Fez Loygro-ppse, FCC Compliance Statement: This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in residential installations. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Quick Menu wor Connect the air exhaust system. Setup computer and connect with engraving system properly. Turn oN host computer system. Use Windows-based program, such as Correlated, to operate with the engraver. Install the GCC Driver. (for first time use only) Tum oN engraver. The lens carriage should move to the home position {upper left corner) after system initialization. Focusing: under OFF-LINE status, lower the table and put the work piece on the table, move X-Axis (Please refer to Fig.
® The choices of DPI must be the same for both editing and printing out a file. ® Turn on the air exhausting system and press font LINE] to setup engraver in ON-LINE condition before engraving.
Content Quick Menu VIL VIOL Soft Wale —-m--NM mere ss mm mmm 7 Cabling Connection Exhaust Vent. Environment aa S—| Control Panel -11 Operation Flow -14 A. Specification B.
« “auction: ® The weight of Laser Pro is about 330 ponds. To prevent damage to machinery or injury to wankers, please get assistance. Do not lift the equipment alone. ® Please save the original shipping crate in case any returning service is needed. ® Please inspect what you have received from the shipped carton by comparing with the following listed items.
Step 1. Put the side board on the floor. Make sure the outer side faces up. Fig. 3 Step 2. Remove the fixed bar LL Arrow pointing toward front Fig.
° Computer: Your PC must be sufficient to equip with Window 95 at least. We recommend the specification of PC for better work as below: CPU Pentium at least DRAM 32 MB RAM or up FDD One 3.5" 1.44 MB floppy HDD 1.2 GB Hard Drive or up SAGA 15 Super VGA Monitor Scanner Flat Bed Minimum resolution: 200 DPI Software GCC driver (designed under Window 95 OR Windows 3.1) Windows Window 95 or higher Correlated 7.
(Caution: ® Tum all equipment off before making any connection. ® Check the plug of the power cord to see if it mates with the wall outlet. If not, please contact your dealer. Cabling Connection: 1. Insert the power cord (male) into a grounded power outlet. 2. Plug the other end (female) into the engraver. The engraver has been design to switch from 100 240 VAC automatically. 3. The engraver can communicate with a computer through either a serial (RS-232C) or a parallel port (Electronics.
@® Parallel Transmission Connect a parallel cable to the engraver (parallel port) then to the parallel port of the host computer. [Caution: Never use a mechanical switch box when a second printer port is required. The electrical surges can cause damage to the computer and the engraver. ® Serial Transmission If you are using IBM PC, PS/2 or their compatibles, connect the supplied RS232C cable to the engraver (serial port) then to the serial port of the host computer.
Install GCC printer driver for windows 95 Power On, click START] — choose Settings and click [Printers — Double click |Add printer and start Add printer wizard Next step Choose Local and click [Next ste choose Have disk and click Next step Insert the GCC Driver disk properly into the floppy drive then click jok! choose the port where your laser system is connected and click [Next step name your system or bypass choose the driver to be default printer Next step select No when asked to print a test page and c
Environment ® A clean, welt-ventilated room with a temperature of 10°C~ 40°C and a relative humidity between 30% and 70%, as an office type environment. Stable floor isolated from vibration. Avoid from unstable voltage supply. Short path for an effective air exhaust. Have a fire extinguisher available at any time. Control Panel Fig. 10 ON/OFF LINE ON-LINE: The laser engraving system is ready to receive data from the host computer and start engraving or cutting.
Arrow Buttons Move cursor on the display for selection. ESC (Escape) Exit and back to the main menu. SPEED Setup laser speed for desired effect. Working without using GCC’s driver only. Press FUNCTION key, select one of the sixteen steps then set up desired cutting speed. ’ POWER Setup laser power for desired depth and effect. Other conditions are same as above stated in SPEED. RED BEAM On/off red beam DATA CLEAR Under OFF-LINE condition press this key will clear the data of the current file.
1. Select Setup #1-16? [ENTER —> Setup # 1-16 —® press ERROR KEY to chose setup number — press POWER / SPEED then MALARKEY for proper power / speed selection —% ENTER, the chosen power and speed have been saved in the selected number. the next step "Select Baud Rate?" 2. Select Baud Rate? Baud Rate is to determine the speed of data transmission to communicate with the host computer. Setting Range: 9600, 19200 Defaults: 9600 3 got the next step "Set Data Bit/Parity?" 3.
K “auction: ® Keeping the optics and motion system clean is essential to an excellent quality engraving and the reliability of your engraver. ® Never pour or spray any solution directly onto the laser system. ® Turn off the system and unplug the laser engraver before cleaning. 1. Inside the System: Open the top door, front door and the back door (if necessary). Vacuum clean inside the engraver and vent area thoroughly. 2.
® Clean without disassembling the Carriage: 1. Remove screws #1 and #2 (Please refer to Fig.12) 2. Take out the focus carriage, clean the lens and mirror by using a cotton swab and proper clean solution. ® Clean the mirror and lens by removing them from Carriage: Clean the mirror 1. Remove screw #3 and pull away the mirror carefully. 2. Drop a lens cleaner on the middle area of the mirror, gently pull the lens tissue across the mirror in one direction to absorb the fluid. 3. Let it air dry and reinstall it.
Quality Problems ® Check focus length. ® Focus Lens and O-ring are not installed correctly. Focus Lens loose in the holder. ® Debris or dust builds up in the bearing tracks and X-Axis rails. ® The focus lens and the mirror in the carriage are damaged or need to be cleaned. Non-operational Problems ® Laser beam is not generated. If the red alignment beam is not revealed; the laser beam is misalignment. Adjust reflection mirrors for exact focus.
A. Specification 7] |] Laser Pro L-12 L-25 L-50 Laser Source 12W 25W S50W Sealed CO, laser ‘Work Area 24x 187 (610mm x 457mm) Max. Working Piece (WD Thick) 337 x 37° x 7.57 (back & front door closed) (850mm x 570mm x 190mm) Max. Working Piece (Windex Thick) 307% 00 xT” (back & front door opened) 750mm » oo x 180mm Table Size 33” x 21° (840mm * 530mm) Overall Dimensions 437 WxDxH (1100mm x 720mm * 1000mm) Drive DC servo control Speed Control Adjustable from 0.
