WG‐500P Hotspot in a Printer Address List ‐ Display the filtering address(s). Delete Disable Select the check boxes and click ‘Delete’ to delete the filtering address(s). Click Add to List button to add a new entry. Click Apply button to save the new settings. Click Delete All & Apply button to delete all entries.
WG‐500P Hotspot in a Printer 3‐2‐4‐3 Secure Remote This feature allows you to create a secure connection to a remote site or back end system with VPN PPTP Client. If “Secure Remote” is enabled, the RADIUS packet/ syslog will be transferred to this secure connection. Figure 3‐2‐28 Secure Remote Setting Screen Item Auto-connect at Start-up Default Disable (Always connect) Description Enable the check box to automatically establish the PPTP connection.
WG‐500P Hotspot in a Printer 325 SYSTEM 3‐2‐5‐1 System Define the WG‐500P System configuration.
WG‐500P Hotspot in a Printer Item System/Host Name Default Empty Description The system name can consist of up to 40 alphanumeric characters. Domain Name Empty The Domain name can consist of up to 80 alphanumeric characters. Location Information Empty Enter your location information. Time Zone GMT Select the appropriate time zone for your location. Manual Setting Click Manual Setting to set the system date and time. Date Year/Month/Day Enter the Date for the system.
WG‐500P Hotspot in a Printer Addresses addresses or a range to allow remote control access from network. Multicast Pass Through Enable This function allows for multiple transmissions to specific recipients at same time. Allow remote user to ping Enable the device This function allows remote user to ping the WG-500P through Internet. Ping is normally used to test the physical connection between two devices, to ensure that everything is working correctly.
WG‐500P Hotspot in a Printer 3‐2‐5‐2 WAN/LAN Figure 3‐2‐30 WAN/LAN Setting Screen 65
WG‐500P Hotspot in a Printer Item Default Description LAN IP Address 10.59.1.1 The internal LAN IP address of your Wireless Subscriber Server Gateway. Subnet Mask 255.255.255.0 Enter the subnet mask for the IP address. WAN MAC Address IP Address The default MAC address is set to the WAN physical interface on device. DHCP Client The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP.
WG‐500P Hotspot in a Printer Keep alive Disable This option keeps your PPPoE enabled Internet access connected Redial Period 30 Seconds indefinitely, even when it sits idle. The Redial Period maximum value is 65535 seconds.
WG‐500P Hotspot in a Printer 3‐2‐5‐3 Server Server Figure 3‐2‐31 Server Setting Screen Item Default Description Web Server HTTP Port 80 Enter the HTTP port number. The HTTP port allowed range is 80 or 8010 to 8060. For access the WG-500P system under NAT, please tab the “http://HTTP Port IP Address: Port Number”. HTTPS Port 443 Enter the HTTPS port number. The HTTPS port allowed range is 443 or 4430 to 4440.
WG‐500P Hotspot in a Printer DHCP Server—Enable DHCP server function. DHCP Relay To route DHCP through an external server, the administrator needs to enable the DHCP relay and assign a valid DHCP server IP address. DHCP Server IP Address Empty Enter the IP address of DHCP server. DHCP Server The WG-500P's DHCP server is turned on and running by default when you install it in your network. DHCP Pool Starting 10.59.1.2 Enter the DHCP Pool Starting IP address.
WG‐500P Hotspot in a Printer Static DHCP This function allows subscriber to assign IP address on the LAN to specific individual computers based on their MAC Address. Figure 3‐2‐32 Server Setting Screen Item IP Address Default Empty Description Enter the IP address that subscriber want to assign to the computer on LAN with the MAC address the subscriber will also specify. MAC Address Empty Enter the MAC address of a computer on your LAN. Click Apply button to save the new settings.
WG‐500P Hotspot in a Printer 3‐2‐5‐4 Customization Login Page The WG‐500P provides three different login page formats, including standard, redirect, advanced and frame format.
WG‐500P Hotspot in a Printer Item Standard Default Description For some service providers, they may hope to have a customize subscriber’s login page to the users. This function helps them to realize the ideal. The page elements are including login page title, background color, subtitle etc. Logo Disable Select the check box to display service provider’s logo. Title Welcome Enter the title name of subscriber login page. The maximum allowed characters length is 80.
WG‐500P Hotspot in a Printer page. Copy and paste the following HTML Code into your home page to produce redirect subscriber login page. Figure 3‐2‐35 Preview Redirect Login Page Code Advanced This function allow user to design login page of WG-500P. Welcome Slogan Welcome The maximum allowed characters length is 80. Page Background None The page background can be none or specified color. For the background color format please views the color grid. The allowed format is Hexadecimal.
WG‐500P Hotspot in a Printer like “Please Contact to our Customer Service Center, EXT 141”. The maximum character of the comment is 80. Frame If “Frame” is selected the subscriber login page will be separate into Top Frame and Bottom Frame. Bottom Frame is a default format for username and password input, Top Frame is allowed to be specified a URL to link. Top Frame URL Link Empty The input format can be http://www.yahoo.com. The maximum character of the URL Link is 200.
WG‐500P Hotspot in a Printer Logo This function allows service provider to upload the customer’s logo image file which can be shown on the standard login page and account printout of PC‐connected printer. Figure 3‐2‐37 Logo Setting Screen Item File Path Default Empty Description Enter the file pathname of the logo file in the File Path field. Click Apply button to save the logo file to system. Click Delete button to delete the logo file.
WG‐500P Hotspot in a Printer Information Window This function allow service provider can decide whether they want an “Information Window” pop‐up on subscriber PC when authenticate successful or not and specified text of information window. Subscriber can type “http://1.1.1.1/info” to open the information window again or enter “http://1.1.1.1/logout” to logout immediately if accumulation billing selected.
WG‐500P Hotspot in a Printer Billing Type=Time to Finish Can be replenished by subscriber=Enable Figure 3‐2‐40 Information Window Billing Type=Accumulation Can be replenished by subscriber=Disable Figure 3‐2‐41 Information Window Billing Type=Accumulation Can be replenished by subscriber=Enable Figure 3‐2‐42 Information Window 77
WG‐500P Hotspot in a Printer Account Printout This function allow service provider to specified text of account printout. Figure 3‐2‐43 Account Printout Customization Setting Screen Note: If you don’t print out QR code on the ticket, please disable “QR Code”.
WG‐500P Hotspot in a Printer Credit Card Figure 3‐2‐44 Credit Customization Setting Screen 79
WG‐500P Hotspot in a Printer Item Standard Login Page Description This function allow service provider to customize the additional credit card message for the standard login page. Service Selection Page This function allow service provider to customize the additional credit card message for the standard login page. Fail Page This function allow service provider to customize the message for the fail page. Click Apply button, the success dialog box appears.
WG‐500P Hotspot in a Printer User Agreement Page This function allow user to design user agreement page of Internet Subscriber Server.
WG‐500P Hotspot in a Printer 3‐2‐5‐5 Portal Page This feature allows redirecting subscriber’s browser to a specified portal page after successful login. Figure 3‐2‐46 Portal Page Setting Screen Item Default Description URL Link Empty Enter the URL Link page. The input format can be “http://www.yahoo.com”. The maximum character of the URL Link is 200. Click Apply button, the success dialog box appears. Click on Back to return to Portal Page setting screen.
WG‐500P Hotspot in a Printer 3‐2‐5‐6 Advertisement The system allow service provider to input 5 URL links for advertisement link purpose. Figure 3‐2‐47 Advertisement URL Link Setting Screen Item Frequency Default One Time Only Description One Time Only—One Time Only means to send the advertisement link once after the subscriber Login. Every~Min(s)—The field means to send the advertisement link every interval minutes. The value range is 1 to 60 (minutes).
WG‐500P Hotspot in a Printer 3‐2‐5‐7 Walled Garden We prepare ten URL links that allows subscriber to access the specific Web pages even they didn’t have a username or password. It’s free trying and can use for advertisement. Figure 3‐2‐48 Walled Garden Setting Screen Item Name Description The name is allowed user to set the prompt string in user customize login page. The maximum allowed characters length is 80. URL 1~5 The input format can be “http://www.yahoo.com”.
WG‐500P Hotspot in a Printer 3‐2‐5‐8 DDNS The DDNS service (Dynamic Domain Name Service), an IP Registry provides a public central database where information such as email addresses, host names, IP addresses etc. can be stored and retrieved. This solves the problems if your DNS server uses an IP associated with dynamic IP addresses. When the ISP assigns the WG‐500P a new IP, the WG‐500P must inform the DDNS server the change of this IP so that the server can update its IP‐to‐DNS entry.
WG‐500P Hotspot in a Printer Item Force to update every~day(s) when Default Description 1 day Enter a number in the field to set the force update WAN IP address keeps no change interval (in days). No 01~03 The index number of a DDNS account. Active Disable Click on check box, active or inactive the DDNS record. Update Status Now Click the Update Status Now button to do manual update. Settings Enter the account information of DDNS Server.
WG‐500P Hotspot in a Printer 3‐2‐5‐9 Wireless Figure 3‐2‐50 Wireless Setting Screen 87
WG‐500P Hotspot in a Printer Item Default Description General Settings Wireless Connection Enable To Enable or Disable wireless connection. Channel 6 Select the channel ID for wireless connection. Multiple ESSID Setting Click Edit button for each of 4 ESSID setting. Figure 3‐2‐51 EDDID Setting Screen General Settings ESSID The ESSID’s name by default is related to the last 4 numbers of Wlan MAC. If the Wlan MAC is“00-90-0E-00-12-34＂, the default is“Wireless-1234_1(2,3,4)".
WG‐500P Hotspot in a Printer are from 0 to 65535. Share Secret Key Empty Enter the RADIUS secret key Beacon Interval 200 This value valid range is 1 to 1000 indicates the frequency interval of the beacon. RTS Threshold 2347 This value valid range is 256-2342. This setting determines the packet size at which the WG-500P issues a request to send (RTS) before sending the packet.
WG‐‐500P Hotspott in a Printer 33 System m Status Disp play WG‐50 00P system basic b statuss, including,, 1. 2. 3. 4. 5. 6.
WG‐500P Hotspot in a Printer 331 System The System Information Menu displays current system basic information including the service connection message, host name, LAN, WAN, DHCP Configuration, DNS, E‐mail Redirection, SSL Certificate, network traffic Information and the system firmware version number.
WG‐500P Hotspot in a Printer 332 Account List You can display a list of all the account information on this device. This table includes the username, password, usage time, time created, login time, expiration time and status. Figure 3‐3‐3 Account List Click refresh button to update the account list page. Click the column button (S/N, Status, Username, ….,etc.) to sort the column in ascending/descending order. Select the check boxes and click Delete to delete the accounts.
WG‐500P Hotspot in a Printer 333 Account Log The account log shows the accounts’ log information. Figure 3‐3‐4 Account Log Click Export to export the account logs to a text file format. (export.log) Click Clear Log button to remove all account log entries. Click refresh button to update the account log page. Click the column button (S/N, Username, Time Created, …,etc.) to sort the column in ascending/descending order.
WG‐500P Hotspot in a Printer 334 Current User Display the current logged‐in subscribers’ status. It allow service provider to disconnect any subscribers. Figure 3‐3‐5 Current User List Click refresh button to update the current user list page. Click the column button (Interface, Type, Username, IP Address, …, etc.) to sort the column in ascending/descending order. Select the check boxes and click ‘Delete’ to delete accounts. Click Delete ALL to delete all accounts in current user list.
WG‐500P Hotspot in a Printer 335 DHCP Clients The DHCP client table shows the current DHCP users on the LAN. Figure 3‐3‐6 Current User Screen 336 Session List The remote site administrator could monitor the real time usage status of WG‐500P via this page.
WG‐‐500P Hotspott in a Printer 34 4 System m Tools Thiss allows serrvice provid der or admiinistrator to o process Firmware F up pgrade, chaange passsword and backup or restore r conffiguration. 1. 2. 3. 4. 5. 6. 7. 8. 9.
WG‐500P Hotspot in a Printer 341 Configuration Use the Configuration item to save, restore or reset configuration parameters of the WG‐500P. Figure 3‐4‐2 Configuration Setting Screen Item Default Description Backup Click it to save the system configuration to your computer. (export.cfg) Remote TFTP Server IP Empty Enter the IP address of TFTP Server. File Name Empty Enter the file name in the File Name field. Restore Click it to restore your system configuration.
WG‐500P Hotspot in a Printer 342 Firmware Upgrade The Firmware Upgrade menu loads updated firmware to be permanent in flash ROM. The download file should be a binary file from factory; otherwise the agent will not accept it. After downloading the new firmware, the agent will automatically restart it. Manual Firmware Upgrade Figure 3‐4‐3 Manual Firmware Upgrade Setting Screen Item Default Description This allow administrator to upgrade the firmware via HTTP.
WG‐500P Hotspot in a Printer Scheduled Firmware Upgrade Scheduled Firmware Upgrade is a program that enables an automatic upgrade to the latest firmware version through the TFTP server. Figure 3‐4‐4 Scheduled Firmware Upgrade Setting Screen Item Default Description Disable/Enable Disables or enables the scheduled firmware upgrade function. TFTP Server IP Empty Enter the IP address of TFTP Server. File Synchronization Empty Enter the file name and location in the File Synchronization field.
WG‐500P Hotspot in a Printer 343 Boot Code Figure 3‐4‐6 Boot Code Upgrade Setting Screen 344 Controller Board Firmware Figure 3‐4‐7 Controller Board Firmware Upgrade Setting Screen 100
WG‐500P Hotspot in a Printer 345 System Account Use the System Account screen to change the system accounts.
WG‐500P Hotspot in a Printer Item Description Username The username can consist of up to 20 alphanumeric characters and is sensitive. Password The password can consist of up to 20 alphanumeric characters and is sensitive. Confirm The password for confirmation Super Subscriber Disables or enables the super account function. Idle Time Out The user idle time out valid is 1 to 1440 minutes.
WG‐500P Hotspot in a Printer Web‐Based Accounting Manager Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 3‐4‐11 Web Browser Location Field (Factory Default) Step 2: The WG‐500P configuration main menu will appear. Enter account as the Username and account as the password and click Login.
WG‐500P Hotspot in a Printer Supervisor Account Step 1: Start your Web browser and enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter. Figure 3‐4‐14 Web Browser Location Field (Factory Default) Step 2: The WG‐500P configuration main menu will appear. Enter supervisor as the Username and supervisor as the password and click Login.
WG‐500P Hotspot in a Printer Super Subscriber Account Start your Web Browser; a subscriber login page will appear. Enter super as the Username and super as the password and click Enter, you can use Internet now. Figure 3‐4‐16 Subscriber Login Page 346 SSL Certificate The function allows you to download the registered CA certificate into the WG‐500P. Figure 3‐4‐17 SSL Certificate Download Setting Screen Note: The password field must the same as the CA’s registered password.
WG‐500P Hotspot in a Printer 347 Ping Command The Ping function can check the WG‐500P networking connective or not. Figure 3‐4‐18 Ping Command Screen Item Description IP or URL Enter the IP address or the URL link. 348 Restart If your WG‐500P is not operating correctly, you can choose this option to display the restart WG‐500P screen. Clicking the apply button restart the WG‐500P, with all of your settings remaining intact.
WG‐500P Hotspot in a Printer 4 QR Code Service 41 QR code setting Please find Advance setting > Customization > Account Printout >QR code. If you don’t print out the QR Code on the ticket, please disable it and click Apply button.
WG‐500P Hotspot in a Printer 42 Additional information for QR code use If you will activate QR code service for Apple iOS 6 device and later, 1. Please find Advance setting > Security > Pass Through. 2. Choose “Enable”. 3. Add www.apple.com into PASS THROUGH list in WG‐500P because iOS6 device and later is required. 4. Click Add to List button. 5. Choose Active on the Pass Through List. For certain QR code Apps, please add go.redirectingat.com and follow the above steps.
WG‐500P Hotspot in a Printer 43 Use QR code to access the Internet Please follow the steps to access the Internet for clients. 1. Print out the Ticket. You can find the ESSID and WPA/WPA2 printed on the ticket. Figure 4‐3‐1 QR Coding Ticket 2. Connect to the ESSID(ex: Handlink_WG‐500P ), input WPA/WPA2 password(ex: 1234567890).
WG‐500P Hotspot in a Printer 3. Open up QR code APP and Scan. Scan QR code Figure 4‐3‐3 Scan 1 Screen 4. Some Apps may require user to click "Go to URL".
WG‐500P Hotspot in a Printer 5. Client can use the Internet now.
WG‐500P Hotspot in a Printer 5 Personal ID Recognition Some countries or areas would ask users to show their personal identification when accessing WiFi service according to laws for the cybercrime investigation. WG‐500P provides the function Personal Identification Recognition. The default is disabled. Subscribers need to activate it by the following steps.
WG‐500P Hotspot in a Printer 51 Personal ID Recognition Setting Step1. Active the function: Go to Advanced Setup ‐> System ‐> System. Enable the Personal ID Recognition Mode. Please refer the Chapter 3‐2‐5‐1 System.
WG‐500P Hotspot in a Printer Step2. The first billing profile you activate is the Personal ID Recognition selection. There is only ONE billing profile in the Personal ID Recognition mode. Please refer the Chapter 3‐2‐2‐1 Billing to modify your first billing profile. Figure 5‐1‐2 Billing Setting Screen Step 3: Start your browser, and then enter the factory default IP address 10.59.1.1 in your browser’s location box. Press Enter.
WG‐500P Hotspot in a Printer Step 4: The WG‐500P configuration tools menu will appear. In the Username and Password field, type the factory default user name “account” and password “account” and click Login. Figure 5‐1‐4 Configuration Tools Menu Step 5: ONLY account manager can operate PIR and printout the ticket. There are 3 types for the account manager to choose, including Driver License NO., Passport No. and Identify card No. Fill in numbers and click “+” or “‐” for usage time.
WG‐500P Hotspot in a Printer Figure 5‐1‐6 PIR Ticket Step 6: Click Logout and then click the Apply button to finish it.
