User's Manual

Bluetooth Module

Installation Guide

Model: BT3014-GP

BT3014-GP Bluetooth Module is an integrated module for implementation in various

applications to enable electronic devices to communicate wirelessly with other

Bluetooth

- enabled devices.

Specifications

User Interface:

USB : USB 1.2 compliant

Software:

Bluetooth HCI interface supports USB

(1.1)

Operating Frequency

Range:

2402 MHz to 2480MHz

Modulation:

GFSK

Tx Data Rate:

Downstream: 723 Kbps (max)

Upstream : 57 Kbps (max)

Sync : 433Kbps (max)

Rx Sensitivity:

-87 dB min

Hopping Channel:

Data Rate:

1Mbps

Antenna Interface:

50 ohm

PAGE 1
Bluetooth Module Installation Guide Model: BT3014-GP BT3014-GP Bluetooth Module is an integrated module for implementation in various applications to enable electronic devices to communicate wirelessly with other BluetoothTM - enabled devices. Specifications User Interface: Software: Operating Frequency Range: Modulation: USB : USB 1.2 compliant Bluetooth HCI interface supports USB (1.
PAGE 2
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
