User’s Manual Thank you for buying a Samsung Camera. This manual will guide you through using the camera, including capturing images, downloading images and using the application software. Please read this manual carefully before using your new camera.
Instructions ƈ Use this camera in the following order Set up the camera driver Before connecting the camera to a PC, via the USB cable, you will need to set up the camera driver. Install the camera driver that is contained in Application software CD-ROM. (p.118) Take a picture. (p.26) Take a picture Insert the USB cable Check the camera’s power Check [Removable Disk] Insert the supplied USB cable into the PC’s USB port and the camera’s USB connection terminal. (p.127) Check the camera’s power.
Contents READY ƃGetting to know your camera ƃDanger ƃWarning ƃCaution ƃSystem chart ƃIdentification of features ƈFront & Top ƈBack & Bottom ƈSide / 5-function button ƈCradle ƈSelf-timer lamp ƈCamera Status Lamp ƈMode icon ƃConnecting to a Power Source ƈUsing the SAC-41 ƈHow to charge the rechargeable battery (SLB-1237) with the SAC-41.
Contents PLAY ƃStarting play mode 64 ƈPlaying back a still image 64 ƈPlaying back a movie clip 65 ƈHow to capture the movie clip 65 66 ƈOn camera movie trimming ƈPlaying back a recorded voice 67 ƃLCD monitor indicator 68 ƃUsing the camera buttons to adjust the camera 69 70 ƈThumbnail / Enlargement button ƈVoice memo / Up button 70 ƈPlay & Pause / Down button 71 ƈDelete button 72 ƈRed eye / Printer button 73 74 ƈLeft / Right / Menu / OK button ƈAlbum button 75 ƈRemote control 78 ƃSetting up the play back fun
Getting to know your camera Thank you for buying a Samsung Digital Camera. ƃ Prior to using this camera, please read the user manual thoroughly. ƃ When you require After Sales service, please bring the camera and the cause of the camera malfunction (such as battery, Memory card etc.) to the A/S centre. ƃ Please check that the camera is operating properly prior to when you intend to use it (e.g. for a trip or an important event) to avoid disappointment.
Danger ƈ Do not attempt to modify this camera in any way. This may result in fire, injury, electric shock or severe damage to you or your camera. Internal inspection, maintenance and repairs should be carried out by your dealer or Samsung Camera Service centre. ƈ Please do not use this product in close proximity to flammable or explosive gases, as this could increase the risk of explosion. ƈ Should any form of liquid or a foreign object enter the camera, do not use it.
Caution ƈ Leaking, overheating, or burst battery could result in fire or injury. ҮUse battery with the correct specification for the camera. ҮDo not short circuit, heat or dispose of battery in fire. ҮDo not insert the battery with the reverse polarities. ƈ Remove the battery when not planning to use the camera for a long period of time. Battery may leak corrosive electrolyte and permanently damage the camera’s components. ƈ Do not fire the flash while it is in contact with hands or objects.
System chart Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre. < Included items > Camera case DPOF compatible printer (see p.86) AC cord Remote control User manual, Product warranty Camera strap Software CD (see p.117) SD memory card/MMC (see p.
System chart System Requirements For Windows Computer (see p.127) PictBridge compatible printer(see p.91) ҮWindows 98/ 98SE/ 2000/ ME/ XP ҮPC with processor better than Pentium II 450MHz (Pentium 700MHz or better is recommended) Ү200MB of available hard-disk space (Over 1GB is recommended) ҮMinimum 64MB RAM (XP : 128MB) Ү1024x768 pixels, 16-bit colour display compatible monitor (24-bit colour display recommended) ҮDirectX 9.
Identification of features Front & Top Power button Shutter button Microphone Self-timer lamp Remote control sensor Auto Focus lamp Flash Lens / Lens cover Back & Bottom Camera status lamp Wide button Red-eye button / Printer button Zoom W button (Thumbnail) Zoom T button (Digital zoom) M(Mode/Album) button LCD monitor Play mode button Strap eyelet Speaker +/-, Delete button E (Effect) button Tripod ŝ10Ş 5 function button DC/USB/AV connection terminal Cradle connector
Identification of features Side/ 5-function button Voice memo / Voice Recording / Up button Menu / OK button Battery chamber cover Self-timer / Remote / Right button Flash / Left button Battery chamber Memory card slot Macro / Down button Play & Pause button Cradle ƈ You can recharge your rechargeable battery, transfer a captured image to print, and download images with the cradle.
Identification of features ƈ Self-timer lamp Icon Status Blinking Blinking Blinking Description For the 2 seconds, the lamp blinks quickly at 0.25-second intervals. For the first 8 seconds, the lamp blinks at 1 second intervals. For the final 2 seconds, the lamp blinks quickly at 0.25-second intervals. A picture will be taken after about 10 seconds and 2 seconds later a second picture will be taken.
Connecting to a Power Source ƈ You should use the rechargeable battery (SLB-1237) supplied with the camera. Be sure to charge the battery before using the camera. ƈ SLB-1237 rechargeable battery Specification Model SLB-1237 Type Lithium Ion Capacity 1280mAh Voltage 3.7V Charging time Approx. 170 MIN (Using the SAC-41) ƈ Number of images and battery life Still image Movie Battery life Number of images Recording time Approx. 180 MIN Approx. 340 Approx.
Connecting to a Power Source Using the SAC-41 If you have access to a mains supply, using an SAC-41 allows the camera to be used for long periods of time. Plug the SAC-41 into the DC connection terminal on the camera or cradle. Before turning on the camera power with an SAC-41, insert the rechargeable battery that was charged for over 10 minutes with turning off the camera. DANGER ƃ Always turn off the power before taking the SAC-41 out of the mains supply.
Connecting to a Power Source ƈ How to charge the rechargeable battery (SLB-1237) with the SAC-41. ƃ Charging with the camera 1. Insert the rechargeable battery into the battery chamber. 2. Put the SAC-41 into your power socket and DC connection terminal of the camera.
Connecting to a Power Source ƈ Charging LED of the SAC-41 Status Using the cradle Direct to the camera Being Charged Red LED is on Red LED is on Charging is complete Green LED is on Green LED is on Charging error Red LED is off or blinking Red LED is off or blinking ƃ If there is a charging error, please check all the power connections are in place. ƃ A USB cable for transmitting data can’t be used for charging the rechargeable battery.
Connecting to a Power Source Using the battery : If the camera does not turn on after you have inserted battery, please check whether the battery are inserted with the correct polarity(+/-). 1. Open the battery chamber cover by pushing in the direction of the arrow. 2. Insert the battery taking note of the polarity (+ / -). 3. To close the battery chamber cover, push it until it clicks. Removing the battery 1. Turn off the camera power. Open the battery chamber cover and move the battery holder aside.
Instructions on how to use the memory card ƃ Be sure to format the memory card (see p.99) if you are using a newly purchased memory for the first time, if it contains data that the camera cannot recognise, or if it contains images captured with a different camera. ƃ Turn off the camera power whenever the memory card is being inserted or removed. ƃ Repeated use of the memory card will eventually reduce the memory card’s performance. Should this be the case, you will need to purchase a new memory card.
Instructions on how to use the memory card INFORMATION ƃ Don't remove the memory card when the camera status lamp is blinking as this may cause damage to data in the memory card. ƈ The camera can use SD Memory Cards and MMC (Multi Media Cards). Please consult the enclosed manual for using the MMC Cards. The SD memory card has a write protect switch that prevents image files from being deleted or formatted. By sliding the switch to the bottom of the SD memory card, the data will be protected.
Inserting the memory card 1. Turn off the camera’s power and pull the battery chamber cover in the direction of the arrow to open. 2. Have the front of the memory card facing toward the front of the camera (lens) and the card pins toward the back of the camera (LCD monitor), and then push the memory card into the card slot until you hear a click. 3. To close, push the battery chamber cover until you hear a click. If the memory card does not slide in smoothly, do not attempt to insert it by force.
When Using the Camera for the First Time ƈ Charge the rechargeable battery fully before using the camera for the first time. ƈ When the camera is turned on for the first time, a menu will be displayed to set date, time and language in the LCD monitor. This menu will not be displayed after setting up the date, time and language. Set up the date, time and language before using this camera. ƃ Setting up the date, time and date type 1.
LCD monitor indicator ƈ The LCD monitor displays information about the shooting functions and selections. ƈ You can see the wider angle of subject by using the Wide button (p.54). The illustrations of this manual are based on the normal angle mode. ؊ ؉ ڹ ؈ ں ؇ ڻ ؆ ڼ ڽ ۇ ھ ۆ ڿ ۅ ۀ ۄ ۂ ہ ۃ [Image & Full Status] No. Description 1 Recording mode Icons Page p.58 2 Battery p.17 3 Continuous shot/ Stabiliser p.61 4 Flash p.37 5 Self-timer p.
LCD monitor indicator 17 Image quality / Frame rate 18 Image size 19 TIFF p.60 p.59 Number of available shots remaining 15 Remaining time (Movie clip/ Voice recording) 00:01:30/ 01:00:00 p.19 p.19 20 Voice memo/ Mic. off p.29/27 21 Optical/ Digital Zoom bar/ Digital Zoom rate p.32 Changing the recording mode ƈ You can select the desired working mode by the M (mode) button located on the back of the camera and [MODE], [MODE SET] menu.
Changing the recording mode ƃChanging the recording mode : If the [STILL & MOVIE] menu was selected Steps from 1-4 are the same as those for selecting the [MODE] menu. 5. The recording mode used just before will display. 6. Press the M (Mode) button located on the back of the camera and the recording mode will change to the movie clip mode. 7. Press the M (Mode) button again and a still image mode selected on the [MODE SET] menu will be selected.
Changing the recording mode ƃChanging the recording mode : If the [CUSTOM] menu was selected Steps from 1-4 are the same as those for selecting the [MODE] menu. 5. The recording mode used just before will display. 6. Press the M (Mode) button located on the back of the camera and the mode selection menu will display. 7. You can select modes set as on in the [MODE SET] menu by pressing the Up/ Down/ Left/ Right buttons. Refer to page 58 for more information about using the [MODE SET] menu.
Starting the recording mode ƈHow to use the Auto mode Use this for shooting basic still images. 1. Select the [FULL] sub menu on the [MODE] menu (p.23). 2. Select the Auto mode by pressing the M (Mode) button (p.24). 3. Point the camera towards the subject and compose the image by using the LCD monitor. 4. Press the shutter button to capture an image.
Starting the recording mode ƈRecording the movie clip without voice You can record the movie clip without voice. Steps from 1-3 are the same as those for MOVIE CLIP mode. 4. Press the Up button and the ( ) icon will display on the LCD monitor. 5. Press the shutter button and movie clip is recorded for as long as the available recording time without voice. 6. To stop the recording, press the shutter button again.
Starting the recording mode ƈHow to use the Scene modes Use the menu to easily configure optimal settings for a variety of shooting situations. 1. Select the [FULL] sub menu on the [MODE] menu (p.23). 2. Select the Scene mode by pressing the M (Mode) button (p.24). 3. Point the camera towards the subject and compose the image by using the LCD monitor. 4. Press the shutter button to capture an image. ſ The scene modes are listed below.
Starting the recording mode ƈHow to use the VOICE RECORDING mode A voice recording can be recorded for as long as the available recording time of the memory capacity allows. (Max: 1 hour) 1. In any mode with the exception of the Movie clip, select the VOICE RECORDING mode by pressing the Voice recording button twice. 2. Press the shutter button to record a voice. - Press the shutter button once and voice is recorded RECORD : SHUTTER for as long as the available recording time (Max : 1 hour) allows.
Things to Watch Out for When Taking Pictures ƈPressing the shutter button down half way Lightly press the shutter button to confirm focus and flash battery charge. Press the shutter button all way down to take the picture. [Lightly press the shutter button] [Press the shutter button] ƈThe available recording time may vary depending on shooting conditions and camera settings.
Using the camera buttons to adjust the camera ƈThe recording mode function can be set up by using the camera buttons. POWER button : When the camera is turned on, the power lamp turns on and off. ƃUsed for turning the camera’s power on/ off. ƃIf there is no operation during the specified time, the camera's power will be turned off automatically to save battery life. Refer to page 98 for more information about the auto power off function.
ZOOM W / T button ƈThis camera has a 4.8X optical zoom and a 5X digital zoom function. Using both will offer a total zoom ratio of 24X. ſ The illustrations as shown below are for your information about using the W/ T button. The pre-view images are can be different with the illustrations. ƃTELE Zoom Optical zoom TELE Digital zoom TELE : Pressing the ZOOM T button. This will zoom into the subject i.e. the subject will appear nearer. : When the maximum (4.
ZOOM W / T button INFORMATION ƃImages taken using the digital zoom may take a little longer for the camera to process. Allow time for this to take place. ƃYou may notice a decrease in image quality when using the digital zoom. ƃTo view more clear digital zoom image, press the shutter button halfway at the maximum (4.8X) optical zoom position and press the zoom T button again. ƃThe digital zoom can’t be activated in the [NIGHT], [CHILDREN], [CLOSE UP], [TEXT] and [FIREWORKS] scene modes.
Voice recording( ) / Voice memo( ) / UP button ƈWhile the menu is showing, press the UP button to move up the submenu cursor. When the menu is not displayed on the LCD monitor, the UP button operates as the voice recording or voice memo button. You can record your voice or add your voice-over to a stored still image. Refer to page 29 for more information about the voice recording. ƃRecording a voice memo 1. Press the M (Mode) button to select a Recording mode with the exception of Movie clip mode. 2.
Macro( ) / Down button ƈWhile the menu is showing, press the DOWN button to move from the main menu to a submenu, or to move down the submenu cursor. When the menu is not showing, you can use the MACRO/ DOWN button to take macro pictures. The distance ranges are shown below. Press the Macro button until the desired macro mode indicator displays on the LCD monitor.
Macro( ) / Down button ƈAvailable focusing method, by recording mode ( O: Selectable , X: Not selectable, ∞: Infinity focus range) Mode Normal O O O Macro O X O Auto macro X O X SCENE Mode Normal O O O ū X X ū ū O ū O Macro X X X X X O X X X X X Auto macro X X X X O X X X X X X Focus lock ƈTo focus on the subject positioned outside of the centre, use the focus lock function. ƃUsing the Focus Lock 1. Ensure the subject is in the centre of the autofocus frame.
Flash ( ) / Left button ƈWhen the menu is displayed on the LCD monitor, pressing the LEFT button makes the cursor shift to the left tab. ƈWhen the menu is not displayed on the LCD monitor, the LEFT button operates as the FLASH ( ) button. ƃSelecting the flash mode 1. Press the M (Mode) button to select a Recording [Selecting the Auto flash] mode with the exception of Movie clip mode (p.24). 2. Press the Flash button until the desired flash mode indicator displays on the LCD monitor. 3.
Flash ( ) / Left button ƃFlash mode indicator Menu tab Flash mode Description Auto flash If the subject or background is dark, the camera flash will operate automatically. Auto & Red eye reduction If a subject or background is dark, the camera flash will work automatically and will reduce the red-eye effect by using the redeye reduction function. Fill in flash The flash fires regardless of available light. The intensity of the flash will be controlled, according to the prevailing conditions.
Self-timer( ) / Remote ( ) / Right button ƈ When the menu is displayed on the LCD monitor, pressing the Right button makes the cursor shift to the right tab. The right button can also be used to move to a sub menu to select a different setting. ƈ When the menu is not displayed on the LCD monitor, the RIGHT button operates as the Selftimer ( ) and Remote ( ) button. This function is used when the photographer would also like to be in the image. ƃ Using the self-timer and remote control 1.
Self-timer( ) / Remote ( ) / Right button ƃRemote control range When you take a picture by using the remote control, refer to the illustrations shown alongside about the remote control range. [ Shutter button on the remote control ] ƃReplacing battery for the remote control Make sure the + polarity is toward the top and the - polarity is toward the bottom while installing battery for the remote control. Replace battery for the remote control in the local service centre. Use the CR 2025 3V battery.
MENU / OK button ƈMENU button - When you press the MENU button, a menu related to each camera mode will be displayed on the LCD monitor. Pressing it again will return the LCD to the initial display. - A menu option can be displayed when the following are selected : MOVIE CLIP and STILL IMAGE mode. There is no menu available when the VOICE RECORDING mode is selected.
M (Mode) button ƃHow to use the mode button : In case of [FULL] sub menu and Auto mode [Auto mode] [Pressing the Mode button] [Pressing the Right button] PROGRAM SET:OK [Program mode] AUTO SET:OK [Mode selection menu] MOVIE [Pressing the Left button] SET:OK [Movie cliip mode] [Pressing the Up button] NIGHT PORTRAIT [Pressing the Left/ Right button] SET:OK [Scene mode] SET:OK [Selecting a scene mode] ſ Press the Mode button and the mode selection menu will disappear.
M (Mode) button ƃHow to use the mode button : In case of [CUSTOM] sub menu and Auto mode ſ The illustrated images and modes are for your information. They can be changed as the [MODE SET] menu setting.
E (Effect) button ƈIt is possible to add special effects to your images by using this button ƈStill image mode : You can select the colour, focus, composite and frame menus. Movie clip mode : You can select the colour and stabiliser menus.
Special Effect : Colour 3. Select a desired sub menu by pressing the Up/Down button and press the OK button. : No effect is added to the image : Captured images will be stored in black and white. : Captured images will be stored in a sepia tone (a gradient of yellowish brown colours). : Captured images will be stored in a red tone. : Captured images will be stored in a green tone. : Captured images will be stored in a blue tone. : Save the image in negative mode. 4.
Special Effect : Composite shooting ƈYou can combine 2 ~ 4 different shots in a still image. 1. Press the E button in the program mode. 2. Select the COMP. menu by pressing the Left/ Right button. 3. Select a desired sub menu by pressing the Up/ Down button and press the OK button. - : cancels the composite shooting - : 2 different shots are combined in a still image. - : 3 different shots are combined in a still image. - : 4 different shots are combined in a still image.
Special Effect : Composite shooting ƃChanging a part of composite shot before taking the last shot Before taking the last composite shot, you can change a part of composite shot. 1. During the composite shots, press the +/- button. 2. A previous image will be deleted and new frame will display. If there is an image taken before, press the +/- button again and a previous image will be deleted again. Pressing the +/- button [Before taking the 3rd shot] [Moving backward to the 2nd shot] 3.
Special Effect : Photo Frame ƈYou can add 5 types of frame-like borders to a still image you want to capture. 1. Press the E button in the program mode. 2. Select the FRAME menu by pressing the Left/ Right button. 3. Select a desired sub menu by pressing the Up/ Down button and press the OK button. - : The photo frame will not be added. [Frame 1] [Frame 2] [Frame 4] [Frame 5] 4. The photo frame will appear.
Movie Clip frame stabiliser ƈThis function helps stabiliser images captured during movie recording. You can select this menu only in the MOVIE CLIP mode. ƃHow to use this function 1. Press the E button in the Movie clip mode. 2. Select the STABIL. menu by pressing the Left/ Right button. 3. Select a desired sub menu by pressing the Up/ Down button and press the OK button. : Movie clip frame stabiliser function becomes disabled. : Prevents camera shake during movie recording.
+/- button ƈ You can use the +/- button to adjust the values for the RGB, ISO, white balance, exposure compensation and Long Time shutter speed. Main menu Sub menu RGB R (Red), G (Green), B (Blue) ISO AUTO, 50, 100, 200, 400 WHITE BALANCE AUTO, DAYLIGHT, CLOUDY, FLUORESCENT H, FLUORESCENT L, TUNGSTEN, CUSTOM. Exposure compensation -2.0 ~ 0.0 ~ +2.0 (0.
+/- button ƈ ISO : You can select the ISO sensitivity when taking pictures. The speed or specific light-sensitivity of a camera is rated by ISO numbers. ƃ Selecting an ISO Sensitivity 1. Press the +/- button, and then use the UP and DOWN buttons to select the ISO icon( ). The ISO menu bar will appear as shown. 2. Use the LEFT and RIGHT buttons to select the desired ISO sensitivity value. - AUTO : The camera's sensitivity is automatically changed by variables such as lighting value or subject brightness.
+/- button ƃ Using the Custom White Balance White balance settings may vary slightly depending on the shooting environment. You can select the most appropriate white balance setting for a given shooting environment by setting up the custom white balance. 1. Select the CUSTOM ( ) menu of the White Balance. 2. Place a sheet of white paper in front of the camera so that the LCD monitor shows only white, and then press the SHUTTER button. 3. Your custom white balance value is stored.
+/- button ƈ Long Time shutter : This camera automatically adjusts the shutter speed and aperture values to the shooting environment. However, in NIGHT SCENE mode, you can set the shutter speed and aperture values to your preference. ƃ Adjusting the shutter speed and aperture values 1. Select the [NIGHT] scene mode. (p.24) 2. Press +/- button and Long Time shutter menu (LT, For selecting shutter speed and aperture value) will be displayed. 3.
Wide button ƈ You can select the wide angle mode or normal angle mode by using this button. When you select the wide angle mode the LCD monitor size will change from 4:3 to 16:9 screen size. 8ZM[[QVO \PM ?QLM J]\\WV [Normal angle mode] [Wide angle mode] ſ When you select the wide angle mode, sub menus of [SIZE] menu are changed. For detail sub menu, refer to below table.
Using the LCD monitor to adjust the camera settings ƈYou can use the menu on the LCD monitor to set up recording functions. In any mode with the exception of VOICE RECORDING mode, pressing the MENU button displays the menu on the LCD monitor. INFORMATION ƃThe menu will not be displayed on the LCD monitor in the following circumstances: - When another button is being operated. - While image data is being processed. - When there is no battery capacity.
Using the LCD monitor to adjust the camera settings Menu tab Main menu Sub menu Camera working mode SIZE (Movie clip) (Normal angle mode) 640X480 320X240 160X120 - SIZE (Movie clip) (Wide angle mode) 640X360 384X216 Page p.59 256X144 TIFF SUPER FINE FINE NORMAL 30 FPS 15 FPS MULTI CENTER-WEIGHTED SPOT - SINGLE CONTINUOUS AEB - SOFT NORMAL VIVID - QUALITY FRAME RATE p.60 p.61 METERING SHOOTING p.61 SHARPNESS p.62 FULL OSD OSD INFORMATION SAVE MODE BASIC OSD p.
How to use the menu 1. Turn on the camera and press the MENU button. A menu for each camera mode appears. However, there is no menu for Voice Recording mode ( ). 2. Use the LEFT and RIGHT buttons to navigate through the menus. SIZE 2592X1944 5 5 5 5 Press the LEFT or RIGHT button. QUALITY <1.. 2272X1704 2048X1536 1600X1200 1024X768 TIFF SUPER FINE Press the LEFT or RIGHT button. METERING MULTI CENTER-WEIGHTED SPOT FINE NORMAL 3. Use the UP and DOWN buttons to select a sub menu.
Mode set ƈYou can select the desired recording mode. ƈIf you select the [CUSTOM] sub menu in the [MODE] menu, you can select modes set as on in this menu by pressing the M button. - The maximum custom modes you can select are 7 and the minimum custom modes are 3. - If you select over 7 custom modes, the menus are set as off automatically from the lower placed sub menu.
Size ƈYou can select the image size appropriate for your application.
Quality / Frame rate ƈYou can select the compression ratio appropriate for your application of the captured images. The higher the compression ratio, the lower the picture quality. Mode STILL IMAGE mode MOVIE CLIP mode Icon TIFF Sub menu TIFF SUPER FINE FINE NORMAL 30FPS 15FPS File Format tif jpeg jpeg jpeg mp4 mp4 <1..
