Data Sheet

DS-1258ZJ(Black)

Wall Mount

Features

 Plastic with surface spray treatment

 Internal cable routing design

Dimension

162

.3 mm

(6.39" )

120

(4.72" )

100

(3.94" )

80 mm (3.15" )

65 mm (2.56" )

28 mm (1.10" )

12 mm

(0.47" )

5-M4

Depth: 8 mm

(0.31" )

7 mm (0.28" )

83.5 mm (3.29" )

Available Model

DS-1258ZJ(Black)

Parameter

Model

Parameters

DS-1258ZJ(Black)

Wall Mount

Appearance

Black

Material

ABS+PC

Dimension

Ø 111 mm × 120 mm × 80 mm (4.37" × 4.72" × 3.15")

Weight

200 g (0.44 lb.)

Notes

 The mount should be installed on the flat surface.

 The wall must be capable of supporting at least 3 times as much as the total weight of the camera, and the

mount.

 The maximum load capacity of the mount is 1 kg (2.2 lb.).

PAGE 1
