• Copyright © 2008 Group Sense Mobile-Tech Limited. All rights reserved. • Product specifications and features are for reference only and Copyright Copyright are subject to change without prior notice. Declaration • This Quick Start Guide is published by Group Sense MobileTech Limited without any warranty.
Copyright FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
PLEASE READ THIS CAREFULLY BEFORE USING WF35! • Always treat your product with care and keep it in a clean and dust-free place. • Do not expose WF35 to moisture or humidity. • Do not expose WF35 to extreme high or low temperatures. • Do not attempt to disassemble your product. • Use only the chargers and batteries approved by Group Sense Mobile-Tech Limited. The use of any other type may invalidate Important safety information Important safety information any approval and warranty.
Important safety information • To reduce the risk of fire or burns, do not disassemble, crush or puncture the battery. • Recycle or dispose of the battery safely and properly according to local laws and regulations. • Do not dispose of the battery in fire or water. • Do not let the metal contacts on the battery touch other metal object, it could lead to short-circuit and damage the battery. • For WF35 model, only approved batteries, chargers that are designed for the model can be used with WF35 unit.
Getting to know WF35 7 Contents Contents WF35 overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Installing/removing battery . . . . . . . . . . . . . . . . . . . . . . . 9 Charging battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Getting started Turn on/off WF35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wi-Fi connection settings . . . . .
Contents 6 WF35 settings Screen rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Backlight settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MSR settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Date/Time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Dialing settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
WF35 overview Getting to know WF35 Getting to know WF35 7
Getting to know WF35 1 2 3 4 5 6 7 8 9 10/12 11 13 14 8 Name Description LED light LED light Speaker Reset hole Battery cover Shortcut SD card slot Earphone jack Charging slot Stylus Power key Show the status for Wi-Fi and battery Programmable LED Press to turn on WF35; press and hold to USB socket Mount slot turn off; if WF35 is on, press to suspend Connect to PC for data synchronization Mount your device on other fixed place Reset device Insert external card Connect the adapter to charge batter
Installing/removing battery To install battery 1. Align the metal contacts on the battery with the contacts inside the battery compartment. 2. Press the battery downwards until it fits the battery com- Getting to know WF35 Battery partment; push the battery lock leftwards. 3. Slide the battery cover upwards.
Getting to know WF35 10 To remove battery 1. Press and hold the Power button to turn off WF35. (See “Turn on/off WF35“.) 2. Remove the battery cover by sliding it downwards. 3. Push the battery lock rightwards to unlock battery; gently lift the upper edge of the battery outwards and take it out.
To charge the battery 1. Connect your charger to the charging slot (as below). 2. Plug the charger to the main electrical outlet. 3. The LED light turns orange. 4. When charging is complete, the LED light turns green. Getting to know WF35 Charging battery Note: Charge the unit when the LED is RED.
Getting to know WF35 LED light description There are two LED lights on the front of WF35, we will give the information for the left one here: • Red flash - Battery low • Red - Battery very low • Orange flash - Battery charging • Green - Battery full • Blue flash quickly - Wi-Fi searching • Blue flash slowly - Wi-Fi connected • Off - Wi-Fi disconnected 12
Icon Description ActiveSync MSR connected Swipe the card successfully Fail to swipe the card Getting to know WF35 Description for icons on task bar WLAN connected WLAN searching WLAN disconnected Battery indicator Battery charging Tap to switch application 13
Getting to know WF35 14 Icon Description Short tap to hide/show current Input method keyboard Tap and hold to select another Input method Start menu
Turn on/off WF35 To turn on WF35 Getting started Getting started 1. Press the Power button on the top of WF35. 2. The GREEN LED lights on for a second and the boot logo is shown. It will boot to the WinCE OS. To turn off WF35 1. Press and hold the Power button on the top of WF35 for 2 seconds to turn it off. To suspend WF35 1. If WF35 has been turned on, press the Power button to suspend, so as to save power.
Getting started Wi-Fi connection settings 1. In WinCE desktop, tap in system tray, select “Control Panel” in “Settings”. 2. Select “WLAN” in control panel. Then tap “Choose Network” button.
Getting started 3. Select an available WLAN in the list or add a new connection. Tap “Connect & Lock”.
Getting started 4. Input network password if needed. Tap input method icon on system tray to open soft keyboard. Tap “OK” to finish setting. 5. If connection succeeds, system will show on the status field of Wireless Information screen. Tap 18 to exit.
Getting started 6. In WLAN setting main panel, you can perform Advance Setting, IP Setting, DNS and WINS Setting, and viewing IP info.
Getting started 7. When WLAN connected, there is a taskbar icon and top left LED (blue) to indicate connection status.
To enable Bluetooth 1. Double-click in Control Panel or on taskbar to open Bluetooth Manager page. 2. Tap to enable Bluetooth, and Bluetooth icon Getting started Using Bluetooth on taskbar will change accordingly.
Getting started Status Main page Taskbar Bluetooth Off Bluetooth turning on (yellow) Bluetooth On (Blue) Connecting Receiving 3. Select ON in “Bluetooth boot up default” option to enable Bluetooth automatically when turn on your device each time.
Tap “Settings” tab in “Bluetooth Manager” page to set Bluetooth. Getting started Bluetooth settings • Allow Connection from: you can select “All devices” to connect all Bluetooth devices; or you can select “Paired device only” to connect with paired Bluetooth only.
Getting started • Searchable by nearby Bluetooth devices: check this option, your device will be searchable by nearby Bluetooth devices.
Tap “Paired“ tab in Bluetooth Manager to open Paired page. If Bluetooth is disable, Paired tab will be hidden. To delete a paired device Getting started Paired Bluetooth If you already have paired devices, select a paired device in paired Bluetooth list, and tap “Delete Device“.
Getting started To delete a service When select a device in the paired Bluetooth list, you can view the device’s details, including the device name, address and the service supplied by the device. (the icon before the unpaired service will be gray) Select a paired service, and tap “Delete Service“.
Select a unpaired service and tap “Add Service“ to enter pass key to complete pairing operation.
Getting started Searching for Bluetooth Tap “Search“ tab or “Search“ button in Paired page to open Search page, you can search other Bluetooth device here. If Bluetooth is disable, this tab will be hidden. Select range of searching Bluetooth device from the pull down menu and tap “Search“. Available devices will be displayed in the service list. Select an unpaired service and tap “Add Service“ to add new service.
Tap “Services“ in Bluetooth Manager, all services that your device supports are listed in the Services list. Getting started Bluetooth services Select “File Transfer Profile“ service and tap “Advanced...“ to change the file transfer saving path (the default path is \My Documents).
Getting started Transferring files via Bluetooth 1. In WinCE desktop, tap in system tray, select “My Documents“. 2. Press and hold the file you want to send and select “Send via Bluetooth“ from the pop-up menu.
Getting started 3. Select the paired Bluetooth you want to send the file to, a “Send File“ box will pop up to wait for confirmation from your partner.
WF35 settings WF35 settings Screen rotation Two screen view mode are supported in WF35, you can change it as you like.
In Control Panel, double-click Backlight icon to open Back- light Properties page. Drag the scroll bar to adjust backlight.
WF35 settings 34 Power properties Double-click Power icon in Control Panel to open Power Properties page. you can view the battery information, set scheme and view the device status.
When connect to the MSR, the icon 1. Double-click displays on taskbar. in “Control Panel” to access “MSR Settings”. WF35 settings MSR settings 2. Select On/Off to set beeps on/off; input the prefix/suffix for the information displayed on screen when you swipe your card.
WF35 settings Date/Time settings Double-Click Date/Time icon in Control Panel to open Date/Time Properties page. Tap the pull down arrow of Time zone to select the location where you are, and then set the date and time, tap “Apply” to finish setting.
Double-Click Dialing icon in Control Panel to set dialing properties. WF35 settings Dialing settings You can tap “Edit” to modify the dialing patterns if necessary.
WF35 settings Input methods You have English and Simplified Chinese to use in WF35. Before using WF35, you can adjust input methods first. Regional settings Double-click to open Regional and Laguage Settings page. You can set your location, user interface language and input methods.
“Customize“ to set your location details. 2. Tap “Language” tab to set the language used for menus, dialogs and alerts. 3. Tap “Input“ tab to select the input method when you start WF35 settings 1. Tap the pull down arrow to select your location, and tap your device. Input panel settings Double-click Input Panel icon in Control Panel to change input methods.
WF35 settings You can tap “Options...“ to set details for your selected input methods, but if you are using English or PinYin, “Options” is invalid. Handwriting WF35 enables handwriting recognition in full screen or you can write in Graffiti area. We give English HW as an example.
Space • Delete a character before the cursor • Go to next line • Switch to Graffiti area • Switch to softkeyboard • Switch to number keyboard WF35 settings • Soft-keyboard Besides handwriting input, you also can input with soft-keyboard. We give English keyboard as an example.
WF35 settings 42 • Space • Delete a character before a cursor • Go to next line • Switch to upper case letter • Switch to full screen input mode • Switch to number keyboard • Switch to
You will have an external hard keyboard to connect with your device, so you can input text via hard keyboard.
WF35 settings Network and dial-up connection Double-click “Network and Dial-up Connection” icon to open Connection page, you have three ways to set up connection: Make new connection, USB and WLAN. To connect via making a new connection 1. Double-Click 44 , enter a name for the connection and select the connect type.
WF35 settings 2. Tap “Next“ to set details for your new connection. 3. Tap “Next“ to continue. 4. Tap “Finish“ to complete settings. To connect via USB 1. Connect device to PC via USB. 2. Double-click to connect.
WF35 settings 46 To connect via WLAN Double-click to set up connection.
Double-click to open Storage Properties. WF35 settings Storage manager settings 1. Tap “Format“ to to erase all data on the storage device permanently. 2. Tap “New” to create a new partition. 3. Tap “Delete“ to delete all data on the partition permanently. 4. Tap “Properties“ to view the selected partition properties.
WF35 settings 5. Tap “Format“ in Partition Properties to set format parameters, and then tap “Start“ to format. 6. Tap “Scan“ to start scanning all FATs on volume. 7. Tap “Defrag“ to start defraging.
Please close all active applications/programs before proceeding to backup, it will ensure backup data the most up-to-date snapshot of the system. Double-click WF35 settings System backup to open System Backup page. 1. Tap the pull down arrow to select backup type and corresponding options below, and then tap “Start“.
WF35 settings 2. Select “Restore“, tap “File“ to select files you want to restore, tap “OK“ and tap “Start“ to start restore.
