40,00 8 800 X 600 72,
CARACTÈRISTIQUES DU PRODUIT (suite) Liste des signaux conseillés Signal d’entrée Composite / S (Signal d’entrée VIDEO 1) Mode de signal FRANÇAIS No. Fréquence horizontale (Hz) Fréquence de l'horloge de point(Hz) Nom du signal Définition Fréquence Verticale (Hz) 1 NTSC NTSC-4,43 M-PAL 525 59,94 15,73 - 2 PAL N-PAL SECAM 625 50,00 15,63 - Remarques Signal d’entrée Component (Signal d’entrée VIDEO 1) Mode de signal No.
Hitachi America, Ltd. Computer Division 2000 Sierra Point Parkway. Brisbane, CA 94005-1835,U.S.A Tel:+1-800-HITACHI Fax:+1-650-244-7525 Hitachi Australia Ltd. 13-15 Lyonpark Road, North Ryde N.S.W.
