Gotrec DVR A2pro User Manual Thank you for choosing Dual Camera DVR. For proper usages and application, please read this manual thoroughly before using this product.
Content: 1. 2. 3. 4. 5. 6. 7. 8. Feature: …………………………………………………………. Precaution: …………………………………………………….. Appearance and Parts: …………………………………… Operation Instruction: …………………………………… Application: ………………………………………………….. Specification: …………………………………………………. Troubleshooting: …………………………………………… Accessories: …………………………………………………..
1. Genuine product of Car DVR performance is compiled to genuine manufacture requirement. 2. Dual Full HD Front /Rear camera. 3. Front Camera use 140-degree wide angle Lens to capture every moment. 4. Rear camera use 120-degree wide angle Lens to focus the key image. 5. WDR function improve the good video quality. 6. Built-in G-sensor, the device will automatically record the emergency record upon an even. 7.
Appearance and Parts Operation Instruction A.
to confirm. After setting, press 【Menu key / MEMU】 shortly to exit the menu setting function (Press OK button stop recording first.). Function 2: Mode key / MODE function In standby mode, press and hold [Menu key / MEMU] to switch between the three modes of recording mode / photographing mode / playback mode. 2 OK (confirm) Function 1: start/Stop video / photo / play function In standby mode, short press [Confirm key / OK] to start recording, and short press [Confirm key / OK] again to stop recording.
recording function has been turned off. Short press again to start recording, and the prohibition icon disappears. 5 Wifi One click to open WiFi connection, Configuration with APP: Press and hold for 3 seconds-configuration mode B. Video Interface 1. Current recording time 2. Video icon 3. Loop recording / 3 minutes 4. Gravity sensing / Medium 5. Motion detection ON 6 WDR ON 7. Current time 8. Mic audio recording 9. WIFI Status 10. GPS signal (optional) 11. Resolution Status 12.
D. Camera Interface 1. On the recording interface ( with the recording stopped ), press and hold[ Menu Button ] once to switch to the camera interface. 2. Photograph: Short press [ Confirm Button ] to take a picture ; 3. Photograph setting: On the camera interface, press [ Menu Button ] once to enter the photo setting interface , short press [ Up Button ] or [ Down Button ] to adjust related setting and press [ OK ] to confirm.
E. Playback video / Picture interface 1. Enter the interface: On the recording interface ( with the recording stopped ), press and hold [Menu Button] twice to switch to the video / picture playback interface. 2. Playback: Short press [ Up Button] or [ Down Button ] to select the video / picture to view. Press [ OK] to play, short press [ Menu Button] to return to the previous directory. 3. Delete file: In the playback interface, short press [ Menu Button] once to delete / lock the video, etc.
G. Function introduction 1.Use the automatic recording function Start the car engine, the recorder automatically starts and turns on the recording function, and the video indicator flashes. Turn off the car engine, the recorder automatically saves the recorded content and shuts down. The recorded images are stored on the TF card in sections. When the TF card is full, the recorder will overwrite the previously recorded images.
7.Exposure compensation Users can increase or decrease the exposure intensity of the front camera according to the ambient brightness. 8.Video and audio In the menu setting interface, the user can choose to turn on or off the recorded audio. 9.Date labels In the menu setting interface, after opening the date label, the recorded video will display the date. 10.
16.Automatic shutdown When the automatic shutdown function is set to 1 minute, the machine will shut down after 1 minute without recording and no operation; the system is turned off by default. 17. Screen saving When the screen saving function is set to 30 seconds, the machine will automatically turn off the screen after 30 seconds without any operation. After the screen is closed, press any key to turn on the screen; the system defaults to off. 18.
H. Installation Guide ( Based on the car mode will be designed) 1. Shut down the car engine. 2. Insert the TF card into the recorder card slot. [Note] Please use a high-speed TF card (Class10). The TF card supports a maximum of 512GB. 3. Connect the bracket to the host, and then fix the machine to the front windshield of the car. 4. Connect one end of the installation cable to the machine, and then connect the other end to the fuse box.
Application Application Download 1. For the first time using the recorder, please scan the QR code below with your mobile phone to download the APP: Android Apple 2. After starting the car and turning on the recorder and entering working state, find the WIFI beginning with " DVR_TC2-XXX -****" in the phone settings, and enter the default password 12345678 to connect. 3. Enter the APP after the connection is completed, and the time of the recorder will be synchronized with the current mobile phone time.
Application operation instructions Specification Processor and memory characteristics Processor Type Memory Flash Display External port Speaker MIC NT96675 1 Gbit (Built-in) 8 MByte IPS 2” HD Screen 8 ~ 512G 10class TF card 8 ohm 1 watt mono speaker 4015 Standard omnidirectional microphone Features Front camera Photo Dynamic range adjustment Video format Picture format Storage compression method Language support One second per shot G-sensor Loop recording Parking monitoring IMX307 / 2MP 1080P / 6G+IR 14
Troubleshooting If your device is not working properly, please check it as follows. If the problem cannot be solved, please contact our customer service centre. Malfunction Cannot boot Cannot record No post recording Reason Bad cable No memory card inserted Memory card is damaged Insert card cannot meet the requirements.
Accessories Item Description 1 Main Device*1 2 Rear Camera*1 3 Power cable*1 4 Rear Camera extend cable*1 Pictures
5 Holder*1 6 Cable tube*1 7 Warranty card*1 8 User manual*1 9 Micro SD Card 16G*1 [Note] When the device installed successfully, the device display light; the device starts to enter the recording state, and the recording icon flashes. Please check if the picture on the screen is standard or not. If the display is inverted, please contact us in time. Information provided in the instruction manual of the driving recorder is for reference only.
FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
