Specification

Operator’s Manual for Power Washer 1

FEATURES

• Generac G-Force Engine: Powerful, easy starting

engines make our Powerwagon the natural choice for

any task, and are designed for long life.

• Powered Dumping: A steep 60° dump angle empties

the bed thoroughly at the push of a button, minimizing

the need for raking out materials.

• Gear-Driven Transmission: Three forward speeds

and a powered reverse match any walking pace and

aid maneuverability in tight spaces.

• More Maneuverable in Tight Spots: Two rear wheels

rotate 360°, creating a tight turning radius, allowing

the Powerwagon go through gateways and barn

doors, into wooded areas, on narrow trails, and more!

• Disc Brake: A hand-actuated disc brake checks the

speed of a fully loaded cargo bed when operating on

slopes. Lockable brakes secure the machine in place

for loading and unloading.

Powerwagon

Commercial

Power Tools

Powerwagon

Model: PW27080GENG

UPC: 843530005752

1 of 3

GENERAC PRO POWERWAGON

• 800 lbs (363 kg) capacity (8.0 ft

[0.2 m

]).

• Three forward speeds, one reverse.

• One-piece molded bed; high-density polyethylene.

• Powered dump allows unloading with the push of a button.

• Rear caster-type wheels allow utmost maneuverability.

PAGE 1
Powerwagon Powerwagon Commercial Power Tools 1 of 3 Model: PW27080GENG UPC: 843530005752 GENERAC PRO POWERWAGON • 800 lbs (363 kg) capacity (8.0 ft3 [0.2 m3]). • Three forward speeds, one reverse. • One-piece molded bed; high-density polyethylene. • Powered dump allows unloading with the push of a button. • Rear caster-type wheels allow utmost maneuverability.
PAGE 2
Powerwagon 2 of 3 Specifications General Dimensions Type Speed Motor driven 3.7 mph (5.9 km/h) max forward 1.4 mph (2.3 km/h) reverse Transmission 3-speed plus reverse Assembly Required Some assembly required Hauling 8 ft3 (0.2 m3) Bed Volume Engine Generac G-Force Width 34 in (86 cm) Height 41 in (104 cm) Weight 240 lbs (108.9 kg) Handlebar Height 41 in (104 cm) Fuel System Fuel Capacity Frame Electric with recoil backup Air Filter Element 1.6 qt (1.5 L) Tubular steel (1.
PAGE 3
Model # Product Description 417001 Tire Chains Perfect for snowy or icy conditions. Get extra traction in rough winter weather. These heavy-duty chains mount easily without tools. Zinc-plated to resist corrosion. 417011 Wheel Weight Kit Add stability and traction. Add 30 lbs (13.6 kg) to each wheel for extra stability and traction. 417021 Tool Holder (Set of Two) Attaches to the frame with a single bolt. Perfect for carrying long-handled tools like shovels and rakes. Sold in sets of two.
