Welcome Congratulations on your purchase of a Phone Clip+ Phone Clip+ will allow you to connect your wireless Resound hearing instruments to Bluetooth-enabled mobile phones. This enables clear and hassle-free phone connectivity, whether you are at home, in the office or on the move. Statement: This device complies with Part 15 of the FCC rules.
Changes or modifications can void the users authority to operate the equipment Intended use Phone Clip+ is intended to enable wireless Resound hearing instrument users to better follow phone conversations. The essential performance of the Phone Clip+ is to transfer signals between a phone with Bluetooth capabilities and wireless Resound hearing instruments.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. In JP: This device has been granted a designation number by Ministry of Internal Affairs and Communications under „Ordinance concerning Technical Regulations Conformity Certification etc.
Description 6. Volume control 1. ON/OFF switch 7. Microphone inlet 2. Call pick-up/hang-up button 8. Mounting clip 3. Hearing instrument program toggle 9. Hearing instrument pairing button 4. Hearing instrument microphone mute button 10. Bluetooth pairing button 5.
Getting Started Charging the Battery Before using your Phone Clip+, you need to fully charge the rechargeable battery. To charge it, plug the charging cable into the Phone Clip+ as shown in the picture to the right. Then plug the other end of the charging cable into a power outlet. During the charging process, the LED indicator at the top of the Phone Clip+ will show a solid red light.
1. Make sure Phone Clip+ is turned on. Your hearing instruments must be OFF – this is done by opening the battery door on the hearing instrument(s). 2. Remove the silver cap from the Phone Clip+. With the tip of a pen or similar object, press the small white pairing button one time on the back of your Phone Clip+ (see picture to the right). The LED will now blink yellow every 2 seconds to indicate that is ready to be paired to your hearing instruments.
complete the pairing procedure with the generic steps described here. 1. Turn you Phone Clip+ ON and remove the silver cap. Place your mobile phone next to the Phone Clip+, and make sure your phone is ON. 2. Find the connectivity settings on your phone. Look for the “Bluetooth” feature in the main menu or one of the sub menus, such as “Connectivity”. 3. On your mobile phone, ensure that Bluetooth is turned ON. 4.
Phone operation In the below table you will find an overview of how you operate the Phone Clip+ when using it in connection with phone calls. Answering and ending a call Tap the call pick-up/hang-up button once Note: Except for the answer and end call operations one or more of the below described operations may be phone dependent, i.e. they may either differ slightly or be absent altogether.
Voice dialling Press and hold the call pick-up/hangup button for 2 seconds if two mobile phones are connected this operation applies to the last paired mobile phone This functionality requires that the Voice dialling functionality is available and activated on your Bluetooth phone Increase or decrease the volume of the speaker at the other end of the phone call Push the + sign on the side of the Phone Clip+ to increase the volume Mute or unmute your hearing instrument microphones during a phone call P
When not on the phone, the Phone Clip+ can be used as a simple remote control for your hearing instruments. To unmute your hearing instrument microphones push the microphone mute/unmute button (4 on page 8) once on the front of the Phone Clip+ Volume Control Toggle through hearing instrument programs Increasing the volume of your hearing instrument(s) Push the + sign on the volume control (6 on page 9) to decrease the volume of your hearing instrument(s).
Light indicators The Light indicator (3 on page 8) on your Phone Clip+ serves as a multipurpose user interface, providing information on the status of your device.
Introduction to Bluetooth What is Bluetooth? Bluetooth provides a way for devices like mobile phones to communicate wirelessly. First, check whether the phone you wish to use offers Bluetooth connectivity. Look for the following symbol on the device or its user guide. to a range of approximately 10 meters. Line-of-sight between the devices is not required.
Important Information i Maintenance and Care • Clean the ReSound Unite Phone Clip+ using a damp cloth. Never use household cleaning products (washing powder, soap etc…) or alcohol to clean the device • When ReSound Unite Phone Clip+ is not in use, turn it OFF and store it safely • Protect ReSound Unite Phone Clip+ from excessive moisture (bathing, swimming) and heat (radiator, car dashboard). Protect it from excessive shock and vibration. • Protect the microphone and charger inlets from debris and dirt.
i General Precautions Do not use this device in locations where it is forbidden to use electronic devices. • X-ray radiation (e.g. CT scans, MRI scans) may adversely affect the correct functioning of this device. We recommend that you switch the device OFF before undergoing X-ray procedures and keep it outside the room. • High-powered electronic equipment, larger electronic installations and metallic structures may impair and significantly reduce the operating range.
i Battery warning! • ”Caution” – The battery used in this product may present a risk of fire or chemical burn if mistreated. • Do not attempt to open the product or replace the battery. It is built-in and not changeable. Use of other batteries may present a risk of fire or explosion and the warranty will be terminated. • The battery in your product can not be removed or replaced by the user. Any attempt to do so is risky and may result in damage of the product.
• Do not charge the ReSound Unite Phone Clip+ while it is on your body. Technical specifications Operating range: Wireless: Operating temperature: Charging temperature: Storage temperature: up to 3 meters 2,4 GHz 0 to 45 degree C 0 to 45 degree C -20 to 45 degree C Temperature test, transport and storage information The product is subject to various tests in temperature and damp heating cycling between -25 C and +70C according to internal and industry standards.
Warranty What is not covered by this warranty? The Phone Clip+ is covered by a limited warranty issued by the manufacturer for a period of 12 months from the day of the original purchase. Please notice that extended warranties may apply in your country. Please contact your local Hearing Care Professional for more information.
TROUBLESHOOTING GUIDE Symptom Cause Possible remedy The Phone Clip+ does not respond to any (long or short) presses on the call pick-up/ hang-up button The battery in the Phone Clip+ is depleted Charge the battery The pairing button on the Phone Clip+ is pressed but no pairing melody is played in the hearing instrument after the battery doors have been closed The Phone Clip+ and hearing instrument are not within wireless range Assure that Phone Clip+ and hearing instruments are within wireless range
TROUBLESHOOTING GUIDE Symptom Cause Possible remedy The Bluetooth pairing failed The Phone Clip+ left Bluetooth pairing mode before mobile phone completed the pairing session Repeat the Bluetooth pairing process, and assure that the process is completed within 120 seconds after having been activated in the Phone Clip+ The wrong 4-digit PIN code has been entered Repeat the Bluetooth pairing process and if a PIN code is requested, enter 0000 (four zeros) The Phone Clip+ is powered off Power on the Ph
TROUBLESHOOTING GUIDE Symptom Cause Possible remedy The mobile phone is ringing and the light indicator on the Phone Clip+ does flash, but no ringing tones will sound in one or both hearing instruments The Phone Clip+ and hearing instruments are not within wireless range Assure that Phone Clip+ and hearing instruments are within wireless range The battery in the hearing instruments is so depleted that it no longer supports audio streaming Replace the battery in the hearing instrument with a new one
Be aware of information marked with the warning symbol WARNING points out a situation that could lead to serious injuries, CAUTION indicates a situation that could lead to minor and moderate injuries Advice and tips on how to handle your ReSound Unite accessory better.
