WiFi DISPLAY WMTC-159N WiFi Display Production Description
Content 1 2 Introduction .............................................................................................................3 1.1 Wireless Display .................................................................................................................... 3 1.2 Outlook..................................................................................................................................... 4 Feature Overview ..................................................................
1 Introduction 1.
1.
Connect to TV/Monitor Device via HDMI 5
2 Feature Overview 2.1 Features The following is a list of the Gemtek WiFi Display evaluation board features: Communication protocols supported DLNA DMR (1.5 Certified) WFD Primary Sink Video decoding H.264 CBP (WFD specific) MPEG4, MPEG1, MPEG2, H.264, AVS, VC-1, H.
Receiver latency (WiFi PHY to dongle output) < 40ms (30 fps), or <23 ms (60fps) with HW crypto with HDCP 2 User support GUI: splash screen and connection status display Upgrade over WiFi with fail-safe mechanism Interfaces HDMI Tx 1.3 with CEC Tri-color LED (Blue, Red, Green) Multi-function reset button USB power input WiFi: dual band Selectable (2.4GHz/ 5GHz) 802.11n 1x1 USB Host (Option) Power Consumption Active state: <2.
3 System Overview 3.1 Streaming Mode This mode uses DLNA (Digital Living Network Alliance) protocol: the Smart Phone (or any other device on the network) provides DMC, and optionally DMS functionality while the dongle acts as DMR. The smart phone typically does not transcode the content as long as it conforms to DLNA codec specification. Note that DLNA discovery and connection works over any IP network. DTCP/IP can be used for premium content. Following network topologies can be supported by this mode.
3.
4 Detailed Functional Spec 4.1 Performance Feature Detailed Functional Spec Time from cold boot to splash screen 3 seconds (to HDMI output) Time from splash screen to idle screen (ready 30 seconds for connection) HDMI Video Output Up to 1080p 30 fps HDMI Audio Pass through and Raw Video display Latency through the dongle < 33ms (30 fps) 4.
uploaded from any connected device that has web-browser. Fail-safe upgrade procedure with ability to recover using factory-installed firmware Maximum time to perform upgrade over 20Mbps LAN connection: < 180 seconds Retains persistent connection settings across the upgrade Support for HTTP server for: Firmware upgrade Ability to configure connectivity to a router that does not support WPS Ability to configure any other parameters such as resolution, friendly name, etc. as deemed necessary. 4.
4.5 Hardware Interfaces IO interface Standard Interfaces (exposed on the system enclosure) – HDMI 1.3 with Type A HDMI receptacle – USB power input using Micro-USB type B receptacle that carries 5V DC input power to the board – Push button switch allows the user to access functions such as pairing with another W i-Fi device (an Access Point (AP) or a mobile device in P2P mode), wake from standby, system reset, and restoring factory defaults.
4.6 Power Gemtek WiFi Display is powered by a 5V input on the micro USB type B receptacle. Power can be provided to the receptacle either by a USB host device (i.e. TV) or an external AC power adapter. Maximum current draw is 500mA, for a total power of 2.5W . Power states, as described below. State Power Description No power 0W No power is applied to the device Active 2.3 W Active use. Idle 1.0 W Idle mode.
4.7 Supported Audio Standards Audio Decoder (For MM Max-Bitrate Channel Sample Frequency Video) wav: PCM /ADPCM / 1536kbps 2 48k 448k(L1)/384k(L2)bps 2 48k 320kbps 2 48k all bit rate 5.1 96k all bit rate 5.1 96k all bit rate 2 96k AC3 640kbps 5.1 48k WMA v7/8/9 all bit rate 5.1 48k Window all bit rate 5.1 48k 320kbps 2 48k all bit rate 5.
Window Media Audio v9 all bit rate 5.1 48k DVD LPCM all bit rate 7.1 192k FLAC(stereo) all bit rate 2 96k OGG Vorbis all bit rate 2 64k 96kbps 2 48k all bit rate 5.1 96k all bit rate 2 96k cook: COOK (RealAudio6) raac: MPEG4 AAC-LC (RealAudio9) racp: MPEG4 HE-AAC(RealAudio10) 4.8 Supported Video Standards Standard Resolution Divx 3.11 1920x1080 Divx 4.x 1920x1080 Divx 5.1 1920x1080 Divx 6.x 1920x1080 XviD 1920x1080 MPEG1 768x576 MPEG2 MP@HL 1920x1080 H.264 BP LV 4.
4.9 H.264 MPLV 4.0 1920x1080 H.264 HP LV 4.0 1920x1080 MPEG-4 SP@L 3.0 1920x1080 MPEG-4 ASP@HL 4.
4.10 Supported Video Resolution Wi-Fi Display FPS I/P Supported Res 640x480 60.00 P Y 720x480 60.00 P Y(59.94) 720x576 50.00 P Y 1280x720 30.00 P Y 1280x720 60.00 P Y 1280x720 24.00 P Y 1280x720 25.00 P Y 1280x720 50.00 P Y 1920x1080 25.00 P Y 1920x1080 30.00 P Y 1920x1080 24.00 P Y 800x600 30.00 P Y(29.84) 800x600 60.00 P Y 1152x864 30.00 P Y(30.19) 1152x864 60.00 P Y(60.38) 1360x768 30.00 P Y 1360x768 60.00 P Y 1368x768 30.
4.11 Supported Containers The following AVI, ASF, MP4, MKV, PS, TS, FLV, RM 5 Statement 5.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
- - - -
5.3 Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC.
Česky [Czech] [Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES. Dansk [Danish] Undertegnede [fabrikantens navn] erklæ rer herved, at fø lgende udstyr [udstyrets typebetegnelse] overholder de væ sentlige krav og ø vrige relevante krav i direktiv 1999/5/EF.
