Mainboard D1740 Mainboard D1740 Your mainboard is available in different configuration levels. Depending on the configuration chosen, some of the hardware components described may not be available on your mainboard. Additional information Information on the BIOS Setup and additional descriptions of the drivers are contained: • • • in the readme files on your hard disk on the driver floppy disks included on the CD "Drivers & Utilities Collection" or "Drivers & Utilities" or "ServerStart".
Important notes Important notes With the mainboard installed you must open the system to access the mainboard. How to dismantle and reassemble the system is described in the operating manual accompanying the system. ! Observe the safety notes in the operating manual of your system. Incorrect replacement of the lithium battery may lead to a risk of explosion. It is therefore essential to observe the instructions in the "Add-on modules / Upgrading" - "Replacing lithium battery" section.
List of features List of features Onboard features Chipset Board size D1740-A D1740-C * Intel® 845GV Intel® 845GV µATX µATX ü VGA Audio / 6-channel / S/PDIF 5.1 Buzzer / int. Speaker Support LAN 1 Gigabit / 100Mbit / 10 Mbit ü ü/-/- ü/ü/- ü/- ü/- -/ü/ü -/ü/ü -/-/ü/ü -/-/ü/ü SATA / ATA / RAID -/ü/- -/ü/- FireWireTM / HI-SPEED USB 2.
List of features Internal ports (continued) CD / AUX audio input Front panel Audio (9-pin for headphone, microphone) D1740-A D1740-C -/- -/1 - 1 FireWire™ * (9-Pin, Intel standard header) - - USB Ports* (2.0, ~480 MB/s) 2 2 Serial Ports* (FIFO, 16550 compatible) - - -/-/-/- -/1/-/- SMBus Connector (Case Temperature) - - Cover monitoring (Casing open) - - 1/1/- 1/1/- Fan Connectors PSU** / CPU / AUX1 / AUX2 Power Connectors ATX / ATX12V / AGP Pro External ports VGA Audio Mic.
List of features Silent Drives Hard disks and optical drives (CD-ROM, CD-RW, DVD etc.) are besides the fans some of the greatest sources of noise in a PC. The BIOS-Setup can be used to switch these drives into a quieter mode. Recovery BIOS If an error occurs during a BIOS update (e. g. due to a power failure), the system BIOS will be destroyed. All Fujitsu Siemens Computers mainboards are equipped with a recovery BIOS. With it a destroyed BIOS can easily be restored.
Prior to installation Brief instructions on installing mainboard If you have purchased a separate mainboard, you can install the mainboard in your system in accordance with the following brief instructions. The activities described here assume a basic knowledge of PCs and cannot be carried out by a layperson. If you are not sure whether you have the necessary specialised knowledge, then leave this work to an expert. The illustrations of the system show examples of possible cases.
Prior to installation ► Should no suitable connection field be provided in the case, then you must install the connection field (1) provided. Ensure the plate is aligned properly so that the connections are suitable for the mainboard later. ► Set the mainboard on the edge on which the connection field is located (2) and then insert the board in the case (3). Make sure that spacers in the housing are only mounted at points at which there are mounting holes in the mainboard.
External ports Interfaces and connectors The positions of the interfaces and connectors are shown on page "Cover". The components and connectors marked are not necessarily present on the mainboard. External ports The positions of the external ports are shown on page "Cover".
External ports Audio ports and audio configuration Audio ports Blue 1 Green 2 3 Red Connecting loudspeakers The mainboard supports 2, 4 or 6-channel audio mode. For surround sound it is possible to connect up to 6 analogue speakers and use the digital S/PDIF output. Analogue 2-channel audio output With the 2-channel configuration the functions Line-In, Line-Out and MIC are available. MIC can be configured for operation at the front or rear of the PC (see "Audio configuration" section).
External ports Audio configuration The mainboard supports 2, 4 or 6-channel audio mode. For surround sound it is possible to connect up to 6 analogue speakers and use the digital S/PDIF output (see "Audio ports" section). Depending on the operating system used, the audio driver and additionally installed software, you can configure the audio properties.
Internal ports and connectors Graphics port - Supported screen resolutions Depending on the operating system used, the screen resolutions in the following table refer to the mainboard screen controller. If you are using an external screen controller, you will find details of supported screen resolutions in the operating manual or technical manual supplied with the controller.
Pin assignment of internal ports Pin assignment of internal ports The pin assignment of some internal connections is shown in English in the following. i Some of the following connectors may be optional! Front panel Power On/Off Watch the poling of the LEDs. The positive pole of the connection cables is often indicated with a coloured wire. Reset HD-LED 1) 1) Power On LED 1) 2) 1 2 Recovery Password 1) Cable is not included in the delivery scope.
Pin assignment of internal ports 1 Audio port front Pin 1 Signal Pin Micro input 2 Signal 2 Analogue GND 3 Micro bias 4 Analogue VCC 5 Right line output 6 Right line return 7 not connected 8 Key 9 Left line output 10 Left line return If the audio front panel is not used, you must plug jumpers on pin pairs 5/6 and 9/10.
Pin assignment of internal ports 1 Power supply ATX 11 Pin Signal Pin Signal 1 2 3 4 5 6 7 8 9 10 +3.
Pin assignment of internal ports Settings with switches and jumpers Setting via control-panel plug connector A 1 2 B 1 2 C 1 2 i Pin pair A inserted = Skipping system and BIOS Setup password Pin pair B inserted = System BIOS recovery Pin pair C inserted = factory setting Please pay attention on the exact position of the pin pairs! Skipping system and BIOS Setup password - pinpair A Pinpair A enables skipping the system and BIOS Setup password.
Installing and removing processors Add-on modules / Upgrading ! Exit energy-saving mode, switch off the system and remove the power plug from the mains outlet, before carrying out any of the procedures described in this chapter! Even when you have switched off the device, parts (e.g. memory modules, AGP and PCI extension boards) are still supplied with power. Installing and removing processors Technical data Intel Pentium 4 with 400 or 533 MHz system bus in the mPGA478 design.
Installing and removing processors Mounting heat sink Be sure to use heat conducting material between the processor and the heat sink. If a heat conducting pad (rubber-like foil) is already applied to the heat sink, then use it. Otherwise you must apply a very thin layer of heat conducting paste. Heat conducting pads can only be used once. If you remove the heat sink, you must clean it and apply new heat conducting paste before you remount it.
Installing and removing processors Upgrading main memory Technical data Technology: DDR 200, DDR 266 or DDR 333 unbuffered DIMM modules 184-Pin; 2.5 V; 64 Bit, no ECC Size: 128 Mbytes up to 2 Gbyte DDR-SDRAM Granularity: 128, 256, 512 or 1024 Mbyte for one socket A current list of the memory modules recommended for this mainboard is available on the Internet at: www.fujitsu-siemens.com/mainboards. At least one memory module must be installed.
Adding PCI cards Removing a memory module 1 1 ► Push the clips on the right and left of the memory slot outward (1). ► Pull the memory module out of the memory slot (2). Adding PCI cards Technical data: 32 bit / 33 MHz PCI slots 5 V and 3.3 V supply voltage 3.3 V auxiliary voltage PCI bus interrupts - Selecting correct PCI slot i To achieve optimum stability, performance and compatibility, avoid the multiple use of ISA IRQs or PCI IRQ Lines (IRQ sharing).
Adding PCI cards Multifunctional expansion cards or expansion cards with integrated PCI-PCI bridge: These expansion cards require up to four PCI interrupts: INT A, INT B, INT C, INT D. How many and which of these interrupts are used is specified in the documentation provided with the card.
Adding PCI cards The lithium battery holder exists in different designs that function in the same way. 3 2 3 2 1 3 ► Press the locking lug in the direction of the arrow; the battery jumps somewhat out of the holder (1). ► Remove the battery (2). ► Insert a new lithium battery of the same type into the socket (3).
BIOS update BIOS update When should a BIOS update be carried out? Fujitsu Siemens Computers makes new BIOS versions available to ensure compatibility to new operating systems, new software or new hardware. In addition, new BIOS functions can also be integrated. A BIOS update should always also be carried out when a problem exists that cannot be solved with new drivers or new software. Where can I obtain BIOS updates? The BIOS updates are available on the Internet at www.fujitsu-siemens.de/mainboards.
BIOS Recovery - Recovering System BIOS BIOS Recovery - Recovering System BIOS i All BIOS settings are reset to the default values. ► Open the casing as described in the operating manual. ► Set the jumper for "Restore system BIOS" to ON. (see "Settings with switches and jumpers" chapter) ► Close the casing as described in the operating manual. ► Insert a BIOS update floppy disk and start the PC. ► Note the signals issued from the loudspeaker.
Drivers Safety for processor on Fujitsu Siemens Computers mainboards If the processor uses an old or incorrect microcode, error-free operation cannot be ensured. Fujitsu Siemens Computers has therefore implemented a function on its mainboards that interrupts the booting process if no suitable microcode is available for the installed processor. The output error message is Patch for installed CPU not loaded. Please run the bios flash update diskette.
Electrical Properties Annex Electrical Properties Loadability for connections and fuses i Make sure that the connected devices do not overload the connections. Fuse No.
APM and ACPI system status, energy-saving modes APM and ACPI system status, energy-saving modes System status Normal operation Simple energysaving mode ACPI Status )1 G0 G1 Maximum energysaving mode )4 APM Status Power LED I )2 Power LED II )3 Sleep LED Power consum ption Wake-up time S0 On On/Off On Off Normal S1 Standby Off/On flashin g On Almost like normal Almost immediate ly S3 Off/On flashin g RAM, wake-up compon ents ca. 5s S4 Off/Off Off RAM, wake-up components ca.
Mainboard Revision and BIOS Version Mainboard Revision and BIOS Version The compatibility, e.g. with new processors, can be independent of the BIOS version or the revision status of the mainboard used. The CPU and BIOS compatibility lists are available on the Internet at www.fujitsu-siemens.de/mainboards. Mainboard: Revision level The revision status of the mainboard exactly identifies which mainboard you have.
Error messages Error messages This chapter contains error messages generated by the mainboard. Available CPUs do not support the same bus frequency – System halted! Memory type mixing detected Non Fujitsu Siemens Memory Module detected – Warranty void There are more than 32 RDRAM devices in the system Check whether the system configuration has changed. If necessary, correct the settings.
Error Messages DMA test failed EISA CMOS not writable Extended RAM Failed at offset: nnnn Extended RAM Failed at address line: nnnn Failing Bits: nnnn Fail-Safe Timer NMI failed Multiple-bit ECC error occurred Memory decreased in size Memory size found by POST differed from EISA CMOS Single-bit ECC error occurred Software NMI failed System memory exceeds the CPU’s caching limit System RAM Failed at offset: nnnn Shadow RAM Failed at offset: nnnn Switch the device off and on again.
Error Messages Missing or invalid NVRAM token Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. Monitor type does not match CMOS - RUN SETUP Correct the entry for the monitor type in the Main menu of the BIOS Setup. On Board PCI VGA not configured for Bus Master In the BIOS Setup, in the Advanced menu, submenu PCI Configuration, set the Shared PCI Master Assignment entry to VGA.
DOS error messages System battery is dead - Replace and run SETUP Replace the lithium battery on the mainboard and redo the settings in the BIOS Setup. System Cache Error - Cache disabled Switch the device off and on again. If the message is still displayed, please contact your sales outlet or customer service centre. System CMOS checksum bad - - Default configuration used Call the BIOS Setup and correct the previously made entries or set the default entries.
SmartCard reader - error messages SmartCard reader - error messages This chapter contains error messages generated by the SmartCard reader (chipcard reader). Boot access denied The Sicrypt SmartCard has no access rights to the system. Check your chipcard Either the Sicrypt SmartCard has been wrongly inserted, or it is not a PC-Lock Sicrypt card. Chipcard reader FAIL An error has occurred on the serial port to the SmartCard reader (chipcard reader).
