User's Manual

PRODUCT INFORMATION
02-00038-107 Specifications Subject to Change Without Notice. © 2011 Guard RFID Solutions, Inc.
Conforms to UL-294
FCC ID: VZKST
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Guard RFID Solutions Inc.
#140 – 766 Cliveden
Avenue
Delta, BC
Canada V6M 6C7
Tel: [phone]
Fax: [phone]
www.guardrfid.com
Staff Tag
ST-1BLF, ST-3BLF-TR
F E A T U R E S :
 Low profile for attachment to Proximity Cards
 12 months battery life – Replaceable batteries
 2-way communications for Paging capability
 Two configurable buttons for custom functions
 Audio-Visual Indicators, Motion and Fall Detection
 Splash-resistant
D E S C R I P T I O N :
The ST-1BLF and ST-3BLF-TR are low profile tags for tracking, location and security of
personnel. These tags have locating “Blink” message capability for RTLS applications and also
include a Low Frequency (LF) Receiver so that they can be instantly detected at areas of interest
such as building exits, secure rooms, or workstations. The tags can trigger security-related action,
identification/authentication, and patient interaction recording upon entering detection or security
zones created using GuardRFID Tag Exciters.
The ST-3BLF-TR has two buttons to allow users to send configurable alerts to the system as well
as two visual indicators. It also has a UHF Receiver so that the tag-wearer can receive alerts or
acknowledgements from the system through the indicators and an audible buzzer, and contains a
sensor to provide the ability to sense motion or detect a fall. This enables powerful staff duress
call and personnel safety capability, as well as paging functionality.
The low profile design ensures that they can be comfortably carried using a clip or lanyard. They
can also be coupled with existing personnel badges or proximity cards using the convenient
adhesive label on the tag. Splash-resistance ensures that these tags can be worn outdoors and
can be easily cleaned and sterilized.
S P E C I F I C A T I O N S :
S T - 1 B L F
S T - 3 B L F - TR
Part Number
61-10401
61-10400
Transmit Frequency
433 MHz
433 MHz
Receive Frequency
125 KHz
433 MHz and 125 KHz
Battery Life
12 months – replaceable batteries
12 months – replaceable batteries
Beacon Interval
10 sec
Programmable, 10 sec to 10 min –
default 30 sec
User Interfaces
None
2 x buttons, 2 x Visual Indicators,
Audio transducer
Sensors
None
Fall and Motion Detection
Dimensions
3.28 x 1.94 x 0.17”
(83 x 49 x 4.3 mm)
3.28 x 1.94 x 0.17”
(83 x 49 x 4.3 mm)
Weight
20 gm
20 gm
Operating Temperature
-4° F to 122°F (-20°C to 50°C)
-4° F to 122°F (-20°C to 50°C)
Humidity
0 – 100% RH non-condensing
0 – 100% RH non-condensing
Regulatory
FCC Part 15 Approved
FCC Part 15 Approved
Warranty
Prorated over 12 months
Prorated over 12 months
