GC-TITAN RIDGE 2.0 Installation Guide/安裝指南/安装指南 12WE6-TITAR2-00AR For more product details, please visit GIGABYTE's website. To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
Product Specification Chip Back Panel Connectors Internal Connectors Intel® DSL7540 Thunderbolt™ 3 Controller 1 x DisplayPort, supporting a maximum resolution of 8K (7680x3840)@60 Hz (Note 1) (Note 2) * Support for DisplayPort 1.4 version, HDCP 2.2, and HDR.
產品規格 晶片 後方面板裝置 連接插座 Intel® DSL7540 Thunderbolt™ 3 控制器 1個DisplayPort輸出插座，可支援至最高8K(7680 x 3840)@60 Hz 的解析度(註一)(註二) 2個Thunderbolt™ 3輸出插座(Thunderbolt™ 3插座1/Thunderbolt™ 3插座2)，最高可支援40 Gbps傳輸速度，螢幕可支援 至最高8K(7680 x 3840)@60 Hz的解析度(註一)(註二) 2個Mini-DisplayPort輸入插座(DP_IN1/DP_IN2) 2個6-pin PCIe電源插座 1個USB 2.0/1.1插座 1個5-pin Thunderbolt™ 插座 1個3-pin Thunderbolt™ 插座 PCIe 3.0 介面(PCIe x4) 每埠可支援至最高40 Gbps雙向傳輸速度 支援Windows 10 (64-bit) RS3(含)以上版本 請至技嘉網站查詢有關支援的主機板列表 * 支援DisplayPort 1.4版本、HDCP 2.
产品规格 芯片 后方面板设 备连接插座 Intel® DSL7540 Thunderbolt™ 3 控制器 1个DisplayPort输出插座，可支持至最高8K(7680 x 3840)@60 Hz的 分辨率(注一)(注二) 2个Thunderbolt™ 3输出插座(Thunderbolt™ 3插座1/Thunderbolt™ 3插座2)，最高可支持40 Gbps传输速度，屏幕可支持至最高 8K(7680 x 3840)@60 Hz的分辨率(注一)(注二) 2个Mini-DisplayPort输入插座(DP_IN1/DP_IN2) 2个6-pin PCIe电源插座 1个USB 2.0插座 1个5-pin Thunderbolt™ 插座 1个3-pin Thunderbolt™ 插座 PCIe 3.0 界面(PCIe x4) 每个接口可支持至最高40 Gbps双向传输速度 支持Windows 10 (64-bit) RS3(含)以上版本 请至技嘉网站查询有关支持的主板列表 * 支持DisplayPort 1.4版本、HDCP 2.
Installing the GC-TITAN RIDGE 2.0 Add-in Card 安裝GC-TITAN RIDGE 2.0卡 • 安装GC-TITAN RIDGE 2.
Mini-DisplayPort Cable x 2 Mini-DisplayPort連接線-2條 USB 2.0/1.1 Header Cable x 1 USB 2.0/1.1插座連接線-1條 Mini-DisplayPort连接线-2条 USB 2.
Step 1: Install the GC-TITAN RIDGE 2.0 add-in card in the PCIEX4 slot. 步驟1： 將GC-TITAN RIDGE 2.0卡安裝至PCIEX4插槽。 步骤1： 将GC-TITAN RIDGE 2.0卡安装至PCIEX4插槽。 Step 2: Connect one end of the USB cable to the USB connector on the GC-TITAN RIDGE 2.0 card. 步驟2： 將USB排線的一端接至GC-TITAN RIDGE 2.0卡的USB連 接埠插座。 步骤2： 将USB扁平电缆的一端接至GC-TITAN RIDGE 2.0卡的USB 接口插座。 Step 3: Connect the other end of the USB cable to the F_USB connector on the motherboard.
Step 4: Connect one end of the Thunderbolt™ header cable (5-pin) to the 5-pin Thunderbolt™ header on the GC-TITAN RIDGE 2.0 add-in card. 步驟4： 將Thunderbolt™插座連接線 (5-pin)的一端連接至GC-TITAN RIDGE 2.0卡上的5-pin Thunderbolt™插座。 步骤4： 将Thunderbolt™ 插座连接线 (5-pin)的一端连接至GC-TITAN RIDGE 2.0卡上的5-pin Thunderbolt™插座。 Step 5: Connect the other end of the cable to the Thunderbolt™ add-in card header (Note 1) on the motherboard.
Step 6: Connect one end of the Thunderbolt™ header cable (3-pin) to the 3-pin Thunderbolt™ header on the GC-TITAN RIDGE 2.0 add-in card. 步驟6： 將Thunderbolt™插座連接線 (3-pin)的一端連接至GC-TITAN RIDGE 2.0卡上的3-pin Thunderbolt™插座。 步骤6： 将Thunderbolt™插座连接线 (3-pin)的一端连接至GC-TITAN RIDGE 2.0卡上的3-pin Thunderbolt™插座。 Step 7: Connect the other end of the cable to the Thunderbolt™ add-in card header (Note 2) on the motherboard.
Step 8: Connect the power cables from the power supply to the two PCIe connectors. 步驟8： 將電源供應器上的電源接頭連接至兩組PCIe電 源插座。 步骤8： 将电源供应器上的电源接头连接至两组PCIe电源 插座。 9-2 Step 9: Follow the steps below to use the included MiniDisplayPort cable to connect your graphics card to the GC-TITAN RIDGE 2.0 add-in card. 9-1: Connect the cable from the DisplayPort In connector on the GC-TITAN RIDGE 2.0 add-in card to the DisplayPort on your graphics card.
步骤9： 请依照下列步骤使用所附的Mini-DisplayPort连接线将您的显卡与GC-TITAN RIDGE 2.0卡做连接。 9-1：GC-TITAN RIDGE 2.0卡上的Mini-DisplayPort In插座需链接至显卡的DisplayPort。 9-2：GC-TITAN RIDGE 2.0卡上的Thunderbolt™ 3插座则需链接至Thunderbolt™设备或DisplayPort 屏幕。 •• When connecting DisplayPort monitor, if you connect the Mini-DisplayPort cable to the DP IN 1 connector, you must connect the monitor’s cable to the DisplayPort connector or Thunderbolt™ 3 connector 1.
Daisy-chaining Thunderbolt™ Enabled Devices•串接Thunderbolt™ 裝置• 串接Thunderbolt™ Refer to the following for connecting Thunderbolt™-enabled devices in a daisy-chaining configuration. The following are single-port configurations. (Make sure the Thunderbolt™-enabled devices to be daisy-chained have both Thunderbolt™ in and out ports.
Six Thunderbolt™ devices and three DisplayPort monitors (A graphics card with DisplayPort support is required) 6台Thunderbolt™裝置及3台DisplayPort規格螢幕 (需搭配支援DisplayPort 規格的顯示卡) 6台Thunderbolt™设备及3台DisplayPort规格屏幕 (需搭配支持DisplayPort规格的显卡) Installing the Driver•安裝驅動程式•安装驱动程序 After the computer starts, install the driver for the GC-TITAN RIDGE 2.0 add-in card. Insert the included driver disc and follow the on-screen instructions to install the driver. 電腦重新開機後，請安裝GC-TITAN RIDGE 2.
