Quick Start Guide Please read the quick start guide carefully and keep it properly.
Table of Contents 6 Packing List Camera Appearance Operation EZVIZ SPORTS APP S1 Features S1 Remote Control Appearance Main Menu Operation S1 Connects to Display Appendix Modes Description Appendix Parameters Description Restricted substances or elements identification 4
Packing List Open the packet and check whether the S1 sports camera (Hereinafter referred to as S1) and all accessoriess is in good condition.
Appearance Description 1 2 3 4 6 5 7 8 9 10 11 12 13 14 6
1 Shutter Start/Stop Shooting 2 Camera Status Blue steady: Standby; Flicker: Camera is on. Indicator 3 MIC Audio Input 4 Lens 152°Wide Angel 5 Red light steady when charging. Power Camera Red light off when fully charged. Indicator 6 USB Port 7 Micro SD Card Slot USB data trasfer Micro SD Card Recommendation 70 5 8 micro HDMI 9 Power Button 70 5 5 70 5 70 10 Reset HDMI Output Press and hold for 1 second to power on, 3 seconds to power off. Reset button.
Operation Step 1 Insert micro SD card. Insert the micro SD card into the card slot.
Step 2 Power on the camera. Connect the power cable. Use the USB cable to charge. When the power indicator goes off, the power is fully charged. You are recommended to fully charge the S1 when it is the first time you use it. Power on the camera. Press the for one second, and you will hear the buzzer alerts 5 times. The indicator blinks in purple. When the indicator turns steady blue, the S1 is power-on and standby.
Step 3 Start Recording Start recording. Press record button once,the camera starts recording, and the camera indicator flickers in blue. Stop recording. Press record button, the camera stops recording, and the camera indicator is on You can choose to switch record, capture, burst snapshot with EZVIZ SPORTS App. If no operation with in 120 seconds, the S1 camera shuts down automatically.
Step 4 Connect to the display. You can connect to the S1 to the display to vide the video and picture. Connect the S1 camera and the display with a HDMI wire. Press the the power button and the record button at the same time and then you can view the video and picture stored on the micro SD card on the display.
EZVIZ SPORTS APP Download and install the EZVIZ App, you can get the live video, playback and control the camera. Download EZVIZ SPORTS App. Use the mobile phone to scan the QR code or search in the App Store to download the EZVIZ SPORTS App.
Turn on Wi-Fi of the S1 camera. Press the Wi-Fi button for 3 seconds. When the status indicator flickers in blue, the Wi-Fi is on. Connect the Wi-Fi of the camera and your phone. Turn on the Wi-Fi of your mobile phone. Default Wi-Fi Name: EZVIZ_XXXX Default Wi-Fi Password: 1234567890 You can change the Wi-Fi password and name of the camera with the app. After restore default settings, the Wi-Fi name and Wi-Fi password are restored to default.
What you can do with EZVIZ SPORTS Open EZVIZ SPORTS App. You can set the parameters as you requested. After configuration, you can use the App to record, take photo, share your video and so on.
S1 Remote Control User Manual 16
Appearance Description 1 2 3 4 5 6 7 1 2 3 4 5 6 7 Display Power Indicator OLED Display Red steady when charging; Blue steady when fully charged. Press to enter setting interface of the Return current function˗ /Set Button When in the sub-menu, press to return upper level menu. Sensor UV Sensor Switch Switch to next mode or Button parameters Power Button Press to power on; press and hold for 3 seconds to power off˗ /OK Button When setting, press to enter.
OSD Description GUI Description 1 1 4 2 1280-60 5 3 38:35/59:42 6 S1 Current Mode 2 3 :Photo :Recording :Delay capture :Burst The first number indicates the resolution of video or photo. TheC second is the capture speed and delay interval. Time already recorded and time left for recording/ Captured picture and picture number left for photo 4 S1 Current Battery 5 Looping (Appears only in recording mode.) Apprears when bluetooth is connected. 6 See Appendix for descripion.
Operation Connect the power Use the USB port to charge the battert, when the power indicator goes steady blue, the battery is fully charged. The battery life is 30 days. Start up the remote Press , the remote is on. EZVIZ logo, verision, battery, bluetooth and S1 status will be displayed. V1.2.2 BLUETOOTH REMOTE LOA DI NG . . . S1 POWER ON BLUETOOTH CONNECTED The remote shuts down automatically if it is not connected to the S1 in 30 seconds. Buttons are invalid when the remote is starting up.
Pair the S1 and the remote The remote and the S1 are paired by default. If tou use the remote to control another S1,or if you find the bluetooth icon flickers when starting up, you need to pair them before any operation. 1 Press the and the button at the same time the remote starts searching the S1 nearby. SEARCHING...
2 After power on S1 for 10 seconds, the remote can find the S1 serial No.. 123456789 EXIT If the S1 is not found, it shows“S1 NOT FOUND”and then the remote shuts down automatically. SI NOT FOUND You can restart the S1 and the remote and pair then again.
3 Press to switch to your S1 and press to pair them. BLUETOOTH CONNECTED The remote enters the main menu, see the following figure.
Cancel remote and S1 pairing (Optional) You can also cancel the pairing. 1 Enter the main menu and press and for 5 seconds. BLE CLEARED NEED RESET 2 Press and cancel the pairing.
Cancel remote and S1 pairing (Optional) Enter the main menu and press and Power on/off S1 Start up the remote, if the S1 is powered off, you can power it on with the remote. POWER OFF S1 POWER ON S1 After the S1 is powered off, the remote shows “POWER ON S1”. If you don’t power it on for 120 seconds, the remote shuts itself down automatically. Settings Set S1 parameters as you demand. Enter the main menu and press setting interface shows. Press enter the setting menu. ˖Switch to next item.
Choose the setting you want to set, press the to enter the setting interface directly. S1 Operation (QWHU PDLQ PHQX Press the to execute the current command. E.g. Press the button when in burst mode. The S1 starts burst capture with the preset parameters No operation for 120 seconds, the remote goes to hiberate mode to save battery. Press the button to activate the remote. Enter the main menu and press , until the Shut down the remote Press the remote down.
S1 Connecting to Display Choose the setting you want to set, press the to enter the setting interface directly. You can connect the S1 to a display to view the photo and video stored. Connect the S1 and display with HDMI wire, power on S1, and the remotes shows “HDMI”. HDMI Press to switch; Press 26 to confirm.
Appendix Modes Description In the main menu of the reomte, thera are photo, burst, Delay, UV and power on/off S1. Record Mode 1280-60 38:35/59:42 In photo mode, press the button on the remote or the button on S1 to start recording. And in the remote, recording time is displayed. 1280-60 00:01 In photo mode, press the button on the remote or the button on S1 to stop recording. And in the remote, remaining recording time is displayed.
Photo Mode 12M 386 / 532 In photo mode, press the button on the remote or the button on S1 to take a photo. After taking the photo, the number of photo captured and the remaining capacity for photo are changed.
Burst Mode Capture many photos in a certain time; E.g.5PCS/1S,10PCS/1S,10PCS/2S,30PCS/1S,30PCS/2S When you set it as 10PCS/2S, S1 captures 10 photos in 2 seconds. 10PCS/2S 386 / 532 In burst mode press the button on the remote or press the record button on S1 to start capture. Burst Capture After burst capture, S1 is in standby mode.
Delay Capture Capture after a pre-defined time. E.g., when set the delay time as 0.5SEC, press the record/capture button, the camera capture 1 photo after 5 seconds. 12M 0.5SEC 386 / 532 Press the button on the remote or press the on the S1 camera to start delay capture. Press the button again to stop capture.
UV Detector Mode The remote can detect the UV indicators outdoor to provide information for you to choose protection. UV Value 309 UV Level UV Level Weak Weak ̚ No protection required. Medium ̚ Wear sunhat and sunglasses Strong ̚ Very Strong ̚ Wear sunhat, sunglasses and sunblocking cream. Better not go outside between 10 ap and 4pm. Extremely Strong Better not go outside.
Power on/off S1 Press button when the menu shows”POWER OFF S1”to power it off. Press button when the menu shows”POWER ON S1”to power it on. POWER OFF S1 Parameters Setting You can set the S1 parameters with the remote. E.g. video resolution, recording mode and so on.
Appendix Parameters Description Parameters Video Resolution Description 1920*1080 60fps˗ 1920*1080 30fps˗ 1280*720 120fps˗ 1280*720 60fps˗ 848*484 240fps In order: The camera indicator goes bsteady blue. And you cannot record or take photo when micro SD has no space. Looping˖Video and photo stored in Recording Mode the micro SD card are overwitten after SD card is full.
Parameters Description Capture after a pre-defined time; Delay Capture 0.5SECǃ1SECǃ2SECǃ5SECǃ 10SECǃ30SECǃ60SEC Capture many photos in a certain Burst Capture time; E.g.5PCS/1S,10PCS/1S, 10PCS/2S,30PCS/1S,30PCS/2S Wi-Fi Turn on/ off Wi-Fi GPS Enabling the GPS function, the latitude and longitude data of the video or photo is contained.
Parameters Description Set the remote into standby time. Remote Standby You can choose 120 seconds or cancel it. Version Info Check the information.
Restricted Substances and Elements Restricted substances and elements declaration Parts 3E +J &G &UĎ 3%% 3%'( Medal h Lens h Curciut Board h Plastic Display h Power h Controller h Accesories h ż PHDQV WKH WR[LF DQG KDUPIXO VXEVWDQFHV LQ WKH DVVHPEO\ units are within the limit stipulated by the of the SJ/T11363-2006 standard.
